Endress+Hauser Analytik Jena TOPwave User manual

Operating Manual
TOPwave
Microwave System for Pressure Digestion

Analytik Jena AG
Konrad-Zuse-Str.1
07745 Jena Germany
Phone + 49 3641 77 70
Fax + 49 3641 77 9279
E-mail [e-mail]
Analytik Jena AG
Konrad-Zuse-Str. 1
07745 Jena Deutschland
Telefon + 49 3641 77 7407
Fax + 49 3641 77 7449
E-mail [e-mail]
Follow these instructions for proper and safe use.
Keep for future reference.
http://www.analytik-jena.com
02.19
Analytik Jena AG
© Copyright 2019, Analytik Jena AG
Manufacturer
Service
General Information
Edition
Implementation of the
Technical Documentation

TOPwave Contents
3
Contents
1Basic information............................................................................................................. 5
1.1 User manual notes ...................................................................................................................5
1.2 Intended Use.............................................................................................................................6
1.3 Warranty and liability..............................................................................................................7
2Safety instructions ........................................................................................................... 8
2.1 General notes ...........................................................................................................................8
2.1.1 Safety information on the unit ...............................................................................................8
2.2 Qualified Users .........................................................................................................................9
2.3 Safety instructions, transport and commissioning...............................................................9
2.4 General Safety Information.....................................................................................................9
2.5 Safety Equipment / Emergency........................................................................................... 11
3Installation and Setup ................................................................................................... 13
3.1 Ambient Conditions .............................................................................................................. 13
4Device Description ......................................................................................................... 14
4.1 Basic Unit ............................................................................................................................... 14
4.2 Temperature Control ............................................................................................................ 17
4.3 Pressure Monitoring (Option)............................................................................................. 17
4.4 Pressure Vessels and Rotor System .................................................................................... 18
5Installation and Setup ................................................................................................... 21
5.1 Unpacking .............................................................................................................................. 21
5.2 Installing TOPwave............................................................................................................... 21
5.2.1 Selecting Setup Parameters................................................................................................. 24
6Operating........................................................................................................................ 27
6.1 Setup Methods ...................................................................................................................... 27
6.1.1 General Notes........................................................................................................................ 27
6.1.2 Control Unit............................................................................................................................ 28
6.1.3 Selecting/modifying Applications ....................................................................................... 29
6.1.4 Developing new Applications .............................................................................................. 32
6.2 Performing a Digestion Procedure...................................................................................... 33
6.3 Sample Loading..................................................................................................................... 38
6.3.1 Handling of PM 40, PM 60 and PL 100 Pressure Vessels............................................... 38
6.3.2 Handling of pressure vessels QX 20 / QX 22..................................................................... 42
6.3.3 Handling of pressure vessels CX 100.................................................................................. 43
6.4 Sample Removal.................................................................................................................... 45
6.5 Digestion Reports.................................................................................................................. 47
6.6 Data export using USB.......................................................................................................... 49
6.7 Evaporating Unit (Option) ................................................................................................... 51
6.7.1 Installation and Commissioning.......................................................................................... 52
6.7.2 Operating ............................................................................................................................... 53
6.8 PC Control (Option) .............................................................................................................. 55
6.8.1 Safety information ................................................................................................................ 55
6.8.2 Security settings .................................................................................................................... 58
6.8.3 PC Control via Web visualization......................................................................................... 59
6.8.4 Data transfer.......................................................................................................................... 60
7Care ................................................................................................................................. 61
7.1 Safety information ................................................................................................................ 61
7.2 Cleaning ................................................................................................................................. 61
8Maintenance .................................................................................................................. 65
8.1 Aligning Pressure measurement......................................................................................... 65
8.2 Output power measurement ............................................................................................... 66
8.3 Troubleshooting.................................................................................................................... 67

Contents TOPwave
4
8.4 Fuse replacement ..................................................................................................................68
9Information on Disposal ................................................................................................ 70
10 Specification ................................................................................................................... 71
10.1 Technical Data .......................................................................................................................71
10.2 Guidelines and standards .....................................................................................................73
11 Appendix......................................................................................................................... 74
11.1 Tips and Tricks.......................................................................................................................74
11.1.1 Small sample quantity...........................................................................................................74
11.1.2 Multiple samples per vessels................................................................................................74
11.1.3 Higher sample throughput ...................................................................................................74
11.1.4 Cooling down samples ..........................................................................................................75
11.1.5 Dilating Sealing lips...............................................................................................................75
11.1.6 Rupture discs and locking lids ..............................................................................................75
11.1.7 Weighing cup .........................................................................................................................76
11.2 Applications............................................................................................................................76
11.3 Positioning the vessels in the rotors ...................................................................................77
11.4 Conversation of units ............................................................................................................78
11.5 Abbreviation...........................................................................................................................79

