Dräger Alcotest 6000 User manual

i
Dräger Alcotest®6000
WARNING
Strictly follow the Instructions for Use.
The user must fully understand and strictly observe the instructions.
Use the product only for the purposes specified in the Intended use
section of this document.
!
enUS Instructions for use
3
es Instrucciones de uso
21

2
11 1310
1
9
4
7
8
6
5
12
00100217.ai
2
3
14

Safety-related information
3
en
1 Safety-related information
Before using this product, carefully read these instructions for use and those
of the associated products.
Strictly follow the instructions for use. The user must fully understand and
strictly observe the instructions. Use the product only for the purposes
specified in the intended use section of this document.
Do not dispose of the instructions for use. Ensure that they are retained and
appropriately used by the product user.
Only trained and competent users are permitted to use this product.
Comply with all local and national rules and regulations associated with this
product.
Only trained and competent personnel are permitted to inspect, repair and
service the product. Dräger recommend a Dräger service contract for all
maintenance activities and that all repairs are carried out by Dräger.
Do not use a faulty or incomplete product. Do not modify the product.
Notify Dräger in the event of any component fault or failure.
Use only genuine Dräger spare parts and accessories. Otherwise, the
proper functioning of the product may be impaired.
These instructions for use can be downloaded in other languages in
electronic form on the relevant product page (www.draeger.com/ifu), or a
free printed copy can be obtained from Dräger or the distributor.
Only use battery chargers, power packs, batteries, or rechargeable batteries that
Dräger has approved for this product.
2 Conventions used in this document
2.1 Meaning of the alert icons
The following alert icons are used in this document to notify the user of possible
dangers. The meanings of the alert icons are defined as follows:
WARNING
Indicates a potentially hazardous situation. If not avoided, it could result in death
or serious injury.

Description
4
en
CAUTION
Indicates a potentially hazardous situation. If not avoided, it could result in
physical injury. It may also be used to alert against unsafe practices.
NOTICE
Indicates a potentially hazardous situation. If not avoided, it could result in
damage to the product or environment.
2.2 Typographical conventions
This symbol indicates information that may make the use of this product
easier.
3 Description
3.1 Product overview (see Page 2)
1 Breath-alcohol analyzer
2 button (switch instrument on/off, confirm entry)
3 button (access menu, set value)
4 LEDs
5 Mouthpiece receptacle (configurable: right or left)
6 Display
7 button (set value)
8 USB connection (Important: Not for charging the device, for service only)
9 Wrist strap
10 Battery compartment cover
11 Battery
12 Pull strap for battery replacement
13 Loudspeaker (Important: No reset button)
14 Mouthpiece
Text Text in bold refers to labeling on the device and screen text.
►This triangle indicates options for avoiding the hazard in
warnings.

Use
5
en
3.2 Intended use
The Dräger Alcotest®60001) breath-alcohol analyzer is used to measure the
alcohol concentration in human breath. The measurement is used as an
indication for alcohol intoxication. It is not permitted for therapeutic measures to
be initiated on the basis of the measurement.
4 Use
WARNING
Small parts of the device may become detached and be swallowed.
The device is not intended for children under 3 years.
4.1 Prerequisites for use
The device is factory-calibrated when delivered. If the calibration date is longer
ago than 12 months, the instrument should be calibrated, e.g., by DrägerService.
Observe a wait time of approx. 15 minutes after the last consumption of
alcohol.
The wait time cannot be reduced by rinsing your mouth with water or with
non-alcoholic beverages.
Residual mouth alcohol or aromatic beverages (e.g., fruit juice), mouth
sprays containing alcohol, medication and drops, as well as belching and
vomiting may cause incorrect measuring values.
Rinsing the mouth with water or non-alcoholic drinks does not replace the
wait time!
4.1.1 Before sampling
The subject must breathe regularly and calmly before sampling.
The subject must be able to provide the required minimum breath volume
for the sampling.
4.1.2 Attaching the wrist strap
The wrist strap should be used to secure the device on the wrist.
1. Guide the fastening lug on the wrist strap through the eye on the device.
2. Pull the top part of the wrist strap through the fastening lug.
1) Alcotest®is a registered trademark of Dräger.

