Event Lighting PIXBAR12x12 User manual

0
LED Pixel Bar
PIXBAR12x12
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications within this
manual are subject to change without notice. Event Lighting assumes no liability or responsibility for any
errors or omissions. Please consult Event Lighting for any clarification or information regarding this item.
www.event-lighting.com.au
V3.2

www.event-lighting.com.au
1
CONTENTS
Safety Instructions
Product Installation
Diagrams
Control Board Operation
Special Chaser Mode
DMX Values
Technical Specifications
Warranty

www.event-lighting.com.au
2
Safety Instructions
WARNING
• Do not open this device, there is no user-serviceable parts inside. Risk of electric shock.
• Do not look at the light source when the device is on.
• CAUTION: This unit's housing may be hot during and after operation.
• Install this device in a location with adequate ventilation, at least 20 inch (50 cm) from adjacent surfaces.
• Do not leave any flammable material within 50 cm of this unit while operating or connected to power.
• Use a safety chain when mounting this device overhead.
• Do not operate this device outdoors or in any location where dust, excessive heat, water, or humidity may affect it.
• Do not operate this device if the housing, lenses, or cables appear damaged.
• Do not connect this device to a dimmer or rheostat.
• ONLY connect this device to a grounded and protected circuit.
• ONLY use the hanging bracket to carry this device.
• In case of a serious operating problem, stop using immediately.
• The maximum ambient temperature is 104° F (40° C). Do not operate this device at higher temperatures.
Power Input & Power Linking
This device has an auto-switching power supply work with input voltage range of 100~240 VAC, 50/60 Hz.
Link up to the maximum of 8A. DO NOT exceed this number.
Product Installation
This device can be mounted in many orientations provided each individual device is secured by the use of correct
mounting bracket.
Use a safety chain when mounting this device overhead.
Fuse Replacement
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuse holder on the rear panel with a fitting screwdriver from the housing (anticlockwise).
Step 2: Remove the old fuse from the fuse holder.
Step 3: Install the new fuse in the fuse holder.
Step 4: Replace the fuse holder in the housing and fix it.

www.event-lighting.com.au
3
Lux Chart
Dimensions

www.event-lighting.com.au
4
CONTROL BOARD OPERATION
Display Options / Values Function
01.DMX Address <001> - <512> Set DMX address
02.DMX Channel <03> <04> <06> <08> <12>
<24> <72> <74>
Select DMX channel mode
03.Dimmer Curve <01> <02> <03> <04> Select dimmer curve
04.Static Color R, G, B, W, A, U, GB, RB,
RG, …. RGBWAU
Select static colour
05.Manual Color R<000> - <255>
G<000> - <255>
B<000> - <255>
W<000> - <255>
A<000> - <255>
U<000> - <255>
S<000> - S<030>
Set intensity of each colour separately for color mixing
and strobe rate
06.Manual WCT WCT: <01> - <11>
DIM: <001> - <100>
Set up color temperature WCT 01~11 and adjust the
brightness
07. Auto Program <Pr:01> - <Pr:19>
<Sp:000> - <Sp:100>
<Dim:000> - <Dim:255>
Select built-in automatic programs, auto run speed and
dimmer level
08.Sound Mode Sen:<000> - Sen:<100> Select sound active mode and the sensitivity level from
Sen:<000> to Sen:<100>
09.Master/Slave <M> <S> Select Master/Slave modes
10.Factory Set <No>/<Yes> Recover manufactory default
DMX address
After select the "DMX Address" and press “Enter”, then use “Up” and “Down” to set the desired DMX address, press
"Enter" again to confirm.
DMX modes
After select the "DMX Channel" and press “Enter”, then use “Up” and “Down” to set the desired DMX mode, press
"Enter" again to confirm.
Dimmer curve
After select the "Dimmer Curve" and press “Enter”, then use “Up” and “Down” to set the desired dimmer curve, press
"Enter" again to confirm.
Static Colours
Entered "Static Color", you can select the desired solid color via the “Up” or “Down” buttons, then “Enter” to confirm.
Value Function
R Red
G Green

