Festo CDVI-DN User manual

Description
Electronics
Valve terminal with
direct fieldbus
connection
Fieldbus protocol:
- DeviceNet
CDVI-DN type
Description
539 045
en 0805a
[720 999]
CDVI-DN Valve Terminal
(Type 15)
DeviceNet

Contents and general safety instructions
I
Festo P.BE-CDVI-DN-EN en 0805a
Original de.......................................
Edition en 0805a..................................
Designation P.BE-CDVI-DN-EN........................
Order-no. 539 045.................................
E(Festo AG & Co. KG, D-73726 Esslingen, 2008)
Internet: http://www.festo.com
E-mail: [e-mail]
Copying and distributing this document as well as utilising
and communicating its contents is prohibited without ex-
press authorisation. Offenders will be held liable for com-
pensation of damages. All rights are reserved, in particular
the right to carry out patent, registered design or ornamental
design registration.

Contents and general safety instructions
II Festo P.BE-CDVI-DN-EN en 0805a

Contents and general safety instructions
III
Festo P.BE-CDVI-DN-EN en 0805a
Contents
Intended use VI..........................................................
Target group VII..........................................................
Service VII...............................................................
Notesonthismanual VII...................................................
Important user instructions VIII..............................................
1. Installation 1-1...................................................
1.1 General installation instructions 1-3...................................
1.2 Setting the CDVI-DN 1-5.............................................
1.2.1 Removing and mounting the left-hand end plate 1-5..............
1.2.2 Setting the DIL switches 1-7..................................
1.3 Connecting to the fieldbus 1-14........................................
1.3.1 Fieldbus cable 1-14..........................................
1.3.2 Fieldbus baud rate and fieldbus length 1-15......................
1.3.3 Power supply for the DeviceNet 1-16............................
1.3.4 Pin allocation of the DeviceNet 1-17.............................
1.3.5 Connection example 1-18.....................................
1.3.6 Bus terminal with terminating resistors 1-19......................
1.4 Power supply 1-20..................................................
1.4.1 Calculation of the current consumption 1-20.....................
1.4.2 Selecting the cables 1-21.....................................
1.4.3 Selecting the power supply unit 1-21...........................
1.4.4 Connecting the power supply of the valve terminal 1-22............
1.5 Extending the CDVI 1-29..............................................
1.5.1 Inserting expansion blocks 1-29................................
1.5.2 CP extension connection 1-30..................................
2. Startup 2-1.......................................................
2.1 Preparing the CDVI valve terminal for startup 2-3........................
2.1.1 Switching on the operating voltages 2-3........................
2.1.2 Address assignment of the CDVI-DN 2-4........................
2.2 Startup on the DeviceNet 2-7.........................................

Contents and general safety instructions
IV Festo P.BE-CDVI-DN-EN en 0805a
2.2.1 General remarks 2-7........................................
2.2.2 Configuring DeviceNet station properties (EDS) 2-8...............
2.2.3 Supplementary notes: Modular EDS 2-9........................
2.2.4 General instructions for parametrisation at the DeviceNet 2-10.......
2.2.5 Parametrisation withRSNetWorx: EDS 2-12.......................
2.2.6 Device-specific parametrisation 2-20............................
2.2.7 Explicit message 2-28........................................
3. Diagnostics 3-1...................................................
3.1 Diagnostics by means of LEDs 3-3.....................................
3.1.1 Standard operating status 3-4................................
3.1.2 Indication of errors by the LEDs 3-5............................
3.1.3 LEDs as status indicators of the solenoid coils 3-8................
3.2 Reaction to malfunctions in the control system 3-9.......................
3.3 Diagnostics at the DeviceNet 3-10......................................
3.3.1 Diagnostics with the software configurator 3-10...................
3.4 Short circuit/overload 3-13...........................................
3.4.1 CP output module 3-13.......................................
3.4.2 Sensor supply at an input module 3-14..........................
A. Technical data and accessories A-1...................................
A.1 Technical data A-3..................................................
A.2 Accessories A-5....................................................
B. DeviceNet objects B-1..............................................
B.1 DeviceNet objects B-3..............................................
B.1.1 DeviceNet object model B-3..................................
B.1.2 Overview B-4..............................................
B.1.3 Discrete Input Point Object: class code 8d B-5...................
B.1.4 Discrete Output Point Object: class code 9d B-5..................
B.1.5 Festo Discrete Output Object: class code 100d B-6................
B.1.6 Festo Discrete Input Object: class code 101d B-6.................
B.1.7 Festo Diagnostics Object: class code 102d B-7...................

Contents and general safety instructions
V
Festo P.BE-CDVI-DN-EN en 0805a
B.1.8 Structure of the status byte (diagnostic bytes) B-9................
C. Index C-1.........................................................

