fantastic furniture Java User manual

Version 1.0
Java
Console Table
fantasticfurniture.com.au
Required
Two People

fantasticfurniture.com.au Page 2
Warning: Ensure the wall strap is attached
to avoid serious injury
To avoid any serious or fatal injury, a wall strap has been provided with
this product to prevent toppling. We strongly recommend that this
product is permanently fixed to the wall or other suitable surface. Fixing
of what fixing device to use.
Rattan
Rattan is a natural material that will respond to humidity in the
environment. Low humidity may cause the rattan to shrink.
High humidity may cause the rattan to absorb moisture and expand,
causing the weaving to look loose and wavy.
This is a natural phenomenon and not a defect.
Looks like you’ve found
your Fantastic!
Love it? Share it!
We’re thrilled you’ve chosen Fantastic Furniture
to help create a home you’ll love!
Fantastic buy! Share how it looks at home on Instagram
for your chance to win a $250 Fantastic Furniture Gift Card!
@fantasticfurniture

Read through the instructions carefully
before you begin.
Assembly Checklist
Identify and lay out all of the
components before you begin assembly.
Unless instructed, do not fully tighten
screws until the item is fully assembled.
!Never use power tools unless specifically instructed. They can damage your
components or hardware if used incorrectly.
!The most common mistakes made during assembly are using the wrong hardware or
getting components back to front.
!Always use a soft surface (such as carpet or cardboard) when assembling your
product to avoid scratching or damaging the surface of the product.
!Bulky items such as wardrobes and bunk beds should be assembled in the room they
will be used in as they may not fit through a door once assembled.
!Never use any glue until you are certain that the parts belong together.
!Periodically check and re-tighten all fasteners. Check the product care label or
website for product care instructions.
!If you are having any diculties assembling your product, missing any hardware or
components please visit our website Help Centre for further assistance.
!Please see page 2 for any safety requirements or weight restrictions.
Make sure you have all the required tools.
Never use power tools unless instructed.
Useful Information
fantasticfurniture.com.au Page 3

Parts list
1 x Top Panel (P1)
1 x Bottom Panels (P2)
2 x Side Panels (P3)
1 x Divider Panel (P4)
1 x Back Panel (P5)
2 x Drawer Fronts (P6)
Top Panel (P1)
What you need
to assemble the product
Other tools you need
Flat Head Screwdriver;
Phillips Head Screwdriver;
Mallet
fantasticfurniture.com.au
Page 4
Bottom Panel (P2)
Side Panel
(P3)
Back Panel
(P5)
Drawer Front
(P6)
Drawer Back
(P9)
Drawer Base
(P10)
Drawer Left
Side (P7)
Drawer Right
Side (P8)
Side Panel
(P3)
Divider Panel
(P4)
Drawer Front
(P6)
Drawer Support (P11)
(P7)
(P10)
(P9)
(P8)
(P11)
Leg
(P12)
Leg
(P12)
2 x Drawer Left Sides (P7)
2 x Drawer Right Sides (P8)
2 x Drawer Backs (P9)
2 x Drawer Bases (P10)
2 x Drawer Supports (P11)
4 x Legs (P12)

fantasticfurniture.com.au
Page 5
Hardware Pack
24 x Cam Bolts
(H1)
12 x Large Cam
Nuts (H2)
12 x Dowels ø8mm
(H3)
2 x Handles
(H4)
4 x Screws 16mm
(H6)
12 x Flat Washers
(H9)
8 x Spring
Washers (H10)
4 x Screws 28mm
(H11)
1 x Allen Key
(H12)
4 x Felt Feet
(H5)
8 x Bolts
(H8)
4 x Back Panel
Connectors (H7)
2 x Screws 25mm
(H14)
12 x Small Cam
Nuts (H15)
2 x Wall Straps
(H13)
4 x Dowels ø6mm
(H16)
12 x Screws 38mm
(H17)
4 x Slides
(H19)
24 x Screws 12mm
(H18)

Step 1
Page 6fantasticfurniture.com.au
You will need
Attach 1 x felt foot (H5) onto each leg (P12) as shown.
Step 2
You will need
8 x Bolts
(H8)
Attach 1 x leg (P12) onto bottom panel (P2), using 2 x bolts (H8), 2 x spring washers (H10)
and 2 x flat washers (H9).
Tighten the bolts with allen key (H12).
Repeat this step for the other 3 x legs (P12).
With assistance, turn the assembled frame over.
(P12)
4 x Felt Feet
(H5)
X4
H5
8 x Flat
Washers (H9)
8 x Spring
Washers (H10)
1 x Allen Key
(H12)
(P12)
H12
H8
H9
H10
(P2)
(P12)
(P12)
(P12)
(P12)
(P2)
Required
Two People

