Exibel BNX100 User manual

Bluetooth-högtalare ·Bluetooth-høyttaler
Bluetooth-kaiutin ·Bluetooth-Lautsprecher
Ver. 20151005
English 3
Svenska 9
Norsk 14
Suomi 19
Deutsch 24
Bluetooth Speaker
Art.no. Model
38-6804, 38-6805, 38-7293 BNX100

2

3
English
Bluetooth Speaker
Art.no 38-6804, 38-6805, 38-7293 Model BNX100
Please read theentire instruction manual before using theproduct and then save it for
future reference. We reserve theright for any errors in text or images and any necessary
changes made to technical data. In theevent of technical problems or other queries,
please contact our Customer Services (see address details on theback).
Safety
• This speaker can be used by children aged from 8 years and above if they have been
given supervision or instruction concerning use of theappliance in asafe way and if
they understand thehazards involved. Cleaning and user maintenance shall not be
made by children unless they are older than 8 and supervised. Keep thespeaker and
its charger lead out of reach of children under theage of 8.
• Thespeaker may be used by persons with reduced physical, sensory or mental
capability, lack of experience or knowledge which could jeopardise their safety,
provided they have been instructed in thesafe use of theproduct and understand
thehazards involved. Never let children play with thespeaker.
• Thespeaker should not be taken apart or modified. Never try to open thecasing
of thespeaker. Thecasing houses dangerous current-carrying non-insulated
components. Contact with these can lead to fire or electric shock.
• Do not cover thespeaker. Adequate ventilation, with adistance of at least 5cm
between thespeaker and surrounding surfaces, is necessary to prevent thespeaker
from overheating.
• Place thespeaker on astable, flat surface.
• Do not place thespeaker where it could fall into water or other liquids.
• Do not place thespeaker in constant sunlight or near naked flames such as
wood stoves, lit candles, etc.
• Never subject thespeaker to high temperatures, damp or dusty environments,
heavy vibrations or impacts.
• Protect your hearing. Listening on high volume for prolonged periods can lead to
permanent hearing loss.
• Thespeaker must only be repaired by qualified service technicians.

4
English
1 2 3 4 5 6 7
10
11
12
13
9
8
Buttons and functions
1. [ ] Power switch
2. [◄] Previous track, rewind
3. [ ] Play, pause, accept/reject incoming call
4. [ ] NFC zone
5. [►] Next track, fast forward
6. [−] Lower thevolume
7. [+] Raise thevolume
8. LED indicator for Bluetooth connection
9. Microphone
10. 3.5mm aux input socket
11. Charging indicator
12. Charging socket
13. Lid

5
English
Charging
Connect theincluded charge lead to thecharging port (12) on thespeaker and to
acomputer or other USB charger. Thecharging indicator (11) indicates as follows:
• Steady red light – Charging in progress.
• Steady blue light – Battery fully charged
LED indicator
TheLED indicator (8) indicates as follows:
• Flashing blue light – thespeaker is detectable for other Bluetooth devices.
• Steady blue light – aBluetooth device is connected.
• Two quick flashes with aone-second interval – Bluetooth connection broken.
• Steady red light – external device connected to the3.5mm socket (10).
• Flashing red light – thebattery needs recharging.
Switching the speaker on and connecting
a Bluetooth device
1. Hold in [ ] for 3 seconds, theLED indicator (8) will flash red once and thespeaker
will emit anaudible “Power On” message. Release [ ], thespeaker will emit
anaudible, “Pairing” message, and theLED indicator will flash blue to show that
thespeaker is detectable for other Bluetooth devices.
2. Activate Bluetooth on thedevice to be paired with thespeaker.
3. Thespeaker will appear in thelist of devices on your Bluetooth device as BNX100,
select it and connect it to your device (refer to themanual of your device if you
are unsure). Thespeaker will emit anaudible “Connecting” message, and theLED
indicator will change to asteady blue.
4. Start playback on theBluetooth device. Thevolume level and track can be changed
on either thespeaker or on your external device. Other playback settings can be
controlled from theexternal device.
5. If theBluetooth connection is broken and you need to make thespeaker detectable for
Bluetooth devices again, hold in [ ] for 3 seconds until theLED indicator flashes blue.
Note: If you are prompted to enter aPIN code on your Bluetooth device, you should
enter 0000 (four zeroes). Certain Bluetooth devices may also require you to approve
theconnection.
Connecting a device via the 3.5 mm aux-in socket
1. Connect a3.5 mm audio cable between your device and theaux input (10) on
thespeaker.
2. Start playback on thedevice.

6
English
3. Adjust thevolume level on thespeaker or theexternal device.
Note: Thetrack can be changed using thebuttons on thespeaker once theexternal
device is connected via the3.5mm socket.
Connecting a Bluetooth device using NFC
(Near Field Communication)
Note: This feature is only available if your Bluetooth device is NFC-enabled.
1. Switch on thespeaker.
2. Activate NFC and Bluetooth on your Bluetooth device.
3. Hold thedevice up to theNFC zone (4) on thespeaker.
4. Your Bluetooth device will ask if you wish to connect to thespeaker.
5. Answer Yes and check theplayback via thespeaker and your Bluetooth device.
Switching the speaker off
Hold in [ ] for 3 seconds, theLED indicator (8) will go out and thespeaker will emit
anaudible “Power Off” message.
Incoming calls
If you receive acall whilst your phone is connected to thespeaker via Bluetooth:
• Press [ ] once to answer and use themicrophone in thespeaker.
• Press [ ] once to end thecall.
• Hold in [ ] for 2 seconds to reject thecall.
Care and maintenance
• Thespeaker has aningress protection rating of IPX4 which means that it can
withstand being splashed with water from all directions. This means that thespeaker
should survive light rain showers and damp conditions. Thespeaker is however, not
waterproof and should not be subjected to jets of water or immersion into water
or other liquid.
• Clean thespeaker using alightly moistened cloth. Use only mild cleaning agents,
never solvents or corrosive chemicals.
• If thespeaker is not to be used for along time, thebattery should be fully charged
on aregular basis (every second month) to prolong its capacity.

