Doro TH70 User manual

doro th70/75r

10
8
9
37
1
4
56
2
th80 Silkscreen
Date
Version
: 8 May 2008
Prepared by: Rickard Nilsson
: a
Front Housing - Silkscreen
-Pantone white
Front Housing - keypad area
-laser etching
(for numbers :colour white after laser)
(for on/off keys: green and red respectively)
Lens area - silkscreen
-pantone white
Front Housing - Silkscreen
-Pantone white
1
1
2
2
soft keys - silkscreen
-Pantone white soft keys - background colour -Pantone black
keypad - blind guide
-0.3 rised dome
Lens area - hot stamping
-black chrome Lens area - silkscreen -Pantone black
11
13
14
12
th75r

1 Left menu button/Back/
Internal call
2 Speaker phone
3 Talk button
4 Shared phonebook
5 *and ring signal off/on
6 #and keyguard
7 End call button and on / off
8 Recall button (PBX features)
9 Right menu button/OK
10 Scroll button
Only th75r:
11 Indicators, see separate
description
12 Answer machine functions,
see separate description
13 Paging
14 Message indication/Display

1
English
Connection
1. Connect mains adapter and phone cable to respective wall sockets.
2. Insert battery according to the the markings.
3. Chargethehandsetwiththekeypadfacingoutwards(for24hoursthersttime).
Language
4. Press Menu.
5. Scroll to Settings using {/}. Press OK.
6. Scroll to HS settings. Press OK.
7. Scroll to Language. Press OK.
8. Scroll to desired setting 8/9. Press OK.
9. Press Lto return to standby mode.
Date/Time
10.Press Menu. Scroll to Settings. Press OK.
11.Scroll to Clock/Alarm. Press OK.
12.Scroll to Date/Time. Press OK.
13.Scroll to the required time format using 8/9. Press }.
14.Scroll to the required date format using 8/9. Press }.
15.Entertimeofday(HH:MM).Press}.
16.Enterdate(DDMMYY).PressOK.
17.Press Lto return to standby mode.
Range
The telephone’s coverage will vary between 50 and 300 metres, depending on whether the
radio waves carrying the conversation are blocked by obstacles in their path.
Coverage can be improved by turning one’s head so that the handset is aligned with the
baseunit.Soundqualitydeclinesasthelimitisreacheduntilthecallisnallyinterrupted.
Connection......................1
Range..............................1
Battery.............................2
Base unit indicators........2
The display......................2
Making a call...................3
Receiving a call...............3
Temporary silent mode...3
Volume control................3
Turning On/Off................3
Redial..............................3
Mute button.....................3
KeyGuard........................3
Paging.............................3
Message button..............3
Phonebook......................4
Inc. numbers/Caller ID....5
SMS messages...............6
Msg Indication(voice mail) 8
Other info services..........9
Sound..............................10
Clock/Alarm ....................10
Other settings .................10
Base settings..................11
Register a new handset..11
Expanded system (+1)....12
Answer Machine (th75r)..13
Switching the answer
machine on/off................13
Outgoing message .........13
Screening........................13
Use of answer machine..14
Settings in answer
machine...........................15
Out of memory................15
Activate remote control/
Change remote PIN........16
Remote activation...........16
Remote control ...............16
Troubleshooting..............17
Specic Absorption Rate 18
Declaration of conformity18
Guarantee.......................18