Use
6
en
4.1.3 Preparation for use
1. Ensure that the batteries are charged and inserted.
2. Ensure that a clean mouthpiece is attached.
3. Ensure that the device is held firmly and securely by using the wrist strap as
intended.
4.1.4 Switching the instrument on and off
Switching the instrument on:
1. Hold down the button for about 1 second.
2. Wait until the instrument displays that it is ready to measure.
Switching the device off:
1. Hold down the button for about 3 seconds. A switch-off count down will
be shown as well. If the display is off, stop pressing the button. Otherwise
the device will be switched on again.
The instrument will switch off automatically approx. 2 minutes after the last
use.
Switching off the instrument does not reduce the post-test waiting period
before you can perform another test.
4.2 Initial start-up
A setup wizard is opened when the instrument is switched on for the first time.
This step is not required for pre-configured instrument.
The following settings are made using the setup wizard:
Language
Date format
Date
Time format
Time
Measuring unit
All settings can be changed later on via the menu.
Language
A cursor pre-selects one language in the list. Press briefly on the button to
change the position of the cursor in order to select your needed language. If the

Use
7
en
cursor selects the right language please hold the button for approx. 2 seconds to
confirm.
Date
A cursor pre-selects the day of the date. Press briefly on the button to change
the day until the actual day is shown. Please hold the button for approx.
2 seconds to confirm the day. Please continue with the month and the year in the
same way: short press to change and long press to confirm.
Time format
A cursor pre-selects a time format. Press briefly on the button to change the
position of the cursor in order to select your needed time format. If the cursor
selects the needed time format please hold the button for approx. 2 seconds to
confirm.
Time
A cursor pre-selects the hours of the time. Press briefly on the button to change
the hour until the actual hour is shown. Please hold the button for approx.
2 seconds to confirm the hour. Please continue with the minutes in the same
way: short press to change and long press to confirm.
Measurement unit
A cursor pre-selects a measurement unit in the list. Press briefly on the button to
change the position of the cursor in order to select your needed measurement
unit. If the cursor selects the needed measurement unit, please hold the button
for approx. 2 seconds to confirm.
After the setup wizard is finished, the display shows Welcome and continues with
READY for tests.
The Alcotest®4000 is now adjusted to your settings and is ready for breath tests.
Of course these and further settings can be adjusted in the device menu (see
section 4.8 on page 10).
NOTICE
Loss of default settings
If the battery replacement process takes longer than 5 minutes, the date and
time must be reset. A measurement is only possible with the time set.

Use
8
en
4.3 Carrying out an automatic breath sample
A new mouthpiece must be inserted for each new person who provides a
breath test.
Do not allow any high alcohol concentrations on the sensor, e.g., by rinsing
the mouth with a high proof alcohol shortly before the measurement, as this
will shorten the service life of the sensor.
Procedure
1. Remove the mouthpiece (order no. 68 10 690 "Standard", 68 11 055 "with
exhalation non-return valve") from the packaging.
For reasons of hygiene, leave the protective wrapping around the mouth
contact area until the mouthpiece is firmly attached to the instrument.
2. Attach the mouthpiece at an angle to the mouthpiece receptacle and press
it into the receptacle.
The fluted markings (press-on surface) on the mouthpiece face upwards
while this is done.
The mouthpiece audibly snaps into place (see Page 2).
3. Remove all packaging.
Keep the button pressed for approx.1 second until the startup screen is
displayed. An optional self-test is carried out. The following is shown on the
display for approx. 4 seconds:
READY
The instrument is ready to measure.
4. Blow evenly and without interruptions into the mouthpiece. A progress bar
is displayed. An adequate breath flow is signaled by a continuous tone.
5. Without any further action from the user side. the device takes automatically
a test sample at the end of the breath of the test subject.
6. When an adequate breath sample is provided, the continuous tone stops
with an audible click.The test subject can stop blowing.
The test result is displayed with the date and time after a few seconds
(depending on the device temperature and the measured concentration).
In case of a negative alcohol test, 0,00 will be displayed. In case of a positive
alcohol test, the measured alcohol level will be displayed.
Performing another measurement:

