Festo CPX-FB6 User manual

Description
Electronics
CPX fieldbus node
Type CPX-FB6
Fieldbus protocol:
Interbus
in accordance
with EN 50254
CPX terminal
Description
526434
en 1207c
[762320]

Contents and general safety instructions
I
Festo P.BE-CPX-FB6-EN en 1207c
Original de.......................................
Version en 1207c...................................
Designation P.BE-CPX-FB6-EN........................
Order no. 526434..................................
E(Festo AG & Co. KG, D-73726 Esslingen, 2012)
Internet: http://www.festo.com
E-Mail: [e-mail]
Reproduction, distribution or sale of this document or com-
munication of its contents to others without express author-
ization is prohibited. Offenders will be liable for damages.
All rights reserved in the event that a patent, utility model
or design patent is registered.

Contents and general safety instructions
II
Festo P.BE-CPX-FB6-EN en 1207c
INTERBUS
®
,TORX
®
and VDE
®
are registered trademarks of the respective trademark
ownersincertaincountries.

Contents and general safety instructions
III
Festo P.BE-CPX-FB6-EN en 1207c
Ta b l e o f c o n t e n t s
Intended use III..........................................................
Target group IV..........................................................
Service IV...............................................................
Important user information V..............................................
Instructions on this description VII...........................................
1. Installation 1-1...................................................
1.1 General installation instructions 1-3...................................
1.2 Settings of the DIL switches on the bus node 1-7.........................
1.3 Connecting the fieldbus 1-14..........................................
1.3.1 System structure on the remote bus 1-14........................
1.3.2 Pin allocation of the fieldbus interface 1-17.......................
1.3.3 Connecting the fieldbus 1-18..................................
1.3.4 Fieldbus baud rate and fieldbus length 1-21......................
1.4 Fibre-optic cable connection for Interbus 1-22............................
1.5 Selection of the power supply unit 1-23.................................
1.6 Pin allocation of power supply 1-23....................................
2. Commissioning 2-1................................................
2.1 Configuration and addressing 2-4.....................................
2.1.1 Ascertaining the address range 2-4............................
2.1.2 Address assignment of the CPX terminal 2-14.....................
2.1.3 Address assignment after extension/conversion 2-24..............
2.1.4 Bus configuration and addressing 2-27..........................
2.1.5 Switching on the power supply 2-28............................
2.1.6 Bus configuration with the CMD software 2-29....................
2.1.7 Bus configuration without CMD software 2-38....................
2.1.8 Process data entry via the CMD software 2-39....................
2.1.9 Configuration in the remote controller operating mode 2-42.........
2.2 Parametrisation 2-43................................................
2.2.1 Parametrisation concepts 2-45.................................
2.2.2 Device parametrisation with the CMD software 2-49...............

Contents and general safety instructions
IV
Festo P.BE-CPX-FB6-EN en 1207c
2.2.3 Parametrisation with CMD user functions 2-50....................
2.2.4 Parametrisation with the PLC user program 2-53..................
2.3 Commissioning the CPX terminal on the Interbus 2-54.....................
2.3.1 Fail safe 2-55...............................................
3. Diagnostics and error handling 3-1...................................
3.1 Summary of diagnostics options 3-4...................................
3.2 Diagnostics via LEDs 3-6............................................
3.2.1 Normal operating status 3-7..................................
3.2.2 CPX-specific LEDs 3-8.......................................
3.2.3 Interbus-specific LEDs 3-11....................................
3.3 Diagnostics via Interbus 3-13.........................................
3.3.1 Status bits 3-13.............................................
3.3.2 I/O diagnostics interface 3-15..................................
3.3.3 Diagnostics via the PCP channel 3-16............................
3.3.4 Peripheral faults (PF) 3-18.....................................
3.4 Error handling 3-20..................................................
A. Technical appendix A-1.............................................
A.1 Technical data bus node type CPX-FB6 A-3..............................
A.2 Accessories A-5....................................................
A.3 Access to parameters and data via the PCP channel A-6...................
A.4 Parameters in the operating mode Remote I/O A-8.......................
A.4.1 System parameters A-8......................................
A.4.2 Module parameters A-9......................................
A.4.3 Diagnostic memory parameters A-18............................
A.4.4 Diagnostic memory data A-18..................................
A.4.5 System diagnostics data A-20..................................
A.4.6 Module diagnostics data A-21..................................
A.4.7 System data A-22............................................
A.4.8 Module data A-22............................................
A.4.9 Length of the PCP data objects A-24.............................
B. Index B-1.........................................................

