2ENGLISH
Summary
1. GENERAL INFORMATION 3
1.1 Structure of the manual and procedure for consulting ............................................................ 3
1.1.1. Symbols Used ................................................................................................................................................................. 3
1.1.2 Aim and content .............................................................................................................................................................. 3
1.1.3 Maintenance.................................................................................................................................................................... 3
1.2 Introduction............................................................................................................................ 3
1.2.1 Intended use.................................................................................................................................................................... 3
2 AVVERTENZE DI SICUREZZA 3
2.1 General provision ................................................................................................................... 3
2.2 Provisions relating to electrical hazard.................................................................................... 3
2.3 Provisions of use..................................................................................................................... 3
2.4 Use ......................................................................................................................................... 3
2.5 Contraindication to use........................................................................................................... 4
2.6 Residual risk ........................................................................................................................... 4
3. PRODUCT DESCRIPTION 4
3.1 Reference to illustrations ........................................................................................................ 4
3.2 Description ............................................................................................................................. 5
3.3 Optional extras ....................................................................................................................... 5
3.4 Technical specification ............................................................................................................ 6
3.4.1 Technical specification ..................................................................................................................................................... 6
3.4.2 Electric components......................................................................................................................................................... 7
4. ASSEMBLY 7
4.1 Unpacking............................................................................................................................... 7
4.2 Assembly................................................................................................................................ 7
5. USE 10
5.1 Use of the medical device ....................................................................................................... 10
6. TROUBLESHOOT 11
7.
ROUTINE MAINTENANCE .......................................................................................................... 12
7.1 Routine maintenance table..................................................................................................... 12
7.2 Cleaning metal partse ............................................................................................................. 12
7.3 Cleaning plastic parts.............................................................................................................. 12
7.4 Cleaning wooden parts ........................................................................................................... 12
7.5 Replacement of worn parts..................................................................................................... 13
7.6 Storage ................................................................................................................................... 13
7.7 Disposal.................................................................................................................................. 13
8. WARRANTY 13
8.1 warranty ............................................................................................................................... 13
8.2 Expected lifespan.................................................................................................................... 13

3
ENGLISH
1. GENERAL INFORMATION
1.1 Structure of the manual and procedure for
consulng
The instrucon manual is an integral part of the provision of this
bed. The manual is for customers, owners, safety personnel, us-
ers and maintainers.
1.1.1. Symbols Used
The following pictograms can be found in the manual.
Operaon must be carried out
by qualied personnel only
or an assistance centre.
Read the intrucon manual
Operaon that must be done
by two persons
Warning! Danger
Warning! Important informaon
Use protecve gloves
1.1.2 Aim and content
This manual provides with informaon on proper use, technical
characteriscs and safety warnings; it cannot, however, replace
the user appropriate experience.
1.1.3 Maintenance
This manual must be kept in an accessible and well-known place
by all the operators, protected against humidity, heat and light.
1.2 Introducon
1.2.1 Intended use
The device intended to be used as a bed only.
This bed is intended to be used in private home, care home,
hospital, or community environment, by users over 12 years old.
Dierent uses are not contemplated.
This product can only be paired with the products featured in the
list of compable accessories.
Use with other products must be evaluated in advance and may
invalidate the warranty.
2 AVVERTENZE DI SICUREZZA
2.1 General provision
 ⚠ Do not proceed to assembling this product before consulng
this instrucon manual.
 ⚠ Every alteraon of the product unbeknown to the manufac-
turer is the full responsibility of whoever makes the chang-
es. Alteraons made without the authorizaon of Longway
Medical Technology Co., Ltd. will invalidate any warranty and
invalidate the declaraon of conformity to the applicable
direcves.
 ⚠ It is forbidden to use the product in a dierent way from the
one described in this user manual.
 ⚠ Longway Medical does not any responsibility for malfunc-
ons or damages to objects and persons due to the incorrect
use of the product.
 ⚠ Operators must carefully read this manual, follow the given
instrucons and familiarize themselves with the procedures
for the use and maintenance of this product.
 ⚠ When the paent is not under surveillance, the medical bed
should be set in the lower posion with the siderails up in
order to reduce the risk of falls and injuries.
 ⚠ Avoid any inappropriate use of the power cord. The dangers
arising could be - for example - kinks, cuts and other me-
chanical damages.
 ⚠ In the event that cables from other equipment are located
inside the medical bed, it is necessary to take precauons in
order to avoid them to be crushed between other compo-
nents of the medical bed.
 ⚠ Due to the limited space under the medical bed, it is neces-
sary to use it with suitable liing devices.
 ⚠ Use and perform any maintenance on the product following
the instrucon provided by this manual and use only spare
parts and assistance approved by Longway Medical.
 ⚠ Do not use the product for purposes other than those for
which it was built and designed for.
 ⚠ Retain this manual for consulng or personnel training. It is
intended to be kept together with the product if sold or used
by new users.
2.2 Provisions relang to electrical hazard
Power supply must be provided to the machine using a protect-
ed line in order to avoid overcurrent through automac magne-
to-thermal switch and di; these devices must provide enough
electrical power to protect the size of the power wires.
⚠ If extension cords are necessary, the power wires must end
with a plug which is indissolubly plugged or with other devic-
es able to avoid water entering during the cleaning process
of the bed.
⚠ The medical bed must be provided with a suitable equip-
ment in order to maintain the power wire free from any
mobile part or mechanism of the medical bed when this is
funconing, or while it is moved, in order to avoid any dam-
ages to the power wire.
Power cords must be adequately protected against damages
that may be caused if they come in contact with one or more
moving parts or they rub against sharp angles and surfaces
inside the medical bed.
2.3 Provisions of use
Warnings on the use of the medical device are shown below.
⚠ Before operang the moving parts of the bed, make sure
they don’t damage any pipe, electric cable, catheters and
other devices else and ensure they will not make the user
uncomfortable or in any sort of problemac situaon; see
this manual for informaon on the procedure.
⚠ When provided, wheels have the sole purpose of moving the
bed when sanitaon, therapy etc. are necessary and they
should be kept braked at any other me.
2.4 Use
The daily use of the product is allowed only when each and ev-
ery safety security feature and funconal part is well-funconing

