FAAC E045 User manual

E045
E045

E045 2 732786 - Rev.C
8.8.
VOLTAGE
HIGH
AREA
C
B
A
1
ENGLISH
CE DECLARATION OF CONFORMITY
The manufacturer
Company name: FAAC S.p.A. Soc. Unipersonale
Address: Via Calari, 10 - 40069 Zola Predosa BOLOGNA - ITALY
hereby declares that the following product:
Description: control board
Model: E045
conforms to the essential safety requirements of the following ECC directives:
LowVoltage Directive 2014/35/EU
Electromagnetic Compatibility Directive 2014/30/EU
Directive ROHS 2 2011/65/EU
Furthermore, the following harmonised standards have been applied:
EN 60335-1:2012 + A11:2014 - EN 61000-6-2:2005 - EN 61000-6-3:2007 + A1:2011
Additional note: this product underwent tests in a typical uniform configuration (all products
manufactured by FAAC S.p.A.).
Bologna, January the 1st 2016 CEO
·
·Interrupt the electrical power supply
before working on the control unit. The
protectioncover(1) needstobe installed
before switching on the power supply.
F

E045 3 732786 - Rev.C
ENGLISH
WARNINGS FOR THE INSTALLER
GENERAL SAFETY OBLIGATIONS
13. Makesurethattheearthingsystemisperfectly
constructed, and connect metal parts of the
means of the closure to it.
14. Theautomatedsystemsthatfeatureabuilt-inanti-
crushing safety device in any case require a
functional check in accordance with the pro-
visions of the Standards indicated at point 9.
15. Thesafetydevices(EN12978standard)protect
any danger areas against mechanical mo-
vement Risks, such as crushing, dragging,
shearing, lifting.
16. Useofatleastoneindicator-light(e.g.:flashing
lamp) is recommended for every system, as
well as a warning sign adequately secured.
17. FAACS.p.A.declinesallliabilityasconcernssa-
fety and efficient operation of the automated
system, if system components not produced
by FAAC S.p.A. are used.
18. Formaintenance, strictly useoriginal parts by
FAAC S.p.A.
19. Donotinanywaymodifythecomponentsofthe
automated system.
20. TheinstallershallprovidetheUserwithallinfor-
mation concerning manual operation of the
system in case of an emergency.
21. Donotallow children oradultstostay near the
product while it is operating.
22. Keepradio controls orother pulsegenerators
awayfrom children, toprevent theautomated
system from being activated involuntarily.
23. Transit isallowedonly when theautomationis
fully open.
24. TheUsermustnotattemptanykindofrepairor
direct action whatever and contact qualified
personnel only.
25. Anythingnotexpresslyspecifiedintheseinstruc-
tions is not permitted.
1. ATTENTION!Toensurethesafetyofpeople, it
is important that you read all the following
instructions.Incorrect installationor incorrect
use of the product could cause serious harm
to people.
2. Carefullyreadtheinstructionsbeforebeginning
to install the product.
3. Donotleavepackingmaterials(plastic,polystyre-
ne, etc.) within reach of children as such
materials are potential sources of danger.
4. Store the instructions for future reference.
5. Thisproduct was designed andbuiltstrictlyfor
the use indicated in this documentation. Any
otheruse, not expresslyindicated here, could
compromise the good condition/operation of
the product and/or be a source of danger.
6. FAACS.p.A.declinesallliabilitycausedbyimpro-
per use or use other than that for which the
automated system was intended.
7. Donotinstallthe equipment in an explosive at-
mosphere: the presence of inflammable gas
or fumes is a serious danger to safety.
8. FAAC S.p.A. is not responsible for failure to
observe Good Technique in the construction
ofthe closing elementsto be motorised,or for
any deformation that may occur during use.
9. The installation must conform to Stan-
dards EN 12453 and EN 12445.
For non-EU countries, to obtain an adequate
levelof safety, theStandards mentionedabo-
ve must be observed, in addition to national
legal regulations.
10. Beforeattemptinganyjobonthesystem,cutout
electrical power and disconnect the batteries
if present.
11. Themainspowersupplyoftheautomatedsystem
mustbe fitted withan all-pole switchwith con-
tact opening distance of 3mm or greater. Use
of a 6A thermal breaker with all-pole circuit
break is recommended.
12. Makesurethatadifferentialswitchwiththreshold
of 0.03 A is fitted upstream of the system.
MEANING OF THE SYMBOLS USED
Important for the safety of persons and for the
good condition of the automated system. Notes on the characteristics and operation of the product.

