Festo CPX Series User manual

Electronics
manual
CPX field bus node
Type CPX-FB6
Field bus protocol:
Interbus as per
EN 50254
CPX terminal
Manual
526 434
en 0112NH
[653 608]

Contents and general instructions
I
Festo P.BE-CPX-FB6-EN en 0112NH
Author P. Mauch...................................
Editors H.-J. Drung, M. Holder........................
Original de.......................................
Translation transline Deutschland.....................
Layout Festo AG & Co., Dept. KG-GD...................
Type setting KI-DT..................................
Edition en 0112NH.................................
Designation P.BE-CPX-FB6-EN........................
Order no. 526 434.................................
E(Festo AG & Co., D-73726 Esslingen, Federal Republic of
Germany, 2001)
Internet: http://www.festo.com
e-mail: [e-mail]
The copying, distribution and utilization of this document as
well as the communication of its contents to others without
expressed authorization is prohibited. Offenders will be held
liable for the payment of damages. All rights are reserved, in
particular the right to carry out patent, utility model or orna-
mental design registration.

Contents and general instructions
II Festo P.BE-CPX-FB6-EN en 0112NH

Contents and general instructions
III
Festo P.BE-CPX-FB6-EN en 0112NH
Contents
Designated use V........................................................
Target group V..........................................................
Service V...............................................................
Important user instructions VI..............................................
Notesontheuseofthismanual VIII...........................................
1. Installation 1-1...................................................
1.1 General instructions on installation 1-4................................
1.2 Settings of the DIL switches on the field bus node 1-8....................
1.3 Connecting the field bus 1-13.........................................
1.3.1 System structure on the remote bus 1-13........................
1.3.2 Pin assignment of field bus interface 1-16........................
1.3.3 Connecting the field bus 1-17..................................
1.3.4 Field bus baud rate and field bus length 1-19.....................
1.4 Optical-fibre waveguide connection for Interbus 1-20......................
1.5 Pin assignment of power supply 1-21...................................
2. Commissioning 2-1................................................
2.1 Configuration and addressing 2-4.....................................
2.1.1 Ascertaining the address range 2-4............................
2.1.2 Address assignment of the CPX terminal 2-7.....................
2.1.3 Address assignment after extension or conversion 2-15............
2.1.4 Bus configuration and addressing 2-18..........................
2.1.5 Switching on the power supply 2-19............................
2.1.6 Bus configuration with the CMD software 2-20....................
2.1.7 Bus configuration without CMD software 2-29....................
2.1.8 Entering process data via the CMD software 2-30..................
2.2 Parametrizing 2-33..................................................
2.2.1 Parametrizing concepts 2-35...................................
2.2.2 Device parametrizing with the CMD software 2-39.................
2.2.3 Parametrizing with CMD user functions 2-40......................
2.2.4 Parametrizing by means of the PLC user program 2-43.............

Contents and general instructions
IV Festo P.BE-CPX-FB6-EN en 0112NH
2.3 Commissioning the CPX terminal on the Interbus 2-44.....................
2.3.1 Fail safe 2-45...............................................
3. Diagnosis and error treatment 3-1....................................
3.1 Overview of diagnostic possibilities 3-4................................
3.2 Diagnosis via LEDs 3-6..............................................
3.2.1 Normal operating status 3-7..................................
3.2.2 CPX-specific LEDs 3-8.......................................
3.2.3 Interbus-specific LEDs 3-11....................................
3.3 Diagnosis via Interbus 3-13...........................................
3.3.1 Status bits 3-13.............................................
3.3.2 I/O diagnostic interface 3-15..................................
3.3.3 Diagnosis via the PCP channel 3-16.............................
3.3.4 Periphery fault (PF) 3-18......................................
3.4 Error treatment 3-20.................................................
A. Technical appendix A-1.............................................
A.1 Technical specifications of field bus node type CPX-FB6 A-3................
A.2 Accessories A-4....................................................
A.3 Access to parameters and data via the PCP channel A-5...................
A.3.1 System parameters A-7......................................
A.3.2 Module parameters A-8......................................
A.3.3 Diagnostic memory parameters A-14............................
A.3.4 Diagnostic memory data A-14..................................
A.3.5 System diagnostic data A-16...................................
A.3.6 Module diagnostic data A-17..................................
A.3.7 System data A-18............................................
A.3.8 Module data A-18............................................
A.3.9 Length of PCP data objects A-20................................
B. Index B-1.........................................................
B.1 Index B-3.........................................................

Contents and general instructions
V
Festo P.BE-CPX-FB6-EN en 0112NH
Designated use
The field bus node type CPX-FB6 described in this manual has
been designed exclusively for use as a slave on the Interbus.
The CPX terminal may only be used as follows:
– in accordance with designated use
– in its original state
– without any modifications by the user
– in faultless technical condition.
– The maximum values specified for pressures, tempera-
tures, electrical data, torques etc. must be observed.
Please comply with national and local safety laws and regula-
tions.
Target group
This manual is intended exclusively for technicians trained in
control and automation technology, who have experience in
installing, commissioning, programming and diagnosing
slaves on the Interbus.
Service
Please consult your local Festo service centre if you have any
technical problems.