4ENGLISH
and correctly maintained.
The bed is intended to be used in private or care home’s, hos-
pitals and community environment by users over 12 years old.
The only possible use is the one described in this manual; we
recommend to read the instrucons carefully in order to be fully
aware of the funconality of the product.
2.5 Contraindicaon to use
It cannot be used when moving parts are not connected or weld-
ed, or show abnormalies.
• It cannot be used in environment subject to water splashing or
crical and adverse weather condions.
• It cannot be used if defecveness is shown: this can cause unex-
pected situaons of danger.
2.6 Residual risk
If the requirements displayed in this manual are not observed
• Risk of limbs crushing if limbs are placed under the moving
parts during downward movements.
• Risk of injury or re if the electrical components come in con-
tact with uids.
• Risk of damages to the product if this is subject to crical or
adverse weather condions.
3. PRODUCT DESCRIPTION
CODES:
LW05202(B) Standard Electric Homecare Bed(with wooden slat)
LW05203(B) Economy Standard Electric Homecare Bed(with
wooden slat)
LW05207(B) Electric Homecare Bed(with wooden slat)
LW05208(B) Economy Electric Homecare Bed(with wooden
slat)
LW05202S Standard Electric Homecare Bed New
LW05202SL Extra Low Standard Electric Homecare Bed New
LW05206 Heavy Duty Homecare Bed
LW05211 Two Funcon Homecare Bed
LW05212 Three Funcon Homecare Bed
LW05204 Electric Low Bed
3.1 Reference to illustraons
1. Monkey pole
2. Handle
3. Back secon
4. Buon/remote with cable
5. Wheels with brake
6. Footboard
7. Foot secon
8. Side panels
9. Thigh secon
10 Pelvis secon
11 Maress stopper
12 Electric actuator
13 Power Led
14 Trendelenburg/Antrendelenburg acvaon
(not for LW05211 and LW05212)
15 Bed base height adjustment (not for LW05211)
16 Legs-back simultaneous adjustment
17. Legs secon adjustment
18. Back adjustment
19. Wheel with brake
The manufacturer reserves the right to bring modicaons to
the product and its instrucon manual without advance noce
or modifying earlier producons.
The manufacturer is relieved of any responsibility for damages
resulng from misuse by untrained personnel, unauthorized al-
teraons or operaons, use of non-original spare parts, excep-
onal events, total or paral disregard of the instrucons dis-
played in this manual.
Bed control unit

