Raffaello Megaline Espresso Coffee Machine
Raffaello Megaline
Espresso Coffee Machine
Technical Handbook and User Manual
Specifications subject to change without notice.
1

Raffaello Megaline Espresso Coffee Machine
Contents
Page Description
3 General Data
4 Introduction
5 Important Safety Precautions
8 Instruction for use
10 Installation
17 Electronic Control Board and Settings
1Main Features
2Hardware
3Function
4Programming of the keys
5System Programming
6Auditing
7Alarms and Time Outs
8Special functions
9Accessory functions
94 Setting parameters and procedures
97 Hydraulic diagram
99 Electric diagram
105 Start-Up
105 Dispensing beverages
109 Cleaning of the coffee brewing circuit / group
110 Cleaning of the milk foamer
114 Other cleaning operations
115 How to dismantle the machine
Specifications subject to change without notice.
2

Raffaello Megaline Espresso Coffee Machine
General Data
Manufacturer: ECM S.p.A.
Viale delle Industrie 26
20090 Settala (Mi)
Italy
Tel. + 39 02 950 754 1
Fax + 39 02 950 754 99
Email [email protected]
Series: ECM Raffaello Megaline Espresso Coffee Machine
Versions: Raffaello Megaline A 1 (1 group) with automatic portion control
Raffaello Megaline A 2 (2 groups) with automatic portion control
Raffaello Megaline S 1 (1 group)with semiautomatic portion control
Raffaello Megaline S 2 (2 groups) with semiautomatic portion control
Technical data:
Voltage: Please refer to machine’s technical data plate
Rated power: Please refer to machine’s technical data plate
Boiler capacity: Raffaello Megaline A1, Raffaello Megaline S 1: 8 litre
Raffaello Megaline A 2, Raffaello Megaline S 2: 14 litres
Dimensions: Raffaello Megaline A 1 and S 1 (W x D x height without feet):
475 mm x 515 mm x 500 mm / 18.7 in. x 20.3 in. x 19.7 in.
Raffaello Megaline A 2 and S 2 (W x D x H without feet):
625 mm x 515 mm x 500 mm / 24.6 in. x 20.3 in. 19.7 in.
Manufactured since: 1996
Distributed by:
Specifications subject to change without notice.
3

Raffaello Megaline Espresso Coffee Machine
Introduction
Read and understand all instructions. These instructions provide important information on the correct
installation, safe and correct use and maintenance of this product. Thoroughly read this manual before
you start to use this product. In particular, be sure to read and fully understand the Safety Precautions
described in this manual before you use this product.
For further information or additional handbooks, please contact your distributor or the manufacturer.
Also, store this manual in a safe place so that it can be easily referred to during use of this product...
This handbook is an essential part of the machine.
This handbook reflects the current manufacturing requirements and is subject to change according to
future modifications.
The manufacturer is free to modify this manual without updating previous editions except in
exceptional cases.
The manufacturer accepts no responsibility for damage to persons or objects caused by incorrect
installation and unreasonable use and maintenance
The instructions in this handbook are in no way a substitute for the safety instructions and technical
data on the machine or the packaging concerning installation and function.
The machines come with the following accessories:
Raffaello Megaline A 1 and S 1: 1 Instruction manual
1 One cup filter holder
1 Two cups filter holder
1 One cup filter basket
1 Two cups filter basket
1 Blind filter basket
Raffaello Megaline A 2 and S2:: 1 Instruction manual
1 One cup filter holder
2 Two cups filter holder
1 One cup filter basket
2 Two cups filter basket
1 Blind filter basket
Specifications subject to change without notice.
4

