INSTRUCTION MANUAL
DIJON 3 SEAT SOFA-BED
ITEM CODE: 15DIJ3SS
115DIJ3SS
Imported by Furniture Solutions (Aust) Pty Ltd
10-16 Daisy St,
Revesby, NSW. 2212
www.furnituresolutions.com.au

PRE-ASSEMBLY PREPARATION
Before you start:
1. Choose a clean, level, spacious assembly area. Avoid hard surfaces that may
damage the product
2. Take care when lifting. Product should be assembled as near as possible to
the point of use
3. Ensure that you have all required contents for complete assembly
4. Always read the assembly instructions carefully before beginning assembly.
5. Keep all hardware parts and packaging out of reach of small children.
6. Do not over tighten the screws and bolts as this may damage the threads
215DIJ3SS
20
MINUTES
ALLOW TIME PEOPLE REQUIRED
X2
Special Notice: Parts are located in zipper pocket in base
in sofa.

PARTS LIST
PART QTY CODE IMAGE
A STEEL LEG 2 P410513L
B BOLT: M6 x25mm 16 P410513B
C TOOL: 4MM 1 P410513K
D SUPPORT LEG 1 P410513SL
315DIJ3SS

415DIJ3SS
ASSEMBLY INSTRUCTIONS
Step1: Please prepare work area as instructed in page 2:
As indicated in diagram below lay front of sofa face down.
You will see a zipper in dust cover, inside you will find legs and hardware pack.
Once all items are checked against list on previous page, you may start assembly.
Please locate the threaded holes towards the ends of sofa.
Then take leg [A] and place as shown in diagram below, aline holes in leg with
threaded holes in base of sofa. Once aligned take bolt [B] insert thru hole in leg
and into thread hole in sofa base and by hand seat the thread correctly by turning
bolt 2-3 times, once thread has gripped, fit other 3 bolts. Once all seated correctly
take Allen Key [C] and tighten all bolts until firm. Do not over tighten. Repeat for
second leg.
Move to step 2

415DIJ3SS
ASSEMBLY INSTRUCTIONS
Step2: Fit Support Leg
As indicated in diagram below support leg is fitted in centre of sofa. Locate
threaded hole and insert threaded end of support leg [D] and by hand seat thread
correctly and tighten till firm. Do not over tighten.

515DIJ3SS
INSTRUCTIONS-OPERATING OF FUNCTIONS
About CLICK CLACK mechanism:
The ratchet system used is designed only to work one way, whenever back or
arms mechanism is in a position other than flat to change position you will
need to unlock ratchet. To unlock you will be required to gently push back/arm
fully forward till you hear a clack sound, then you can lower back/arm to go
flat.
Click Clack has a 3 stage mechanism which uses a ratchets system.
First position is flat for use as a bed. This model has added armrest function.
Second position is Lounger when back is mid way up in locked position.
Third position is as a Sofa full upright locked position.
Please view Images of positions available and move to next page for written
instruction.

615DIJ3SS
INSTRUCTIONS-OPERATING OF FUNCTIONS
Instruction start from fully flat position:
Starting from flat position to move to Sofa position.
With a person on each side of sofa, in unison lift backrest up till you hear a
click noise, this should then hold mid way lock, then to full upright continue
the lifting of backrest till you here another click this should hold in place.
To go from Sofa position to Lounger position.
You will need to revert back to flat position as instructed below.
To go back to flat or Bed position, you will need to release locking mechanism.
This done by lifting and pushing backrest forward till you here clack.
Once you here the clack lower backrest till flat.
Starting from flat position go to side of sofa and lift using same instruction
above.
Note/Warning:
The ratchet mechanism is designed only to work one way you can only lock the
2 upright positions from flat starting.
So can not go from Sofa position to Lounger position must always go back to
flat position.
If for some reason you do not get a lock position when raising from flat
position.
Lift backrest all the way to the clack release point then back again, sometimes
doing it twice has better success.