5
ENGLISH
3.2 Descripon
The bed was designed and built to provide high-quality standards and sturdiness.
The medical device is composed of a bed base, named applied part, a footboard and a support headboard.
This three joint, four secon bed with adjustable height has the following specics:
• Steel square-meshed net frame 200x89 cm which is height adjustable using electronic controls provided in 43 or 86 cm
• Back secon adjustable from 0° to 70° using the electronic pusher (24V dc).
• Fixed pelvis secon
• Legs secon adjustable from 0° to 30° using the electronic pusher (24V dc).
• Back secon connuously adjustable together with the legs secon
• Removable wooden siderails
• Headboard and footboard height 44 cm
• This bed is intended to be used in private or care home, hospital or community environment, by users over 12 years old. However, it
can also be used as room furniture in the same environment. Use with other products must be evaluated in advance.
• Supplied wheels with brakes for headboard and footboard of 12,5 cm Ø
3.3 Oponal extras
ITEM
CODE
DESCRIPTION PHOTO
LW10205 Deluxe Bedrail
OPTIONAL EXTRA MAY
NOT BE AVAILABLE
LW10206 N-shaped Bedrail
OPTIONAL EXTRA MAY
NOT BE AVAILABLE
LW10207 Li Round Pole
The use of the dierent types of maresses from those shown requires the observance of the
minimum height for the later parapets and the requirements set by the UNI 60601-2-52 standard.
WARNING! Taking into account the safety devices for the paent, the manufacturer declines all
responsability in the case of using a dierent type of maress which fails to comply with the
minimum height of the parapets set by the UNI 60601-2-52 standard.

6ENGLISH
3.4 Technical specicaon
3.4.1 Technical specicaon
LW05202(B)
LW05207(B)
LW05202S
LW05202SL
LW05203(B)
LW05208(B)
LW05211
LW05212
LW05204 LW05206 (120cm
/ 140cm)
Bed mass 120 kg 108kg 70kgs(LW05211)
110kgs(LW05212) 200kg 165kgs/178kgs
Max capacity
(maress + user +
accessory)
180 kg 180kgs 170kgs 180kgs 280kgs
Maximum dimension 2150 X 1020 mm 2120 x 1030mm 2080 x 1020mm 2200 x
1015mm
2150 x 1320mm /
1520mm
Bed base height from
the oor (min/max)
380 / 790 mm
270 / 680 mm
(LW05202SL)
380/790 mm 420mm(LW05211)
330/650mm(LW05212) 315/685mm 380/790 mm
Backboard/footboard
height 560 mm 560 mm 560 mm 560 mm 560 mm
Bed base size 2000 X 900 mm 2000x900mm 2000x900mm 2000x900mm 2000x1200/
1400mm
Head secon 790 X 715 mm 790x 715 mm 790x 715 mm 790x 715 mm 820/840x715mm
Pelvis secon 860 X 205 mm 860x 205 mm 860x 205 mm 860x 205 mm 890/910x205mm
Legs secon 790 X 295 mm 790x 295 mm 790x 295 mm 790x 295 mm 820/840x295mm
Foot secon 790 X 440 mm 790x 440 mm 790x 440 mm 790x 440 mm 820/840x440mm
Angle moving back
secon (max) 70° 70° 70° 70° 70°
Angle moving legs
secon (max) 25° 25° 25° 25° 25°
Moving legs secon
height from the bed
base (max)
210 mm 210 mm 210 mm 210 mm 210 mm
Storage and packaging
temperature (in a dry
environment)
-10 ÷ 50°C -10 ÷ 50°C -10 ÷ 50°C -10 ÷ 50°C -10 ÷ 50°C
Temperature range of
usage environment 10 ÷ 50°C 10 ÷ 50°C 10 ÷ 50°C 10 ÷ 50°C 10 ÷ 50°C
Maress weight (max) 30 kg 30 Kg 30 Kg 30 Kg 30 Kg
User weight (max) 135 kg
Packaging sizes
HEADBOARD/
FOOTBOARD + BED
SPRING
1240 X 410 /
450(B) X 960 mm
(LW05202(S);
1240 X 390 / 410(B)
X 930 (LW05207)
1240 x
410/450(B) x 960
mm(LW05203);
1240x390/410(B)
x930(LW05208)
960x290x1040m-
m(LW05211); 960x215x-
1 0 4 0 m m ( b e d b o d y )
1550x315x940mm (bed
base)-LW05212
2150x285x-
950mm
1115x270x-
1300/1500mm
Packaging sizes SIDE
PANELS
2050 x 150 x 110
mm
2050 x 150 x 110
mm 2050 x 150 x 110 mm 2050 x 150 x
110 mm
2050 x 150 x 110
mm
Packaging sizes
MONKEY POLE
2074 x 400 x 400
mm
2074 x 400 x 400
mm 2074 x 400 x 400 mm 2074 x 400 x
400 mm
2074 x 400 x 400
mm