Raffaello Megaline Espresso Coffee Machine
Important Safety Precautions
Front view of machine (i.e.: Raffaello Megaline A 2)
Fig. A
•Read and understand all instructions. These instructions provide important information on the
correct installation, safe and correct use and maintenance of this product. Thoroughly read this
manual before you start to use this product. In particular, be sure to read and fully understand the
Safety Precautions described in this manual before you use this product.
Also, store this manual in a safe place so that it can be easily referred to during use of this product.
Copies are available from your local distributor or the manufacturer.
This handbook is an essential part of the machine.
•If you have questions please contact the manufacturer or the authorized technical service before
you install and/or use the machine.
•The instructions in this handbook are in no way a substitute for the safety instructions and
technical data on the machine or the packaging concerning installation and function.
•This machine is designed for the sole purpose of producing coffee, hot water and steam for hot
drinks. All other uses are incorrect and, therefore, dangerous.
Specifications subject to change without notice.
5

Raffaello Megaline Espresso Coffee Machine
•Do not touch hot surfaces as steam (fig. A-6 and 10) and hot water wands (fig. A-7), the metal
parts of the brewing group (fig. A-12) and the metal parts of the filter holder (fig. A-11).
Attention: never hold your hands under the brewing group (fig. A-11), the filter holder (fig. A-12),
the steam and hot water wands (fig. A-6 and A-7). Hot drinks, hot steam and hot water are
dispensed. Danger!
•To protect against electric shock do not immerse any part of the machine, as well as cord and
plugs in water or other liquid.
•Do not allow liquids to get inside the coffee machine.
•Close supervision is necessary when any appliance is used near children.
•Allow the machine to cool before putting on or taking off parts.
•Never allow any contact of machine’s internal and external parts with any kind of liquids (i.e.
cleaning products etc.).
•Do not operate any appliance with a damaged cord, plugs, or after the appliance malfunctions or
has been damaged in any manner. Do always contact the authorised technical service.
•The use of accessory attachments not allowed by the appliance manufacturer and may cause
injuries.
•Do not use outdoors.
•The machine’s surrounding area has to be safe and hygienic.
•Do not place on or near a hot gas or electric burner or in a heated oven.
•Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.
•To disconnect the plug from the wall outlet, turn any control to “off”, then remove plug.
•The information contained in this manual relating to installation and operation is not a substitute
for safety instructions and technical data affixed to the machine and/or its packaging.
•The manual provides information that is current at the time of publication. The information is
subject to amendment or alteration without notice.
•Your machine should only be operated in accordance with instructions contained in this manual
and verbal instructions and training provided by an authorised ECM dealer.
•This machine is to be operated according to the instructions supplied in the handbook by a
responsible and trained adult operator, authorized installation and/or service technician.
•Installation and maintenance MUST be carried out by technicians and service providers
authorised by the manufacturer.
•The manufacturer accepts no liability for injury and damage to person, persons or property caused
by incorrect installation, use and maintenance, neglect of the machine or any other circumstances
beyond its control.
Specifications subject to change without notice.
6
•Maximum water inlet pressure is 3,5 bar (0,35 MPa). Please install a pressing reducing valve if
water pressure from the mains is higher.

Raffaello Megaline Espresso Coffee Machine
•The machine should not be operated with temperatures under 8°C (46°F) and over 44 °C (110 °F).
•The machine has to be used with soft clean drinking water: In case please use and adequate water
filter.
•The machine must be operated by a professionally trained adult and should not be used by minors
or other non-trained individuals.
•The user must respect the safety regulations at the point of installation.
•Save these instructions.
Specifications subject to change without notice.
7