E045 4 732786 - Rev.C
ENGLISH
INDEX
WARNINGS FOR THE INSTALLER...........................................................................................3
1. TECHNICAL SPECIFICATIONS............................................................................................5
2. PREPARING FOR INSTALLATION.......................................................................................6
3. BOARD LAYOUT...................................................................................................................6
4. ELECTRICAL CONNECTIONS.............................................................................................8
4.1 J1 - PRIMARY MAINS POWER SUPPLY .........................................................................8
4.2 J2 - MOTORS AND FLASHING LAMP.............................................................................8
4.3 J3 - COMMAND AND SAFETY DEVICES INPUTS..........................................................9
4.4 J9 - ACCESSORIES POWER SUPPLY............................................................................10
4.5 J11 - INDICATOR LIGHT/ELECTRIC LOCK OUTPUTS ..................................................10
4.6 J10 - BUS-2EASY ACCESSORIES .................................................................................11
BUS-2EASY photocells........................................................................................................11
Address assignment of BUS-2EASY photocells..................................................................12
Connection of BUS-2EASY photocells.................................................................................12
BUS-2EASY encoder...........................................................................................................13
Connection - Address assignment of BUS-2EASY Encoder................................................13
4.7 J5 - XF MODULE RAPID CONNECTOR ..........................................................................14
5. PROGRAMMING ...................................................................................................................15
5.1 BASIC PROGRAMMING FUNCTIONS.............................................................................16
5.2 ADVANCED PROGRAMMING FUNCTIONS....................................................................21
5.3 BUS-2EASY DEVICE INSTALLATION .............................................................................24
5.3.1 BUS-2EASYDEVICE ENTRY.......................................................................................24
Checking the securing devices entered on the board..........................................................25
5.4 TIME LEARNING - SETUP................................................................................................26
5.5 TESTING THE AUTOMATED SYSTEM............................................................................27
6. MEMORISING THE RADIO CODE........................................................................................28
6.1 MEMORISING THE
SLH/SLH LR RADIO CONTROLS ...................................................28
6.2 MEMORISING LC/RC RADIO CONTROLS (ONLY 433 MHZ).........................................29
6.2.1 REMOTE MEMORISATION OF LC/RC RADIO CONTROLS...................................30
6.3 MEMORISING
DS RADIO CONTROLS............................................................................30
6.4 DELETING THE RADIO CONTROLS...............................................................................31
7. START-UP..............................................................................................................................32
7.1 CHECKING THE LEDs......................................................................................................32
8. SIGNALLING ERRORS AND ALARMS................................................................................33
8.1 ERRORS............................................................................................................................33
8.2 ALARMS............................................................................................................................34
9. TROUBLESHOOTING...........................................................................................................34
10. MANAGING THE CONFIGURATION FILE – J8 USB .......................................................35
11. FUNCTION LOGICS ............................................................................................................38

E045 5 732786 - Rev.C
ENGLISH
CONTROL BOARD E045
We thank you for having chosen one of our products. FAAC is certain that from it you will obtain
all the performance you require. All our products are the result of years of experience in the field of
automated systems.
1. TECHNICAL SPECIFICATIONS
PURPOSE: this control board has been designed and built to control swing-leaf gates for vehicle and
pedestrian access control.
During programming you can choose between different function logics.
2 programming levels are available from the board (BASIC andADVANCED), using buttons and LCD
display.
Mains power supply With power supply switching 230 V~ ± 15% ; 50/60Hz
Power absorbed from mains Stand By = 4W ; MAX about 800 W
MAX load for motors 800 W
Accessories power supply 24 V"
MAX. accessories current +24V MAX 500 mA BUS-2EASY MAX 500 mA
LOCK (FAAC) 12 V~ / 24 V"
Operating ambient temperature from -20°C to +55°C
Power supply safety fuses F1 = F5 A
Work time Self-learned through SETUP - (Max 4 min and 10 sec)
Pause time Programmable (from 0 to 9 min and 50 sec)
Motor power Programmable on 50 levels
Connector inputs XF433/868 Module, USB
Terminal board inputs Mains power supply, BUS-2EASY, OPEN-A, OPEN-B,
STOP
Terminal board outputs Flashing lamp, Motors, Electric lock (LOCK), OUT1, Ac-
cessories power supply
Tab. Technical specifications