Step 3
Page 7fantasticfurniture.com.au
You will need
Step 4
You will need
(P2)
H1
Screw 6 x cam bolts (H1) into top panel (P1), using a phillips head screwdriver.
6 x Cam Bolts
(H1)
Phillips Head
Screwdriver
6 x Cam Bolts
(H1)
Phillips Head
Screwdriver
Screw 6 x cam bolts (H1) into bottom panel (P2), using a phillips head screwdriver.
H1
H1
H1
H1
H1
H1
H1
H1
H1
H1
H1
(P1)

Step 5
Page 8fantasticfurniture.com.au
You will need
Phillips Head
Screwdriver
6 x Screws
12mm (H18)
4 x Slides
(H19)
Mallet
H19
Separate the slide runners (H19-2) and slide tracks (H19-1)
from 4 x slides (H19) by following the steps below:
Extend the slide runner all the way out.
Press down the plastic release lever on the slide
and pull out the slide runner (H19-2) completely.
H19
Slide runner H19-2 Slide track H19-1
Note the position
of the rubber stopper
Attach 1 x separated slide track (H19-1) onto side panels (P3) with 3 x screws (H18),
using a phillips head screwdriver as shown.
Repeat this step for the other side panel (P3).
Ensure the slide tracks (H19-1) are attached so the rubber stopper is positioned near
the grooves on the side panel (P3).
Insert 4 x dowels (H3) into each panel (P3) as shown.
If needed use a mallet to gently tap the dowels into place.
H19-1
8 x Dowels
ø8mm (H3)
H18
(P3)
H3
H3
H3
H3
X2
H18
H18 H19-1
H19-1
H19-1
Adjust runner to access the screw holes.
Please fasten the screws through
these holes for this step.

Step 6
Page 9fantasticfurniture.com.au
You will need
Phillips Head
Screwdriver
6 x Screws
12mm (H18)
2 x Slide
Tracks (H19-1)
Mallet
H19-1
Note the position
of the rubber stopper
Insert 4 x dowels (H3) into divider panel (P4) as shown.
If needed use a mallet to gently tap the dowels into place.
Attach 1 x slide track (H19-1) onto the side of divider panel (P4) without cam nut holes
using 3 x screws (H18) as shown.
Turn divider panel (P8) over.
Attach 1 x slide track (H19-1) onto divider panel (P4) with 3 x screws (H18) as shown,
using a phillips head screwdriver.
It is important to note that the screws on this side need to be fixed into dierent holes
compared to the slide track (H19-1) on the other side of the divider panel (P4).
H19-1
4 x Dowels
30mm (H3)
H18
(P4)
H3
H18
Important Note:
The screws need to be fixed
into dierent holes compared
to the other side.
H19-1
H19-1
H3
H3
H3
H19-1
H19-1
H18
H18
H18
H18
(P4)
Please fasten the screws through
these holes for this step
Please fasten the screws through
these holes for this step

Step 7
Page 10fantasticfurniture.com.au
You will need
Position panels (P3 x 2, P4) onto bottom panel (P2) as shown.
Make sure the grooves in panels (P2, P3) are on the same side.
Insert 6 x large cam nuts (H2) into panels (P3 x2, P4).
Rotate the cam nuts so the arrows point towards the incoming
cam bolts and turn clockwise to lock with a flat head screwdriver.
Step 8
Slide back panel (P5) into the grooves
on side panels (P3) and bottom panel (P2).
Flat Head
Screwdriver
6 x Large Cam
Nuts (H2)
This is how a cam nut works........
The head of the cam
bolt goes into the open
mouth of the cam nut.
You then turn the cam
nut so it tightens over
the bolt.
(P2)
(P2)
(P5)
(P4)
(P3)
(P3)
(P3)
(P3)
Laminated
edge
H2
H2
H2
H2
H2
H2

Step 9
Page 11fantasticfurniture.com.au
You will need
Position top panel (P1)
onto panels (P3 x 2, P4) as shown.
Make sure the groove in
top panel (P1) is on the same side
as the back panel (P5).
Insert 6 x large cam nuts (H2)
into panels (P3 x2, P4).
Rotate the cam nuts so the arrows
point towards the incoming cam bolts
and turn clockwise to lock
with a flat head screwdriver.
Step 10
Flat Head
Screwdriver
6 x Large Cam
Nuts (H2)
(P1)
(P4)
(P3)
(P3)
H2
H2
H2 H2
H2
H2
You will need
If necessary, gently adjust the top panel (P1) sideways in either direction
until XX and YY are equal.
Holding it in place, fix 4 x back panel connectors (H7) to assembled unit
with 4 x screws (H6) as shown, using a phillips head screwdriver.
Phillips Head
Screwdriver
4 x Screws
16mm (H6)
4 x Back Panel
Connectors (H7)
H7
H7
H6
(P5)
(P5)
(P1)
(P5)
XX
YY
Required
Two People
XX=YY
XX
YY
(P1)
(P1)
H7
H7
H7
(P5)
(P1)
H7

