Dura Trel Melrose Trellis 11191 User manual

Model# 11191
Melrose Trellis
W221122-A5080
*W201121-A2040*
*W201121-A2040*
*W201121-A2040*
*W201121-A2040*
*W201121-A2040*
*W201121-A2040*
QUESTIONS? COMMENTS? CONTACT US!
115 Vision Parkway 1-877-258-6020
P.O. Box 122 www.dura-trel.com
Sheboygan Falls, WI 53085 [e-mail]
Assembly Instruction Manual
Please read instructions thoroughly before beginning assembly.
Check boxes carefully for contents listed. Some parts are packaged inside of others.
Assemble on a clean, flat, non-abrasive surface to prevent scratching.
In the event of missing or damaged parts please call or email our customer service department at
the contact info below.
Tools Required
-Battery or Electric Drill (#2 phillips bit)
Tape Measure
-Hammer or Rubber Mallet (Recommended)
-Shovel or Post Hole Digger (Recommended)
-PVC, Super or Crazy Glue

75"
35"
45"
Melrose Trellis - Page 2

Lay out one right post (part 2). Starting at
bottom, insert one bottom cross rail (part 3) and
five center cross rails (part 4).
Insert two 66" vertical slats (part 7) through outer
holes of center cross rails and into bottom cross
rail. Insert two 63" vertical slats (part 6) through
inner holes of center cross rails and into bottom
cross rail.
Insert top bent rail (part 5) through right post,
inserting vertical slats into top bent rail.
1
2
3
Melrose Trellis - Page 3

Insert bent top rail through left post (part 1),
inserting center cross rails and bottom cross rail
into left post.
Using 1¼” screws, screw together trellis. Be
sure that all parts are fully inserted into posts
before securing.
Using PVC, super or crazy glue; glue post
caps onto posts.
4
5
6
Melrose Trellis - Page 4

Option 1 (soft ground)
Slide one ground anchor (part 12) into bottom of each
post until it meets bottom cross rail. Using two 1” self-
tapping screws per post, screw the post to ground
anchor using the pilot holes for guides.
Using ground anchor installation layout drawing, dig
holes approximately 12” deep. Set trellis in holes and
level. Back fill with soil removed from holes.
Option 2 (permanent installation)
NOTE: There is very little room for error with this
installation method.
Using ground anchor installation layout drawing, dig
holes 12” deep according to dimensions. Fill with
cement and place ground anchors in wet cement. Be
sure that ground anchors are straight and in accordance
with dimension of ground anchor installation layout
drawing. Allow cement to dry.
Slide trellis over ground anchors. Using two 1” self-
tapping screws, fasten post to ground anchor.
Ground Anchor Installation
Ground Anchor Layout Drawing
34.75"
Melrose Trellis - Page 5