E045 6 732786 - Rev.C
DL10USB
DL10
U
RADIO 1
DL12DL11
RADIO 2
DL1
2
RADI
O
RADIO
1
DL1
1
+/R1 F-/R2
BUS MON.
US
MO
N
DL14
HIGH
VOLTAGE
AREA
BUS
BUS
DL15
SW3
SW1 SW2
8.8.
USB-A
2EASY
STOPLAMP OP-ACOMAC MAIN W.L. OP-BCLOPCOM
18171615
CLOP
2EASY
LOCK
RADIO 433-868
J5
PE N L 1 2 3 4 5 6 7 8 9 10 11 15 16 17 18 20 21
RL1 RL2 RL3 RL4 RL5
TH2 TH1
QC4 QC3
IC1
C52
TF1
F1
DB1
24V ERROR
DL13 DL17 DL16
5V
ERROR
4V
E
STOP OP-B OP-A
OP A
OP B
STOP
DL7
DL8
DL9
J1
J3 J9 J2 J11
FL1
2120111087M2M1 9654321LNPE 24V
QC4
C5
H
I
G
H
V
O
LTAGE
A
REA
8
.
8.
RL1
RL2
RL3
RL4
RL5
TH2
TH1
QC3
TF1
F
1
DB
1
2
E
D
L1
3
D
L1
7
D
L1
6
5V
ERR
3
6
5V
24V
E
7
FL1
24
E
ERR
4V
E
52
52
F1
SW1 SW2 SW3
J1 J2 J3
J5
J8J9 J11
J10
DL7
DL10
DL11 DL12
DL13
DL14
DL15
DL16 DL17
LCD
DL8DL9
ENGLISH
3. BOARD LAYOUT
2. PREPARING FOR INSTALLATION
For safety reasons, it is important for people to carefully follow all the warnings and
instructions contained in this manual. Incorrect installation or incorrect use of the
product can causeserious harmto people.Before proceeding with product installation,
carefully read the entire manual. Keep these instructions for further reference.
Always cut off the electrical power before carrying out any work on the control unit
(connections, maintenance).
Always separate the power cables from the control and safety cables (button, receiver,
BUS-2EASYencoder, photocells, etc.). Avoid any electrical disturbance using separate
sheathing or a shielded cable (with shield connected to the earth).
• Ensure that upstream of the system there is a suitable magnetothermic differential switch with
omnipolar cut-off, as provided for in current safety regulations.
• Check for the presence of an adequate earthing system.

E045 7 732786 - Rev.C
ENGLISH
LCD Signalling/Programming display
SW1 “+/R1” Programming button
SW2 “-/R2” Programming button
SW3 “F” Programming button
DL7 “STOP” Input status control LED
DL8 “OP-B” Input status control LED
DL9 “OP-A” Input status control LED
DL10 “
USB ” Signalling LED
DL11 “
RADIO1-XF ” Signalling LED (OMNIDEC)
DL12 “ RADIO2-XF ” Signalling LED (OMNIDEC)
DL13 “ ERROR ” Error/alarm signalling LED
DL14
“BUS MON“BUS-2EASY diagnostic signalling LED
DL15 Device signalling LED to
BUS-2EASYACTIVE
DL16 Microprocessor power presence LED
DL17 +24V"Accessories power supply presence LED
J1 230 V~ ± 15% Power supply connector
J2 Motors and flashing lamp power supply connector
J3 Input connector
J5
XF 433/ XF 868 (OMNIDEC) receiver module connector
Channel 1 - OPENA (Total Opening)
Channel 2 - OPEN B (Partial Opening)
J8 HOSTUSB-A for Mass Memories connector
J9 +24V"Accessories power supply connector
J10
BUS-2EASY Device connector
J11 Indicator Light/ Electric Lock output connector
F1 Motor and power supply safety fuse