7
English
Troubleshooting guide
TheBluetooth speaker
will not switch on.
• Thebattery might be flat. Recharge thebattery.
No sound from
thespeaker when
anexternal device
is connected via
Bluetooth/NFC.
• Check thevolume and play/pause status on both
theexternal device and speaker.
• Make sure that theBluetooth/NFC connection is
functioning properly.
• Test theplayback of thefile on theBluetooth device on
its own to make sure it works before connecting it to
thespeaker.
• Try using another file. Thefile you are attempting to play
may be incompatible or damaged.
• Make sure that no other wireless devices are disrupting
thecurrent Bluetooth connection.
No sound from
theexternal device
connected via
the3.5 mm aux-in
socket.
• Check for sufficient volume level on theconnected
device and thespeaker. Check theplay/pause button
on theconnected device.
• Check that thecable connecting thedevice and
thespeaker is undamaged and securely connected.
• Test theplayback of thefile on thedevice itself before
connecting it to thespeaker.
• Try using another file. Thefile you are attempting to play
may be incompatible or damaged.
Resetting to
factory settings.
• If theabove measures don’t solve theproblem,
thespeaker may need to be reset to its original factory
settings. Turn thespeaker on and press [-] and [+]
simultaneously to initiate afactory reset.
Responsible disposal
This symbol indicates that this product should not be disposed of
with general household waste. This applies throughout theentire EU.
In order to prevent any harm to theenvironment or health hazards
caused by incorrect waste disposal, theproduct must be handed in
for recycling so that thematerial can be disposed of in aresponsible
manner. When recycling your product, take it to your local collection
facility or contact theplace of purchase. They will ensure that
theproduct is disposed of in anenvironmentally sound manner.

8
English
Specifications
Output 2×3.2W
Speaker 4 Ω, 3W
Built-in battery 2200 mAh lithium
Charging current 5 V, 500mA
Bluetooth 4.0
Range Approx. 10m
IP rating IPX4
Size 189×49×88.5mm
Weight 445g

9
Svenska
Bluetooth-högtalare
Art.nr 38-6804, 38-6805, 38-7293 Modell BNX100
Läs igenom hela bruksanvisningen före användning och spara den sedan för framtida bruk.
Vi reserverar oss för ev. text- och bildfel samt ändringar av tekniska data. Vid tekniska
problem eller andra frågor, kontakta vår kundtjänst (se adressuppgifter på baksidan).
Säkerhet
• Högtalaren får användas av barn från 8 år om de har fått instruktioner om hur den
på ett säkert sätt ska användas och förstår faror och risker som kan uppkomma.
Rengöring och skötsel får utföras av barn från 8 år i vuxens närvaro. Håll högtalaren
och dess laddkabel utom räckhåll för barn under 8 år.
• Högtalaren får användas av personer med någon form av funktionsnedsättning,
brist på erfarenhet eller kunskap som skulle kunna äventyra säkerheten, om de
har fått instruktioner om hur högtalaren på ett säkert sätt ska användas och förstår
faror och risker som kan uppkomma. Låt aldrig barn leka med högtalaren.
• Högtalaren får inte demonteras eller ändras. Försök aldrig öppna högtalaren.
Farlig spänning finns oskyddad på komponenter under höljet. Kontakt med
dessa kan leda till brand eller ge elektriska stötar.
• Täck inte över högtalaren. Tillräcklig ventilation, med ett minsta avstånd på 5 cm
mellan högtalaren och omgivande ytor, är nödvändig för att förhindra att högtalaren
blir för varm.
• Placera högtalaren så att den står stadigt på en plan yta.
• Placera inte högtalaren så att den kan falla ner i vatten eller annan vätska.
• Placera inte högtalaren i ihållande solljus eller i närheten av öppen eld som
vedspis/kamin eller levande ljus.
• Utsätt aldrig högtalaren för höga temperaturer, dammig miljö, starka vibrationer
eller stötar.
• Skydda din hörsel. Lyssning med hög volym under lång tid kan leda till bestående
hörselskador.
• Högtalaren får endast repareras av kvalificerad servicepersonal.

10
Svenska
1 2 3 4 5 6 7
10
11
12
13
9
8
Knappar och funktioner
1. [ ] På/av
2. [◄] Föregående spår, snabbspolning bakåt
3. [ ] Play/pause, besvara/avfärda inkommande samtal
4. [ ] Område för NFC-anslutning
5. [►] Nästa spår, snabbspolning framåt
6. [−] Sänk volymen
7. [+] Höj volymen
8. LED-indikator för Bluetooth-anslutning
9. Mikrofon
10. 3,5 mm-anslutning för externa enheter
11. Laddindikator
12. Anslutning för laddkabel
13. Lock
