Enwork FE Series User manual

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
Foundation EX Table
FExxxx
Installation Instructions

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
1) Parts and Fasteners Included
.375-16 x 1.25” .375-16 x 2.25” .25-20 x .50”
.50-13 x 4.00” .375-16 Steel Square Nut .375-16 x .50“
Draw Plate 1
(EAM-1000-1)
Draw Plate 2
(EAM-2000) #12 x 1.00” Screw

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
1) Parts and Fasteners Included
.25”-20 HEX Nut .375 -16 Easy Adjust Glide
Laminate Base Shroud
(FES-1092-x)
C-Channel
(EAM-1001-xx)
Base Leg 1
(FEM-2006-01)
Base Bottom Assembly
(FEM-2004-x) Base Leg 2
(FEM-2006-02)
Top Plate Assembly
(FEM-2003-x)

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
1) Parts and Fasteners Included
#6-18 x .50” #10-24 X .50”
Top Connection Bracket
(EAM-1024)
Extrusion Cap
(EAM-2010-x)
Left Extrusion
(EAA-2002-x-L)
OR
(EAA-2003-x-L)
Right Extrusion
(EAA-2002-x-R)
Or
(EAA-2003-x-R)
Mid Extrusion
(EAA-2002-x-M)
Embedded Brace
(NZBRACEx)
Right Angle Bracket

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
2) Tools and supplies Required
Drill Hex Driver Bit Square Driver bit
Philips Driver Bit Level Philips Screw Driver
Combination Wrench Tape Measure Dead Blow Hammer

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
2) Tools and supplies Required
Ratchet Socket Utility Knife
Marker

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
Install the glides into the Base Bottom Assembly.
Note: 8X assemblies
Fig 3.1
Line up Base Leg 1 with the inside connection holes
on the Base Bottom Assembly. Secure together with
.375-16 x 1.25” bolts.
Note: 2X assemblies
Fig 3.2
Note: 2X assemblies
Fig 3.3
3) Base Assembly
2x
2x
8x
Line up Base Leg 2 with the outside connection
holes on the Base Bottom Assembly. Secure
together with .375-16 x 1.25” bolts.

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
Carefully pick up and slide the Laminate Shroud
down over the Base Legs, until it covers the Bottom
Base Assembly.
Fig 3.4
Carefully lift up the Top Plate Assembly, align it over
the Base Shroud with its connection holes. Slowly
let the Top Plate Assembly down until it is resting
on the top of the Base legs. Once aligned, secure
together with .375-16 x 1.25” bolts.
Fig 3.5
Note: 2X assemblies
Fig 3.6
3) Base Assembly
Connect the Right Angle Bracket to each side of the
Top plate assembly using ta 10-24 x ½ bolt
2x

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
Connect the Right Angle Bracket to the inside of the
Base Shroud using a #6-18 x .50” screw provided.
Fig 3.7
3) Base Assembly
Note: 2X assemblies
Fig 3.8
Repeat the last seven steps to assemble the second
base.
When the base assemblies are completed, place
them in there final position with the access doors
facing in.
2x

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
In a clear area, on a non marring surface, place the
extrusions in an order similar to there completed
position.
Note: the orientation of the extrusions.
(The number of Mid-Extrusions(0-2) is dependent on
table length)
Fig 4.1
Position the C Channel with the embossed “T”
facing up and with the opening of the C to the
outside of the extrusion (See Fig 4.2).
Fig 4.2
Insert the C-Channel into the first extrusion. Line up
2 of the threaded holes. Install (2) .25”-20 x .50”.
and finger tighten.
Repeat for all Extrusion.
Do not tighten the bolts at this time
Fig 4.3
4) Extrusion Assembly

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
Slide the next extrusion on to the C-Channel.
Install Draw Plate 1, Draw Plate 2 and a .50 -13 X
4.00” bolt into each Extrusion connection hole and
tighten so the extrusions line up flush on all sides.
Important: The extrusions must be aligned and
square before they fully tightening. Adjust as
necessary while tightening.
Fig 4.4
Once the Draw Plates are fully tightened, Fully
tighten of the (2).25-20 x .50” on top of the
extrusion and install and fully tighten (6) .25-20 x
.50” into the top and bottom of the extrusion (as
shown)
Depending on table length, Left & Right Extrusions
may be assembled at this point.
Fig 4.5
4) Extrusion Assembly