E045 8 732786 - Rev.C
MAX
500 mA
{
C1 C2
J11J3 J9J2
J1
15 16 17 18
20 219 10 11
PE N L 1 2 3 4 5 6 7 8
ACMAIN
PE N L M1123 W.L. 21
LOCK
20
LAMP
78
24V
3W
230V~
MAX 60W
Mot1 Mot2
COM OP CL
OP-A OP-B STOP
-
15
-
16
+
17
+
1891011 24V M2456
COM OP CL
230V~ ±15%
50/60 Hz
12V~
24V
J1 J2 J3 J11 J9
**
ENGLISH
4. ELECTRICAL CONNECTIONS
4.1 J1 - PRIMARY MAINS POWER SUPPLY
PE Earthing Connection For correct operation, you must con-
nect the switching power supply to the
system’s earthing conductor. Ensure
that upstream a suitable differential
magnetothermic switch has been in-
stalled.
NPower Supply Connection
230 V~ ± 15% Neutral
LPower Supply Connection
230 V~ ± 15% Line
MotorforSINGLE-LEAFor
FIRST LEAF during ope-
ning(closesforthesecond)
OPEN A
Total gate opening
(contact N.O.)
OPEN B
Partial gate opening
(contact N.O.)
STOP
Gate stop
(contact N.C.)
*
Blue or grey Photocells and safety de-
vices: for connection, see
the related paragraph.
4.2 J2 - MOTORS AND FLASHING LAMP
1M1 - COM Common contact motor 1 M1=firstleafwhenopeningorsingleleaf
M2 = second leaf when opening - CAN-
NOT be used for single leaf
To verify correct wiring and direction
of motor rotation, (see 6.4 TIME LEAR-
NING - SETUP)
2M1 - OP OP phase motor 1
3M1 - CL CL phase motor 1
4M2 - COM Common contact motor 2
5M2 - OP OP phase motor 2
6M2 - CL CL phase motor 2
7LAMP Flashing lamp connection (MAX 60 W)
8

E045 9 732786 - Rev.C
ENGLISH
4.3 J3 - COMMAND AND SAFETY DEVICES INPUTS
9OP-A OPEN A contact - N.O.
TOTAL opening Connect a button or other pulse generator which, by closing a contact, commands TOTAL opening of both leaves.
10 OP-B OPEN B contact - N.O.
PARTIAL opening
Connect a button or other pulse generator which, by closing
a contact, commands the PARTIAL opening.
on 2-motor systems = 100% of leaf 1 opening;
on 1-motor systems = 50% of leaf 1 opening.
Whena logic requiring a CLOSE (
b
b,
C
C)input is selected, the,
OPEN B input automatically becomes CLOSE - N.O. (leaves
closing command).
To install more than one OPEN A or OPEN B pulse generator, connect the N.O. contacts in
parallel (see related Fig.)
11 STOP STOP contact - N.C. Connect a button or other pulse generator which, by opening
a contact, stops movement of the automated system.
To install more than one STOP device, connect the N.C. contacts in series (see related Fig.).
If stop devices are NOT connected, jumper terminals STOP and GND.
Fig. e.g.:Connecting2N.O.contactsinparallel. Fig. e.g.:Connecting2N.C.contactsinseries.

E045 10 732786 - Rev.C
ENGLISH
4.4 J9 - ACCESSORIES POWER SUPPLY
15 - GND Accessories power supply negative
16
17 + +24 Accessories power supply positive (MAX. load = 500mA)
18
4.5 J11 - INDICATOR LIGHT/ELECTRIC LOCK OUTPUTS
20 W.L. Indicator Light Output
24 V"- MAX Load 100mA
21 LOCK Electric lock (12 V~ or 24 V")
operated 2 sec before opening
of leaf 1
WhenBUS-2EASYencoder is disabled,the electric
lock is operated before each opening (in whatever
position the leaf is in).
When BUS-2EASYencoder is enabled, the electric
lock is operated before opening, only if the leaf is
closed position.