Raffaello Megaline Espresso Coffee Machine
Instruction for use
•This machine is designed for the sole purpose of producing coffee, hot water and steam for hot
drinks. All other uses are incorrect and, therefore, dangerous.
•This machine is designed for professional use only.
•The machine’s components are made of non toxic and long lasting parts which are easily accessed
for cleaning and maintenance.
•The machine must be operated by a professional trained adult and should not be used by minors or
other non-trained individuals.
•The user must respect the safety regulations at the point of installation.
•To ensure efficient and correct operation it is essential to follow the manufacturer’s instructions
concerning the periodic maintenance carried out by ECM authorized service technician.
•The authorized service technician, the user and the person in charge of maintenance are obliged to
inform the manufacturer of all defects or damages which could affect the safety of the original
installation.
•The authorized service technician must check the surrounding area to ensure safe and hygienic use
is guaranteed.
•The machine component’s manufacturers are responsible for the parts supplied by them. The
buyer and user of this equipment are responsible for the personal use of the equipment.
•Do not expose the machine to elements as sun, rain etc.
•When the machine is idle and not in use for an extended period of time, it has to be emptied
completely and to be stored in an area with temperature above 4°C or 39 °F and under 44 °C (110
°F). These operations have to be effected by an authorized service technician.
•All maintenance must be carried out exclusively by ECM authorized service technicians.
•All spare parts must be original parts.
•Before carrying out any maintenance operations disconnect the machine from the mains.
•Never use a damaged electrical supply cable. It might cause fire or electrical shock. Do not place
objects on electrical supply cables, or pull, bend, twist, heat, damage or modify them.
•Do not let cord hang over edge of table or counter, or touch hot surfaces.
•Unplug the machine or turn off the main switch before cleaning the machines interior.
•Never use detergents of any kind.
•To reduce the risk of electrical shock, do not touch the machine with wet hands or wet or bare feet.
•The machine has to be installed with an efficient grounding/earthing system; the manufacturer
recommends a wooden platform on which the operator can stand.
Specifications subject to change without notice.
8

Raffaello Megaline Espresso Coffee Machine
•Do not allow liquids to get inside the coffee machine.
•Do not place heavy objects or climb on top of the coffee machine.
•Do not use aerosol sprays near the machine.
•Never touch coffee groups, boilers, metal pipes, spouts, steam and hot water valves and wands.
They are hot and could cause burns.
•Never operate the machine without water.
•The machine must be operated with soft clean drinking water. Use water filters if the water has a high mineral
content. Mineral deposits may obstruct the machine’s water circuit which may cause damage to the machine
and possibly personal injury.
The machine has to operate with soft water. The water hardness being between:
50 to 100 American degrees
7 to 14 German degrees
4 to 8 French degrees
•Whenever unattended from the operator, disconnect the power plug from the power outlet and
close the connection to the water mains.
Specifications subject to change without notice.
9

Raffaello Megaline Espresso Coffee Machine
Installation
This equipment is to be installed to comply with the applicable federal, state or local plumbing
codes having jurisdiction.
The manufacturer has tried to foresee all possible safety devices to ensure the safety of the users.
Anyhow different conditions of installation or of equipment moving can cause situations which cannot
be controlled or foreseen. Therefore it’s absolutely necessary to evaluate all remaining risks and to
care about the following:
•Installation and maintenance MUST be carried out by technicians and service providers
authorised by the manufacturer.
•Do not leave such packing items as plastic bags, Styrofoam, nails, etc. around because children or
other people could get hurt or damaged.
•Any defect or discrepancy has to be notified immediately to the authorised persons for installation
and maintenance.
•This machine is safe only when it has been correctly connected to an efficient grounding /earthing
system, implemented in accordance with the current safety regulations.
•All electrical connections have to be effected exclusively by authorised and qualified technicians.
Any improper cable connection is forbidden.
•Check the integrity of all components and do not install defective or damaged parts. Ask for
replacement.
•Check that capacity of the electrical system is sufficient for the maximum rated power shown on
the data rating plate of the machine.
•The customer has to protect the electrical feeding of the machine by means of a safety switch
system.
•The machine has to operate with clean soft drinking water. Building up of scale will seriously
damage this equipment and can also cause injuries.
•Before installation, the manufacturer strongly recommends to control the water supply system and
the electrical connections.
•Check the mains water pressure which should not exceed 3,5 bar (0,35 MPa); otherwise it is
recommended to install a water pressure reducing valve. The minimum water pressure should be
at least 1,5 Bar (0,15 MPa).
•The machine must be installed with an electrical switch with adequate fuses and safety devices.
•Check the efficiency of the main drain. Then proceed with the connection of the water drain hose
to the machine. Check again pouring an adequate quantity of water directly into machine’s drain
tray (located under the drip tray).
•This equipment must be installed on a flat, level and stable surface.
•Handle the machine with care.
•The machine has to be used with soft clean drinking water. If necessary install a water filter.
Specifications subject to change without notice.
10

