Elo TouchSystems 2243L User manual

Elo TouchSystems
2243L, 2244L Touchmonitor
User Manual
User Manual – 2243L, 2244L
SW601560 Rev C - Page 1 of 20

User Manual – 2243L, 2244L
SW601560 Rev C - Page 2 of 20
Copyright © 2011 Tyco Electronics Corporation, a TE Connectivity Ltd. Company.
All Rights Reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or
translated into any language or computer language, in any form or by any means, including, but not
limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission
of Tyco Electronics.
Disclaimer
The information in this document is subject to change without notice. Tyco Electronics Corporation and
its Affiliates in the TE Touch Solutions business unit in the TE Connectivity Ltd. family of companies
(collectively "TE") makes no representations or warranties with respect to the contents herein, and
specifically disclaims any implied warranties of merchantability or fitness for a particular purpose. TE
reserves the right to revise this publication and to make changes from time to time in the content
hereof without obligation of TE to notify any person of such revisions or changes.
Trademark Acknowledgments
Elo TouchSystems, IntelliTouch, TE Connectivity, TE connectivity (logo) and TE (logo) are trademarks
of the TE Connectivity Ltd. family of companies. Windows is a trademark of the Microsoft group of
companies. Other product names mentioned herein may be trademarks or registered trademarks of
their respective companies. Tyco Electronics claims no interest in trademarks other than its own.

User Manual – 2243L, 2244L
SW601560 Rev C - Page 3 of 20
Table of Contents
Chapter 1 - Introduction ........................................................................... 4
Chapter 2 – Installation............................................................................. 5
Chapter 3 – Mounting................................................................................ 9
Chapter 4 – Operation............................................................................... 10
Chapter 5 – Technical Support............................................................... 14
Chapter 6 – Safety & Maintenance........................................................ 15
Chapter 7 – Regulatory Information..................................................... 16
Chapter 8 – Warranty Information......................................................... 19

User Manual – 2243L, 2244L
SW601560 Rev C - Page 4 of 20
Chapter 1 - Introduction
Product Description
Your new touchmonitor combines Elo TouchSystems’ reliable performance with the latest
developments in touch technology and display design. This combination of features creates a
natural flow of information between a user and the touchmonitor.
This touchmonitor incorporates a 24-bit color, active matrix thin-film-transistor LCD panel to
provide high quality display performance. Its Full HD resolution of 1920x1080 is suitable for
displaying graphics and images. Its LED backlight significantly reduces power consumption and
eliminates mercury (compared to CCFL-backlit panels). Other features that enhance this LCD
monitor’s performance are Plug & Play compatibility and on-screen display (OSD) controls.
Precautions
Follow all warnings, precautions and maintenance as recommended in this user manual to
maximize the life of your unit and prevent risks to user safety. See the Safety & Maintenance
chapter for more information.
This manual contains information that is important for the proper setup and maintenance of the
unit. Before setting up and powering on your new touchmonitor, read through this manual,
especially the Installation, Mounting, and Operation chapters.

Chapter 2 –Installation
Unpacking the Touchmonitor
Open the carton and verify the following items are present:
Touchmonitor with protective sheet for its face
Elo TouchTools CD & User Manuals CD
Quick Install Guide
Japanese language regulatory information pamphlet
DVI cable
VGA cable
USB cable
Mounting brackets
Connector Panel & Interfaces
Touchmonitor Connections
1. Connect the DVI or VGA video cables between the monitor’s DVI/VGAinput connectors and
your DVI/VGA video source. Tighten the video cable’s screws for best performance.
2. Connect the USB touch cable between the monitor’s USB connector & your PC’s USB port.
3. Connect a 12VDC power supply to the monitor’s input power jack.
5. The touchmonitor ships in an ON state, video should be displayed on your monitor already.
User Manual – 2243L, 2244L
SW601560 Rev C - Page 5 of 20

Installing the Touch Technology Software Drivers
Some software installation is required for your touchmonitor to work with your computer.
The drivers for the Windows 7, XP, Vista, WePOS, and 32-bit Server 2003 and 2008 operating
systems are provided with your touchmonitor on a CD.
Visit the Elo TouchSystems website www.elotouch.com for:
The most up-to-date touch driver versions
Additional touch driver information
Detailed touch driver installation guides
Touch drivers for other operating systems
Insert the Elo TouchTools CD into your computer’s CD-ROM drive. The CD should
automatically run the Elo TouchTools application. Select “Install Driver for This computer”:
User Manual – 2243L, 2244L
SW601560 Rev C - Page 6 of 20

For Windows XP, Vista, Server 2003, Server 2008, and WEPOS installations, install the “USB
Touchscreen Drivers” when prompted:
For Windows 7 installations, check the “Install driver” box under “Elo USB Interfaces – Other
Touchscreens”
After accepting the end-user license agreement, the drivers will finish installing.
Reboot your computer after the install is complete.
User Manual – 2243L, 2244L
SW601560 Rev C - Page 7 of 20

Chapter 3 – Mounting
General Mounting Information
The OSD text can be rotated through the OSD menu to better suit your mounting orientation.
Side Bracket Mount
Threaded holes are provided on the sides of the monitor for mounting using the provided
brackets.
User Manual – 2243L, 2244L
SW601560 Rev C - Page 8 of 20

User Manual – 2243L, 2244L
SW601560 Rev C - Page 9 of 20
Chapter 4 – Operation
Power
To turn the touchmonitor on or off, press the touchmonitor power button once.
The Power Status LED on the OSD controller functions according to the following table:
TouchMonitor/Computer Module status LED status
OFF OFF
SLEEP PULSING
ON ON
The system consumes low power when in SLEEP and OFF modes. For detailed power
consumption specifications, refer to technical specifications on the Elo website
http://www.elotouch.com
Touching the screen will bring the attached host PC out of SLEEP mode (similar to moving the
mouse or pressing a keyboard key).
To improve reliability and reduce wasteful power consumption, disconnect the AC power cable
from the power adapter when long periods of disuse are planned.
APR Touch Technology
For full APR touch functionality, the input video image should be fully scaled to the display’s
native resolution.
Your APR Touchmonitor is factory-calibrated and will never need manual calibration.

The APR performance can be customized to better suit your application. Access the “Set APR
Preference” window from the Mode tab of the Elo APR driver control panel:
Select the usage type best suited for your application, then press Apply.
General: No particular optimization (default)
Best Signature: APR performance optimized for signature capture applications
Point of Sale:APR performance optimized for Point-of-Sale applications
Gaming: APR performance optimized for gaming applications
User Manual – 2243L, 2244L
SW601560 Rev C - Page 10 of 20