TOPwave Basic information
5
1Basic information
1.1 User manual notes
The user manual describes the TOPwave microwave digestion system.
The TOPwave is intended for operation by qualified specialist personnel observing this
user manual.
The user manual informs about the design and function of the TOPwave and provides
the necessary know-how for the safe handling of the device and its components to per-
sonnel familiar with analysis. The user manual further includes notes on the mainte-
nance and service of the equipment and potential causes and remedies of any faults.
Instructions for actions which occur in chronological order are numbered and combined
in action units.
Warnings are indicated by a warning triangle and signal word. The type, source and
consequences of the danger are stated together with notes on preventing the danger.
The meaning of the signal words used is explained in section "Safety instructions" p. 8.
The elements of the control and analysis program are indicated as follows:
Program terms are identified with SMALL CAPS (e.g., Menu FILE).
Buttons are shown by square brackets (e.g., [OK])
Menu items are separated by arrows (e.g.FILE OPEN)
The user manual uses the following symbols and signal words to indicate hazards or in-
structions. The warnings are always placed before an action.
WARNING
Means that failure to follow
the safety instructions may cause severe personal injury,
death or severe property damage.
CAUTION
Means that failure to follow the
safety instructions may cause personal injury or some
property damage.
NOTICE
Provides indications of
potential material and environmental damage.
Content
Conventions
Symbols and signal words

Basic information TOPwave
6
The following signal signs are used in the manual!
WARNING
Warning of dangerous explosive substances!
WARNING
Warning of dangerous electrical voltage
!
1.2 Intended Use
WARNING
The unit is
not designed for extraction and metabolization procedures employing orga-
nic solvents.
WARNING
Since sample composition is generally not precisely defined, a certain residual risk exists
when performing pressure digestion processes. Careful working prac
tices and conscious
compliance with safety regulations can only minimize this risk, not totally eliminate it.
Due to different degrees of mixing, even identical samples can exhibit totally different
behaviors during the course of the reaction!
Please stric
tly comply with the operating instructions, particularly when handling the
pressure vessels, that is, when removing and opening the vessels. Incorrect handling of
the hot, pressurized vessels can result in injuries from escaping acid vapors!
The TOPwave microwave digestion system has been designed to perform chemical di-
gestion procedures under extreme pressure and temperature conditions in chemical la-
boratories. Digestion is understood to mean the decomposition of a solid material by
means of a suitable digestion reagent at increased temperature in a vessel that is per-
meable with regard to microwaves. The digestion solutions are directly heated through
the absorption of the microwave radiation by the polar digestion reagent, which gene-
rally also contains ionic components.
Digestion reagents used include nitric acid (65 %), hydrochloric acid, hydrofluoric acid,
phosphoric acid, and sulfuric acid, as well as mixtures of these acids. The maximum ini-
tial weight for organic compounds depends on the digestion vessel being used and the
sample’s carbon content, must always be observed. The use of organic solvents is strictly
prohibited in microwaves since the spontaneous combustion of any solvent vapors that
escape into the oven chamber cannot be precluded.
Heating in the pressure vessel results in digestion temperatures in excess of 200 °C
(392 °F). The TOPwave has been specially developed for sample preparation for AAS
and ICP spectroscopy procedures. Very temperature spikes >280 °C (>536 °F) such as can
occasionally occur during the course of exothermic reactions can result in irreversible da-
mage to the Teflon vessels.
Signal signs