Contents and general safety instructions
VI Festo P.BE-CDVI-DN-EN en 0805a
Intended use
The CDVI valve terminal with direct fieldbus connection
described in this manual is intended exclusively for use as
station on the DeviceNet fieldbus.
This CDVI valve terminal has been certified by the ODVA.
Thevalveterminalmaybeusedonlyasfollows:
– As intended in an industrial environment
– In original condition without unauthorized alterations.
Only the conversions or modifications described in the
documentation supplied with the product are permitted.
– In perfect technical condition
The limit values specified for pressures, temperatures, electri-
cal data, torques etc. should be observed.
If conventional accessory components such as sensors and
actuators are connected, the specified limits for pressures,
temperatures, electrical data, torques etc. should be ob-
served.
Comply with the regulations of the trade associations and
the German Technical Control Board (TÜV) and the VDE
conditions or corresponding national conditions.
Observe the measures in section 1.4.4 when implementing an
emergency stop function.

Contents and general safety instructions
VII
Festo P.BE-CDVI-DN-EN en 0805a
Warning
If the valve terminal is to be used as explosion-proof
equipment, make sure:
•Electrical connections are not disconnected under
voltage.
•The completely installed valve terminal with all the
plugs, adapters and protective caps used complies
at least with protection class IP65.
Target group
This manual is intended exclusively for technicians trained in
control and automation technology who have experience in
installing, commissioning, programming and diagnosing sta-
tions on the DeviceNet.
Service
Please consult your local Festo repair service if you have any
technical problems.
Notesonthismanual
This manual contains specific information on installing,
commissioning, programming and diagnosing CDVI valve
terminals with direct connection for DeviceNet.
Informationonthepneumaticscanbefoundinthe
“Pneumatics manual, P.BE-CDVI-....”

Contents and general safety instructions
VIII Festo P.BE-CDVI-DN-EN en 0805a
Important user instructions
Danger categories
This manual contains instructions on the possible dangers
which may occur if the product is incorrectly used. These
instructions are indicated with a signal word (Warning,
Caution etc), printed on a shaded background and addition-
ally indicated with a pictogram. A distinction is made between
the following danger warnings:
Warning
... means that failure to observe this instruction may result
in serious personal injury or material damage.
Caution
... means that failure to observe this instruction may result
in personal injury or material damage.
Note
... means that failure to observe this instruction may result
in material damage.
Electrostatically sensitive devices: inappropriate handling can
cause damage to components.

Contents and general safety instructions
IX
Festo P.BE-CDVI-DN-EN en 0805a
Identification of specific information
The following pictograms indicate text passages which
contain specific information.
Pictograms
Information:
Recommendations, tips and references to other sources of
information
Accessories:
Details on necessary or useful accessories for the product
Environment:
Information on the environment-friendly usage of the prod-
ucts
Text designations
•The bullet point indicates activities which may be carried
out in any sequence.
1. Digits indicate activities which must be carried out in the
specified sequence.
– Arrowheads indicate general lists.

Contents and general safety instructions
XFesto P.BE-CDVI-DN-EN en 0805a
The following product-specific terms and abbreviations are
used in this manual:
Term/abbreviation Definition
CDVI-DN Clean design valve terminal with direct fieldbus connection for
DeviceNet
CP Compact performance
CP cable Special cable for coupling the various CP modules
CP connection Socket or plug on the CP modules which enable the modules to be
connected with the CP cable
CP modules Collective term for the various modules that can be integrated in a CP
system.
CP system System consisting of CDVI-DN and CP modules
Dual expansion block Expansion block which helps control two solenoid coils per valve
position
IDigital input
I/Os Digital inputs and outputs
I/O modules Collective term for the CP modules which provide digital inputs and
outputs (CP input modules and CP output modules)
Load voltage Power supply of the valves
Manifold block Block with 4 or 8 valve positions. Each CDVI-DN has exactly one
manifold block.
Mono expansion block Expansion block which helps control one solenoid coil per valve
position
ODigital output
Operating voltage Power supply for the electronics
PLC/IPC Programmable logic controller/industrial PC
Tab. 0/1: Terms and abbreviations