Use
9
en
To prepare a new measurement, press the button.
After the sensor’s recovery time (see "Technical data" on Page 16) READY
is displayed and the device is ready to use again.
4.4 Carrying out a manual breath sample (optional)
If the test subject cannot provide the required minimum volume, the sampling
can be triggered manually.
Carrying out a manual breath sample:
1. Follow steps of the automatic breath sample.
2. If the progress bar is displayed after starting the breath sample, tap the
button.
In the results display, MANUAL is also displayed.
4.5 Carrying out a passive breath sample (optional)
During passive sampling, the sampling is manually initiated by the instrument
user. Possible applications include the testing of ambient air or the breath of
persons for the presence of alcohol.
Carrying out passive sampling:
1. Keep the button pressed for approx. 1 second until the startup screen
appears.
2. Hold the instrument, which is ready to measure, into the air to be analyzed
without a mouthpiece.
3. Tap the button to initiate the measurement.
In the results display, PASSIVE is also displayed. If no alcohol is detected, the
No Alcohol will be displayed and the LED will be green. In case alcohol is
detected, Alcohol will be displayed and the LED will be red.
4.6 Removing the mouthpiece
1. Push the mouthpiece up and out of the mouthpiece receptacle (see
illustration on Page 2).
2. Dispose of the mouthpiece in accordance with local regulations.
Do not reuse a mouthpiece.
4.7 Menu control
Accessing the menu:
Press the button.

Use
10
en
Navigating in the menu or changing settings:
Press the or button.
Confirm the selected feature/input with the button.
Exiting the menu:
In the sub-menu, select the Back menu item.
In the main menu, select the Measuring menu item.
4.8 Menu items
The following table provides an overview of the menu options and how to use
them:
Menu option Description Interaction instruction
Measuring Option to leave the menu
and to go back to the READY
screen to perform a test.
Hold the button for
2 seconds to leave the
menu.
Bluetooth®
(optinal)
Menu option to switch
Bluetooth®on or off.
Select Bluetooth®On or
Off with the or
button.
Confirm with the
button.
The device is set up for connection to an app via
Bluetooth®.
An active Bluetooth®connection is displayed by a
corresponding symbol in the display.
Bluetooth®must not be selected in aircraft.
Printer Menu option to set a default
printer and to switch the
function on and off.
Select the printer using
the and buttons.
Confirm with the
button.

Use
11
en
Results Overview of the last 10 tests
performed on the device
(incl. result, date, time, test
ID). There is one test
displayed per screen.
Navigate through the test
result list using the
and buttons..
Hold the button for
2 seconds to leave the
submenu.
Device info Serial no and part no of the
device
Hold the button for
2 seconds to leave the
submenu.
Next service Overview, in how many days
the device...
should get serviced,
should be adjusted
and should get an
accuracy check.
Hold the button for
2 seconds to leave the
submenu.
Date & time Date, time as well as date
format (yyyy/mm/dd, yyyy-
mm-dd, mm/dd/yyyy,
dd.mm.yyyy) and time format
(12h, 24h) can be adjusted.
The submenu can be left via
the Back option.
Change the digits using
the and buttons.
Confirm with the
button.
Select the Back option
and hold the button for
2 seconds to leave the
submenu.
Contrast The display contrast can be
adjusted within 5 levels.
Select the contrast setting
using the and
buttons.
Confirm with the
button.
Hold the button for
2 seconds to confirm the
setting and leave the
submenu.
Menu option Description Interaction instruction

Use
12
en
Loudspeaker Any acoustical signals of the
device can be turned off or to
a volume of 50 % or 100 %.
Adjust the volume using
the and buttons.
Confirm with the
button.
Hold the button for
2 seconds to confirm the
setting and leave the
submenu.
Language The language of the display
can be adjusted.
Select the language using
the and buttons.
Confirm with the
button.
Hold the button for
2 seconds to confirm the
setting and leave the
submenu.
Measurement
unit
The measurement unit for
the alcohol test results can
be adjusted within the
following options: %, ‰, g/L,
mg/100 mL, mg%, mg/mL,
mg/L, g/100 mL, g%, g/L,
g/210 L
Select the measuring unit
using the and
buttons.
Confirm with the
button.
Hold the button for
2 seconds to confirm the
setting and leave the
submenu.
Software
version
Software version and part
number are displayed.
Hold the button for
2 seconds to leave the
submenu.
Login For service technicians
only.Do not enter this menu.
Enter the four-digit code
to open the service menu.
Switch off Menu option to switch the
device off.
Tap the button.
The device switches off.
Menu option Description Interaction instruction

Troubleshooting
13
en
4.9 Printing measurement results
Every device is equipped with Bluetooth, and can be configured accordingly if
necessary. To print the measurement results, the device can be connected to the
Dräger Mobile Printer Bluetooth®(see order list, part number: 3700421) via
Bluetooth®.
Observe the Dräger Mobile Printer Bluetooth®'s instructions for use.
Bluetooth®must not be selected in aircraft.
5 Troubleshooting
An error message is displayed in the event of instrument faults. The number that
appears below the message is used for service functions. If the fault remains
after switching the instrument on and off several times, contact DrägerService or
your dealer.
Fault/message Cause Remedy
The instrument cannot
be switched on.
Battery drained. Replace battery.
Volume too low /
sample invalid.
Test subject is blowing
intermittently or not hard
enough.
Blow into the mouthpiece
harder and continuously.
Instrument outside
temperature range
Instrument is too hot or too
cold.
Allow the instrument to
cool down or become
warmer.