TOPwave Basic information
7
Since such scorching cannot always be avoided, even with optimum microwave power
regulation, damage of this kind is excluded from the warranty! When quartz glass inse-
rts are employed, the greatest care must be taken when handling the glass as even the
slightest amount of damage to the surface can greatly diminish surface strength. For
this reason, glass components are excluded from the warranty!
Adapters for evaporating and concentrating digestion solutions are optionally available
for all vessel types, except PM 40.
Qualified handling and, possibly, proper transport, storage, set-up, and use, as well as
conscientious maintenance are all prerequisites for the trouble-free and safe operation
of the TOPwave microwave digestion system.
The system may only be used within the context of data and applications specified in
this documentation and the associated user manuals.
The digestion system may only be used:
intended
in a technically flawless condition
without unauthorized alterations or modifications
by qualified users
Please also observe all regulations published by professional/trade associations, the
TÜV, VDE regulations, or corresponding national regulations.
1.3 Warranty and liability
The warranty duration and liability comply with the legal requirements and the provisi-
ons in the general terms and conditions of Analytik Jena.
Deviations from the intended use described in this user manual result in limitations of
warranty and liability during a damage event. Damage to wearing parts is not included
in the warranty.
Warranty and liability claims are excluded for personal injury and property damage due
to one or several of the following causes:
use of the TOPwave other than intended
improper commissioning, operation and servicing of the device
modifications of the equipment without prior consultation with Analytik Jena
operation of the device with faulty safety equipment or improperly fitted safety and
protection equipment
inadequate monitoring of the equipment components subject to wear
use of other than original spare parts, wearing parts or consumables
improper repairs
faults due to the non-observance of this user manual

Safety instructions TOPwave
8
2Safety instructions
2.1 General notes
For your own safety and to ensure error-free operation of the TOPwave, please read this
chapter carefully before using the appliance.
Observe all safety notes listed in this user manual and all messages and notes displayed
by the control and analysis program on the monitor.
Besides the safety instructions in this user manual and the local safety regulations appli-
cable to the operation of the device, the general applicable regulations regarding acci-
dent prevention, occupational health and safety and environmental protection must be
observed and complied with.
References to potential dangers do not replace the work protection regulations which
must be observed.
2.1.1 Safety information on the unit
Warnings and notice symbols have been attached to the TOPwave which must always
be observed.
Damaged or missing warnings and notice symbols can cause incorrect actions leading to
personal injury or material damage! The symbol labels must not be removed or wetted
with methanol! Damaged symbol labels must be replaced without delay!
Danger high Voltage!
This label is located on the right side of the device.
Attention! Pressurized vessel - only open carefully after cooling down.
This label is located on upper edge of the oven chamber.
Danger note
Caution note

TOPwave Safety instructions
9
Notice symbol Meaning Remark
Prohibited for persons
with heart pacemakers
This label is located on the right side of
the device
China RoHS Label The TOPwave contains restricted sub-
stances (according to China RoHS direc-
tive SJ/T 11363-2011). Analytik Jena
AG guarantees, that those hazardous
substances may not leak out during the
next 25 years when the device is used
in accordance with its intended pur-
pose.
2.2 Qualified Users
Only Qualified Users should operate this equipment. Qualified Users with respect to this
manual are relevantly schooled and trained specialists with a basic knowledge of che-
mistry and technology. They should be trained in the relevant legal regulations for
handling of chemicals.
Prohibited for persons with heart pacemakers!
WARNING
The microwave device must not be operated by persons with heart pacemakers.
2.3 Safety instructions, transport and commissioning
Transport always with two persons.
WARNING
Two persons should remove the microwave system from its packaging and place it on a
lab bench.
2.4 General Safety Information
Performing microwave digestion procedures involves taking into account various safety
precautions which go beyond those for general laboratory practices. The following gene-
ral safety information should therefore be read carefully prior to using the system, and
should be observed at all times.
The following information must be complied with when working with the associated di-
gestion vessels!
We can assume no liability for damages resulting from improper handling of a failure to
comply with this information.
Notice symbol
Heart pacemaker
Transport

