Dormakaba SVA 2000 User manual

EN
Original document
Mounting instructions
060044-45532/16387 – 05/2023
SVA/SVI

SVA/SVI Mounting instructions
060644-45532 – 05/20232
Contents
1 Information about this document 2
1.1 Contents and purpose 2
1.2 Target group 2
1.3 Other applicable documents 2
1.4 Abbreviations 2
1.5 Symbols used 2
1.5.1 Hazard categories 2
1.5.2 Further labeling 2
2 Safety 3
3 Mounting 3
3.1 Required parts 3
3.2 Requirements for mounting 4
3.3 Overview of parts 4
3.3.1 Tubular frame door variants 4
3.3.2 Solid door variants 4
3.4 Preparations for mounting 5
3.5 Installation steps 5
3.6 Establish electrical connection
(only in the case of electrical locks) 5
3.7 Parameterize lock
(SVA locks of series 2xxx and 2xxxF only) 5
3.8 Complete mounting 5
4 Maintenance 5
5 Disassembly and disposal 5
6 Image section 6
6.1 Dimensions 6
6.2 Mounting illustrations 12
1 Information about this document
1.1 Contents and purpose
This document describes the mounting of the SVA/
SVI lock series on a 2-leaf door unit. The locks are
available in various versions and designs for tubular
frame doors and solid doors. The individual mounting
steps are illustrated in the image section of the
manual.
1.2 Target group
The locks must only be mounted by technically
qualified personnel.
1.3 Other applicable documents
• Commissioning instructions for the SVA/SVI locks
• Manual for the connection cable SVP-A1100/2100
(not necessary for SVI5xxx)
• Assembly instructions for the fittings used, e.g. door
handles, panic bar or knob.
1.4 Abbreviations
SVAActive, self-locking (anti-)panic
lock for the passive door leaf
SVI
Inactive, self-locking
(anti-)panic lock for the active
door leaf
2xxx/2xxxF,
4xxx, 5xxx
All versions of a lock; the exact
lock type is marked with 3 digits
instead of xxx.
FFire protection – integrated PR
module
1.5 Symbols used
1.5.1 Hazard categories
WARNING
This signal word indicates a possible
hazardous situation that may result in
death or serious injury if not averted.
ATTENTION
This signal word indicates a situation of
potential risk that could lead to damage to
property or the environment if not averted.
Note
This signal word indicates useful information
for efficient and trouble-free operation.
1.5.2 Further labeling
1
The picture number in the text
document refers to an illustration in
the image section of the assembly
instructions
1. 2. Step-by-step graphics
1 2 Position numbers of parts
6Reference to chapter or page number

SVA/SVI Mounting instructions
060644-45532 – 05/2023 3
2 Safety
Color
WARNING
Danger to life from crowding in front of a
jammed door.
If the door leaf is deformed by more than
5mm, the door may not always open
reliably!
• SVA/SVI locks should only be installed in
doors with a maximum deformation of
5mm!
• In case of more severe deformation, verify
that the door opens reliably with the
fitting!
WARNING
Danger to life due to incorrect mounting on
fire and smoke protection doors.
Mounting on fire and smoke protection
doors is only permitted if the usability
certificates for these doors provide for the
mounting.
• Observe the requirements in the usability
certificates.
3 Mounting
SVI commissioning manuals
https://techdoc.dormakaba.com/cds/go/SVI
SVA commissioning instructions
https://techdoc.dormakaba.com/cds/go/SVA
3.1 Required parts
The following parts are required for mounting the
SVA/SVI door locks:
SVA lock
1 door lock for the active door leaf (SVA).
SVI lock
1 door lock for the passive door leaf (SVI).
SVI accessories set
The accessories set contains the rod striking plate (1),
the switch lock (2), the lower rod guide (5), the sliding
plug for the upper espagnolette bolt, a mounting aid
for the upper espagnolette bolt and the dormakaba
torque tool.
Note
Use the torque tool only once. After that,
the function is no longer given.
SVP‑A1100/2100
For each door lock with an electrical connection, the
door leaf must be equipped with an SVP-A1100/2100
connection cable (4) and a concealed cable loop (e.g.
dormakaba KÜ 480).
TRS XX espagnolette bolt set
The espagnolette bolt set contains the upper
espagnolette bolt (4) and the lower espagnolette bolt
(5).
Masking plate
A masking plate suitable for the espagnolette bolt,
PHA2122 (7) or PHA2121 (8).
Locking cylinder
1 profile cylinder or 1 round cylinder depending on SVA
lock version.
Door fittings and pressure pin
See technical information of the locks

