Feig Electronic ID ISC.MRMU102-A User manual

Date: 2012-06-11
Vers. no. 1.12
m. dudde hochfrequenz-technik
Rottland 5a
D-51429 Bergisch Gladbach/ Germany
Tel: [phone]
Fax [phone]
Annex no. 5
User Manual

INTEGRATION
final – public (B)
2012-12-03 – Integration Manual M21112-1e-ID-B.docx
ID ISC.MRMU102-A
Module Version

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 2 of 21 Integration Manual M21112-1e-
ID-B.docx
Note
Copyright 2012 by
FEIG ELECTRONIC GmbH
Lange Strasse 4
D-35781 Weilburg
Tel.: [phone]
http://www.feig.de
With the edition of this document, all previous editions become void. Indications made in this manual may be
changed without previous notice.
Copying of this document, and giving it to others and the use or communication of the contents thereof are
forbidden without express authority. Offenders are liable to the payment of damages. All rights are reserved
in the event of the grant of a patent or the registration of a utility model or design.
Composition of the information in this document has been done to the best of our knowledge. FEIG
ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this
manual and may not be held liable for damages ensuing from incorrect or incomplete information. Since,
despite all our efforts, errors may not be completely avoided, we are always grateful for your useful tips.
The instructions given in this manual are based on advantageous boundary conditions. FEIG ELECTRONIC
GmbH does not give any guarantee promise for perfect function in cross environments and does not give
any guaranty for the functionality of the complete system which incorporates the subject of this document.
FEIG ELECTRONIC call explicit attention that devices which are subject of this document are not designed
with components and testing methods for a level of reliability suitable for use in or in connection with surgical
implants or as critical components in any life support systems whose failure to perform can reasonably be
expected to cause significant injury to a human. To avoid damage, injury, or death, the user or application
designer must take reasonably prudent steps to protect against system failures.
Use Exclusion in Transportation Market: Devices which are subject of this document may NOT be sold,
used, leased, offer for sale, or otherwise transferred, exported, and imported by anyone in the Transportation
Market. “Transportation Market” means (i) Electronic Toll and Traffic Management (ETTM), (ii) Public Sector
Vehicle Registration, Inspection and Licensing Programs, (iii) Railroad Locomotive and Wagon tracking, (iv)
airport based ground transportation management systems (GTMS) and taxi dispatch, (v) revenue based
parking, and (vi) vehicle initiated mobile payment applications, where the RFID sticker/tag is initially attached
to the vehicle but not incorporated at the point of vehicle manufacture.
FEIG ELECTRONIC GmbH assumes no responsibility for the use of any information contained in this docu-
ment and makes no representation that they free of patent infringement. FEIG ELECTRONIC GmbH does
not convey any license under its patent rights nor the rights of others.
OBID®and OBID i-scan®are registered trademarks of FEIG ELECTRONIC GmbH.

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 3 of 21 Integration Manual M21112-1e-
ID-B.docx
General information's regarding this document
•The sign "" indicates extensions or changes of this manual compared with the former issue.
•If bits within one byte are filled with "-", these bit spaces are reserved for future extensions or
for internal testing- and manufacturing-functions. These bit spaces must not be changed, as this
may cause faulty operation of the reader.
•The following figure formats are used:
0...9: for decimal figures
0x00...0xFF: for hexadecimal figures,
b0...1 for binary figures.
•The hexadecimal value in brackets "[ ]" marks a control byte (command).

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 4 of 21 Integration Manual M21112-1e-
ID-B.docx
Contents
1. Safety Instructions / Warning - Read before start-up ! 5
2. Performance Features of the Reader 6
2.1. Available Reader Types ....................................................................................................6
2.2. Optional Accessories........................................................................................................6
3. Assembly and Wiring 7
3.1. Module Versions................................................................................................................7
3.1.1. Dimensions..................................................................................................................7
4. Connections 8
4.1. Antenna Terminals............................................................................................................8
4.1.1. External Antenna ANT 1 - 3 .........................................................................................8
4.1.2. Internal Antenna ANT 4..............................................................................................10
4.2. Power Supply via Connector X1.....................................................................................10
4.3. RS232 Interface on Connector X2 ..................................................................................11
4.4. USB Interface on Connector X3......................................................................................12
5. Control and Display Elements 12
5.1. LED...................................................................................................................................12
6. Technical Data 13
7. Radio Approvals 16
7.1. Europe (CE)......................................................................................................................16
7.2. Declaration of Conformity...............................................................................................17
7.3. USA (FCC) and Canada (IC)............................................................................................19
7.3.1. USA (FCC) and Canada (IC) warning notices............................................................ 19
7.3.2. USA (FCC) and Canada (IC) approved antennas ...................................................... 20
ANNEX A - Accessories.........................................................................................................21