Safety instructions TOPwave
10
Do not use per-chloric acid.
No organic solvents (alcohols, hydrocarbons, etc.) may be placed in the pressure vessels
or the microwave.
WARNING
Highly reactive substances which spontaneously react at higher temperatures or in the
presence of oxidizing agents or which may be nitrated and are potentially explosive may
not be digested in the microwave. Examples of such substances include: explosives
(TNT, etc.), perchlorates, ether, pyrophoric substances, etc.
Use only digestion vessels and spare parts authorized by Analytik Jena for use with the
TOPwave.
These can be obtained either from your local dealer or directly from Analytik Jena.
WARNING
Always wear safety glasses/goggles and protective gloves when working with the pres-
sure vessels!
Note any changes in the appearance of the p
ressure vessel which could indi
cate possible
material fatigue, e.g., deformation of the vessel, difficulty screwing on lids, etc. even
when the vessel is cold and not under pressure. All such vessels should be immediately
returned to
Analytik Jena for inspection.
Never attempt to use force to open the vessels. Never use tools to open the vessels!
The pressure vessels are equipped with a rupture disc which produces a spontaneous
pressure release upwards through the screw
-on tube connections in case of excessive
vess
el pressure. In some cases, such a spontaneous pressure release may occur after the
vessel has been removed from the microwave oven.
Hot gases and vapors may be released from the digestion vessel when it is opened! Al-
ways make sure the vent opening on pressure vessels faces away from both yourself and
other individuals!!
Only open the digestion vessel under a fume hood or other exhaust system. Particular
care is required when working with hydrofluoric acid (HF). Observe all relevant data
sheets and safety i
nstructions!
Never use more than one rupture disc per vessel!
Only use rupture discs which are designed for the respective vessel!
Always wear eye protection!
WARNING
Always wear safety glasses/goggles and protective gloves during work
which may in-
volve contact with chemicals, that is, when working with acids, pressure vessels, during
cleaning, etc.!
Explosion hazard
Pressure vessels
Protection

TOPwave Safety instructions
11
The unit employs high voltage and generates microwave radiation!
WARNING
The
TOPwave must always be carefully connected to a grounded conductor. Provided
the wall outlet used is equipped with a ground connection, the supplied power cord will
ensure proper connection. If it is necessary to use an extension cord to connect the sys-
tem to the power supply, o
nly a three-wire cord with a ground connection may be
employed.
The unit should not be set up near any devices which are sensitive to electromagnetic
radiation. If necessary, a warning sign or label indicating “Caution, Microwave Emissions”
should be appli
ed or attached to the unit. Should there be any suspicion or indication of
increased levels of microwave radiation, please immediately inform the Service Depart-
ment at Analytik Jena AG.
The housing cover may only be removed by authorized trained personnel!
The unit must be disconnected from the mains power supply.
Renew vessels!
WARNING
Renew the vessels after around 10,000 digestions to maintain reliable operating condi-
tions and to prevent negative influences on your analysis results
(e.g. memory effects
etc.).
Analytik Jena includes its digestion vessels in the warranty coverage. Nevertheless
all of the vessels are subject to a certain aging process, which also depends on the type
and frequency of the application. Typically the servi
ce life is 10,000 digestion processes
or at least 3 years.
2.5 Safety Equipment / Emergency
The system is equipped with a solid, PFA-coated, stainless-steel housing with a
swiveling safety lid for maximum user safety. The electronic lid-locking mechanism can
only be opened by means of the software control. In addition, 3 interlock switches are
installed which shut the microwave off if the lid is opened by force during microwave
operation.
WARNING
The unit emits microwave radiation!
Never operat
e the microwave oven if the swiveling lid or
the related lock mechanism has
been damaged. Contact your local, authorized dealer or Analytik Jena AG to obtain the
required service
.
Microwave radiation
Vessels
Swiveling lid

Safety instructions TOPwave
12
All vessels are equipped with a rupture disc which produces a spontaneous pressure re-
lease upwards through the screw-on tube connections in case of excessive vessel pres-
sure. In some cases, such a spontaneous pressure release may occur after the vessel has
been removed from the microwave oven.
WARNING
Ru
pture discs used for overpressure protection!
Use only original Analytik Jena rupture discs and protective cover sheets. These can be
obtained from your local, authorized dealer or Analytik Jena.
Never use more than one rupture disc per vessel!
Only use ru
pture discs which are designed for the respective vessel!
All pressure vessels are equipped with a sealed connection to a gas collection system
which (without PM 40), in turn, must be connected to an exhaust system via a PFA vent
tube. The PFA tube is connected to the screw-on connection located in the center of the
top of the microwave. Any hot acid vapors released when the rupture disc activates are
safely removed through this PFA vent tube.
WARNING
Hot acid vapors may be released!
The sup
plied vent tubes must therefore always be properly connected and attached to
an exhaust system.
Make sure the PFA tube is securely attached so that it cannot pop off its connection fit-
ting in case of a percussive pressure burst as occurs when a
rupture disc activates.
The system is equipped with a temperature control of all sample temperatures.
An emergency shut-off occurs in case of a rupture disc break.
Optionally, the system can be equipped with a pressure monitoring system for one or all
vessels.
For safety reasons, the microwave automatically switches itself off in case the magnet-
ron, the microwave oven, or the high voltage transformer overheats
In the following situations, the unit must be disconnected from the mains power supply
and be locked out to prevent accidental use:
if the unit evidences visible signs of damage
if unit parts or components are found to be loose
if the unit fails to operate
if the unit is to be stored for extended periods of time under unfavorable conditions
(e.g., outdoors, in very moist or humid environments)
Rupture discs
Gas exhaust
Temperature control
Pressure control
Over-temperature protec-
tion