E045 11 732786 - Rev.C
ENGLISH
4.6 J10 - BUS-2EASY ACCESSORIES
This board features a BUS-2EASY circuit for facilitating connection to the safety devices of a high
number of auxiliary BUS-2EASY (MAX 16 pairs of photocells), encoder and control devices.
If no BUS-2EASY accessories are used, leave the BUS-2EASY connector free.
BUS-2EASY photocells
Before connecting the photocells, arrange them for the duly address assignment, depending on their
position and operation mode:
Photocells during closing:
trip only during the
closing of the automated system - suitable for
protecting the closing area from risk of impact.
Photocells during opening: trip only during the
opening of the automated system - suitable for
protecting the opening area from risk of impact.
Photocells during opening/closing: trip during
both the opening and closing - suitable for protec-
ting the entire movement area from risk of impact.
Pulse generators: used as pulse generators for
opening the automated system
.
Closing
safety devices Opening
safety devices
Opening/clo-
sing safety
devices
Should use of traditional photocells be required, you must use a BUS Interface Module
to be connected to the BUS-2EASY J10 terminal.
For further information, refer to the BUS Interface Module instructions.

E045 12 732786 - Rev.C
BUS-2EASY
J10
ENGLISH
Address assignment of BUS-2EASY photocells
To assign the address to each pair of photocells, you must set the Dip-Switches (DS1) located on the
transmitter and corresponding receiver.
The transmitter and receiver of a pair of photocells must have the same
DIP-SWITCH setting.
Two or more pairs of photocells must not have the same DIP-SWITCH setting.
Dip1 Dip2 Dip3 Dip4 TYPE OF PHOTOCELLS
OFF OFF OFF OFF
OPENING (max 6 pairs)
OFF OFF OFF ON
OFF OFF ON OFF
OFF OFF ON ON
OFF ON ON OFF
OFF ON ON ON
ON OFF OFF OFF
CLOSING (max 7 pairs)
ON OFF OFF ON
ON OFF ON OFF
ON OFF ON ON
ON ON OFF OFF
ON ON OFF ON
ON ON ON OFF
OFF ON OFF OFF OPENING and CLOSING (max 2 pairs)
OFF ON OFF ON
ON ON ON ON OPEN PULSE (1 pair)
Connection of BUS-2EASY photocells
For connecting you have to use two cables without polarity (see the specific device instructions).
DL1 = Alignment
DL2 = BUS-2EASY status/
Power supply
DS1 = Programming
Dip-switches

A
B
E045 13 732786 - Rev.C
GATECODER S800 ENC
J10
BUS-2EASY
DL1
DL2
DL3
DL1
DL2
DL3
J10
BUS-2EASY
DL3
DL2
DL1
DL3
DL2
DL1
DL1
DL2
DL3
M2 DL1
DL2
DL3
M1
DL1
DL2
DL3
M2
DL1
DL2
DL3
M1


ENGLISH
BUS-2EASY encoder
BUS-2EASY encoder connection is done using the bi-polar cables supplied with.
Connection - Address assignment of BUS-2EASY Encoder
The polarity of the BUS-2EASY line connection determines the correspondence of the
encoder to one leaf or the other.
pay careful attention to the indications of the status LEDs located on the body of each
encoder.
LEAF 1 opens first and closes last.
M1 : 2 LEDs on
M2 : 1 LED on
·
·Note: to correct the coupling of the
encoder with motor M1 or M2, swap both
wires on the terminals.