www.event-lighting.com.au
5
B Blue
W White
A Amber
UV UV
GB Green + Blue
RG Red + Green
RB Red + Blue
RW Red + White
GW Green + White
BW Blue + White
WA White + Amber
RA Red + Amber
GA Green + Amber
BA Blue + Amber
RGB Red +Green + Blue
RGW Red + Green + White
RBW Red + Blue + White
GBW Green + Blue + White
GBA Green + Blue + Amber
BWA Blue + White + Amber
RGA Red + Green + Amber
GWA Green + White + Amber
RWA Red + White + Amber
RGBA Red + Green + Blue + Amber
GBWA Green + Blue + White + Amber
RGBW Red + Green + Blue + White
RBWA Red + Blue + White + Amber
RGWA Red + Green + White + Amber
EGBWA Red + Green + Blue + White + Amber
RGBWAU Red + Green + Blue + White + Amber + UV
Manual Colour mode
Entered "Manual Color" mode, use “Up” and “Down” button to select the each colour RGBWAUV intensity from 000 to
255, select strobe (S) speed from S000 to S100. (S000 is strobe off). Press “Enter" to save new setting.
Manual WCT
Entered "Manual WCT" mode, use “Up” and “Down” button to select preset colour temperature from WCT01 to WCT11.
Press “Enter" and use “Up” and “Down” button to select dimmer from dim000 to dim100. Press “Enter" to save new
setting.
Automatic Mode
PR 01 4 colors switching
PR 02 36 colors switching
PR 03 6 colors fading(slow in slow out)

www.event-lighting.com.au
6
PR 04 36 colors fading(slow in slow out)
PR 05 6 colors fading(slow in fast out)
PR 06 36 colors fading(slow in fast out)
PR 07 6 colors fading(fast in slow out)
PR 08 36 colors fading(fast in slow out)
PR 09 Color Macros
PR 10 Auto chasing 1
PR 11 Auto chasing 2
PR 12 Auto chasing 3
PR 13 Auto chasing 4
PR 14 Auto chasing 5
PR 15 Auto chasing 6
PR 16 Auto chasing 7
PR 17 Auto chasing 8
PR 18 Auto chasing 9
PR 19 Multi fixture chasing
Set auto run PR 01 - PR 18
Entered "Auto Program" mode, use “Up” and “Down” button to select the built-in programs. Press “Enter" and use “Up”
and “Down” button to select auto run speed from <Sp000> to <Sp100>. Press “Enter" and use “Up” and “Down” button
to select dimmer of “Auto Program” from <dim000> – <dim255>. Press “Enter" to save new setting.
Set multi fixture chases PR 19
Before starting, go to each fixture and reset the menu to fixture defaults.
1. On the master unit, setup the DMX address to the total number of fixtures in the string. For example, you may
have a total of 20 par cans including the master, so the DMX address should be set to “20”.
2. On the master unit, go to master/slave menu setting and set the unit to master
3. On the master unit, set the unit to “Auto Mode” “PR 19” which supports multi fixture chases.
4. On each slave unit, setup the DMX address to the fixture position in the string. For example, if this unit is the
2nd unit in the string including the master, then set the DMX address to 2. If this the last unit of 20, then the
DMX address should be set to 20. It is possible to double up fixture positions as well as fixture 1.
5. On each slave, go to the master/slave menu setting and set it to slave.
Sound Mode
After select the "Sound mode", use “Up” and “Down” to set the sound sensitivity Sen 000 ~ Sen 100, press “Enter” to
confirm.
Master/Slave Operation
1. Set the master fixture to one of the standalone operating modes: auto, sound, static color or manual color modes
2. Set the slaves, entered “Mas/Sla” mode, set to “s”, press “Enter”
Factory set
To recover factory default, select the "Factory Set" and press “Enter”, then use “Up” and “Down” to choose “Yes”, press
"Enter" again to confirm to recover manufactory default