715DIJ3SS
CARE AND MAINTENANCE
Varieties of materials are used in construction of “Click Clack sofa” furniture range, Such as
Stainless Steel; Chrome plated steel: Powder coated steel, Timber, PU synthetic fabric & a
variety fabrics. All will require some form of maintenance to extend the life of finishes and
general appearance.
Please see below instruction unique to your chosen model.
Dijon Click Clack Sofa-bed
Covering : Polyester Fabric
Legs : Polished Steel
Polyester Fabric;
Vacuum regularly with a soft brush attachment to remove dust and grit, & or wipe with a
soft colourfast cloth dampened with plain water.
This should be done as often as necessary or at least every 2 weeks.
Do not rub excessively.
Special note salts and body oils which occur naturally in human skin can build up in fabric,
please consider having a professional clean done depending on use once a year.
In areas of high humidity more frequent cleaning will be required.
Do Not;
Expose direct to sunlight, intense heat, weather and soak unnecessarily.
Always avoid excessive hard rubbing.
Do not use saddle soap, detergents, solvents, abrasives, unidentified cleaners, or any
product containing silicon or solvent. Do not dry clean or machine wash.
Polished Steel;
For best results use microfiber cloth or moist clean cloth. Ensure not to leave
damp.

815DIJ3SS
SAFETY WARNINGS AND ADVICE
Notices and Advice
Please be advised that products are limited in design for residential use only and are not
suitable for commercial use.
Please be advised that materials used in your furniture are not impervious to neglect, acts of
god, abuse, alcohol spills, improper use of chemicals such as bleach or any solvent based
products.
Please be advised that heat sources such as direct sunlight, log fires, heaters and air
conditioners can have adverse affects on your furniture.
Please be advised that fitting, bolts, nuts and or screws should be checked periodically to
ensure they have not loosened over time. Remember do not overtighten.
DO NOT
•Place in direct sunlight.
•Place in close proximity to open flame or heaters.
•Place in direct line of air conditioning ducting.
•Leave spills or food on sofa clean off immediately
•Pull loose thread, cut them instead.
Safety warnings
•DO NOT:
•drop, drag always with the help of another person lift and place, to avoid damage to floor
surface & or legs of sofa.
•Sit on arms or back when upright, this could damage internal mechanism.
•Fold mechanism with linen or cushions on sofa.
•Pull loose thread, cut them instead.
•Jump, flop or stand on sofa.
•When using as a bed sit first then reline into sleep position

915DIJ3SS
WARRANTY DETAIL
1 Year Warranty
A one (1) year warranty applies to product against any defect associated with faulty
workmanship for a period of (1) year from date of purchase.
Furniture Solutions accepts no responsibility for defects caused by incorrect assembly,
mishandling, acts of god, general wear & tear including fading, creasing of covering, aging of
foam and fiber filling IE Height reduce over time, stains from spills, chipping/scratching,
exposure to extreme heat/cold, mould/mildew, hardware corrosion, misuse of the products
& defects caused by failure in duty of care for the product in accordance with the care
instructions. Warranty is based on normal household use and not for commercial use.
Warranty only extends to original purchaser and is not transferable, except when given as a
gift.
Notice:
While every effort is made to use quality materials our products are limited in design for
domestic use only & are not suitable for commercial use.
Care should be taken not to place product near heat sources.
Duty of care:
While every attempt is made to supply product using quality components there is always a
need from consumer to help ensure long life of use for product. Instruction manuals are
designed with the nature of materials used in construction of the product.
*Proper use of item only what it is designed to do
*Regular maintenance and cleaning
In areas of high content of salt air, pollution & moisture require more frequent cleaning.
Claim management:
To make a warranty claim, customers can either contact the retailer where the purchase was
made or Furniture Solutions on contact details below. Proof of purchase will be required
before proceeding with any claim. In the case of product defects providing photos may be
able to speed up processing of the claim. If missing parts please refer to assembly
instructions for identification of said part and contact either of the above.
“Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure”.