2
English
Battery
As batteries only have a certain lifespan it is quite normal that call time and standby time
willdecreasesomewhatcomparedtothespecicationswhenthetelephoneisusedregularly.
Fully-chargedbatteries(10hourscharging)willlastforapprox.100hoursstandbytimeor
approx.10hourscalltime.Thesetimesapplyatnormalroomtemperature.
Full battery capacity will not be reached until the batteries have been charged 4-5 times.
The base unit has an automatic charging mechanism that prevents the batteries from being
overcharged or damaged due to prolonged charging.
Please note!
Use only original battery (3.7V Li-ion polymer 465mAh) and original power adapter (7.5V DC
th70-400mA & th75r-600mA). Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instruction in your country. The base unit should not be
located close to other electrical equipment, in direct sunlight or near any other strong heat source!
This is to minimize the risk of any interference. It is normal for the device to become warm during
charging and this is not dangerous.
Base unit indicators
th70 th75r
7Steady light while charging.Steady light while charging.. q Flashes during calls and during ring.
Flashes when new SMS* message received.
The display
* Only functions in certain countries.
In order to save the batteries, the display is very dark on standby, press L
once to illuminate. During calls, use .
Icon Function
Shown when in range of base unit
Key lock activated.
Ring signal disconnected.
Alarm activated.
Speaker phone.
During calls.
Icon Function
Battery charge indicator.
New SMS* received.
New number received.
Message waiting Message indication*.
Only th75r:
New message on answer machine.
Flashes when memory is full.
Answer machine on.

3
English
Making a call
1. Enter the required number.
2. Press O, and the number will be dialled. Press Lto end the call.
Receiving a call
1. Wait for the handset to ring.
2. Press Oto answer. Press Lto end the call.
Please note!
Toswitchbetweenhandset/speakerpress .Pleaserememberthatinspeakermode,itisonlypossibleforonepersonata
time to talk.
This product does not usually ring on the rst signal to allow correct matching to the phone book.
Whenthebatteryisloworwhenthereistoogreatadistancetothebaseunitthetelephonewillbeunabletoconnecttoa
line.
Temporary silent mode
When someone calls, you can press Silence to turn off the handset ring signal.
Volume control
The volume can be adjusted during a call with }/{.
Turning On/Off
Press and hold the Lbutton for a few seconds to turn the handset off or on.
ConrmdisconnectionbypressingYes.
Redial
Press {and scroll through the 15 most recently dialled numbers using {/}. Press O.
Mute button
The microphone can be switched on/off during a call using b.
KeyGuard
The KeyGuard is turned off/on by pressing and holding #.
Paging
The handset will ring when J(onthebaseunit)ispressed.Thesignalwillstop
automatically after a while or if the Lbutton on the handset or the Jbutton on the base
unit are pressed.
Message button
Can be used when there is a new message in e.g. Caller ID or SMS.
Press the button to access the different messages.

4
English
Phonebook
200telephonenumbers(max.24digits)withnames(max.15letters)canbestoredinthe
handset’s phonebook.
If you subscribe to a caller ID service, the name allocated to the caller in the phonebook
will be shown for incoming calls.
You can also select different ring signals for different groups of numbers that are stored in
the phonebook.
Letters
Each number key has been allocated certain letters. The phonebook is arranged according
to the order of the buttons, which is not the same for all languages.
1.....................................[Space]
#.....................................Switch between upper/lower case letters ABC/abc/Abc
0(press & hold) .............Pause in telephone number
Save name/number in handset
1. Press 8(b).PressOption.
2. Scroll to New entry. Press OK.
3. Press equivalent digit key one or more times for desired name. Press }.
4. Enter the telephone number, including the area code.
5. Press OKtosaveorrstpress}and scroll with 8/9to assign the position to a ring
signal group.
Managing the phonebook
1. Press 8(b).
2. Scroll among the entries with {/}. You can quick search the phonebook by pressing
thecorrespondingnumberkeyfortherstletter.
3. Press Oto make a call or press Option for the following choices:
- New entry see description above.
- Edit entry - revise information.
- View to see stored information.
- Copy/Copy all to duplicate positions on other handsets.
- Delete entry/Delete all
- Capacity shows the number of free positions.
- Edit call Gp. to select a certain ring signal for certain groups of numbers.
- Speed dial to assign a position to a certain button in order to make it easier to make
a call. To dial a speed dial number press down the equivalent 2-9 button.
First scroll to the desired button, press OK, then scroll to the desired position in the
phonebook. Press OK.

