Original Instructions for Cordless MULTIMASTER.
Symbols, abbreviations and terms used.
Symbol, character Explanation
Make sure to read the enclosed documents such as the Instruction Manual and the General
Safety Instructions.
Do not touch the saw blade. Danger of sharp application tools moving back and forth.
Warning against sharp edges of application tools, such as the cutting edges of the cutter
blades.
Observe the instructions in the text or graphic opposite!
Before commencing this working step, remove the battery from the power tool. Other-
wise there may be danger of injury caused by unintentional starting of the power tool.
Use eye protection during operation.
Use ear protection during operation.
Use a dust mask during operation.
Use protective gloves during operation.
Gripping surface
Do not charge damaged batteries.
Keep the battery away from fire. Protect the battery against heat, e. g., against continuous
intense sunlight.
Observe the information in the adjacent text!
Confirms the conformity of the power tool with the directives of the European Commu-
nity.
This sign indicates a possible dangerous situation that could cause severe or fatal injury.
Recycling symbol: designates recyclable materials
Worn out power tools and other electrotechnical and electrical products should be
sorted separately for environment-friendly recycling.
Battery type
Low oscillation rate
High oscillation rate
WARNING
Character Unit of measure,
international Unit of measure, national Explanation
UVVRatedvoltage
nS/min /min Rated oscillation rate
° ° Oscillation angle
