Front Runner RRAC190 User manual

RRAC190_REV_A01 © 2021 FRONT RUNNER VEHICLE OUTFITTERS
front runner
RRAC190
ENG
1
Thank you for purchasing a Front Runner Handle/Light Sports Rack Bracket.
Before you start, take a moment to familiarize yourself with the Fitting Instructions and the components received.
Refer to Page 2 for a list of all the components, quantities and tools required.
READ ME !
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT
RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND
DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY
FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.
NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.
Please call us if you have any questions about the installation of this product.
Handle/Light Sports Rack
Bracket

RRAC190_REV_A01 © 2021 FRONT RUNNER VEHICLE OUTFITTERS 2
TOOLS NEEDED
FIGURE 1.1
GET ORGANIZED
1
IN THE BOX
1
2
3
5mm
4
1 1 X Handle Light Rack Bracket
2 2 X M8 x 12 Button Head Bolt
3 2 X M8 Shnorr Washer
4 2 X M8 Thin Nut
SOME ELECTRICAL CONNECTION MAY BE REQUIRED.
AS ALL ELECTRICAL EQUIPMENT IS A POTENTIAL HAZARD AND COULD CAUSE SERIOUS INJURY IT IS
STRONGLY ADVISED THAT A QUALIFIED ELECTRICIAN HANDLE ALL WIRING AND CONNECTIONS REQUIRED.
CHECK ONLINE FOR LATEST FITMENT GUIDE WWW.FRONTRUNNEROUTFITTERS.COM

RRAC190_REV_A01 © 2021 FRONT RUNNER VEHICLE OUTFITTERS
3
FIT AND SECURE BETWEEN SLATS2
2.1
Add Text
2.1
2.2
Slide two M8 Half nuts (Item 4) into the
T-Slot and Remove the Self forming Screws
indicated.
Secure the Handle Light Rack Bracket
(Item 1) to your Roof Rack using M8x12
Button Heads, M8 Schnorr Washers,
M8 Half Nuts & M6 x 25 Self forming Screws
(Items 2,3 & 4).

RRAC190_REV _A01 © 2021 FRONT RUNNER VEHICLE OUTFITTERS 4
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
4
Now's the time to visit your favorite Front Runner Dealer in person or online.
Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam
Share your adventures on:
FINISH
3
Congratulations! You did it. Take a step back and admire your work!
INSTALL ROOF RACK POWER POINT4
4.1
Roof Rack Power point, refer to fitment
guide RRAC165 (Sold Seperataly).
