D-CUT LT-330 User manual

OPERATION MANUAL
PVC Flooring Cutter LT-330
www.dcutproducts.com
CUTTING AND C

2
SAFETY RULES FOR THE FLOORING CUTTER
1. READ AND UNDERSTAND THIS INSTRUCTION MANUAL BEFORE
OPERATING THE D-Cut MULTI-FLOORING CUTTERS.
2. If you are not thoroughly familiar with the operation of D-Cut Multi-flooring
Cutter, obtain advice from a qualified instructor or call 800-982-3434 USA
3. Stay alert. Do not operate while under the influence of drugs, alcohol, or
medication.
4. Always wear safety approved eye protection with side shields(ANSI Z87.1)
5. Keep work area free of debris.
6. Keep children and unauthorized persons away from the D-Cut Multi-flooring
Cutter and work area.
7. Make sure tool is secure. Operate only on a firm substrate or solid stand.
8. Use the right tool. Do not force the D-Cut Multi-flooring Cutter or use it for a
job for which it was not designed; use only on approved materials.
9. Keep the blade sharp. A dull blade will not perform properly.
10. Always keep hands away from blade while operating or carrying the cutter.
11. Do not alter or misuse this tool. The D-Cut Multi-flooring Cutter is precision
built; modifications not specified in this manual may result in a dangerous
and unsafe environment.
12. Maintain the D-Cut Multi-flooring Cutter with care. Keep Blade sharp and
clean. Follow instructions for changing accessories.
13. Use only recommended accessories. The use of improper accessories may be
hazardous and cause injuries.
14. Never leave the D-Cut Multi-flooring Cutter unattended. Secure the handle
with the lock chain when not in use.

3
Installation of the Cutter
Insert the handle into the handle base
as shown.
Warning: Do not put your fingers
against the sharp edge of the blade at
any time.
Changing the Blade
Use the provided Allan wrench to
remove the five screws, then hold the
blade by each end and carefully move
the blade out of blade holder.
Note: The flat side of the blade faces
the table.
Warning: Do not put your fingers
against the sharp edge of the blade at
any time.

4
45° Cut
Swing the angle attachment to 45°.
Insert material between the cutting
blade and the base, against the angle
attachment as shown, then push the
handle down to complete a cut.
Warning: Do not put your fingers
against the sharp edge of the blade at
any time.
Straight Cut
Insert the material between the cutting
blade and the base, flush with the gauge as
shown and hold the material then push
handle down to complete a cut.

5
Part List
'

6
Parts Q’ty Parts Q’ty
1 Hex Head Screw M4 × 25 2 27 Handle Ball 1
2 Plain Washer 4φ6 28 Handle 1
3 Rubber Feet A 2 29 Hook B 1
4 Nylon Lock Nut M4 4 30 Rotating Shaft A 1
5 Hex Head Screw M5 × 16 5 31 Customized Ring φ10 2
6 Pressure Plate 1 32 Customized Screw M8 × 22 2
7 Nylon Bar 1 33 Customized Ring φ8 2
8 Hex Head Screw M6 × 10 5 34 Hex Head Screw M6 × 16 8
9 Blade 1 35 Hex Head Screw M5 × 16 3
10 Cutter Base 1 36 Nylon Board A 1
11 Spring 2 37 Blade Holder 1
12 Spring Pin φ6 × 16 2 38 Nylon Board B 1
13 Spring Base 2 39 Aluminum Eccentric Cam 1
14 Left Rotating Plate 1 40 Stopper 1
15 Left Side Frame 1 41 Handle Base 1
16 Hex Head Screw M6 × 16 4 42 Hex Head Screw M5 × 8 2
17 Hex Head Screw M8 × 16 2 43 Hex Headless Screw M5 × 10 1
18 Nylon Lock Nut M5 4 44 Stopper Pin 1
19 Working Table Base 1 45 Spring Washer φ6 1
20 End Cap 2 46 Hex Head Screw M6 × 20 1
21 Rivet 2 47 Right Rotating Plate 1
22 Hook A 1 48 Rotating Shaft B 1
23 Working Table 1 49 Right Side Frame 1
24 Hex Head Screw M5 × 10 4 50 Hex Head Screw M4 × 16 2
25 Cutting Guide 1 51 Rubber Feet B 2
26 Chain 1 52 Blade Protector
