Dura Trel Sunburst Trellis 11147/8 User manual

Model# 11147 / 8 Assembly Instructions
Part # Description
1 2" sq. x 59½" Left Post
2 2" sq. x 59½" Right Post
3⅞ x 3 x 27½" Bottom Cross Rail
4⅞ x 3 x 27½" Center Cross Rail
5⅞ x 3 x 27½" Top Cross Rail
6⅞ x 1½ x 27½" Bent Top Rail
7 24 x 48" Green or White Lattice
8 Hardware Bag (includes:)
2" sq." Post Cap
1¼" Painted Screw
⅝ x 9½" Tube
⅝ x 11" Tube
9 Trellis Ground Anchor Kit (includes:)
16" Steel Ground Anchor (L-Shaped)
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY. #8 - 1" Painted Self Tapping Screw
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
…
Battery or Electric Drill with #2 phillips bit
…PVC, Super, or Crazy Glue
…
Hammer or Rubber Mallet (recommended)
…
Straight Blade Screwdriver (if combining trellis with planter)
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
4
1
1
Qty
1
Sunburst Trellis
2
1
1
3
1
1
6
General Information
1
1
2
2
www.dura-trel.com
[e-mail]
Tools Required
1-877-258-6020
1

150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
1-877-258-6020
2
www.dura-trel.com
[e-mail]
Please call manufacturer direct with questions concerning missing or defective parts at Toll Free:
877
-258-6020.
Dura
-trel, Inc. products are warranted to be free from manufacturing defects resulting in delaminating,
peeling, flaking, corroding, cracking, crazing, or extreme amounts of fading or bleaching causing the
PVC to change to its natural color for a period of 20 years from the date of purchase.
Normal weathering is defined as exposure to sunlight and extremes of weather and atmosphere which
will cause any colored surface to gradually fade.
CONDITIONS NOT COVERED BY THIS WARRANTY:
A. Physical abuse, misuse, neglect, or improper storage.
B. Improper installation or installation not in strict adherence to the instructions written by Dura
-Trel,
Inc.
C. This warranty does not apply if materials are painted, varnished, or coated with any substance.
D. Dura
-Trel, Inc. is not responsible for damages to product during shipping.
E. Damage attributable to atmospheric pollutants, hail, lightning, hurricane, tornado, wind borne
objects, earthquake, fire, mildew, casualty, act of God, building or ground settlement, or subjection to
stress or weight.
CLAIMS AND REMEDIES:
If a Dura
-Trel, Inc. product is determined to have a manufacturing defect which is covered by this
warranty, Dura
-Trel, Inc. will replace the material containing the defect (labor not included) F.O.B from
the point of manufacture. Dura
-trel, Inc. will not be responsible for any cost incurred in the removal or
reinstallation of the product.
Important:
An claims must be sent to the following address and should describe the defect claim.
Dura-Trel, Inc., P.O. Box 122, Sheboygan Falls, WI 53085
Dura
-Trel, Inc. reserves the right to discontinue or change its design, and or color. If the original color
or style is not available, Dura
-Trel, Inc. shall have the right to substitute a product designated by Dura-
Trel, Inc.
Dura
-
Trel, Inc. shall not be liable for any incidental, special, or consequential damages arising out of the
use of these products
Warranty Statement
20 Year Guarantee

3
Sunburst Trellis
Insert lattice (part 7) through 27½" center cross rail (part 4). Insert one end of lattice into 27½" bottom
cross rail (part 3) and other end into 27½" top cross rail (part 5). Insert one end of three cross rails into
corresponding holes in left post (part 1). Insert bent top (part 6) into left post. Insert one 11" tube and
one 9½" tube into left outer hole of top cross rail, with 11" tube on outside (left side). Insert one 9½"
tube into hole in middle of top cross rail. Insert one 9½" tube and one 11" tube into right outer hole of
top cross rail, with 11" tube on outside (right side). Insert free ends of tubes into bent top. Insert free
ends of bent top and cross rails into right post (part 2).
Using six 1¼" screws, screw together trellis. Be
sure that all parts are fully inserted into legs before.
If combining with Model# 11153 Large Green Lattice Planter or Model# 11154 Large White Lattice
Planter to make a planter trellis, use a straight blade screwdriver to pop off two 2" sq. post caps of one
long side of the planter and slide trellis over the planter legs. Using two 1" painted self
-tapping screws
from trellis ground anchor kit (part 9), fasten trellis to planter.