SVA/SVI Mounting instructions
060644-45532 – 05/20234
3.2 Requirements for mounting
• The maximum permissible door leaf
dimensions are:
Max. weight 300kg
Height max. 3500mm
Width max. 1800mm
• The door leaves are not deformed.
3.3 Overview of parts
SVA door lock on the active door leaf
SVI door lock on the passive door leaf
(1) Rod striking plate
(2) Switch lock
(3) Upper espagnolette bolt
(4) SVP-A1100/2100 connection cable
(not required for SVI5xxx and
SVA5xxx)
(5) Lower espagnolette bolt
(6) Lower rod guide
(7) Masking plate PHA2122
(8) Alternative masking plate PHA2121
3.3.1 Tubular frame door variants
1
2
3
4
5
6
7
8
SVI
SVA
SVI 21xxFSVI 41xx
SVI 51xx SVA 2xxxF
SVA 2xxx
SVA 4xxx
SVA 5xxx
SVA 6xxx
3.3.2 Solid door variants
1
2
3
4
4
5
6
7
8
SVI
SVA
SVA 2xxxF
SVA 2xxx
SVA 4xxx
SVA 5xxx
SVA 6xxx
SVI 20xxF
SVI 40xx
SVI 50xx

SVA/SVI Mounting instructions
060644-45532 – 05/2023 5
3.4 Preparations for mounting
• Prepare the door leaves, door frame and
espagnolette bolts according to the dimension
drawings in the image section. Align all recesses
with the selected fittings on site.
• Deburr cutting edges. Clear the recesses of any
chips or shavings.
• Depending on the lock, settings must be made
before mounting on the lock (see the SVA/SVI locks'
commissioning instructions).
3.5 Installation steps
Carry out the installation steps according to the
illustrations in the image section (see Chapter 6.2).
ATTENTION
Damage to the door leaves due to incorrect
mounting.
The mounting of the SVA lock is shown on a
DIN-right door. The mounting of the SVI lock
is shown on a DIN-left door. For a reversed
version, the procedure must be mirror-
inverted.
3.6 Establish electrical connection
(only in the case of electrical locks)
Connect the SVA/SVI locks according to the pin
assignment (see SVA/SVI locks' commissioning
instructions).
3.7 Parameterize lock
(SVA locks of series 2xxx and 2xxxF
only)
See SVA lock commissioning instructions
3.8 Complete mounting
1. Check all gaps. The dimensions must be according
to the specifications from the dimension
drawing in the SVA/SVI assembly instructions. If
necessary, adjust the door leaf in the door frame.
Then adjust the upper espagnolette bolt (see
Figure 14, Chapter 6.2).
2. Carry out initial maintenance and pass this
manual and the technical information for the
locks to the facility operator. Refer the facility
operator to the regular maintenance and
recording duties (see Chapter 4).
4 Maintenance
Perform the following maintenance steps
at least once a month to ensure safe use of
the SVA/SVI lock:
• Check and operate all parts of the door lock. Ensure
that they are fully operational.
• Ensure all the parts provided have been mounted
and that no subsequent modifications have been
made or additional locking devices added.
• Make sure that the locking points are not blocked
and the espagnolette bolts are guided without
friction.
• Check that the bolt has been retracted flush
against the unlocked SVA. The bolt actuator must
not protrude.
ATTENTION
Risk of drive damage from increased
friction resistance in the lock components
espagnolette bolts and switch lock.
Check the components for smooth
operation. If necessary, adjust the door leaf
in the door frame. Then adjust the upper
espagnolette bolt (see Figure 14, Chapter
6.2).
• Use a force gauge to measure and record the
actuating forces required to release the escape door
lock. The actuating forces may be max. 70 N for
escape doors according to EN 179 and max. 80 N for
escape doors according to EN1125. The actuating
forces must not have changed significantly
compared to the measurement after the initial
installation.
• Clean the masking plate.
• Note the date of maintenance, the corrective
actions taken and the name of the person
performing the work.
Note
The locks have a permanent dry lubrication
with bonded coating. If necessary,
supplementary lubrication with Teflon spray
(acetone-free) is permitted.
5 Disassembly and disposal
Disassembly is carried out in reverse order of the
mounting instructions.
The product must not be disposed of in
domestic waste.
Dispose of the product in an environmentally
friendly manner at the arranged acceptance
and collection points.
Observe the applicable national legal regulations.

