Crux Sightline MRVBM-77Q User manual

MRVBM-77Q
Backup Camera and Video Interface for
2017 and up BMW & Mini Vehicles with Evo2 iDrive5 Systems
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.1104201 of 7
- Adds front and rear aermarket camera inputs.
- Retains funconality of the OEM backup camera if present.
- Front camera automacally shows on the screen aer changing the gear from reverse to drive.
- Provides power and ground for the cameras.
- Adds 1 A/V Input.
- Adds 2 video and 1 audio outputs.
PRODUCT FEATURES:
PARTS INCLUDED:
MRVBM-77Q Module MRVBM-77Q Power Harness LVDS Cable
Push Buon Switch I/O Cable Remote Control
IR Cable

Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.1104202 of 7
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
MRVBM-77Q
Backup Camera and Video Interface for
2017 and up BMW & Mini Vehicles with Evo2 iDrive5 Systems
DIP SWITCH SETTINGS:
4 POSITION SWITCH
DIP STATUS FUNCTION
1
UP AV1 ON
DOWN AV1 OFF
2
UP Front Camera ON
DOWN Front Camera OFF
3
UP
Set to OFF
DOWN
Set all DIP switches DOWN
8 POSITION SWITCH
DIP DIP #4 DIP #5 FUNCTION
STATUS
UP UP 1440 x 540 (5, 7, X5 Series) (10.25” screen)
UP DOWN 1280 x 480 (8.8” screen)
DOWN DOWN 800 x 480 (6.5” screen)
DOWN UP 1280 x 480 (Mini with Touch)
DIP switches 1 to 3:
DIP switches 4 and 5:
DIP STATUS FUNCTION
6
UP 5, 7 Series
DOWN 1, 2, 3, 4, 6, X Series, Mini
7
UP Use OEM Backup Camera
DOWN Use Aermarket Backup Camera
8
UP CAN in/out mode
DOWN CAN bypass mode
DIP switches 6 to 8:
Please make sure to power cycle the interface (unplug power harness then plug back in) aer changing
the DIP switch sengs.

Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.1104203 of 7
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
MRVBM-77Q
Backup Camera and Video Interface for
2017 and up BMW & Mini Vehicles with Evo2 iDrive5 Systems
ON SCREEN DISPLAY (OSD) SETTINGS:
KEY FUNCTION
POWER & PIP No Funcon
MENU Acvate OSD Menu
OK Make the selecon / Change the image display
Move UP
Move DOWN
Move LEFT (Press for 2 seconds to Access Factory Mode)
Move RIGHT (Press for 2 seconds to Reset User Data)
REMOTE CONTROL:
PARK
UTIL1
UTIL2
INFO
H-POSITION
V-POSITION
Menu of FACTORY
MENU to Return SEL to Select/Save
H-POSITION : Move the image horizontally
V-POSITION : Move the image vercally
H-SIZE(NAVI) : Adjust the size of navigaon
image horizontally
Adjusng Screen Sengs (Menu of NAVI)
Make sure the IR receiver is connected to the module and is in a clear view for the IR Remote to contact.
There are two menus on the interface. “Menu of Navi” and “Menu of FACTORY”. In order to access the Menus
you must be in the AV source. Tap the PURPLE wire (SAFE) to ground and use the OK buon on the IR remote to
switch sources (same funcon as momentary switch included). Press the “MENU” buon on the remote control
to enter Menu of NAVI.
In this menu, user can set the image BRIGHTNESS, CONTRAST,
SHARPNESS and set a USER IMAGE.
To access the “Menu of FACTORY”, exit the Menu of NAVI, press and hold the le arrow for 3 seconds while in
the same AV source. Use the arrows to navigate the menu.
Seng the Rear View Camera (Menu of FACTORY)

Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.1104204 of 7
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
MRVBM-77Q
Backup Camera and Video Interface for
2017 and up BMW & Mini Vehicles with Evo2 iDrive5 Systems
PARK
UTIL1
UTIL2
INFO
Menu of FACTORY
MENU to Return SEL to Select/Save
AVOUT SELECT
FCAM FUNC
ARGB MODEL
FACTORY RESET
AVOUT SELECT: Select background sound via car AUX
- Plug in Audio Output to Car’s Aux input
UTIL1
FCAM FUNC: Front Camera Funcon aer a Reverse Process
- 15x: Displays front camera for 15, 10, 5 or 3 seconds
-OFF: Front camera will not be displayed
ARGB MODEL: Not used
FACTORY RESET: Reset unit to factory defaults
PARK
UTIL1
UTIL2
INFO
Menu of FACTORY
MENU to Return SEL to Select/Save
IDRV REMOTE
IDRV CONTROL
VOICE KEY
MEMORY KEY
CALIBRATE
VOICE KEY: Enable/disable the OEM voice buon on the steering
wheel for more changes on select vehicles. Default is OFF.
MEMORY KEY: Enable/disable the use of the OEM memory
buons. Default is OFF.
PARK
UTIL1
UTIL2
INFO
PAS TYPE
PAS SETUP
REAR TYPE
SAFE ENABLE
RADAR ENABLE
Menu of FACTORY
MENU to Return SEL to Select/Save
PAS TYPE: Parking Guide Line Seng
- NOT USED: No use parking guide line
- PAS ON: Selecng Dynamic parking guide line
- PAS OFF: Selecng xed parking guide line
PAS SETUP: Adjusng the posion of the parking guide line
REAR TYPE: Choose Rear Camera Recognion
- CAN: Reverse Camera is triggered by CAN when shiing into
reverse. CAN wire of module must be connected to CAN
wire of car.
- LAMP: Reverse Camera is triggered when the reverse light
turns on. Connect “Rear-C” cable of the power cable the
reverse light.
RADAR ENABLE: Seng up the parking Distance Alarm Sensor
SAFE ENABLE: ENABLE to enter OSD Menu

Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.1104205 of 7
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
MRVBM-77Q
Backup Camera and Video Interface for
2017 and up BMW & Mini Vehicles with Evo2 iDrive5 Systems
OEM BUTTON FUNCTIONS:
The MRVBM-77Q allows the user to control the unit using vehicle’s steering wheel controls, iDrive knob or the
memory buons on the dashboard.
Steering Wheel Controls iDrive Memory Buons
SECTION BUTTON OPERATION FUNCTION
Steering Wheel Voice Short Press Mode Switch
Short Press PIP Mode Choice
Memory #7 Short Press Mode Switch
iDrive
MAP Long Press (3 sec.) Mode Switch
Short Press Return to OEM
COM Long Press (7 sec.) Safe ON / OFF
OPTION Short Press
Return to OEMMEDIA Short Press
RADIO Short Press
BACK Long Press (7 sec.) Factory Mode: ON
Short Press Factory Mode: BACK
MENU
Long Press (3 sec.) Mode Switch
Short Press Return to OEM screen
(On FCAM screen, turn o FCAM screen
Knob UP Short Press OSD Menu Up
Knob DOWN Short Press OSD Menu Down
Knob Press Short Press OSD Menu Select

Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.1104206 of 7
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
MRVBM-77Q
Backup Camera and Video Interface for
2017 and up BMW & Mini Vehicles with Evo2 iDrive5 Systems
1. Remove the headunit and unplug the Quadlock
connector. Unplug the Fiber Opc cable connector
from the main connector housing.
2. Plug in the ber opc cable connector to the
female Quadlock connector supplied on the
MRVBM-77Q power harness.
3. Plug the male Quadlock connector of the
MRVBM-77Q power harness to the headunit.
4. Plug the OEM Quadlock connector to the mang
connector on the MRVBM-77Q power harness.
WIRING AT THE HEADUNIT
See below
I/O CABLE
Supplied LCD
Cable
OEM LCD
Cable
OEM Monitor
A
U
D
I
O
(R)
IN
A
U
D
I
O
(L)
IN
V
I
D
E
O
IN
A
U
D
I
O
(R)
O
U
T
A
U
D
I
O
(L)
O
U
T
F
C
A
M
R
C
A
M
R
C
A
M
12
V
F
C
A
M
12
V
S
A
F
E
R
E
A
R
V
1
I
R
OEM Headunit
V
I
D
E
O
Out
1
V
I
D
E
O
Out
2
Power
Harness
MRVBM-77Q
S
W
I
T
C
H
WIRING DIAGRAM:

Crux Interfacing Solutions • Chatsworth, CA 91311
phone: [phone] • fax: [phone] • www.cruxinterfacing.com
rev.1104207 of 7
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
MRVBM-77Q
VEHICLE APPLICATIONS:
BMW & Mini with 8.8” or 10.2” Monitors and Evo2 iDrive5 Systems
BMW
2017 – 2018
2017 – 2018
2017 – 2018
2017 – 2018
2017 – 2018
2017 – 2018
2017 – 2018
2017 – 2018
2017 – 2018
2017 – 2018
1 Series
2 Series
3 Series
4 Series
5 Series
6 Series
7 Series
X3
X4
X5
Backup Camera and Video Interface for
2017 and up BMW & Mini Vehicles with Evo2 iDrive5 Systems
Mini
2017-2018 Mini
5. Plug the cameras to be used to the corresponding video RCAs on the I/O harness. Use the power and
camera ground wires supplied on the same harness.
6. Test the cameras for funconality. Put the gear in reverse and conrm that the backup camera image shows
up on the screen. Put the gear to drive and the front camera image should show on the screen (conrm
front camera seng on the OSD on page 2).
7. If using the AV input, plug in an AV source to test for funconality. Use the selector buons as stated on
pages 4 an 5.
8. Once funconality tests are completed, reinstall the headunit.
