GE Power Break II SPUV012DC User manual

Catalog
Number
Voltage
Rating ❿Peak Inrush Current, A ❡
Nominal RMS
Current, mA
SPUV012DC 12 Vdc 19 300
SPUV024DC 24 Vdc 15 140
SPUV048DC 48 Vdc 7.5 70
SPUV125DC 125 Vdc 3 30
SPUV250DC 250 Vdc 1.5 15
SPUV024AC 24 Vac 15 370
SPUV048AC 48 Vac 7.5 210
SPUV120AC 120 Vac 3 80
SPUV208AC 208 Vac 1.9 60
SPUV240AC 240 Vac 1.5 45
❿ 24–240 Vac devices are rated for
Peak 50/60 Hz.inrush current is present for 2–6 ms after activation.
This number is provided so that fuses and supplies can be chosen
appropriately.
—
Table 1. Catalog numbers and voltages for the Undervoltage Release.
Installation
WARNING: Before installing any accessories, turn
the breaker OFF, disconnect it from all voltage
sources, and discharge the charging springs.
AVERTISSEMENT: Avant d’installer toute accessoire,
mettre le disjoncteur en position OFF, le déconnecter
de toute tension d’alimentation, et décharger
les ressorts d’armement.
GEH6285 I NSTRUCTIONS
Power Break® II Circuit Breaker Accessories
Undervoltage Release
1
The Under voltage Release is installed in the accessory
compartment through the front of the circuit breaker in the
position shown in Figure 2.
Introduction
The Undervoltage Release (UVR) accessory, shown in Figure
1, can be installed in 800–4000 ampere frame Power Break II
circuit breakers. This accessory trips the circuit breaker
when the input control voltage drops to 35–60% of its rated
value and prevents an open breaker from closing until the
input control voltage is greater than 80% of the rated value.
In addition to providing a trip signal to the breaker, the UVR
accessory can be set up to interact with other Power Break II
accessories, when used with a MicroVersaTrip Plus or
MicroVersaTrip PM Trip Unit. DIP switches on the rear of
the breaker Trip Unit can configure the UVR accessory to
activate a Bell Alarm–Alarm Only accessory or a Bell Alarm
with Lockout accessory when a UVR trip occurs. The
Accessory Configuration section below describes how this
can be done. If the breaker is equipped with a Power+ Trip
Unit, it is configured so that only protection trips will
activate a Bell Alarm–Alarm Only or Bell Alarm with Lockout.
The catalog numbers for the UVR for various voltage applica -
tions are listed in Table 1.
—
Figure 2. Accessory compartment on front of circuit breaker, with Undervoltage Release slot indicated.
—
Figure 1. Undervoltage Release.
Operation
Apply control voltage to terminals 29 and 30 of the terminal
strip on the right side of the breaker. When the applied
control voltage is above 80% of the UVR’s rated value, the
breaker can be closed. When the voltage drops to 35–60% of
the rated value, the UVR will trip the breaker.

Use the following procedure to install the UVR accessory
into the UVR slot in the accessory compartment of the
circuit breaker:
Open the hinged door over the accessory compart-
ment and Trip Unit.
To remove an existing accessory module, loosen the
accessory locking screw and pull the module out with
the Rating Plug Removal Tool (catalog number
TRTOOL).
Insert the UVR accessory into the proper slot, as
illustrated in Figure 3. The UVR accessory is keyed for
the correct slot in the accessory compartment. If the
accessory cannot be fully seated in the compartment,
check that the compartment position is correct.
Tighten the locking screw on the front of the accessory
until it is snug (torque of 9 in-lb.)
CAUTION: Overtightening the locking screw may damage
or distort the case of the accessory.
ATTENTION: Le serrage excessif de la vis de verrouillage
peut déformer le boîtier d’accessoire.
If the breaker is equipped with a MicroVersaTrip Plus
or MicroVersaTrip PM Trip Unit, the UVR accessory can
be configured to activate installed Bell Alarm Alarm
Only or Bell Alarm with Lockout accessories when a
UVR trip occurs, with the procedure described in the
Accessory Configuration section.
Connect the control wiring for the UVR to terminals 29
and 30 at the terminal block on the right side of the
breaker.
Test the UVR to ensure proper operation, according to
the procedures below.
Reconnect power to the circuit breaker and any other
accessories.