Contents and general safety instructions
V
Festo P.BE-CPX-FB6-EN en 1207c
Intended use
The bus node documented in this description CPX-FB06 is
exclusively for use as a participant in the Interbus.
The CPX terminal must only be used as follows:
– as intended in an industrial environment
– in original condition, without unauthorised modifications.
Only the conversions or modifications described in the
documentation supplied with the product are permitted.
– in excellent technical condition.
If standard ancillary components, such as sensors and actuat-
ors, are connected, the specified limits for pressures, temper-
atures, electrical data, torques, etc. must be complied with.
Observe the standards specified in the respective chapters
and comply with the regulations of the trade association and
the German Technical Control Board (TÜV), the VDE specifica-
tions or relevant national regulations.
Warning
• Only use PELV circuits in accordance with IEC/EN
60204-1 (protective extra-low voltage, PELV) for the elec-
trical power supply.
• Observe also the general requirements for PELV power
circuits in accordance with IEC/EN 60204-1.
• Only use voltage sources which guarantee reliable elec-
trical isolation of the operating voltage in accordance
with IEC/EN 60204-1.
Through the use of PELV circuits, protection against electric
shock (protection against direct and indirect contact) is en-
sured in accordance with IEC/EN 60204-1.

Contents and general safety instructions
VI
Festo P.BE-CPX-FB6-EN en 1207c
Target group
This description is intended exclusively for technicians
trained in control and automation technology, who have ex-
perience in installing, commissioning, programming and dia-
gnosing slaves on the Interbus.
Service
Please consult your local Festo Service if you have any tech-
nical problems.

Contents and general safety instructions
VII
Festo P.BE-CPX-FB6-EN en 1207c
Important user information
Danger categories
This description includes instructions on the possible dangers
which can occur if the product is used incorrectly. These in-
structions are marked with a signal word (Warning, Caution,
etc.), printed on a shaded background and marked addition-
ally with a pictogram. A distinction is made between the fol-
lowing danger warnings:
Warning
... means that failure to observe this instruction may result
in serious personal injury or material damage.
Caution
... means that failure to observe this instruction may result
in personal injury or material damage.
Note
... means that failure to observe this instruction may result
in material damage.
In addition, the following pictogram marks passages in the
text which describe activities with electrostatically sensitive
devices:
Electrostatically sensitive devices: Incorrect handling may
cause damage to devices.

Contents and general safety instructions
VIII
Festo P.BE-CPX-FB6-EN en 1207c
Marking special information
The following pictograms mark passages in the text which
contain special information.
Pictograms
Information:
Recommendations, tips and references to other information
sources.
Accessories:
Specifications on necessary or useful accessories for the
Festo product.
Environment:
Information on the environmentally friendly use of Festo
products.
Text designations
• Bullet points indicate activities which may be carried out
in any sequence.
1. Numerals identify activities which must be carried out in
the sequence specified.
– Arrowheads indicate general lists.