E045 14 732786 - Rev.C
DL12DL11
DL12
DL11
RADIO 433-868
J5
24V ERROR
DL13 DL17 DL16
5V
ERRO
R
4V
E
2
E
5V
ERR
5V
24V
E
24
E
ERR
4V
E
ENGLISH
LED ON FLASHING OFF
DL1 Power present
Communication present Power present Communication absent Power absent
Communication absent
DL1 must always be on to confirm correct encoder/board connection.
DL2 Leaf 1 / Leaf 2
DL2 indicates the leaf on which the encoder is installed; it must be on for leaf 1 and off for
leaf 2.
DL3 Stationary leaf Leaf in motion Stationary leaf
DL3 indicatespulse readingduring leaf movementusing steadyflashing. In stationarystatus
of the leaf, the DL3 can be either on or off.
In case of incorrect connection (DL2 on or off for both of the encoders), during the
BUS-2EASY accessories learning procedure, the DL1 leds of both encoders are
FLASHING.
Tab. BUS-2EASY Encoder LEDs Status
4.7 J5 - XF MODULE RAPID CONNECTOR
Plug-in rapid connector dedicated to OMNIDEC
2-channel decoding module.
ALWAYS cut off power to the board BE-
FORE inserting/removing the module.

E045 15 732786 - Rev.C
ENGLISH
5. PROGRAMMING
Programming is divided in two levels:
• BASIC programming
• ADVANCED programming
The programming phases are (see Tab.):
1. to access PROGRAMMING (1A or 1B);
2. to show the set values and modify them, if you want. Changing the values is effective immediately,
while the final memorisation must be carried out upon exiting programming (St).
3. exitthe programming byusing St function. SelectYto SAVE theconfiguration you justperformed,
otherwise select no to EXIT WITHOUT SAVING any changes.
You can EXIT programming at anytime:
• press and hold Fand then also
-
to switch directly to St.
F
+
- / R2
Tab. BASIC programming phases.
Tab. ADVANCED programming phases
 
PRESS AND HOLD
F:
THE FIRST
FUNCTION
APPEARS
1
F
RELEASE F:
THE FUNCTION
VALUE IS
DISPLAYED
F
USING
+
OR
-
,
SCROLL THE
AVAILABLE VALUES
UNTIL THE DESIRED
ONE
-/ R2
+/ R1
PRESS F:
TO MOVE TO
THE NEXT
FUNCTION
1
F
FUNCTION St
(LAST FUNCTION)
SELECT YTO SAVE
THE PROGRAMMING
OTHERWISE
SELECT no TO EXIT
THE PROGRAMMING
WITHOUT SAVING
PRESS THE BUTTON
FTO CONFIRM;
AT THE END THE
DISPLAY RETURNS
TO VISUALIZE THE
AUTOMATED SYSTEM
STATUS
F
 
PRESS AND HOLD
FAND THEN ALSO
+
:
THE FIRST
FUNCTION
APPEARS
1
F
+
+/ R1
RELEASE THE
BUTTONS:
THE FUNCTION
VALUE IS
DISPLAYED
F
+
+/ R1
USING
+
OR
-
,
SCROLL THE
AVAILABLE VALUES
UNTIL THE THE
DESIRED ONE
-/ R2
+/ R1
PRESS F:
TO MOVE TO
THE NEXT
FUNCTION
1
F
FUNCTION St
(LAST FUNCTION)
SELECT YTO SAVE
THE PROGRAMMING
OTHERWISE
SELECT no TO EXIT
THE PROGRAMMING
WITHOUT SAVING
PRESS THE BUTTON
FTO CONFIRM;
AT THE END THE
DISPLAY RETURNS
TO VISUALIZE THE
AUTOMATED SYSTEM
STATUS
F

1
1THE FUNCTION IS DISPLAYED UNTIL YOU HOLD

E045 16 732786 - Rev.C
ENGLISH
5.1 BASIC PROGRAMMING FUNCTIONS
Display Basic Function Default
dF
DEFAULT:
Yindicates that all the set values correspond to the default values.
no indicates that one or more set values are different from the default.
Set Yif you want to restore the default settings.
Y
LO
FUNCTION LOGICS:
ESemi-automatic
EP Semi-automatic Step-by-Step
SP Automatic Step-by-Step Safety Devices
AAutomatic
AP Automatic Step-by-Step
bSemi-automatic “b”
CDead-man
When a logic requiring a CLOSE (b,C), input is selected, the
OPEN B inputs will automatically be changed to CLOSE. , if you
choose a logic that does not require the use of CLOSE inputs,
these inputs will change to OPEN B.
For a description of how the logics operate, see the related paragraph.
E