Step 11
Page 12fantasticfurniture.com.au
You will need
Insert 1 x dowel (H16) into each drawer side panel (P7, P8) as shown.
Use a mallet to gently tap the dowels into place if needed.
Step 12
H16
You will need
X2
Mallet
4 x Dowels
ø6mm (H16) H16
(P7) (P8)
Position 1 x drawer left side (P7)
and 1 x drawer right side (P8)
and 1 x drawer support (P11) onto
drawer front (P6) ensuring the grooves
in each panel align.
Insert 6 x small cam nuts (H15)
into drawer sides (P7, P8) and drawer support (P11).
Rotate the cam nuts so the arrows point towards
the incoming cam bolts. Using a flat head screwdriver turn clockwise to lock.
Repeat this step for the other 1 x drawer left side (P7), 1 x drawer right side (P8)
and 1 x drawer support (P11).
X2
(P8)
(P7)
(P11)
H15
H15
H15
(P6)
H1
H1
H1
H1
H1
Screw 6 x cam bolts (H1) into each drawer front (P6), using a phillips head screwdriver.
12 x Cam Bolts
(H1)
Phillips Head
Screwdriver
X2
Step 13
You will need
Flat Head
Screwdriver
12 x Small Cam
Nuts (H15)
(P6)

Step 14
Page 13fantasticfurniture.com.au
Step 15
You will need
Slide drawer base (P10) into
the grooves on panels (P6, P7, P8).
Repeat this step for the other drawer assembly.
X2
(P10)
12 x Screws
38mm (H17)
Phillips Head
Screwdriver
Slide drawer base (P10) into the grooves on panels (P6, P7, P8).
Attach drawer back (P9) to an assembled drawer with 6 x screws (H17),
using a phillips head screwdriver as shown.
Repeat this step for the other drawer assembly.
X2
H17
(P7)
(P8)
(P11)
H17
(P9)
(P7)
(P8) (P6)
Ensure the pre-drilled holes on drawer sides (P7, P8)
align with holes on back panel (P9),
and the holes on back panel (P9) H17
align with the holes on
drawer support (P11).
(P6)

Step 16
Page 14fantasticfurniture.com.au
You will need
Step 17
You will need
Attach 1 x slide runner (H19-2) to each drawer left side (P7) and drawer right side (P8)
with 3 x screws (H18), using a phillips head screwdriver as shown.
Repeat this step for the other drawer assembly.
4 x Screws
28mm (H11)
Phillips Head
Screwdriver
2 x Handles
(H4)
Attach 1 x handle (H4) onto a drawer front (P6) with 2 x screws (H11),
using a phillips head screwdriver as shown.
Repeat this step for the other drawer assembly.
4 x Slide
Runners (H19-2)
Phillips Head
Screwdriver
12 x Screws
12mm (H18)
H11
H19-2
(P7)
H19-2
H19-2
(P8)
X2
X2
H4
(P6)
Please fasten the screws through
these holes for this step.

Step 18
Page 15fantasticfurniture.com.au
Move inner ball bearing track
to front of slide track (H19-1).
H19-2
H19-1
Gently insert drawer slide runner (H19-2)
in between the ball bearing track.
Position drawer so that slide runners (H19-2) align with slide tracks (H19-1) as shown.
Gently push drawer into the closed position.

Step 19
Page 16fantasticfurniture.com.au
You will need
Step 20
You will need
Fix 2 x wall straps (H13) to top panel (P1) with 2 x screws (H14)
and 2 x flat washers (H9) as shown, using a phillips head screwdriver.
(P1)
H13
H9
H14
H13
H14 H9
(P1)
H13
H9
H14
(P5)
(P5)
2 x Flat
Washers (H9)
2 x Screws
25mm (H14)
2 x Wall Straps
(H13)
Phillips Head
Screwdriver
2 x Flat
Washer (H9)
Phillips Head
Screwdriver
Seek advice from a qualified
trades person on how to
attach this wall strap to
your specific wall.
Screw and wall plug are not included.
Please use appropriate fixtures for your wall.
With assistance, move the console table to the final position.
Attach the wall straps to the wall.
Make sure they are firmly attached and secure.
H9
Wall
Screw
We strongly recommend
that this product is permanently
fixed to the wall
or other suitable surface.
Required
Two People

Step 21
Page 17fantasticfurniture.com.au
Job complete!
In the interest of our environment please dispose
of all packaging thoughtfully.