Contents and general instructions
VI Festo P.BE-CPX-FB6-EN en 0112NH
Important user instructions
Danger categories
This manual contains instructions on the possible dangers
which may occur if the product is not used correctly. These
instructions are marked (Warning, Caution, etc.), printed on a
shaded background and marked additionally with a picto-
gram. A distinction is made between the following danger
warnings:
Warning
This means that failure to observe this instruction may
result in serious personal injury or damage to property.
Caution
This means that failure to observe this instruction may
result in personal injury or damage to property.
Please note
This means that failure to observe this instruction may
result in damage to property.
The following pictogram marks passages in the text which
describe activities with electrostatically sensitive compo-
nents.
Electrostatically sensitive components may be damaged if
they are not handled correctly.

Contents and general instructions
VII
Festo P.BE-CPX-FB6-EN en 0112NH
Marking special information
The following pictograms mark passages in the text contain-
ing special information.
Pictograms
Information:
Recommendations, tips and references to other sources of
information.
Accessories:
Information on necessary or sensible accessories for the
Festo product.
Environment:
Information on environment-friendly use of Festo products.
Text markings
•The bullet indicates activities which may be carried out in
any order.
1. Figures denote activities which must be carried out in the
numerical order specified.
– Hyphens indicate general activities.

Contents and general instructions
VIII Festo P.BE-CPX-FB6-EN en 0112NH
Notesontheuseofthismanual
Please note
This manual refers to CPX field bus node type CPX-FB6 as
from software version 1.4 and hardware version 06/01.
This manual contains special information on installing, com-
missioning, programming and diagnosing with the CPX field
bus node for Interbus.
General basic information on the method of operation, on
fitting, installing and commissioning CPX terminals can be
found in the CPX system manual.
Information on further CPX modules can be found in the man-
ual for the relevant module. The table below gives an over-
view.

Contents and general instructions
IX
Festo P.BE-CPX-FB6-EN en 0112NH
Type Title Description
Electronics
Manual
“System manual”
type P.BE-CPX-SYS-...
Overview of structure, components and
method of operation of CPX terminals;
Installation and commissioning instructions
as well as basic principles of parametrization
“CPX I/O modules”
type P.BE-CPX-EA-...
Connection technology and instructions on fit-
ting, installing and commissioning both input
and output modules of type CPX-... as well as
CPA and Midi/Maxi pneumatic interfaces
“CPX field bus node”
type P.BE-CPX-FB...
Instructions on fitting, installing and diagnosing
theappropriatefieldbusnode
Pneumatics
Manual
“Valve terminals with
CPA pneumatics”
type P.BE-CPA-...
Instructions on fitting, installing and commis-
sioning CPA pneumatics (type 12)
“Valve terminals with
Midi/Maxi pneumatics”
type P.BE-Midi/Maxi-03-...
Instructions on fitting, installing and commis-
sioning CPA Midi/Maxi pneumatics (type 03)
Tab. 0/1: Manuals on the CPX terminal

Contents and general instructions
XFesto P.BE-CPX-FB6-EN en 0112NH
The following product-specific terms and abbreviations are
used in this manual:
Term/abbreviation Meaning
CP Compact Performance
CPA Pneumatic modules/valve terminal type 12
CPX bus Data bus via which the CPX modules communicate with each other and
via which they are supplied with the required operating voltage.
CPX modules Common term for the various modules which can be incorporated in a CPX
terminal.
CPX terminal Modular electric terminal type 50
DIL switches Dual-in-line switches consist of several switch elements with which
settings can be made.
Field bus node Provides the connection to specific field buses. Transmits control signals
to the connected modules and monitors their ability to function.
IDigital input
I/O diagnostic interface The I/O diagnostic interface is a bus-independent diagnostic interface at
I/O level which permits access to internal data of the CPX terminal.
I/O modules Common term for the CPX modules which provide digital inputs and out-
puts (CPX input modules and CPX output modules).
I/Os Digital inputs and outputs
Midi/Maxi Pneumatic modules/valve terminal type 03
ODigital output
PLC/IPC Programmable logic controller/industrial PC
Pneumatic interface The pneumatic interface is the interface between the modular electric
periphery and the pneumatics.
Status bits Internal inputs which supply coded common diagnostic messages.
Tab. 0/2: CPX-specific terms and abbreviations

