Dynojet Power Commander III 705-411 User manual

i705-411 1998-2001 Ducati 996 - PCIII USB - 1
1998-2001 Ducati 996
Installation Instructions
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89031 [phone] www.powercommander.com
Parts List
1Power Commander
1USB Cable
1CD-ROM
1Installation Guide
1Power Adapter
2Power Commander Decals
2 Dynojet Decals
1 Velcro®Strip
1Alcohol Swab
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
The ignition MUST be turned
OFF before installation!
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Button Adjustment Display
Faceplate Buttons
USB Port
Expansion Port

1Lift the rear section.
2Remove the left hand side fair-
ing.
3 Locate the plug that resides in
between the two throttle bodies
(Fig. A). This plug has a round,
silver retaining ring on the end
of it.
4Unscrew this connector by turn-
ing it counter-clockwise.
Note: You may want to route the wires
for the PCIII from the tail sec-
tion to this area before plugging
it in. This will make for a
cleaner installation.
5Plug the female connector from
the PCIII into the wiring harness
(Fig. B).
6) Plug the male connector from
the PCIII into the stock female
connector on the bracket
(Fig. C).
Fig. AFig. B
Fig. C
i705-411 www.powercommander.com 1998-2001 Ducati 996 - PCIII USB - 2
Loosen these bolts
Screw the female end of
the PCIII into the harness
PCIII connectors
Stock connector
Unscrew this connector
PCIII Stock harness

7Attach the ground wire from the
PCIII to front, left hand, mount-
ing point of the ECU (Fig. D).
8Attach the PCIII to the top of
the ECU using the supplied vel-
cro. (Fig. D). Make sure to clean
both surfaces with the alcohol
swab before attaching the velcro.
9Make sure all wires are routed
so they do not get damaged.
10 Reinstall the left hand side fair-
ing.
Fig. D
i705-411 www.powercommander.com 1998-2001 Ducati 996 - PCIII USB - 3
Ground wire