www.event-lighting.com.au
7
DMX CHART
Channel Function Min
DMX
Max
DMX
Ch3 Ch4 Ch6 Ch8 Ch12 Ch24 Ch72 Ch74
1 1 1 1 1 Red 0%-100% 0 255
2 2 2 2 2 Green 0%-100% 0 255
3 3 3 3 3 Blue 0%-100% 0 255
4 4 4 4 White 0%-100% 0 255
5 5 5 Amber 0%-100% 0 255
6 6 6 UV 0%-100% 0 255
7 7
Master Dimmer 0% ~ 100% for
CH1, 2, 3, 4, 5, 6, 9 & 10 0 255
8 8
No function 0 9
Strobe （slow to fast) 10 255
9
No function 0 9
White colour temperature 01 10 31
White colour temperature 02 32 54
White colour temperature 03 55 77
White colour temperature 04 78 100
White colour temperature 05 101 123
White colour temperature 06 124 146
White colour temperature 07 147 169
White colour temperature 08 170 192
White colour temperature 09 193 215
White colour temperature 10 216 238
White colour temperature 11 239 255
10
No function 0 9
4 colors switching 10 21
36 colors switching 22 34
6 colors fading(slow in slow out) 35 47
36 colors fading(slow in slow out) 48 60
6 colors fading(slow in fast out) 61 73
36 colors fading(slow in fast out) 74 86
6 colors fading(fast in slow out) 87 99
36 colors fading(fast in slow out) 100 112
Color Macros 113 125
Auto chasing 1 126 138
Auto chasing 2 139 151
Auto chasing 3 152 164
Auto chasing 4 165 177
Auto chasing 5 178 190
Auto chasing 6 191 203

www.event-lighting.com.au
8
Auto chasing 7 204 216
Auto chasing 8 217 229
Auto chasing 9 230 242
Sound active mode 243 255
11 Auto run speed 0 255
12
Use preset dimming curve 0 9
dimmer curve 1 10 70
dimmer curve 2 71 132
dimmer curve 3 133 194
dimmer curve 4 195 255
1 LED1-LED3 Red 0%-100% 0 255
2 LED1-LED3 Green 0%-100% 0 255
3 LED1-LED3 Blue 0%-100% 0 255
4 LED1-LED3 White 0%-100% 0 255
5 LED1-LED3 Amber 0%-100% 0 255
6 LED1-LED3 UV 0%-100% 0 255
7 LED4-LED6 Red 0%-100% 0 255
8 LED4-LED6 Green 0%-100% 0 255
9 LED4-LED6 Blue 0%-100% 0 255
10 LED4-LED6 White 0%-100% 0 255
11 LED4-LED6 Amber 0%-100% 0 255
12 LED4-LED6 UV 0%-100% 0 255
12 LED7-LED9 Red 0%-100% 0 255
14 LED7-LED9 Green 0%-100% 0 255
15 LED7-LED9 Blue 0%-100% 0 255
16 LED7-LED9 White 0%-100% 0 255
17 LED7-LED9 Amber 0%-100% 0 255
18 LED7-LED9 UV 0%-100% 0 255
19 LED10-LED12 Red 0%-100% 0 255
20 LED10-LED12 Green 0%-100% 0 255
21 LED10-LED12 Blue 0%-100% 0 255
22 LED10-LED12 White 0%-100% 0 255
23 LED10-LED12 Amber 0%-100% 0 255
24 LED10-LED12 UV 0%-100% 0 255
1 1 LED1 Red 0%-100% 0 255
2 2 LED1 Green 0%-100% 0 255
3 3 LED1 Blue 0%-100% 0 255
4 4 LED1 White 0%-100% 0 255
5 5 LED1 Amber 0%-100% 0 255
6 6 LED1 UV 0%-100% 0 255
7 7 LED2 Red 0%-100% 0 255
8 8 LED2 Green 0%-100% 0 255