5
English
Shared phone book
The phone book in the base unit is shared by all handsets and has 10 entries which only
need to be stored once however many handsets there are. Useful telephone numbers are
pre-programmed in certain models.
Howeverthesenumbersmaynotmatchwithcalleridenticationforname/ringtone.
1. Press .
2. Scroll among the entries with {/}.
3. Press Oto dial or scroll to the entry that is to be replaced. Press Option.
4. Scroll to Edit entry. Press OK.
5. Enter name. Press }.
6. Enter the telephone number, including the area code. Press OK.
Incoming numbers/Caller ID
The display shows you who is calling and the 30 most recent incoming numbers. New calls
are indicated by in standby mode.
If one and the same number calls in more than once it will be saved as only one entry.
Please note!
This function requires a subscription from your service provider.
Retrieving and dialling
1. Press }. Scroll to the required entry using {/}.
2. Press Oto make a call or press Option for misc. choices.
Caller identication messages
Unavailable No information received, e.g. an international call.
Withheld Number cannot be shown.
Caller ID settings
1. Press }. Press Option.
2. Scroll to Settings. Press OK.
3Scroll to required function, e.g. Category. Press OK.
4. Scroll to desired setting using 8/9. Press OK.
Category Select whether the telephone will store missed or all incoming calls.
New call alert You can activate a tone that is heard when new numbers have been
received.

6
English
SMS messages
Thisappliesonlytosubscribersoftextmessagingservices(SMS).
Thisserviceisnotyetavailableinallcountries.Maximum160signspermessage.
AnewSMSmessageisindicatedwiththetextNew SMS and the symbol .
The memory can store up to 20 messages.
Please note!
Program the correct number for your operator, see next page.
In most cases you must subscribe to the SMS service as well as the caller ID service supplied by your
service provider for message reception to function.
Information about the functions you can use varies depending on the service provider. It is not
certain that all service providers can send/receive SMS with all types of equipment.
With certain service providers you can send an SMS even to people without SMS equipment. In those
cases the message is read by an automated voice.
Failed SMS are saved in the outbox.
There are also templates for frequently used texts.
Read new SMS/inbox
1. Press Menu. Scroll to SMS. Press OK.
2. Scroll to Inbox. Press OK.
3. Scroll to selected entry. Press Read.
4. Read your message. Press Option.
5. Scroll to the required selection:
6. Press OK and follow the instructions in the display.
Write new SMS message
1. Press Menu. Scroll to SMS. Press OK.
2. Scroll to Write new SMS. Press OK.
3. Presscorrespondingdigitkeyoneormoretimesforthedesiredtext.
1.....................................[Space]
#.....................................Switch between upper/lower case letters ABC/abc/Abc
4. Press Option. Scroll forward to send or store the message. Press OK.
5. Enter the telephone number including the area code, or press Option to retrieve the
telephone number from the phonebook.
6. Press Send.
7. The display shows if the SMS has been sent successfully or not. If no error report is
shown, the message has been sent successfully.

7
English
Entering the telephone number to SMS service centre/Send service
Check that the correct number for your service provider has been programmed.
UK only
E.g. for BT:
  SMS-Centre1(sending):147017094009
  SMS-Centre2(receiving):0800587529
- ToregisterfortheSMStextmessagingserviceyoucaneithersendatextmessageto
anothertelephonenumber,ortextREGISTERto00000.
- ShouldyouwishtoresetyourSMSsettingstextRESETto00000.
- You can also request a delivery report by entering * 0 # prior to any SMS message.
- An SMS message can also be sent to a telephone number that does not support this
feature, and will be received as a voice message.
- Notallnetworks(iemobile,cable)arecompatible.
1. Press Menu. Scroll to SMS. Press OK.
2. Scroll to SMS settings. Press OK.
3. Scroll to Service centre. Press OK.
4. Scroll to selected entry. Press OK.
5. Enter number. Press OK.
Under Send service you specify which of the stored numbers is to be used for outgoing SMS.
Message Alert
You can activate a tone that is heard when new messages have been received.
1. Press Menu. Scroll to SMS. Press OK.
2. Scroll to SMS settings. Press OK.
3. Scroll to New SMS alert. Press OK.
4. Scroll to desired setting. Press OK.