Contents and general safety instructions
IX
Festo P.BE-CPX-FB6-EN en 1207c
Instructions on this description
This description contains information about the following
module:
CPX bus node Type
designation
Description Connection technology
CPX-FB6 CPX bus node for Interbus
Data transmission:
– Interbus uses the closed
loop protocol (user data are
encapsulated by outline
data).
– Real-time-capable
Standards and norms with ref-
erence to Interbus:
– EN 50254
– IEC 61158
– IEC 61784
incoming: Sub-D (plug)
continued: Sub-D (socket)
Tab. 0/1: Overview, CPX bus node for Interbus

Contents and general safety instructions
X
Festo P.BE-CPX-FB6-EN en 1207c
Note
This description refers to the following revision:
Revisions Newly supported modules
as from software status 26 May
2003
1)
– Support for the handheld,
type CPX-MMI-1
– MPA1 pneumatics (type 32)
from Revision 22
2)
– MPA1 pneumatics (type 33
and 34)
– MPA2 pneumatics (type 32,
33 and 34)
– CPX-FB6 as remote controller
(e.g. with CPX-FEC)
–CPX-CPinterface
– Pneumatic interface for
VTSA- and /VTSA-F-Pneu-
matic (Type 44 and 45)
1)
Software status (SW) see name plate
2)
Revision identification, see name plate
Fig. 0/1: New CPX-FB6 modules supported through the bus
node
This description contains specific information on installing,
commissioning, programming and diagnosing with the CPX
bus node for Interbus.
Additional information about Interbus can be obtained in the
internet:
– www.interbusclub.com
– www.ibsclub.com
General basic information about the mode of operation,
mounting, installation and commissioning of CPX terminals
can be found in the CPX system description.

Contents and general safety instructions
XI
Festo P.BE-CPX-FB6-EN en 1207c
Information about additional CPX modules can be found in
the description for the respective module.
An overview of the structure of the CPX terminal user docu-
mentation is contained in the CPX system description.
Product-specific information about the control system (IPC,
PLC or I/O controller) can be found in the manufacturer's
product documentation accompanying the product.

Contents and general safety instructions
XII
Festo P.BE-CPX-FB6-EN en 1207c
The following product-specific terms and abbreviations are
used in this manual.
Term/abbreviation Significance
A0
H
Hexadecimal numbers are marked by a low-set “h”
Bus nodes Create the connection to certain networks or fieldbusses, pass on control
signals to the connected modules and monitor their functioning
CP Compact Performance installation system, comprising a CP master with
one or more CP strings. The system consists of CP or CPI modules (without
or with extended functions).
CPA Pneumatic modules/valve terminal type 12
CPX bus Data bus via which the CPX modules communicate with each other and
are supplied with the necessary operating voltage.
CPX modules Collective term for the various modules which can be integrated into a
CPX terminal.
CMD software Parametrisation, commissioning and diagnostic software for stations on
the Interbus (configuration, monitoring, diagnostics).
CPX terminal Modular electric terminal type 50
DIL switch Dual-in-line switches consist of several switch elements with which set-
tings can be made.
FEC Front End Controller, e.g. CPX-FEC, can be used as:
– stand-alone system controller (PLC, stand alone operating mode)
– system controller (PLC, remote controller operating mode)
– fieldbus slave (remote I/O operating mode)
Handheld Handheld terminal (handheld, CPX-MMI) for CPX modules for commission-
ing and service purposes (man-machine interface, MMI)
IDigital input
ID code By means of the Identification code (in brief: ident. code), the interface
module ascertains the type and the process data length of all stations.
Interface module The interface module is the central device for controlling the Interbus data
ring. It exchanges the data transported serially in the data ring with the
higher-order controller or computer system and the lower-order Interbus
stations in both directions acyclically or cyclically.