Accessory Configuration
This section only applies if Bell Alarm–Alarm Only or Bell Alarm
with Lockout accessories are installed in the breaker, along
with a MicroVersaTrip Plus or MicroVersaTrip PM Trip
Unit. If the breaker is equipped with a Power+ Trip Unit, the
factory default settings, listed in Table 2, can not be changed.
The UVR accessory can be configured to activate the Bell
Alarm–Alarm Only or Bell Alarm with Lockout accessories if a
UVR trip occurs. The configuration can be changed by removing
the Trip Unit from the breaker, setting the DIP switches on the
rear of the Trip Unit, and reinstalling the Trip Unit. Figure 4
illustrates the Trip Unit read DIP switches and their functions.
Table 2 lists the switch functions and the factory settings for
each.
Switch Factory
Setting Function
1 Disabled Shunt trip activates Bell Alarm–Alarm
Only
2 Disabled UVR trip activates Bell Alarm–Alarm
Only
3 Enabled Protection trip activates Bell
Alarm–Alarm Only
4 Disabled Shunt trip activates Bell Alarm with
Lockout
5 Disabled UVR trip activates Bell Alarm with
Lockout
6 Enabled Protection trip activates Bell Alarm
with Lockout
2
—
Figure 3. Inserting the Undervoltage Release into the accessory compartment.
—
Figure 4. Accessory switch on the rear of the MicroVersaTrip Plus™ or MicroVersaTrip PM™ Trip Unit,
showing the factory settings (solid part indicates that the switch is pushed in on that side).
—
Table 2. Accessory switch settings, including the factory defaults.
4.
5.
6.
7.
8.
3.
2.
1.
Close and lock or seal the door over the accessory
compartment and Trip Unit to prevent unauthorized
changes to Trip Unit settings and to keep contaminants
out of empty accessory slots.
9.

Description of Switch Settings
Following are descriptions of the effects of each accessory
switch when it is enabled:
When a Shunt Trip accessory causes the breaker to
trip, the contacts of the Bell Alarm–Alarm Only also
change state. (The factory switch setting is disabled. )
When an Undervoltage Release accessory causes the
breaker to trip, the contacts of the Bell Alarm–Alarm
Only also change state. (The factory switch setting is
disabled. )
When a protection trip (long-time, short-time,
instantaneous, ground-fault, or protective-relay)
occurs, the contacts of the Bell Alarm–Alarm Only also
change state. (The factory switch setting is enabled .)
When a Shunt Trip accessory causes the breaker to
trip, the contacts of the Bell Alarm with Lockout also
change state. (The factory switch setting is disabled. )
When an Undervoltage Release accessory causes the
breaker to trip, the contacts of the Bell Alarm with
Lockout also change state. (The factory switch setting
is disabled. )
When a protection trip (long-time, short-time,
instantaneous, ground-fault, or protective-relay)
occurs, the contacts of the Bell Alarm with Lockout
also change state. (The factory switch setting is
enabled. )
Procedure for Changing Switch Settings
Change the accessory switch settings with the following
procedure:
WARNING: Before beginning this procedure,
turn the breaker off, disconnect it from all
voltage sources, and discharge the closing springs.
AVERTISSEMENT: Avant de commencer cette
procédure, mettre le disjoncteur en position OFF, le
déconnecter de toute tension d’alimentation, et désarmer
les ressorts de fermeture.
1.
2.
Loosen the four #8-32 screws on the breaker trim-plate
assembly and remove the trim plate.
Loosen the four #10-32 screws at the corner of the
breaker cover. Remove the cover from the breaker face.
Pull the Trip Unit locking lever to the right, then hold
the Trip Unit near the battery cover and lift it straight
out of the breaker.
3.
4.
6.
7.
8.
Refer to Figure 4 and Table 2 to determine the
switches to be changed.
Push in the appropriate “Enable” or “Disable” side of
the switch.
Confirm all switch settings before reinstalling the Trip
Unit in the breaker.
Pull the Trip Unit locking lever to the right. While
holding the lever, carefully align the connector on the
rear of the Trip Unit with the connector in the breaker.
Press down on the Trip Unit, while holding it near the
battery cover. When the Trip Unit is fully seated, slide
the locking lever back to the left.
Reinstall the breaker top cover and tighten the four
#10-32 screws to 32 in-lbs.
Replace the trim plate and tighten the four #8-32
screws to 20 in-lbs.
Verify that the switch settings are correct by inducing
breaker trips from the UVR and Shunt Trip or Shunt
Trip with Lockout (if present) and checking the
responses of the Bell Alarm–Alarm Only and Bell Alarm
with Lockout accessories.