www.event-lighting.com.au
9
9 9 LED2 Blue 0%-100% 0 255
10 10 LED2 White 0%-100% 0 255
11 11 LED2 Amber 0%-100% 0 255
12 12 LED2 UV 0%-100% 0 255
13 13 LED3 Red 0%-100% 0 255
14 14 LED3 Green 0%-100% 0 255
15 15 LED3 Blue 0%-100% 0 255
16 16 LED3 White 0%-100% 0 255
17 17 LED3 Amber 0%-100% 0 255
18 18 LED3 UV 0%-100% 0 255
19 19 LED4 Red 0%-100% 0 255
20 20 LED4 Green 0%-100% 0 255
21 21 LED4 Blue 0%-100% 0 255
22 22 LED4 White 0%-100% 0 255
23 23 LED4 Amber 0%-100% 0 255
24 24 LED4 UV 0%-100% 0 255
25 25 LED5 Red 0%-100% 0 255
26 26 LED5 Green 0%-100% 0 255
27 27 LED5 Blue 0%-100% 0 255
28 28 LED5 White 0%-100% 0 255
29 29 LED5 Amber 0%-100% 0 255
30 30 LED5 UV 0%-100% 0 255
31 31 LED6 Red 0%-100% 0 255
32 32 LED6 Green 0%-100% 0 255
33 33 LED6 Blue 0%-100% 0 255
34 34 LED6 White 0%-100% 0 255
35 35 LED6 Amber 0%-100% 0 255
36 36 LED6 UV 0%-100% 0 255
37 37 LED7 Red 0%-100% 0 255
38 38 LED7 Green 0%-100% 0 255
39 39 LED7 Blue 0%-100% 0 255
40 40 LED7 White 0%-100% 0 255
41 41 LED7 Amber 0%-100% 0 255
42 42 LED7 UV 0%-100% 0 255
43 43 LED8 Red 0%-100% 0 255
44 44 LED8 Green 0%-100% 0 255
45 45 LED8 Blue 0%-100% 0 255
46 46 LED8 White 0%-100% 0 255
47 47 LED8 Amber 0%-100% 0 255
48 48 LED8 UV 0%-100% 0 255
49 49 LED9 Red 0%-100% 0 255
50 50 LED9 Green 0%-100% 0 255

www.event-lighting.com.au
10
51 51 LED9 Blue 0%-100% 0 255
52 52 LED9 White 0%-100% 0 255
53 53 LED9 Amber 0%-100% 0 255
54 54 LED9 UV 0%-100% 0 255
55 55 LED10 Red 0%-100% 0 255
56 56 LED10 Green 0%-100% 0 255
57 57 LED10 Blue 0%-100% 0 255
58 58 LED10 White 0%-100% 0 255
59 59 LED10 Amber 0%-100% 0 255
60 60 LED10 UV 0%-100% 0 255
61 61 LED11 Red 0%-100% 0 255
62 62 LED11 Green 0%-100% 0 255
63 63 LED11 Blue 0%-100% 0 255
64 64 LED11 White 0%-100% 0 255
65 65 LED11 Amber 0%-100% 0 255
66 66 LED11 UV 0%-100% 0 255
67 67 LED12 Red 0%-100% 0 255
68 68 LED12 Green 0%-100% 0 255
69 69 LED12 Blue 0%-100% 0 255
70 70 LED12 White 0%-100% 0 255
71 71 LED12 Amber 0%-100% 0 255
72 72 LED12 UV 0%-100% 0 255
73 Master dimmer 0 255
74
No function 0 9
Strobe （slow to fast) 10 255

www.event-lighting.com.au
11
TECHNICAL SPECIFICATIONS
Power
-Input Voltages: 100V~240V AC, 50/60Hz
-Power Consumption: 150W
-Power Connection: Neutrik® Powercon Input & Output Connection
Photometrics
-Light Source: 12 pcs 12W RGBWAU LEDs
-Beam Angle: 30° (Optional 55° )
-Output: 2,050 lux @2.0 M RGBWAU full on
-PWM: 12,000 Hz
-LED Life: 50,000 hours
Effects
-4 x 16-bit Dimming Curves
-Strobe: 1 - 30 Hz
Control
-Operational Modes: Static, Color Fade, Auto Program, Sound Active, Multi Fixture Chases, Master / Slave & DMX
Modes,
-Display: 4-button LCD Display Control Panel
-DMX Protocol: DMX512
-DMX Channel Mode: 3 / 4 / 6 / 8 / 12 / 24 / 72 / 74
-DMX Interface: 3-Pin (Optional 5-Pin XLR)
-Software Upgrade via DMX: Yes
Housing
-Housing Materials: Aluminium Housing
-Housing finish: Matte Black
-Cooling: Fanless Cooling
-Dimension: 1050 x 165 x 80 mm
-Net Weight: 4.5 kg
WARRANTY
Please refer to your local dealer or please contact Event Lighting Pty Ltd
Website: www.event-lighting.com.au
