1537L 15" LCD Open-Frame Touchmonitor
Space- aving de ign ideal for kio k, gaming, and light indu trial application
The Elo 1537L open-frame LCD touchmonitor complements
the Elo TouchSystems expanding family of touch solutions
for kiosk information systems, gaming and amusement,
and light industrial shop-floor automation. This compact
touchmonitor is “designed for touch,” with proven Elo
expertise and reliability built in. An integrated precision
mini-bezel seals the touchscreen against dirt, dust and
liquids, which simplifies integration into the final enclosure.
Long-lasting product availability can be expected as the
design and tooling is controlled by Elo specifications,
allowing future-generation panels to be phased in without
external changes.
The 1537L is available with a choice of industry-leading
Elo touch technologies: AccuTouch five-wire resistive,
APR (acoustic pulse recognition), CarrollTouch infrared,
IntelliTouch surface acoustic wave, SecureTouch vandal-
resistant surface wave and surface capacitive. A dual
serial/USB touch interface is available on most models,
with only a USB interface on the APR monitor. Worldwide
agency approvals cover the whole monitor, which is
developed, built, serviced and supported by a true single-
source supplier. The 1537L open-frame LCD touchmonitor
provides an economical solution for system integrators
and VARs.
Benefits
■Elo reliability and quality at an economical price point
■“Designed for touch” from the ground up
■Choice of Elo touch technologies: AccuTouch, APR,
CarrollTouch, IntelliTouch, SecureTouch and surface
capacitive
■Touchscreen sealed against dirt, dust and liquids
■Compact and easy to integrate with mounting from
sides or top and bottom; also a VESA mount option
■Dual serial/USB touch interface on most models;
APR is USB only
■Worldwide agency approvals
■Three year standard warranty
Applications
■Kiosk information systems
■Gaming and amusement
■Light industrial shop-floor automation

1537L 15" LCD Rear-Mount Touchmonitor Specification
Case/Bezel color Silver minibezel
Display type Active matrix TFT LCD
Display size 15.0” diagonal
Aspect ratio 4 x 3
Useful screen area orizontal: 12” (304 mm); Vertical: 9” (228 mm)
Monitor dimensions Width: 13.2” (336 mm)
eight: 10.4” (264 mm)
Depth: 1.6” (41 mm)
Dimensional drawing number MS600159
Optimal (native) resolution 1024 x 768
Other supported resolutions 1024 x 768 at 60, 65 (Sun), 70, or 75 z; 832 x 624 at 75 z (Mac); 800 x 600 at 56, 60,
72, or 75 z; 720 x 400 at 70 z; 720 x 350 at 70 z; 640 x 480 at 60, 66 (Mac), 72,
or 75 z
Colors 16.2 million colors with dithering
Brightness (typical) LCD panel: 250 cd/m2
LCD panel with touchscreen AccuTouch: 200 cd/m2
(typical) Acoustic Pulse Recognition: 230 cd/m2
CarrollTouch: 230 cd/m2
Surface Capacitive: 213 cd/m2
Response time 14.5 msec (typical)
Viewing angle (from center) orizontal (left / right): 140° total;
Vertical (up /down): 115° total
Contrast ratio (typical) 500:1
Input video format RGB analog
Input sync format Separate & V sync, composite sync, and sync-on-green
Input video signal connector Mini D-Sub 15-Pin VGA type
Scanning frequency orizontal: 31.5 - 60.2 k z; Vertical: 56.3 - 75 z
Power dissipation 30 W max.
Power supply Type: external brick; Input (line) voltage: 100-240 VAC, 50/60 z;
Monitor input voltage, current: +12 VDC +/- 5% at 2.5A maximum
Temperature Operating: 0°C to 40°C; Storage: -20°C to 60°C
umidity Operating: 20% to 80% (non-condensing); Storage: 10% to 90% (non-condensing)
Backlight lamp life Typical 30,000 hours to half brightness
Monitor MTBF 50,000 hours demonstrated
(excluding lamps)
Weight (approx.) Actual: 6.6 lbs (3.0 kg); Shipping: 9.7 lbs (4.4 kg)
Warranty Touchmonitor: 3 years in U.S.
User’s controls OSD buttons: menu, up, down, select, power; OSD: contrast, brightness, /V position,
RGB (color temp), clock, phase, recall, language (English, German, Spanish, Japanese,
French); OSD disable/enable: power, OSD menu
Mounting options 100 mm or 75 mm VESA mount; open-frame with brackets; mounting brackets included
Agency Certification UL, cUL , FCC, CE, TÜV-GS, VCCI, IC, C-Tick
Tyc Electr nics reserves the right t change r update, with ut n tice, any inf rmati n c ntained herein; t change,
with ut n tice, the design, c nstructi n, materials, pr cessing r specificati ns f any pr ducts; and t disc ntinue r
limit pr ducti n r distributi n f any pr ducts.
AccuT uch, Ac ustic Pulse Rec gniti n, El T uchSystems, IntelliT uch, TE L g , and Tyc Electr nics are trademarks.
C pyright 2008 Tyc Electr nics C rp rati n 6/08