Test Procedure
Use the following procedure to test the UVR for proper
operation.
3
1.
2.
3.
4.
5.
6.
9.
10.
5.
Open the breaker.
Turn off the power to the UVR.
Try to manually close the breaker; the breaker should not
close.
Apply at least 80% of the rated voltage specified on the
UVR name plate to the UVR control inputs.
Try to close the breaker; it should close as normal.
If a MicroVersaTrip Plus or MicroVersaTrip PM Trip Unit is
installed, check that the Trip Unit display is active
(powered).
With the breaker closed, reduce the UVR control voltage
to 35–60% of the rated voltage; the breaker should trip
within 0.5 second.
If a Bell Alarm–Alarm Only or Bell Alarm with Lockout is
present, ensure that they activate (or do not activate) as
selected by the MicroVersaTrip Plus or MicroVersaTrip
PM Trip Unit DIP switches.
1.
2.
3.
4.
5.
6.
7.
8.

Symptom Possible Cause Corrective Action
The UVR accessory will
not insert completely in
the breaker.
3. The breaker will not close
when the UVR is
energized.
The breaker does not trip
when UVR control
power is removed.
The Bell Alarm–Alarm Only
or Bell Alarm with
Lockout does not trip
correctly (trips when it
shouldn’t or doesn’t trip
when it should).
The accessory is inserted
incorrectly.
The UVR lockout plunger is
not engaged.
The UVR is actually energized.
The UVR solenoid is not
energized.
The breaker is not closed.
UVR control power is actually still
applied.
The UVR trip connection is poor.
The Bell Alarm–Alarm Only or Bell
Alarm with Lockout configuration
switches on the back of the
MicroVersaTrip Plus or
MicroVersaTrip PM Trip Unit are
not properly set. Note that this
feature is not available with Power
+™ Trip Units.
The Bell Alarm–Alarm Only or Bell
Alarm with Lockout accessory is
improperly installed.
Ensure that the accessory is inserted in the correct slot, as in
Figure 2, and that the label is upright. Ensure that the
accessory is completely seated and that the screw is
tightened.
Remove the UVR accessory. Check that the lockout plunger
protrudes approximately
1
⁄4 inch out of the accessory; if it does
not, replace the UVR. If the plunger length is correct, reinsert
the UVR, ensuring good alignment of the accessory to the
pocket. Ensure that it is completely seated, flush with the top
of the pocket, then tighten the screw to 9 in-lb.
Check that the control power to the UVR is off.
Check that UVR control power is applied at greater than 80%
of the UVR rated voltage. Check that the accessory is
completely inserted; reinsert if necessary.
If using a 12 Vdc UVR, check that the polarity of the control
power matches that shown on the label of the UVR accessory.
Note that an otherwise unpowered Trip Unit would be
powered up by an energized UVR accessory.
Verify that the breaker is closed.
Check that the UVR control power has been removed or that
its voltage is less than 35% of the rated value.
Check that the UVR accessory is completely inserted.
Check that the Trip Unit is seated correctly. If the Trip Unit
was removed to set the switches, check that it has been
correctly installed; remove and reinstall, if necessary.
Follow the procedure to remove the Trip Unit and set the
switches. Check that the switches have been set correctly.
See the Trouble-Shooting Guide for the Bell Alarm with
Lockout in GEH6278 or the Bell Alarm–Alarm Only in GEH6275.
1SQC930030M0201, GEH6285 December 2019
4
—
ABB Inc.
305 Gregson Drive
Cary, NC 27511.
electrification.us.abb.com
—
We reserve the right to make technical
changes or modify the contents of this
document without prior notice. With
regard to purchase orders, the agreed
particulars shall prevail. ABB Inc. does not
accept any responsibility whatsoever for
potential errors or possible lack of
information in this document.
We reserve all rights in this document and
in the subject matter and illustrations
contained therein. Any reproduction or
utilization of its contents – in whole or in
parts – is forbidden without prior written
consent of ABB Inc.
Copyright© 2019 ABB
All rights reserved
—
GE is a trademark of GE. Manufactured
by ABB Inc. under license from GE.
Trouble-Shooting
The following guide is provided for troubleshooting and isolating common problems. It does not cover every possible
situation. Contact the Customer Support Center at 800-843-3742 if any problem is not resolved by these procedures.
The breaker closes when
the UVR is de - energized.
1.
4.
5.