TOPwave Installation and Setup
13
3Installation and Setup
3.1 Ambient Conditions
The setup location must meet the following requirements:
Ambient temperature during operation +10 °C to +35 °C (50 °F to 93 °F)
Ambient temperature during operation
during shipping and storage
– 40 °C to +70 °C (-40 °F bis 158 °F)
Max. rel. humidity: 85 %
Space requirements (D X W X H): ca. 90 cm x 80 cm x 90 cm
(approx.: 35.4 x 31.5 x 35.4 inch)
Load bearing capacity: min. 80 kg (176 lb)
Electrical connection: 230 V; 50/60 Hz
Ventilation slots at the rear must be free (minimum distance 15 cm).
Make sure that the TOPwave microwave system is set up and operated in a corro-
sion-free environment.
If the microwave is used in a fume hood it is not allowed to use open acid in this
hood. As well the opening of the microwave pressure vessel must happen in a sepa-
rate fume hood.
When the system is installed outside the hood the released gases must be safely
discharged through the vent system via the PFA exhaust tube that is to be inserted in
the oven.

Device Description TOPwave
14
4Device Description
4.1 Basic Unit
The TOPwave microwave system is designed for pressure digestion
at temperatures up to 230 °C (446 ° F) in continuous use and, depending on the type of
vessels employed, pressures up to a max. of 100 bar (1450 psi).
This is a top loading microwave made of 1.4301 (SS 304) stainless steel and equipped
with a swiveling safety lid, electromechanical locking mechanism and a circular sample
chamber for uniform microwave distribution. The oven has a highly chemicals resistant
PFA coating protecting it from corrosion. Three over-temperature switches and three
micro-switches guarantee the necessary operating safety. The chamber is permanently
ventilated by a special fan.
A RTM thermometer that permits the temperature of the vessel contents to be quickly
determined and regulated is integrated in the microwave oven. The measurement physi-
cally determines the temperature radiation emitted by the vessel contents, that is, the
digestion solution. Radiation components emitted by the vessel walls and, in particular,
the exterior of the vessel, are completely filtered out.
Optionally the system can be equipped with a contact-free, optical pressure monitoring
system for either individual or for all vessels. This records the internal vessel pressure. If
a vessel is approaching its maximum pressure, the system automatically switches to a
pressure-controlled mode for the microwave output.
An unpulsed regulated 2.45 GHz magnetron provides up to 1,450 W. The microwave is
controlled by a separate controller with touch-screen. After entering the desired tempe-
rature profile, the microwave output is infinitely varied in accordance with the measured
sample temperatures. The target and actual temperatures of all samples are displayed
on the screen in real time and saved to memory.
Basic Unit

TOPwave Device Description
15
As the following figures illustrate, the TOPwave is equipped with various connection op-
tions.
1 Control unit 4 Swiveling lid with vent connection
2 Magnetron cooling 5 Vent connection on swiveling lid
3 Vent connection oven 6 Electrical connections
The electrical connections are located on the right hand side of the microwave system.
1 Power switch 3 Connection power cord
2 Fuses 4 RS-232 port
The mains power switch is located on the back of the unit. Next to this are connections
for the power cord, fuses.
The RS-232 port is used for connecting to the basic instrument and the Ethernet port to
a network.
Connections at Basic unit

Device Description TOPwave
16
1 Mains power switch
2 Main power connection
3 Fuses
4 USB port
5 RS-232 port
6 Ethernet port
A separate control unit Power PC 5200 with 5.7” touch screen and graphics display is
used to control the microwave oven. The control software is preinstalled at the factory.
Key Function
[Application]
Function for selecting or modifying a stored application. The active ap-
plication is displayed (in ex
ample above “Calcite; Dolomite”).
[Data]
Function to review stored digestion process data. The last data file is
di
splayed (in example above „Data: ddir1_0“).
Logged in
Display of login status
After pressing the line the login window appears.
[Open]
Release the electronic lid locking
(only possible when microwave is stopped).
[Setup]
Setup menu.
A user with "master" login can select basic unit parameters (see section
"
Installation" p. 21).
[Start]
Configuration and start of microwave
[Service]
Service menu.
Access for service technicians only.
The version number of the control software is displayed in the header of the main menu
and in the footer the version number of the firmware of the TOPwave and the status of
the swivel lid.
Control unit
Main menu
Key functions