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
Place the fully assembled beams on the Base
Assembly, seating the channel of the extrusion in
the U Channel of the base.
Note: There may only be (2) beams on each side
depending on the size of the table length.
Fig 5.1
Align the holes of the assembled beams to the
holes of the assembled bases.
Fig 5.2
Secure the ends of both extrusion to the bases
using a .375-16 x 1.25” bolt, then proceed to secure
the extrusion with the using (2).375-16x 2.25” bolts.
Repeat process for the other end of the table.
Fig 5.3
5) Table Frame Assembly

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
Note: if this assembly does not have mid beams,
skip ahead to section 6.
If this is an assembly with mid beams, position a
Left & Right Extrusion as shown.
Slide the extrusions completely until the surfaces
meet. The C Channel holes should alight with the
top slots on the middle extrusion assembly like
shown below.
Fig 5.4
Insert (2) .25-20 x .50” into the extrusion slots to
secure the C-Channel and finger tighten.
Do not tighten the bolts at this time
Fig 5.5
Install Draw Plate 1, Draw Plate 2 and a .50 -13 X
4.00” bolt into each Extrusion connection hole and
tighten.
Important: The extrusions must be aligned and
square before they fully tightening. Adjust as
necessary while tightening.
Fully tighten the bolts connecting the extrusion to the
base at this time.
Fig 5.6
5) Table Frame Assembly

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
Insert the .375-16 Square Nuts into the top and
bottom track on the inside of the extrusions
There will be 2 for every Top Connection Bracket
(EAM-1024).
Fig 6.1
Attach the Top Connection Bracket to the square
nuts using .375-16 x .50” bolts
Position the 2 outer most Top Connection Brackets
10”-16” from the end of the extrusion and then
evenly distribute the remaining Brackets along the
length of the extrusion.
Do not tighten yet. These may need to be
repositioned later in the assembly process.
Fig 6.2
Attach the Extrusion Cap (EAM-2010-x) using (4)
square nuts and .375-16 x .50” bolts.
Note: Press the end cap in all the way tight against
the end of the extrusion . insure the back side of the
cap is flush with the end of the extrusion.
Fig 6.3
6) Table Top Assembly
2x

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
On a non-marring surface, attach the Embedded
Braces to the routings in the bottom of the Top
using the #10 x 1.00 Pan Head Phillips Wood
Screws.
When attaching the braces to the ENDS of the
work surface. Be sure to use only every other
screw hole provided. This will aid when attaching
the work surface to the table frame.
Note: number of surfaces may vary depending on
table length.
Fig 6.5
Before attaching the work surface to the table tops
assembly, verify there is no interference with the
Top Connection Bracket and any power
unit/cutouts.
Location of the Top Connection Bracket can be
adjusted as needed.
Tighten all of the brackets to the extrusion at this
time.
Fig 6.6
6) Table Top Assembly
Fig 6.4
Place the work surfaces onto the table frame.
When placing the end piece on, be sure there is
no interference between the screw heads
holding the braces on. Remove any screw(s)
that are causing the interference between the
Top and the table frame. This will only occur on
the End Work Surface pieces.
Install all work surfaces and snuggly attach all
tight joints. Align work surfaces and fully
tighten.

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
Fig 6.7
Verify the work surface is aligned and centered,
then fully tighten the Tight Joints.
Attach the work surface to the table assembly using
the Top Connection Bracket and “12 x 1” screws.
Fig 6.6
6) Table Top Assembly

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
INSTALLATION GUIDE
Placing a Level in center of the work surface, level
the entire table using a ratchet to adjust the glides
of each base.
Fig 7.1
Feed any power cords down through the base top
plate, and down into the floor core (Fig 7.2) (if used)
Fig 7.2
7) Leveling and Finish
Line up and re attach the inside access panel.
Fig 7.3

F A x x x x
Foundation EX Installation Guide REV A DATE:(08/01/22)
12900 Christopher Drive Lowell, MI 49331
800.815.7251 www.enwork.com
Specifications subject to change without notice.