E045 17 732786 - Rev.C
ENGLISH
Display Basic Function Default
PA
PAUSE A and PAUSE B TIME (visualised only with Automatic logics)
Isthepause time inaTOTAL openingandPARTIAL opening(it is enabledonly
if a logic with pause time has been selected).
Adjustable from 00 to 59 sec, in 1-second steps.
Next the value 59, the viewing changes to minutes and tenths of a second
(separated by a decimal point) and time is adjusted in 10-second steps up to
the maximum value of 9.5
minutes.
e.g.: if the display shows
2.5, the time is 2 min and 50 sec.
30
Mn
NR. OF MOTORS:
You can select the number of motors present in the system:
1= 1 motor
2= 2 motors
Ifthe SETUPis performed with only one motor, and later two motors
are used, the board will signal error 14 - configuration error, which
can be deleted by repeating the SETUP with two motors or by re-
turning to one motor.
If a SETUPis performed with two motors and later only one is used,
the board will not signal an error. Only the motor connected to input
M1 will move.
2

E045 18 732786 - Rev.C
ENGLISH
Display Basic Function Default
F1
MOTOR 1 POWER:
You can adjust the maximum power of motor 1, which is the same during
both opening and closing.
01 = minimum power
50 = maximum power
If the power is modified, we recommend performing a new SETUP
- see the related paragraph.
If hydraulic motors are used, power must be programmed to maximum
level (50).
25
F2
MOTOR 2 POWER (visualised only with the function Mn = 2):
You can adjust the maximum power of motor 2, which is the same during
both opening and closing.
01 = minimum power
50 = maximum power
If the power is modified, we recommend performing a new SETUP
- see the related paragraph.
If hydraulic motors are used, power must be programmed to maximum
level (50).
25
En
ENCODER USE:
You can enable/disable the use of encoders:
Y= encoders on both motors
no = encoders disabled
no
Cd
DELAY FOR CLOSING LEAF (visualised only with the function Mn = 2):
Is the delay time for starting leaf 1 closing with respect to leaf 2. Makes it
possible to avoid overlapping of the two leaves.
Adjustable from 00 to 59 sec, in 1- second steps.
Next the value 59, the viewing changes to minutes and tenths of a second
(separated by a decimal point) and time is adjusted in 10-second steps up to
the maximum value of 1.3
minutes.
e.g.: if the display shows
1.2, the time is 1 min and 20 sec
05

E045 19 732786 - Rev.C
ENGLISH
Display Basic Function Default
bu
BUS-2EASY DEVICES ENTRY:
See the related paragraph.
no
M2
MOTOR 2 dead-man DRIVE mode (visualised only with the function
Mn = 2)
+/ R1
OPENS (visualising oP) until the button is held down
-/ R2
CLOSES (visualising cL) until the button is held down
--
M1
MOTOR 1 dead-man DRIVE mode
+/ R1
OPENS (visualising oP) until the button is held down
-/ R2
CLOSES (visualising cL) until the button is held down
--
tL
WORK TIME LEARNING (SETUP):
See the related paragraph.
--

E045 20 732786 - Rev.C
ENGLISH
Display Basic Function Default
St
AUTOMATED SYSTEM STATUS:
You can exit programming, choosing whether or not to save the configuration
you just performed.
1. set the choice:
Yto SAVE and EXIT the programming
no to EXIT the programming WITHOUT SAVING
2. pressthe button Ftoconfirm; at theend thedisplayreturns tovisualize the
automated system status:
Y
00 = CLOSED
01 = OPEN
02 = Stationary then “OPENS”
03 = Stationary then “CLOSES”
04 = In “PAUSE”
05 = during Opening
06 = during Closing
07 = FAIL SAFE in progress
08 = checking BUS-2EASY devi-
ces in progress
09 = Pre-flash then “OPENS”
10 = Pre-flash then “CLOSES”
WARNING If power is lost to the board prior to confirmation (step
2.), all changes made will be lost.
F
+
- / R2
You can EXIT programming at any time: press and hold Fand
then also
-
to switch directly to St.
