Enabling Devices 4551 User manual

For Technical Support:
For Technical Support:For Technical Support:
For Technical Support:
Call our Technical Service Department
Monday through Friday, 9 a.m. to 5 p.m. (EST
800-832-8697
[e-mail]
Te
TeTe
Textured Tunes
xtured Tunesxtured Tunes
xtured Tunes Lights, Music &
Lights, Music & Lights, Music &
Lights, Music &
Vibration
VibrationVibration
Vibration #4551
#4551#4551
#4551
USER’S UIDE
USER’S UIDEUSER’S UIDE
USER’S UIDE
50 Broadway
Hawthorne, NY 10532
Tel. [phone] / Fax [phone]
Toll Free 800.832.8697
www.enablingdevices.com

With two stimulating textures, the two interchangeable plates on our
Textured Tunes are perfect for hands-on sensory exploration. Size: 9¾"D
x 6"H Weight: 3¼ lbs. Battery: 4 AA and 2 C
Operation:
Operation:Operation:
Operation:
1. Textured Tunes requires 4 AA & C size batteries. Use alkaline
batteries only (e.g. Duracell or Energizer brand . Do not use
rechargeable batteries or any other type of batteries because they
supply lower voltage and the unit will not perform properly. Never mix
old and new batteries together or different brands or types together.
2. The battery compartments are located on the underside of the unit.
To install the batteries, turn the unit over. You will need to first
remove the Lazy Susan Base to access the 2 AA battery
compartments. The Lazy Susan is held in place by two Phillips head
screws. Rotate the metal base until the two screws are visible (see
Fig. 1 . Remove the screws and lift the Lazy Susan off. Next remove
the small Phillips head screws from the black battery cases. Next
slide the covers off.
3. Install the batteries, following proper (+ & (- battery polarity. Replace
covers and screws. Replace the Lazy Susan and secure with the
screws. Mounted on a Lazy Susan base allows users the ability to
spin the Textured Tunes for easy access to all of the textures. Turn
the On/Off/Volume knob and set to an audible level. Vibration can
also be set to On/Off using the toggle switch. There is also an On/Off
switch for the lights. The On/Off slide switch for the lights is located
on the front side of the C battery case.
4. The Textured Tunes plays six different melodies. When you push
anywhere on one of the four interchangeable textured tops it will play
one of six melodies while the LED lights flash and illuminate. The
melodies will play in its entirety; once the music stops another
activation of the textured top will play the next melody.
Changing
ChangingChanging
Changing the Textured T
the Textured Tthe Textured T
the Textured Tops:
ops:ops:
ops:
5. The textured tops are removable to give the user different textures
and also for easy cleaning. With one hand hold down on the black
base and lift up on the textured top’s yellow disk. Please Note: Do not
remove any of the tops by the top’s themselves. Only remove them by
pulling on their yellow disc plate. The textured tops are held in place
by Velcro. To replace a top simply press in firmly down on the base to
insure a strong hold.
Troubleshooting:
Troubleshooting:Troubleshooting:
Troubleshooting:
Problem:
Problem:Problem:
Problem: The units sounds melodies or lights fails to operate, or operates
incorrectly.
Action:
Action:Action:
Action: Check all batteries making sure they are installed with proper (+
& (- battery polarity.
Action:
Action:Action:
Action: Check that all batteries are fresh, if not replace with new
batteries.
Problem:
Problem:Problem:
Problem: top plate seems to be stuck / jammed.
Action:
Action: Action:
Action: visually inspect the switch plate area underneath, making sure
there is nothing obstructing or blocking the plate from moving freely.
Care of Unit:
Care of Unit:Care of Unit:
Care of Unit:
The Textured Tunes can be wiped clean with any household multi-
purpose cleaner or disinfectant. We recommend Simple Green, which is a
non toxic biodegradable all-purpose cleaner. Use caution not to get
cleaning fluid or any liquid under the plate areas.
Do not submerge
Do not submergeDo not submerge
Do not submerge the unit, as it will damage the electrical components.
Do not use abrasive cleaners,
Do not use abrasive cleaners,Do not use abrasive cleaners,
Do not use abrasive cleaners, as they will scratch the surface of the unit.
Rev
Rev Rev
Rev 10/6/17
10/6/1710/6/17
10/6/17