(over range)
Measuring range
exceeded. Alcohol
residues that are still in the
mouth may cause
incorrect measuring
values.
A wait time of at least
15 minutes after alcohol
was last orally consumed
must have elapsed (see
Page 8).
To repeat, press the
button.
Volume too small Breath sample volume too
small.
Repeat breath sample.

Maintenance
14
en
6 Maintenance
Have the device calibrated every 12 months, as drift effects increase the
uncertainty of measurement over time. Calibrationand maintenance should only
be carried out by authorized persons, e.g., DrägerService.
The last 30 days before next adjustment / service is needed, a day count down
will be shown as information in the display after switching on the device. You
have to confirm this information with the button. After the adjustment / service
date the device starts to count up how many days it is over requested adjustment
/ service. This information has to be confirmed by pressing the button as well.
It shall remember you that the device needs to be adjusted / serviced.
Have the instrument re-calibrated, if an accuracy check does not produce a
result per NHTSA‘s EBT Model Specifications. Calibrations should only be
carried out by authorized persons, e.g. DrägerService
6.1 Replace battery
1. Switch off the device.
2. Slide the battery cover off.
3. Replace the battery (battery type: 3 V CR123A; order no.: 83 21 390),
paying attention to the correct polarity.
4. Fit the battery cover.
5. Check that the time is correctly set.
Volume too great Measuring range
exceeded.
Repeat breath sample.
Sample interruption Irregular exhalation,
abrupt end, or inhalation
Repeat breath sample.
Fault number Instrument fault Switch the instrument off
and on again. If the fault
remains, contact
DrägerService.
Fault/message Cause Remedy

Maintenance
15
en
If the battery replacement process takes longer than 5 minutes, the time
must be reset. A measurement is only possible with the time set.
CAUTION
Damage to the instrument.
Do not try to charge any kinds of batteries via the USB port. The instrument
comes without a recharging function.
Recharge the rechargeable batteries outside the instrument.
6.2 Cleaning
The instrument should be cleaned with an ethanol-based cleaning agent.
Cleaning the device:
1. Wipe the device down with a disposable cloth with the cleaning agent. Do
not apply cleaning agent directly to the device.
Ensure that no liquid enters the gas inlet.
2. After cleaning the device, store it unpacked at room temperature (20-25 °C)
for at least 24 hours.
3. Afterward, carry out passive sampling to ensure that no ethanol residue
remains in the device and the result "No alcohol" is displayed.
Do not immerse in fluids and avoid contact of fluids with the electrical receptacles.
Do not use any cleaning agents containing alcohol, solvents or substances
containing citrus. Wipe down the instrument with a disposable cloth.

Storage
16
en
7 Storage
CAUTION
Damage to the device
Leaking battery acid can damage the device.
Remove the batteries if the device will remain unused for an extended
period of time.
8 Disposal
9 Technical data
This product must not be disposed of as household waste. This is
indicated by the adjacent symbol. You can return this product to
Dräger free of charge. For more information please contact the
national marketing organizations or Dräger.
It is not permitted for batteries to be disposed of as household waste.
This is indicated by the adjacent symbol. Collect and dispose of
batteries and rechargeable batteries at battery collection centers in
accordance with applicable regulations.
Measuring principle
Electrochemical sensor
Measuring range
Breath alcohol concentration 0.000 to 0.500 g/210L
Blood alcohol concentration 0.000 to 0.500 % BAC
Small values will be shown as
0.000
0.000 to 0.0063 g/210L
For the above data, a conversion factor of 2100 is used for breath and blood
alcohol concentration data (factory setting, country-specific conversion factors
can be configured).