Contents and general safety instructions
XIII
Festo P.BE-CPX-FB6-EN en 1207c
Term/abbreviation Significance
I/Os Digital inputs and outputs
I/O diagnostic interface The I/O diagnostic interface is a bus-independent diagnostic interface at
I/O level, permitting access to internal data of the CPX terminal.
I/O modules Common term for the CPX modules which provide digital inputs and out-
puts (CPX input modules and CPX output modules).
Midi/maxi Pneumatic modules/valve terminal type 03
MPA Pneumatic modules/valve terminal type 32
ODigital output
Parameter data Data for parametrisation, diagnostics and configuration which are trans-
mitted acyclically in a multiplex procedure via the PCP channel.
PCP channel Stations that can also process parameter data are also known as PCP
stations. Communication between these stations and the interface mod-
ule takes place via the Peripheral Communication Protocol (in brief: PCP
or PCP channel). PCP is an integral part of the Interbus protocol.
Peripheral faults (PF) Malfunctions in the peripherals of Interbus stations are shown by means
of peripheral faults (dependent on station), e.g.:
– load voltage failure
– short circuit at the outputs, etc.
The peripheral fault is a common error message and does not contain any
module-specific information.
PLC/IPC Programmable logic controller/industrial PC
Pneumatics interface The pneumatics interface is the interface between the modular electrical
peripherals and the pneumatics.
Process data I/O data from the Interbus stations transmitted cyclically via the Interbus,
e.g. for:
– light barriers, sensors
– valves, contactors
– diagnostic I/Os.
Remote bus The remote bus bridges long distances within an Interbus system (main
string). With baud rates of 500 kBd and 2 MBd, it can be up to 12.8 km
long (from the interface module to the last connected remote bus sta-
tion). Individual segments can be up to 400 m long.

Contents and general safety instructions
XIV
Festo P.BE-CPX-FB6-EN en 1207c
Term/abbreviation Significance
Status bits Internal inputs which supply coded common diagnostic messages.
VTSA Pneumatic modules/valve terminal type 44
Tab. 0/2: CPX-specific or Interbus-specific terms and abbreviations

Installation
1-1 Festo P.BE-CPX-FB6-EN en 1207c
Chapter 1
Installation

1. Installation
1-2
Festo P.BE-CPX-FB6-EN en 1207c
Ta b l e o f c o n t e n t s
1. Installation 1-1...................................................
1.1 General installation instructions 1-2...................................
1.2 Settings of the DIL switches on the bus node 1-6.........................
1.3 Connecting the fieldbus 1-13..........................................
1.3.1 System structure on the remote bus 1-13........................
1.3.2 Pin allocation of the fieldbus interface 1-16.......................
1.3.3 Connecting the fieldbus 1-17..................................
1.3.4 Fieldbus baud rate and fieldbus length 1-20......................
1.4 Fibre-optic cable connection for Interbus 1-21............................
1.5 Selection of the power supply unit 1-22.................................
1.6 Pin allocation of power supply 1-22....................................

1. Installation
1-3
Festo P.BE-CPX-FB6-EN en 1207c
1.1 General installation instructions
Warning
Before carrying out installation and maintenance work,
switch off the following:
• compressed air supply
• operating voltage supply for the electronics/sensors
• load voltage supply for the outputs and valves.
In this way, you can avoid:
– uncontrolled movements of loose tubing lines,
– accidental movements of the connected actuators,
– undefined switching states of the electronics.
Caution
The CPX bus node includes electrostatically sensitive com-
ponents for Interbus.
• Do not touch any contacts.
• Observe the handling specifications for electrostatically
sensitive devices.
They will help you avoid damage to the electronics.

1. Installation
1-4
Festo P.BE-CPX-FB6-EN en 1207c
Electrical connecting and display elements
The following connection and display components can be
found on the CPX bus node for Interbus:
1 Bus-status-spe-
cific and CPX-spe-
cific LEDs
2 Fieldbus connec-
tion OUT (contin-
ued, 9-pin sub-D
socket)
3 Fieldbus connec-
tion IN (incoming,
9-pin sub-D plug)
4 Service interface
for handheld, etc.
PS
PL
SF
TR
3
41
2
UL
RC
BA
RD M
Fig. 1/1: Connection and display components on the CPX bus node