Contents and general instructions
XI
Festo P.BE-CPX-FB6-EN en 0112NH
The following Interbus-specific terms and abbreviations are
used in this manual:
Term/abbreviation Meaning
CMD software Parametrizing, commissioning and diagnostic software for slaves on the
Interbus (configuration, monitoring, diagnosis).
ID code The Interbus module ascertains the type and the processing data length
of all the slaves with the aid of the Ident. code (ID code).
Interbus module TheInterbusmoduleisthecentraldeviceforcontrollingtheInterbusdata
ring. It exchanges the serially transported data in the data ring with the
higher-order control system or computer system and the lower-order
Interbus slaves in both directions acyclically or cyclically.
Parameter data Data for parametrizing, diagnosing and configuring, which are transmitted
acyclically in multiplex procedure via the PCP channel.
PCP channel Slaves which can also process parameter data are also designated PCP
slaves. Communication between these slaves and the Interbus module is
made via the peripheral communication protocol (PCP or PCP channel).
PCP is an integral part of the Interbus protocol.
Periphery fault (PF) Faults in the periphery of Interbus slaves are registered with the periphery
fault (depending on slave), e.g.:
– failure of operating or load voltages
– shortcircuitattheoutputs,etc.
The periphery fault is a common error message and does not contain any
module-specific information.
Processing data I/O data of the Interbus slaves which is transmitted cyclically via the
Interbus, e.g. for:
– Light barriers, sensors
–Valves,contactors
–DiagnosticI/Os
Remote bus The remote bus bridges the long distances within an Interbus system
(main string). With a baud rate of 500 kBd, it can be up to 12.8 km long
(from the Interbus module to the last connected remote bus slave). Indi-
vidual segments can be up to 400 m long.
Tab. 0/3: Interbus-specific terms and abbreviations

Contents and general instructions
XII Festo P.BE-CPX-FB6-EN en 0112NH

Installation
1-1Festo P.BE-CPX-FB6-EN en 0112NH
Chapter 1

1. Installation
1-2 Festo P.BE-CPX-FB6-EN en 0112NH
Contents
1. Installation 1-1...................................................
1.1 General instructions on installation 1-4................................
1.2 Settings of the DIL switches on the field bus node 1-8....................
1.3 Connecting the field bus 1-13.........................................
1.3.1 System structure on the remote bus 1-13........................
1.3.2 Pin assignment of field bus interface 1-16........................
1.3.3 Connecting the field bus 1-17..................................
1.3.4 Field bus baud rate and field bus length 1-19.....................
1.4 Optical-fibre waveguide connection for Interbus 1-20......................
1.5 Pin assignment of power supply 1-21...................................

1. Installation
1-3
Festo P.BE-CPX-FB6-EN en 0112NH
Contents of this chapter In this chapter you will find information on:
– the setting of the CPX field bus node with DIL switches
– the connection to the field bus
– the pin assignment of the power supply.
Further information Information on fitting and installing the complete CPX
terminal can be found in the CPX system manual
(P.BE-CPX-SYS-..).
Information on installing the I/O modules and the pneumatic
interfaces can be found in the manual for the CPX I/O mod-
ules (P.BE-CPX-EA-..).
Instructions on installing the pneumatic components can be
found in the relevant pneumatics manual.

1. Installation
1-4 Festo P.BE-CPX-FB6-EN en 0112NH
1.1 General instructions on installation
Warning
Before carrying out installation and maintenance work,
switch off the following:
•the compressed air supply
•the operating voltage supply for the electronics/sensors
•the load voltage supply for the outputs and valves.
You can thereby avoid:
– uncontrolled movements of loose tubing
– unexpected movements of the connected actuators
– non-defined switching states of the electronic compo-
nents.
Caution
The CPX field bus node contains electrostatically sensitive
components.
•Do not therefore touch any contacts.
•Observe the regulations for handling electrostatically
sensitive components.
You will then prevent the electronics from being damaged.

1. Installation
1-5
Festo P.BE-CPX-FB6-EN en 0112NH
Electrical connecting and display elements
You will find the following connecting and display elements
on the CPX field bus node for Interbus:
1Bus status
specific and CPX-
specific LEDs
2Field bus connec-
tion OUT (con-
tinuing, 9-pin
sub-D socket)
3Field bus connec-
tion IN (incoming,
9-pin sub-D plug)
4Service interface
for handheld, etc.
PS
PL
SF
TR
3
41
2
UL
RC
BA
RD M
Fig. 1/1: Connecting and display elements on the CPX field bus node

1. Installation
1-6 Festo P.BE-CPX-FB6-EN en 0112NH
Fitting and removing
The field bus node is fitted in a manifold sub-base of the CPX
terminal (see Fig. 1/2).
Removing Remove the field bus node as follows:
1. Loosen the 4 screws in the field bus node with a Torx
screwdriver size T10.
2. Pull the field bus node carefully and without tilting away
from the contact rails of the manifold sub-base.
1Field bus node
2Manifold
sub-base
3Contact rails
4Screws
3
4
1
2
Fig. 1/2: Fitting/removing the field bus node