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 5 of 21 Integration Manual M21112-1e-
ID-B.docx
1. Safety Instructions / Warning - Read before start-up !
•The device may only be used for the intended purpose designed by for the manufacturer.
•The operation manual should be conveniently kept available at all times for each user.
•Unauthorized changes and the use of spare parts and additional devices which have not been
sold or recommended by the manufacturer may cause fire, electric shocks or injuries. Such
unauthorized measures shall exclude any liability by the manufacturer.
•The liability-prescriptions of the manufacturer in the issue valid at the time of purchase are valid
for the device. The manufacturer shall not be held legally responsible for inaccuracies, errors,
or omissions in the manual or automatically set parameters for a device or for an incorrect
application of a device.
•Repairs may only be executed by the manufacturer.
•Installation, operation, and maintenance procedures should only be carried out by qualified
personnel.
•Use of the device and its installation must be in accordance with national legal requirements
and local electrical codes .
•When working on devices the valid safety regulations must be observed.
•Special advice for carriers of cardiac pacemakers:
Although this device doesn't exceed the valid limits for electromagnetic fields you should keep
a minimum distance of 25 cm between the device and your cardiac pacemaker and not stay in
an immediate proximity of the device respective the antenna for some time.

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 6 of 21 Integration Manual M21112-1e-
ID-B.docx
2. Performance Features of the Reader
The Reader ID ISC.MRMU102 is designed for reading of passive data carriers, so-called „Smart
Labels“ at an operating frequency in the UHF band between 860 MHz and 960 MHz. Transponders
according to EPC Class1 Gen2 are supported. Optional an Upgrade Code for the reading of ISO
18000-6-C transponders is available. The reader is designed for application with small tag popula-
tion.
The reader module is equipped with 3 SMA connectors for conduction of external antennas (ANT1
– ANT3). Additional an integrated antenna (ANT4) is available.
For Host communication the reader provides an asynchronous RS232 interface and an USB inter-
face.
The reader is designed for use in applications with small tag populations. Maximum 10 tags at the
same time into the antenna field can be processed.
2.1. Available Reader Types
The following reader types are currently available:
Table 1: Available Reader Types
Reader type Description
ID ISC.MRMU102-A
Module version with asynchronous RS232- and USB-Interface;
3 SMA connectors for external antennas;
1 integrated antenna;
2.2. Optional Accessories
Optional Accessories are listed in the appendix.

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 7 of 21 Integration Manual M21112-1e-
ID-B.docx
3. Assembly and Wiring
3.1. Module Versions
This reader version has been designed for mounting in other equipment.
NOTE:
Before any installation the intended position of the reader should be tested for its suitabil-
ity.
3.1.1. Dimensions
77
137
Ø3,3
Ø7
125
107,5
65
LED
ANT1
FE 741
68,5
54,5
29,5
X2
X3
38,5
ANT2
22,5
ANT3
4,75
[DB1]
Figure 1: Dimensions of the housing version (all dimensions are in mm)

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 8 of 21 Integration Manual M21112-1e-
ID-B.docx
4. Connections
The module version of the reader is equipped with an asynchronous RS232 Interface (X2) and a
USB Interface (X3). The Table 2: Connectors shows which connector can be used for the different
interface cable.
Table 2: Connectors
Connector Description
ANT 1-3 External Antenna ANT 1 - 3
ANT 4 Internal Antenna ANT 4
X1 Power Supply via Connector X1
X2 RS232 Interface on Connector X2
X3 USB Interface on Connector X3
4.1. Antenna Terminals
4.1.1. External Antenna ANT 1 - 3
Three SMA sockets are provided on the circuit board for connecting of the external antennas.
The maximum tightening torque for the SMA socket is 0.45 Nm.
CAUTION:
Higher tightening torque will damage the connector.
Table 3: Connecting an external antenna
Terminal Description
ANT 1-3 Connecting the external antenna
(input impedance 50Ω)
NOTE:
When connecting an antenna, ensure that it does not exceed the permissible limits pre-
scribed by the national regulations for radio frequency devices.

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 9 of 21 Integration Manual M21112-1e-
ID-B.docx

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 10 of 21 Integration Manual M21112-1e-
ID-B.docx
4.1.2. Internal Antenna ANT 4
Additionally the reader is equipped with an internal antenna (ANT4). The internal antenna supports
far field transponders as well as near field transponders. The internal antenna is located in the bot-
tom left corner of the housing and is marked with an antenna symbol. The maximum read range of
the antenna in combination with a far field transponder is approx. 40 cm. In combination with a
near field transponder the maximum read range is approx. 5 cm.
Figure 2: Position of the internal antenna
4.2. Power Supply via Connector X1
The reader needs to be supplied by an external voltage of 12 V DC to 24 V DC. Connect the 12 -
24 V DC/ supply voltage to socket X1 on the circuit board.
Terminal Name Description X 1
X1 / inside Vcc Vcc – supply voltage (+)
X1 / outside GND Ground – supply voltage (-)
Table 4: Connecting the supply voltage
NOTE:
Reversing the polarity of the supply voltage may destroy the device.
The unit has to supplied by a listed NEC Class 2/LPS Power supply, only
NOTE:
The power supply is supplied with a DC/ plug 2.5mm x 5.5mm. This is compatible with
the readers socket X1.