TOPwave Device Description
17
4.2 Temperature Control
The TOPwave is equipped with a temperature monitoring system. This system deter-
mines the temperature inside the pressure vessels by measuring the direct infrared radi-
ation emitted by the sample. This allows the temperatures of all samples to be deter-
mined. This information is forwarded to the power control module which uses the hig-
hest measured temperature to regulate the oven power. Continuous adjustment of the
magnetron output allows the temperature regulation on the base of all vessel contents.
For measurement instrumentation reasons, only temperatures above 50 °C (122 °F) can
be displayed. Temperatures below 50 °C (122 °F) are indicated on the display by “low”.
1 Infrared filter
2 Measurement sensor
4.3 Pressure Monitoring (Option)
Optionally, TOPwave can be equipped with a pressure monitoring system. To achieve
this, the pressure in the vessels is determined by using polarized light to measure any
change in the photoelastic behavior of a glass ring in the vessel lid. This allows the inter-
nal pressures of all or of individual vessels to be detected. This information is conveyed
to the output control module, which can use the highest measured pressure to regulate
the output. By continuously adjusting the magnetron output pressure regulation refe-
renced to individual vessels can be achieved while preventing other over-pressure safety
devices (rupture discs) from being activated.
1 Polarized light
2 Glass ring
3 Optical sensor
4 Internal pressure

Device Description TOPwave
18
NOTICE
The safety of the vessels is guaranteed by the rupture discs. Pressure and temperature
measur
ement serve to control the digestion process, but have no primary safety func-
tion.
4.4 Pressure Vessels and Rotor System
All vessels can be opened and closed tool-free. A rupture disc placed in the vessel lid li-
mits the interior pressure of all vessel types to the maximum permissible value for the
individual type. For all vessels, except PM 40, acid vapors that escape when the rupture
disc activates are guided to a collection system integrated in the rotor. Thereby the va-
pors are vented or suctioned off through the PFA tube connected to the swiveling lid.
PM 40 vessels are made entirely of TFM -PTFE. Aside from chemical resistance to all
mineral acids including hydrofluoric acid, this ensures a high level of mechanical
strength, even at high digestion temperatures.
24 pressure vessels made of TFM-PTFE 24 pressure vessels made TFM-PTFE
(thereof 4 with RPM)
PM 60 and PL 100 vessels are made entirely of TFM-PTFE. Aside from chemical re-
sistance to all mineral acids including hydrofluoric acid, this ensures a high level of me-
chanical strength, even at high digestion temperatures.
PM 40
PM 60/ PL 100

TOPwave Device Description
19
12 pressure vessels mode of TFM-PTFE 12 pressure vessels made of TFM -PTFE
with RPM
CX 100 vessels are made of a TFM-PTFE-pressure vessel with cap. Beside this, this ves-
sel consists of a ceramic pressure jacket and a TFM-PTFE -insert.
8 pressure vessels made of TFM-PTFE 8 pressure vessels made of TFM-PTFE
with RPM
For the digestion of smaller sample quantities the QX 20 quartz glass inserts can be in-
serted into the PM 60 digestion vessel. Use QX 22 quartz glass inserts for PL 100 vessel.
1 Rupture disc holder
2 Rupture disc
3 TFM-PTFE Lid
4 Cent-ring sleeve
5 Quartz glass insert
6 PM 60/PL 100
CX 100
Quartz glass inserts QX
20/QX 22 for smaller
sample quantities

Device Description TOPwave
20
The special MT system inserts can be used for the digestion of smaller quantities of
samples or several samples simultaneously in a PL 100 or CX 100 pressure vessel. The
vessels for the MT system are made of PFA, have a capacity of 10 ml and a graduation
mark at 5 ml (see section "Appendix" p. 74).
1 PFA insert
2
TFM-PTFE insert
3
Pressure vessel CX 100
The MT (multi tube) sys-
tem