SVA/SVI Mounting instructions
060644-45532 – 05/20236
6 Image section
6.1 Dimensions
DSVA
SVAxx7x = 65mm
SVAxx8x = 80mm
SVAxx9x = 100mm
DH (max. 3500)
1050
235 209 185
72(PC) 74(RC)
80
34
21.5 73
Ø 7Ø 7
Ø 7 Ø 7
PC Ø 17 RC Ø 22
Ø 8
Ø 22
38
55
10.5
max.
45°
max.
45°
3
2.5—5
DSVA
24
SVA
SVA
FFL
SVI
98
SVA 2xxxF
SVA 2xxx
SVA 4xxx
SVA 5xxx
SVA 6xxx

SVA/SVI Mounting instructions
060644-45532 – 05/2023 7
1. 1.
2.
3.
*2) with max. gap 2-7 mm
*3) Under-door gap 2-7 mm
DSVI
SVIxx7x = 65 mm
SVIxx8x = 80 mm
SVIxx9x = 100 mm
SVI 20xxF
SVI 40xx
SVI 50xx
3
4
5
5
6
2
1
21/25
101/105
80 19.5
Ø 5.5
Ø 5.5
min. Ø 15
min.Ø 15
Ø 6 Ø 15
Ø 22
Ø 7 Ø 7
7
3
7
7
38
20
60
20
20
20
20
2
3
55
SVI
SVI
SVA
X=DSVI-35
X Y
X/Y
Y=DSVI-27
DSVI
3 33
3
2–7
2–7
2.5–5
41
54
42
20
20
35
73
10
10 10 16
73112
209 185
18
20
12
3
R10
38
235
80
50
L5 L3
UN
1050
L5 = NU-78*3
L3 = NO-39*2
NO
DH (max.3500)
FFL
98
85
ø 8

*2) with max. gap 2-7 mm
*3) Under-door gap 2-7 mm
SVA/SVI Mounting instructions
060644-45532 – 05/20238
1. 1.
2.
3.
SVI 20xxF
SVI 40xx
SVI 50xx
DSVI
SVIxx7x = 65 mm
SVIxx8x = 80 mm
SVIxx9x = 100 mm
3
4
5
7
6
2
1
21/25
101/105
80
Ø 5.5
Ø 5.5
min.Ø 15
min.Ø 15
Ø 6 Ø 15
Ø 22
Ø 7 Ø 7
7
3
7
7
38
20
60
20
20
20
24
2
55
SVI
SVI
SVA
X=DSVI-35
X Y
X/Y
Y=DSVI-27
DSVI
3
2–7
2–7
19.5
3
2.5–5
41
54
42
20
20
35
73
10
10 10 16
73112
209
98
185
75 58
18
24
max.
38.5
38
235
80
50
L5 L3
UN NO
1050
L5 = NU-78*3
L3 = NO-39*2
DH (max.3500)
FFL
85
ø 8

SVA/SVI Mounting instructions
060644-45532 – 05/2023 9
DSVA
SVA xx19 = 35 mm
SVA xx29 = 40 mm
SVA xx39 = 45mm
SVA 2xxx
SVA 2xxxF
SVA 4xxx
SVA 5xxx
SVA 6xxx
4
FFL
3.5–6*2
<19
10
R6
21
24
1579
21.5
141 105
95
1212
130
225
*1) ST 3.9x19 A2-70 (EN ISO 7050)
*2) for SVA RR with U-forend
1050
SVI SVASVA
DSVA-3
DSVA
Ø 22
*2
*1
34
PC Ø 17
92 (PC) 94 (RC)
RC Ø 22
10.5
max.
45°
max.
45°
*1