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 11 of 21 Integration Manual M21112-1e-
ID-B.docx
4.3. RS232 Interface on Connector X2
For the connection of the asynchronous interface RS232 the reader provides a 9-pin D-
Subminiature female connector. (See also Connections).
Table 5: Connection assignment of the connector X2
X2 Interface
2 TxD
3 RxD
5 GND
7 GND
1;4;6;8;9 n.c.
For this reader a serial cable is available.
Table 6: Serial Data Cable
Feig Part No. Description
1690.000.00 ID CAB.RS-A
Interface parameter can be configured via software protocol (e.g. ISOStart). Further information
can be found in the System Manual H10410-Xe-ID-B.pdf of the reader.

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 12 of 21 Integration Manual M21112-1e-
ID-B.docx
4.2. USB Interface on Connector X3
There is a USB-socket X3 on board for the connection of the USB-Interface. The pinout is stand-
ardized. The data rate is reduced to 12 Mbit (USB full speed). A standard USB-cable can be used.
Figure 3: USB interface for host communication
NOTE:
The length of the USB-cable can be a max. of 5 meter. It isn’t allowed to use longer cables!
The reader must be powered with a external power supply even if it is connected to a “high
powered port”.
5. Control and Display Elements
5.1. LED
The Reader’s LED can be configured through software.
The following Table 8: Default Configuration of the LEDs shows the default setting.
Table 7: Default Configuration of the LEDs
Abbreviation Description
LED green "RUN "
-Turns on when the Reader is ready
LED red
„LABEL“
-Turns on when a transponder is detected.
-Flashes if RF-Warning (red – green alternating with 8Hz)
(Temperature alarm, short circuit on antenna output)
LED orange „INITIALIZING“
- Flashes during Reader initialization after power-up.

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 13 of 21 Integration Manual M21112-1e-
ID-B.docx
6. Technical Data
MECHANICAL DATA
Housing -
Dimension (W x H x D) 137 mm x 77 mm x 17 mm
Weight 60 g
Protection Class -
Colour -
ELECTRICAL DATA
Power Supply 12 V DC – 24 V DC
Power Consumption max. 7 W
Operating Frequency 860 MHz to 960 MHz
RF-Power max. 500 mW ±1,5 dB
Antenna Connector 3 x SMA female(50 Ω)
1 x integrated Antenna (ANT4)
Interfaces USB (Full Speed)
RS232
FUNCTIONAL PROPERTIES
Protocol Modes FEIG ISO HOST (Advanced Protocol Frame)
Buffered Read Mode
Scan Mode (RS232, USB: HID Mode)
Supported Transponder Types EPC Class 1 Generation 2
ISO 18000-6-C (Upgrade Code required)
Signaller 1 LED (multi-colour red and green)

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 14 of 21 Integration Manual M21112-1e-
ID-B.docx
Further Features Anticollision (max. 10 Transponders)
RSSI
Temperature Monitoring*
AMBIENT CONDITIONS
Temperature Range
•Operation
•Storage
-25 °C to +55 °C
-25 °C to +85 °C
Humidity 5 % to 95 % non-condensing
APPLICABLE STANDARDS
Radio Regulation
•Europe
•USA
•Canada
EN 302 208
FCC 47 CFR Part 15
IC RSS-Gen, RSS-210
EMC EN 301 489
Vibration EN 60068-2-6
10 Hz bis 150 Hz: 0,075 mm / 1 g
Shock EN 60068-2-27
Accelleration 30 g

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 15 of 21 Integration Manual M21112-1e-
ID-B.docx
* Caution: Overheating of the device may result in performance losses. It is recommended to activate the RF of the reader only if there is a transponder in
the detection range of an antenna.

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 16 of 21 Integration Manual M21112-1e-
ID-B.docx
7. Radio Approvals
7.1. Europe (CE)
When used according to regulation, this radio equipment conforms with the basic requirements of
Article 3 and the other relevant provisions of the R&TTE Guideline 1999/E6 dated March 99.
Equipment Classification according to ETSI EN 301 489: Class 2

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 17 of 21 Integration Manual M21112-1e-
ID-B.docx
7.2. Declaration of Conformity

OBID
i-scan
®
UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH Page 18 of 21 Integration Manual M21112-1e-
ID-B.docx

OBIDi-scan® UHF
Integration
ID ISC.MRMU102-A
FEIG ELECTRONIC GmbH
Page 19 of 21
Integration Manual M21112-1e-
ID-B.docx
7.3. USA (FCC) and Canada (IC)
7.3.1. USA (FCC) and Canada (IC) warning notices
Product name:
ID ISC.MRMU102-A
Reader name:
ID ISC.MRMU102-A
FCC ID:
IC:
PJMMRU102
6633A-MRM102
Notice for USA and
Canada
This device complies with Part 15 of the FCC Rules and with
RSS-210 of Industry Canada.
Operation is subject to the following two conditions.
(1) this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired operation.
Unauthorized modifications may void the authority granted under
Federal communications Commission Rules permitting the operation
of this device.
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Le présent appareil est conforme aux CNR d'Industrie Canada appli-
cables aux appareils radio exempts de licence. L'exploitation est auto-
risée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le fonc-
tionnement.
Warning: Changes or modification made to this equipment not expressly approved by
FEIG ELECTRONIC GmbH may void the FCC authorization to operate this equipment.