Technical data
17
en
Measurement modules
mg/L, g/100 mL, g%, g/L, g/210 L, g/L ‰, %, mg/100 mL, mg%, mg/mL
Ambient conditions
During operation –5 to +50 °C
(23 °F to +122 °F)
10 to 100 % rel. hum.
(non-condensing)
600 to 1300 hPa
During storage –20 to +60 °C
(–4 °F to +140 °F)
15 to 75 % rel. hum. (10 to 100 % rel.
hum. <48 h)
Taking samples
Respiratory volume >1.2 L (default)
Breath flow >10 L/min (default)
Duration of breath >1.6 s (default)
Measurement accuracy
Standard deviation of the repeatability with ethyl alcohol standard
Up to 0.50 mg/L
0.50 mg/L
Up to 0.100 % BAC
0.100 % BAC
0.008 mg/L
1.7 % of the measured value
0.0017 % BAC or
1.7 % of the measured value
Whichever value is higher
Sensitivity drift
Typically 0.4 % of the measured value per month
Wait time for measurement readiness following a previous
measurement with:

Technical data
18
en
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
0.25 mg/L 20 s
0.50 mg/L 40 s
1.00 mg/L 80 s
>1.50 mg/L 120 s
0.050 % 20 s
0.100 % 40 s
0.200 % 80 s
>0.300 % 120 s
Calibration
Recommendation: every 12 months (local deviations are possible)
Dimensions
50/60 mm x 141 mm x 31 mm (W x H x D)
Weight
approx. 7 lbs (150 g)
Power supply
1 x 3 V CR123A
The batteries are designed for up to 1500 measurements (depending on use
and the ambient conditions).
Interface
Micro-USB, 2.0 fullspeed, not for charging the device, for service only
Protection class
IP 54
Interface
USB connection for service only
CE markings
Electromagnetic compatibility
Configuration possible, see name plate

Manufacturer’s Limited Warranty
19
en
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
10 Manufacturer’s Limited Warranty
Draeger Safety Diagnostics, Inc. (DSDI) warrants that this product will be free
from defects in materials and workmanship under normal use and service for a
period of 12 months. The period of this limited warranty shall commence on date
of original purchase. Implied warranties, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose are likewise
limited to a period of 12 months from the date of original purchase. Some States
do not allow limitations on how long an implied warranty lasts, so the above
limitation may not apply to you.
In the event that the product fails to perform as warranted, the sole remedy is that
DSDI will repair or replace (at its sole discretion) any part or component proven
to its reasonable satisfaction to be defective; provided, however, that DSDI is
notified of the warranty claim within ten (10) days of the user becoming aware of
the defect and that any such part is returned, upon request, to DSDI's facilities in
Irving, Texas within the warranty period. DSDI will assume the cost for freight for
warranty repairs.
THIS LIMITED WARRANTY EXTENDS ONLY TO THE ORIGINAL END USER
OF THE PRODUCT AND DOES NOT COVER DAMAGE OR LOSS
RESULTING FROM MISUSE, ABUSE, ACCIDENT, NEGLECT, IMPROPER
INSTALLATION, OPERATION MAINTENANCE OR USE, AND/OR
MECHANICAL, ELECTRICAL OR ENVIRONMENTAL CIRCUMSTANCES
SUCH AS CORROSION BY AMBIENT GASES OR LIQUIDS, EXCESSIVE
DUST, AND/OR OTHER DEPOSITS ON PARTS OF THE PRODUCT. THIS
LIMITED WARRANTY DOES NOT COVER WARRANTED PARTS REPAIRED,
MODIFIED, OR ADJUSTED OUTSIDE OF DSDI'S FACILITIES IN IRVING,

Manufacturer’s Limited Warranty
20
en
TEXAS, WITHOUT PRIOR WRITTEN CONSENT OF DSDI. ANY
UNAUTHORIZED REPAIR, MODIFICATION, OR ADJUSTMENT OF THE
PRODUCT COVERED UNDER WARRANTY VOIDS THE WARRANTY SET
FORTH HEREIN.
The limited warranty set forth above is sole warranty applicable to the product.
Furthermore, DSDI shall not be liable for loss of use, income or profit, incidental,
special or consequential or other similar damages, arising, directly or indirectly,
out of or occasioned by the operation, use, repair, or replacement of the products
whether such damages are based on a claim of breach of express or implied
warranties, tortuous conduct (including negligence and strict liability), or any
other cause of action. Some States do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitations or exclusions may
not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from State to State.
All warranty claims should be directed to:
Draeger Safety Diagnostics, Inc., 4040 W. Royal Lane, Suite 136, Irving, Texas
75063. 1.800.332.6858.
