Enwork ZOR User manual

Zori Freestanding L-Shaped Screens Installation Guide – Rev A.
ZORI FREESTANDING L-SHAPED
SCREEN INSTALLATION GUIDE
SCREENS
ZI0002

INSTALLATION GUIDE
1) PARTS AND FASTENERS INCLUDED
Pre Assembled Panel
Bottom Plate
(FRM-1911)
Stretcher – Upper
(FRA-2065-xx)
Lower Panel
(Laminate FRL-1876-xx)
Upper Panel (Acrylic FRX-1046 or
Acoustic FRX-1064-xx)
L Cap Plate
(FRM-1912-L)
Vertical Support Column
(FRA-2066-xx)
Stretcher – Lower
(FRA-2065-xx)
Top Cap Plate
(CYM-1700)

INSTALLATION GUIDE
1) PARTS AND FASTENERS INCLUDED CONT.
Aluminum U-Channel
(For Acrylic panel only)
(FRA-2068-xx)
5/16-18 X .75 Serrated
Flange Head Cap Screw
Joiner Biscuit
(For Acoustic panel only)
10-24 x 1 Square Drive
Flat Head Type F Screw
#5 X 1/2” Flat Head Wood
Screw, Phillips

INSTALLATION GUIDE
2) TOOLS AND SUPPLIES REQUIRED
Drill Square Head bit ½ in Wrench
(ratcheting recommended)

INSTALLATION GUIDE
Lay pre-assembled Panel at on a non-
marring surface.
Remove Cap Plate and 10-24 x 1 Square Drive Flat
Head Screws from the slotted end of the Vertical
Support Column.
(Set aside to be re-installed later)
Install the Upper and Lower Stretchers and the
Vertical Support Column using (4) 5/16-18 X .75
Cap Screw.
Tighten the Lower stretcher bolt.
Snug the Upper stretcher bolt (Slotted end). This is
to be dis-assembled later.
FIGURE 1
FIGURE 2
FIGURE 3
3) ASSEMBLY:

INSTALLATION GUIDE
Lifts the sub assembly and place it in the
upside-down position.
Install (2) Bottom Plates and the L Cap Plate using
(12) 10-24 x 1 Square Drive Flat Head.
Lift the sub assembly and place it in the upright
position.
Loosen the (2) 5/16-18 X .75 Cap Screw and
remove the Upper Stretcher. Set aside to be re-
installed later.
FIGURE 4
FIGURE 5
FIGURE 6
3) ASSEMBLY:

INSTALLATION GUIDE
NOTE: For Acrylic Installation
Place Aluminum U-Channel on the edge of the
Lower Laminate Panel and fasten using the
supplied #5 X 1/2” Flat Head Wood Screws.
Install Panel.
Note: The number of panels will depend on
screen conguration.
NOTE: For Acoustic Installation
Place Joiner Biscuits into the routed slots of the
Lower Laminate Panel and install the Acoustic
panel.
FIGURE 7
FIGURE 8
FIGURE 9
3) ASSEMBLY:

INSTALLATION GUIDE
Reinstall the Upper Stretcher and tighten the 5/16-18
X .75 Cap Screw (from Fig 6).
Reinstall the Cap Plate (from Fig 2).
Install Cap Plate CYM-1700 using (4) 10-24 x 1 Square
Drive Flat Head.
Install Upper Panel.
Assembly complete.
FIGURE 10
FIGURE 11
FIGURE 12
3) ASSEMBLY:

Specications subject to change without notice.
Rev 07.2020
1.800.815.7251
www.enwork.com
12900 Christopher Dr. Lowell, MI 49331