Raffaello Megaline Espresso Coffee Machine
1. Electrical connection to the
mains
2. Electric switch
3. Electric cable
4. Machine’s main switch (with
Raffaello Megaline 2 groups)
5. Water inlet connection
6. Water discharge recipient
7. Water drain hose
8. Water hose to drain
9. Water valve
10. Water feed from the mains
11. Hose from water mains to water
softener (water softener on
special order)
12. Water softener (optional)
13. Hose from water softener to
water inlet
Voltage: Please refer to machine’s technical data plate
Rated power: Please check machine’s technical data plate
Temperature: The machine should not be operated with temperatures under
8°C (46°F) and over 44 °C (110 °F).
Water: The machine has to be used with soft clean drinking water.
Please install a water filter if necessary.
1 °dF ("French degree of hardness") = 0,56 German degrees
= 0,70 English degrees = 10 American degrees
American German French Water considered
50 - 100 7 - 14 4 - 8 Soft
Water pressure from mains: Maximum water inlet pressure is 3,5 bar (0,35 MPa). Please install
a pressure reducing valve if water pressure from the mains is higher.
Hydraulic connections: Water inlet 3/8” gas
Water drain hose: internal diameter 14 mm
Please make sure that there is at least an open area of at least 100 mm (3.9 inches) on each side and
behind the machine to allow adequate ventilation.
Specifications subject to change without notice.
11

Raffaello Megaline Espresso Coffee Machine
Description of parts
Fig. B
Raffaello Megaline A 2
(2 group machine with automatic portion control)
1Steam handle
2Control light: “Machine on”
3Control light: “Boiler autofill”
4Touch panel
5Cups tray
6Steam wand (Caution: can become hot. Risk of injury!)
7Hot water wand (Caution: can become hot. Risk of injury!)
8Double pressure gauge: shows pump and boiler pressure
9Steam handle
10 Steam wand (Steam wand (Steam wand (Caution: can become hot. Risk of injury!)
11 Filter holder (Steam wand (Caution: its metal parts can become hot. Risk of injury!)
12 Group (“Coffee brewing head”). Steam wand (Caution: can become hot. Risk of
injury!)
13 Drip tray (can be positioned to a low or high level depending on cups size in use)
14 Cups frame
15 Main switch
16 Group solenoid valve’s cover
Specifications subject to change without notice.
12

Raffaello Megaline Espresso Coffee Machine
Specifications subject to change without notice.
13
Fig. C
Raffaello Megaline A 1
(1 group machine with automatic portion control)
1 Steam handle
2 Control light: “Machine on”
3 Control light: “Boiler autofill”
4 Touch panel
5 Cups tray
6 Steam wand (Caution: can become hot. Risk of injury!)
7 Hot water wand (Caution: can become hot. Risk of injury!)
8 On Off switch (starts the machine but not the heating)
9 Heater on/off switch)
10 Double pressure gauge: shows pump and boiler pressure
11 Steam handle
12 Steam wand (Steam wand (Steam wand (Caution: can become hot. Risk of injury!)
13 Filter holder (Steam wand (Caution: its metal parts can become hot. Risk of injury!)
14 Group (“Coffee brewing head”). Steam wand (Caution: can become hot. Risk of injury!)
15 Drip tray (can be positioned to a low or high level depending on cups size in use)
16 Cups frame
17 Group solenoid valve’s cover