SVA/SVI Mounting instructions
060644-45532 – 05/202310
*1) ST 3.9x19 A2-70
(EN ISO 7050)
*2) with max. gap 2-7 mm
*3) Under-door gap 2-7 mm
*4) For SVA RR with U-forend
DSVI
SVIxx19 = 35 mm
SVIxx29 = 40 mm
SVIxx39 = 45mm
SVI 4xxx
SVI 5xxx
1
2
3
4
5
6
7
55
3
3
1.
2.
FFL
DSVI-3
DSVI-3
DSVI
L5 = NU-144*3 L3 = NO-102*2
21/25
101/105
80
Ø 5.5
3
41
21 21 20
42
20
3
2–7
2–7
2
3
20 20
19.5
L5 L3
UN NO
1050
DH (max.3500)
SVI SVI SVA
Ø 6 Ø 15
60
24
22
12
12
131.5
141.5 144.5
157921.5126
17.5
3.5–6*4
265
133.5
*1
*1
R6
10
20
Ø 25
Ø 10

SVA/SVI Mounting instructions
060644-45532 – 05/2023 11
*1) ST 3.9x19 A2-70
(EN ISO 7050)
*2) with max. gap 2-7 mm
*3) Under-door gap 2-7 mm
*4) For SVA RR with U-forend
DSVI
SVI xx19 = 35 mm
SVI xx29 = 40 mm
SVI xx39 = 45mm
5
3
1.
2.
6
7
5 5
SVI 21xxF
1
3
4
L5 = NU-144*3 L3 = NO-170*2
DSVI-3
2
3
20 20
Ø 6 Ø 15
60
22
*1
24
20
2–7
2–7
L5 29 46 L3
UN NO
1050
DH (max.3500)
SVI SVI SVA
21/25
101/105
80 19.5
Ø 5.5
3
3
41
42
20
2121
12
12
204.5131.5
141.5 214.5
336
17.5 126 21.5 79 15
Ø 10
Ø 25
10
R6
3.5–6*4
20
DSVI-3
DSVI
FFL
Ø 5.5
*1

SVA/SVI Mounting instructions
060644-45532 – 05/202312
6.2 Mounting illustrations
1
2
3
SVA SVA
1.
1.
1.
1.
1.
2.
2.
2.
2.
3.
3.
3.
3.
4.
4.
4.
1. 2.
3.
2.
3.
4.
45° 45°
1.5 kN
1.5 kN
SVI
SVISVI
SVI

SVA/SVI Mounting instructions
060644-45532 – 05/2023 13
4
6
7
5
SVI
SVI
1.
1.
1.
2.
2.
2.
3.
3.
4.
5.
6.
2 m – 2.55 m
2.55 m – 2.85 m
2.85 m – 3.15 m
3.15 m – 3.50 m
SVI SVI

SVA/SVI Mounting instructions
060644-45532 – 05/202314
8
9
10
11
SVI
SVI SVA
SVA
SVI
1.
1.
1.
1.
1.
2.
2.
2.
2.
3.
4. M5 x 20, A2-70
Spax 4.5 x 30
90° ± 0.5°90° ± 0.5°
45°

SVA/SVI Mounting instructions
060644-45532 – 05/2023 15
12
13

SVA/SVI Mounting instructions
060644-45532 – 05/202316
14
SVI
1mm
0
0
1.
2.
3.
4.
6.
6.
7. 8.
9.
11.
12.
10.
4.
5. 5.

SVA/SVI Mounting instructions
060644-45532 – 05/2023 17
15
SVI
RR
SVI
VB
1.
1.
2.
3.
1.3 Nm
1.3 Nm
ATTENTION
When tightening the screw, the lock must be
unlocked on tubular frame doors and locked
on solid doors. Do not use the door handle
for solid doors.

SVA/SVI Mounting instructions
060644-45532 – 05/202318

SVA/SVI Mounting instructions
060644-45532 – 05/2023 19

dormakaba Deutschland GmbH
DORMA Platz 1
58256 Ennepetal
Germany
[phone]
www.dormakaba.comwww.dormakaba.com
Copyright ©dormakaba 2023