Installation
1-1
Festo P.BE-CDVI-DN-EN en 0805a
Chapter 1
Installation

1. Installation
1-2 Festo P.BE-CDVI-DN-EN en 0805a
Contents
1. Installation 1-1...................................................
1.1 General installation instructions 1-3...................................
1.2 Setting the CDVI-DN 1-5.............................................
1.2.1 Removing and mounting the left-hand end plate 1-5..............
1.2.2 Setting the DIL switches 1-7..................................
1.3 Connecting to the fieldbus 1-14........................................
1.3.1 Fieldbus cable 1-14..........................................
1.3.2 Fieldbus baud rate and fieldbus length 1-15......................
1.3.3 Power supply for the DeviceNet 1-16............................
1.3.4 Pin allocation of the DeviceNet 1-17.............................
1.3.5 Connection example 1-18.....................................
1.3.6 Bus terminal with terminating resistors 1-19......................
1.4 Power supply 1-20..................................................
1.4.1 Calculation of the current consumption 1-20.....................
1.4.2 Selecting the cables 1-21.....................................
1.4.3 Selecting the power supply unit 1-21...........................
1.4.4 Connecting the power supply of the valve terminal 1-22............
1.5 Extending the CDVI 1-29..............................................
1.5.1 Inserting expansion blocks 1-29................................
1.5.2 CP extension connection 1-30..................................

1. Installation
1-3
Festo P.BE-CDVI-DN-EN en 0805a
1.1 General installation instructions
Warning
Uncontrolled movements of the connected actuators and
uncontrolled movements of loose tubing may cause per-
sonal injury or material damage.
•Before any conversion work on the CDVI-DN, switch off
the following:
– Compressed air supply
– Power supply
•Make sure no control signals from the higher-order con-
troller are present at the solenoid coils.
Note
Observe the CDVI assembly instructions in the “CDVI
pneumatics manual” (CP.BE-CDVI-...) in chapter 2.
The CDVI-DN contains electrostatically sensitive devices.
•Do not therefore touch any electronic components.
•Observe the handling specifications for electrostatically
sensitive devices.
They will help you avoid damage to the electronics.

1. Installation
1-4 Festo P.BE-CDVI-DN-EN en 0805a
Electrical connections
1
2
3
45
1Power supply (plug, M12)
2CP extension (M9)
3Fieldbus input (plug, M12)
4Fieldbus output (socket, M12)
5Auxiliary power supply on expansion
block (plug, M12)
Fig. 1/1: Electrical connections of the CDVI-DN

1. Installation
1-5
Festo P.BE-CDVI-DN-EN en 0805a
1.2 Setting the CDVI-DN
1.2.1 Removing and mounting the left-hand end plate
Note
The CDVI-DN contains electrostatically sensitive devices.
•Do not therefore touch any electronic components.
•Observe the handling specifications for electrostatically
sensitive devices.
They will help you avoid damage to the electronics.
You must remove the left-hand end plate in order to set the
CDVI-DN.
3.5 Nm (... 4 Nm)
Fig. 1/2: Removing/mounting the left-hand end plate

1. Installation
1-6 Festo P.BE-CDVI-DN-EN en 0805a
Removing
1. Switch off all power supplies (electric voltage,
compressed air).
2. Loosen each of the two mounting screws on the left-hand
end plate by approximately one turn.
3. Now unscrew the two mounting screws completely to
avoid twisting or squeezing the separator plate (seal).
4. Pull off the left end plate.
Mounting
1. Place the separator plate (seal) on the manifold block.
The separator plate must be fitted correctly on the guide
sleeves of the manifold block.
2. Position the left end plate too.
3. Tighten the two mounting screws alternately. Torque:
3.5 Nm (... 4 Nm)
Note
•Make sure the separator plate (seal) is not squeezed on
one side as a result of uneven tightening of the cover
screws.
The requirements of the IP protection class cannot be
fulfilled if a seal is squeezed.

1. Installation
1-7
Festo P.BE-CDVI-DN-EN en 0805a
1.2.2 Setting the DIL switches
You will see several DIL switches after removing the left end
plate in accordance with chapter 1.2.1:
12
3
4
Fig. 1/3: DIL switches
You can set the following parameters with the DIL switches:
1Extension of the CP system
2Setting the address assignment
3Setting the baud rate
4Setting the station number (slave address)

1. Installation
1-8 Festo P.BE-CDVI-DN-EN en 0805a
Setting: extension of the CP system 1
Further CP modules can be connected to the CDVI-DN.
You can set the extension of the CP system with the switch
elements 1 and 2 of the dual DIL switch in accordance with
the following table.
Extension Outputs Inputs DIL switch positions
CDVI-DN with 4 / 8 valve
positions (+ expansion blocks)
without CP extension
8/16/24O 8 I (status byte)
CDVI-DN with:
– CP input module
8/16/24O 8 I (status byte)
+16I
CDVI-DN with:
– CP.. valve terminal
or
– CP output module
8/16/24O
+16O
8 I (status byte)
CDVI-DN with:
– CP.. valve terminal /
CP output module
and
– CP input module
8/16/24O
+16O
8 I (status byte)
+16I
Tab. 1/1: Setting the extension of the CP system
The CP system occupies a different number of inputs and
outputs or station numbers, depending on the extension set.
Additional information can be found in section 1.5.