Raffaello Megaline Espresso Coffee Machine
Fig. D
Touch panel of Raffaello Megaline A 1 and A 2
Programming product keys on Raffaello Megaline A 1 and Raffaello Megaline A 2
Raffaello Megaline espresso machines allow automatic portion control of coffee and hot water.
Automatic portion control means that all coffee and hot water product keys (“buttons”) dispense a
programmed quantity of coffee or hot water whenever you press them. You do just start (pushing the
key) the dispensing and the machine will stop the process by itself.
Programming of the product keys is typically done when installing the equipment. Programming can
be done anyhow at any time.
How to proceed:
Automatic
coffee portion
control keys
Program and semi-
auto portion control
key
Automatic hot
water portion
control key
1. Push “P” key (program and semi-automatic portion control key) and keep it pressed until the
LEDs of all keys start flashing.
Now press and release the product key to be programmed. The LED of this product key will be on
(but not flashing), while all the other LEDS are off.
2. The product (coffee or hot water) will be dispensed.
3. When you’re done, press the product key you’re programming again. The dispensing is stopped
and the LED of this key is off while the LEDs on the other keys turn on and flash. From this
moment whenever this programmed product key is pushed the preset quantity will be dispensed.
Specifications subject to change without notice.
14
2 group machines: once the left hand (seen from operator) group has been programmed,
automatically the same portions per key are programmed on the other group. You can of course
proceed to a dedicated programming of second group. This might be useful if you need two different
hot water portions. So you can set a different hot water portion on each of the two hot water buttons
(one on every touchpanel).
We strongly recommend doing the programming under working conditions.
Example: when programming the portion key for product key “1 small espresso” (ristretto), put the
one cup filter basket into the filter holder, fill it with the adequate quantity of correctly ground coffee
and tighten the filter holder firmly into the group. Place a cup under the group.
Now proceed programming this product keyt as explained above.

Raffaello Megaline Espresso Coffee Machine
Description of parts
Fig. E
Raffaello Megaline S 2
(2 group machine with semi-automatic portion control)
1 Steam handle
2 Control light: “Machine on”
3 Control light: “Boiler autofill”
4 Touch panel
5 Cups tray
6 Steam wand (Caution: can become hot. Risk of injury!)
7 Hot water wand (Caution: can become hot. Risk of injury!)
8 Double pressure gauge: shows pump and boiler pressure
9 Steam handle
10 Steam wand (Steam wand (Steam wand (Caution: can become hot. Risk of injury!)
11 Filter holder (Steam wand (Caution: its metal parts can become hot. Risk of injury!)
12 Group (“Coffee brewing head”). Steam wand (Caution: can become hot. Risk of injury!)
13 Drip tray (can be positioned to a low or high level depending on cups size in use)
14 Cups frame
15 Main switch
16 Group solenoid valve’s cover
Specifications subject to change without notice.
15

Raffaello Megaline Espresso Coffee Machine
Fig. F
Raffaello Megaline S 1
(1 group machine with semi-automatic portion control)
1 Steam handle
2 Control light: “Machine on”
3 Control light: “Boiler autofill”
4 Touch panel
5 Cups tray
6 Steam wand (Caution: can become hot. Risk of injury!)
7 Hot water wand (Caution: can become hot. Risk of injury!)
8 On Off switch (starts the machine but not the heating)
9 Heater on/off switch)
10 Double pressure gauge: shows pump and boiler pressure
11 Steam handle
12 Steam wand (Steam wand (Steam wand (Caution: can become hot. Risk of injury!)
13 Filter holder (Steam wand (Caution: its metal parts can become hot. Risk of injury!)
14 Group (“Coffee brewing head”). Steam wand (Caution: can become hot. Risk of injury!)
15 Drip tray (can be positioned to a low or high level depending on cups size in use)
16 Cups frame
17 Group solenoid valve’s cover
Specifications subject to change without notice.
16

