m-Dimension J3468C User manual

Thank you for purchasing our fine product!
This package contains all tools necessary for assembly.
Page 1
Assembly Instructions
WARNING: Failure to follow these directions and warnings can result in serious injury
and/or product damage.
!
!
!
!
!
!
Give us a chance to make it right
Contact our friendly, U.S. based customer service department with any
problems or comments. Replacements for missing or damaged parts
will be shipped promptly.
Toll Free: 866-528-8364
Monday - Friday, 8am-5pm, ET. After business hours, leave a message.
We will return your call the next business day.
#J3468C Eclipse Coffee Table
#J3468C Eclipse Coffee Table
Assistance is required to assemble this table.
Never stand on the table or use it as a ladder.
Periodically re-tighten all bolts and legs.
If any parts become missing, damaged or worn, discontinue use until they are replaced with identical parts.
Always seek assistance before moving furniture.
Do not place hot or wet items directly on the table surface.

Page 2
Assembly Instructions
Give us a chance to make it right.
TOLL FREE: 1-866-528-8364
Monday - Friday, 8am-5pm, ET.
Part
Drawing
Part Name Qty. Part
Drawing
Part Name Qty.
Step 1 - Remove all parts from their packaging and confirm that the quantities match those listed
above. If any parts are damaged or missing, please call our Customer Service Department at 1-866-
528-8364.
#J3468C Eclipse Coffee Table
A
BG
C H
1Table Top
Leg 1
Leg 2
1
1
D I Shelf 1
E J Glass Insert
Long Bolt
w/ Washers
(1/4”x1-3/4”)
Short Bolt
w/ Washers
(1/4”x3/4”)
Leg Bracket
Allen Wrench
Angle Bracket1
16
1
4
1
2
F
PARTS LIST

Assembly Instructions
Give us a chance to make it right.
TOLL FREE: 1-866-528-8364
Monday - Friday, 8am-5pm, ET.
Page 3
#J3468C Eclipse Coffee Table
Step 2 - Place Leg 1 (Part B) upside down on a flat surface. Slide the notch on Leg 2 (Part C) into the
corresponding notch on Leg 1 like shown below. Insert the Long Bolt with Washers (Part F)
through the top of the Leg 2 and into the threaded insert in Leg 1. Tighten the Bolt using the
Allen Wrench (Part I). Do not overtighten the Bolt.
Step 3 - With help, turn the partially assembled frame right side up. Align the bolt holes in the middle
of the Leg Brackets (Part H) with the corresponding threaded insert in the top of Legs 1 and 2
like shown below. Insert 4 Short Bolts with Washers (Part G) through the Leg Bracket and into
the Legs. Tighten the Bolts using the Allen Wrench. Do not overtighten the Bolts.
C
I
B
I
G
H
C
B
F

Assembly Instructions
Give us a chance to make it right.
TOLL FREE: 1-866-528-8364
Monday - Friday, 8am-5pm, ET.
Page 4
#J3468C Eclipse Coffee Table
Step 4 - Place the Shelf (Part D) upside down on a flat surface. Turn the partially assembled frame
upside down and align the Leg Bracket on the shorter leg with the corresponding bolt holes on
the bottom of the Shelf. Align the Angle Brackets (Part J) with the bolt holes on the inside edge
of Leg 2 and the single bolt holes on the bottom of the Shelf like shown below. Insert 2 Short
Bolts with Washers (Part G) through the Angle Brackets and into the threaded inserts in Leg 2.
Insert 4 Short Bolts with Washers through the Leg Bracket and Angle Brackets and into the
threaded inserts in the bottom of the Shelf. Tighten the Bolts using the Allen Wrench. Do not
overtighten the Bolts.
Step 5 - Place the Table Top (Part A) upside down on a flat surface. With help, align the remaining
Leg Brackets with the corresponding threaded inserts on the bottom of the Table Top, like
shown below. Insert 6 Short Bolts with Washers (Part G) through the Leg Brackets and into
the Table Top. Tighten the Bolts using the Allen Wrench. Do not overtighten the Bolts.
II
I
GG
G
J
D
H
H
A

Assembly Instructions
Give us a chance to make it right.
TOLL FREE: 1-866-528-8364
Monday - Friday, 8am-5pm, ET.
Page 5
#J3468C Eclipse Coffee Table
Step 6 - With help, turn the assembled frame right side up. Place the Glass Insert (Part E) into the
corresponding location in the Table Top.
Please note: It may be necessary to adjust the adjustable foot glides in order to properly level
the table.
Assembly is complete.
