Dynojet Power Commander 3 User manual

330-411 www.powercommander.com 06-08 Suzuki M109R- 1
2006-2008 SUZUKI M109R / C109R
Installation Instructions
Parts List
1 Power Commander
1 Installation Guide
1 USB cable
1 CD-ROM
1 Power adapter
2 Dynojet decals
2 Power Commander decals
2 Velcro® Strip
1 Alcohol Swab
1 Port plug set
You can also download the
Power Commander software and
latest maps from our web site at:
www.powercommander.com
THE IGNITION MUST BE TURNED OFF BEFORE INSTALLATION!
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 [phone]

FIG #
FIG #
FIG #
1 Remove the main seat and both side
covers.
2 Remove the fuel tank.
3 Remove the air box.
There are several hoses going into the
air box. We recommend referring to the
service manual for proper removal and
installation.
4 Route the wiring harness from the PCIII
behind the left hand side of the frame and
go towards the throttle bodies (Fig. A).
FIG A
5 Unplug the stock wiring harness from each
injector (Fig. B).
FIG B
FIG C
6 Plug the connectors from the PCV inline
of the stock injectors and the stock wiring
harness (Fig.C).
Orange - cylinder 1- front
Yellow - cylinder 2 - rear
PCV harness
Unplug
Unplug

330-411 www.powercommander.com 06-08 Suzuki M109R - 3
FIG D
FIG E
FIG F
9 Route the ground wire from the PCIII thru
the front hole in the battery box.
10 Attach the ground wire from the PCIII to the
negative side of the battery (Fig. E).
11 Install the PCIII under the left hand side
cover. Zip tie the unit to the metal brace
near the ECU (Fig. F).
12 Reinstall air box and fuel tank.
7 Unplug the Throttle Position Sensor
connector (Fig. D).
This connector is located on the right hand
side of the throttle bodies and is GREY in
color.
8 Plug the PCIII connectors in-line of the
stock wiring harness and TPS
Unplug
Ground

330-411 www.powercommander.com 06-08 Suzuki M109R - 4
13 Plug the Dynojet O2 eliminator into the
stock wiring harness.
14 Route the O2 eliminator harness to the
inside of the frame near the thermostat
housing (Fig. G).
FIG G
15 Ground the other end of the Dynojet O2
eliminator to the bolt of the thermostat
housing (Fig. H).
FIG H
O2 eliminator
Ground
FIG J
16 Secure the PCIII in the tail section using
the supplied velcro. Make sure to use the
alcohol swab to clean both surfaces before
attaching.
17 Bolt the fuel tank back into place. Reinstall
the fairing and seats.