Raffaello Megaline Espresso Coffee Machine
Specifications subject to change without notice.
17
Fig. G
Touch panel of Raffaello Megaline S1 and S2
Semiautomatic portion control key: press to start coffee dispensing and press again to stop it.
Hot water key: press to start hot water dispensing and press again to stop it.
Hot water key
Semi-automatic
portion control
key

Raffaello Megaline Espresso Coffee Machine
Start up
We assume that the equipment has been properly installed according to local law and jurisdiction by
an ECM authorized and qualified technician and is ready for use.
Please proceed as follows:
One group Raffaello Megaline machines (Raffaello Megaline A 1 and S 1)
On/off switch on Raffaello Megaline A1 and S 1
Heater switch on Raffaello A 1 and S 1
Double pressare gauge. Shows boiler pressare
and pump pressare
1. Turn on/off switch on. The control lamps “machine on” (fig. A-2) and “boiler filling”
(fig. A-3) will light. You’ll hear the pump filling automatically the machine’s boiler. When
control lamp “boiler filling” (fig. A-3) switches off, the boiler is filled.
2. Now turn the heater switch on. Wait till the boiler pressure shown on the machine’s pressure
gauge (see above) has reached app. 0,9 bar. Now open one of the steam valves for a couple of
seconds and close it again. The boiler pressure shown will decrease. Please wait until machine
reaches again app. 0,9-1,1 bar. Now the equipment is ready to operate.
Specifications subject to change without notice.
18

Raffaello Megaline Espresso Coffee Machine
Two group Raffaello Megaline machines (Raffaello Megaline A2 and S2
This is the main switch on Raffello 2 group machines.
Double pressare gauge. Shows boiler pressare
and pump pressare
1. Turn main switch from position “0” (machine off) to position 1 (machine on but not
heating up).
The control lamps “machine on” (fig. A-2) and “boiler filling” (fig. A-3) will light. You’ll
hear the pump filling automatically the machine’s boiler. When control lamp “boiler
filling” (fig. A-3) switches off, the boiler is filled.
Specifications subject to change without notice.
19
2. Now turn main switch to position “2”. The heater will start heating. Wait till the boiler
pressure shown on the machine’s pressure gauge (see above) has reached app. 0,9 bar.
Now open one of the steam valves for a couple of seconds and close it again. The boiler
pressure shown will decrease. Please wait until machine reaches again app. 0,9-1,1 bar.
Now the equipment is ready to operate.

Raffaello Megaline Espresso Coffee Machine
Brewing ONE cup of coffee
1. Use one cup filter handle (with 1 spout) and the one cup filter basket.
2. Position the metal
one cup filter basket firmly inside the filter holder
3. Pour
one measuring spoon (app. 6,5-7 g) of ground espresso coffee into the filter basket
4. Tamp the ground coffee gently.
5. Tighten the filter holder firmly into the brewing head (Fig. A-12).
6. Position one cup under the filter holder spout.
7. Push the “P” button for semi-automatic dispensing or one of the automatic coffee portion
control keys to start dispensing the coffee. With the automatic coffee portion control keys the
dispensing will stop automatically while when brewing with “P” button you need to press the
button again to stop dispensing when you’re done.
8. Remove and serve the cup.
9. Remove the filter holder from the brewing head, knock the used coffee grounds out and clean
the border of the filter basket (inside the filter holder) with a clean non abrasive damp cloth.
This will increase the lifetime of the group gaskets.
Caution: the metal parts of the filter holder and the basket can become very hot.
10. Tighten the filter holder with the basket again into the group. This will keep the filter holder
warm.
Automatic
coffee portion
control keys
Program and semi-
auto portion control
key
Automatic hot
water portion
control key
Semi-automatic
portion control
key
Hot water key
Specifications subject to change without notice.
20
