FRAME IT ALL Stack & Extend VEGGIE WALL User manual

VEGGIE WALL
Stack & Extend
Customer Service: 1800-914-9835 | [email protected]
© 2020 Frame It All. All Rights Reserved.
KIT CONTAINS:
Stake
x 3
Adapter Caps
x 3
Cotter Pin x 2 L Connector
x 2
Cap x 3
Lower
Tube
x 3
Upper
Tube x 3
Middle
Tube
x 3
RAISED BED
Sold
Separately
Net x 1
T Connector
x 3
2
1 3 4 5 6
78
9
10 Long Tube x 2
Cross
Brace x 1
Tie
x 28
11 12
13
**Use Stake
if you install
veggie wall
directly in the
ground

Customer Service: 1800-914-9835 | [email protected]
ASSEMBLY INSTRUCTIONS
STEP 1
9
8
7
STEP 1:
Screw the short upper tube into the middle tube and tighten.
Screw lower tube into the connected tubes and , tighten to
complete one upright pole. Repeat to build the other two upright poles.
STEP 2:
Place T-connector into one end of each horizontal tube . To
connect the two horizontal poles, join T-connector and
L-connector to produce the corner hinge. Place the two ends of
horizontal pole without connectors into this connection hinge.
Place this assembly onto ground to attach the cross brace . Make
sure the open connector holes are facing down. Position cross brace
over the pre-drilled holes on both horizontal tubes .
Connect brace onto horizontal tube by pushing the cotter pin
through the cross brace and pre-drilled holes in the tubes, then bend
the pins to create snug fit.
Place the adapter cap on each connection point.
9 8
7 8 9
5
5
4
3
6
5
5
4
4
5
3
3
6
6
6
STEP 2
10
10
11
10
10
11
11
11
10
10

ASSEMBLY INSTRUCTIONS
Customer Service: 1800-914-9835 | [email protected]
STEP 3:
Take the entire assembled top frame and insert on
top of the 3 vertical poles. If you are placing this into
an already built raised garden utilize the stake cover
hole and slide the vertical poles through the
stake cover into the stake (see STEP 4 Image)
2
STEP 3
1
2
STEP 4:
Open the green net completely. Use cable ties to
affix the net onto the frame, making sure to equally
space the cable ties along the tubes. Start at the top
affixing 5 ties to each of the horizontal tubes and
then affixing 6 ties to each of vertical tubes.
STEP 4
Garden
Bed
OPTIONAL
To attach a second veggie
wall to the same garden bed,
attach one L-connector to
a T-connector as show in
the diagram on the right,
When you do this, one
vertical tube is not needed.
5
4
4
5
12