7
ENGLISH
3.4.2 Electric components
Supply voltage 230V AC
Operang voltage 24V DC
MAX power consumpon 220 W
MAX actuators thrust force 6000 N
MAX hand control voltage 24V DC
4. ASSEMBLY
4.1 Unpacking
Il manuale di istruzioni è parte integrante della fornitura.
Il manuale è desnato a clien, proprietari, personale addeo alla sicurezza, uten e manutentori.
Used symbols
The following pictograms can be found in the manual.
The bed comes disassembled into its parts in nr, 2 boxes.
Make sure all the components are in good condion before proceeding.
When the packed product is transported eith a trolley be
careful to avoid injuries from accidental roll.
Open the package and extract content with cauon,
making sure not to demage it.
Aer unpacking the product, make sure it is not damaged; otherwise, please contact the authorized dealer.
Damages caused during incorrect transport, unpacking or assembly are not covered under warranty.
Bed components:
BOX 1 BOX 2
Bed base and motor with in-
built control unit Headboard and footboard Wooden siderails
Operaons must be carried out by qualied personnel only
4.2 Assembly
The product must be transported following the direcons on the package; if manual handling
is necessary, keep in mind that one operator can carry a maximum load of 25 kg.
Li and move the bed slowly in order to avoid injuries from biomechanical overload of the spine.
If moving the product is necessary, we recommend the use of protecve gloves and the presence
of at least two operators to li the product.

8ENGLISH
The assembly operaon of the medical device must be carried out by at least two operators
in order to avoid damages to objects or persons.
Use protecve gloves The device is supplied dismantled
Bed base
- Insert the two inserts at the end of the bed base,
head side. The inserts must be assembled so that
one of them protrudes more than the other.
- Slightly ghten the two bolts, head side
- Push the bed base, foot side, against the two
inserts.
- Tighten the two bolts at the foot side.
- Complete ghtening all the bolts.
Motor and in-built control unit assembly
- When the bed base is assembled,
before proceeding and xing it to the
headboard and the footboard, the bed base must be overturned so that its
hooks are poinng upwards.
For LW05207(B)/LW05208(B)
- Starng from this posion of the bed base, proceed on assembling
the motor unit by pushing and make sure it is xed to the two
pins
- Slide out the two lids from the slots, where the hooks for
the bed shall be put
- Flip the motor and match the slots with the two protruding
hooks and push on.
- Reinsert the two lids into the motor over the hooks to secure
Before locang the hooks, please pay aenon to the the icons axed on the motor to ensure correct orientaon
HEAD SIDE LEG SIDE
For LW05202(B)/LW05203(B)/LW05202S/LW05202SL/LW05206/LW05204/LW05211/LW05212
The control unit is xed on the main bed plate
Labels are applied on the control unit with symbols illustrang the connecon point of the motor and control sockets. Implement the
links according to the following matches:

9
ENGLISH
M1 Head Motor
M2 Foot Motor
M3 Legrest Elevang Motor
M4 Backrest Elevang Motor
Handset Hand control
HEADBOARD /FOOTBOARD assembly
• Hook the bed base onto the headboard /footboard and push ghtly in order to block it in posion
• Tighten the bolts
WIRING assembly
For LW05207(B)/LW05208(B)
23. Headboard motor connecon
24. Footboard motor connecon
25. Remote connecon
Connect the motor of headboard
For LW05202(B)/LW05203(B)/LW05202S/LW05202SL/LW05206/LW05204 /LW05211/LW05212
To prevent cables from being damaged when the engines are acvated, follow the instrucons below:
• Connect the cables of the test/foot motors directly on the control unit.
• Connect the height adjustment motor cables contained in the heads directly on the control unit
• Connect the remote control cable to the control unit
• Connect the mains cable to the general 230V power supply.
• Bring the head/foot motors to a high posion.
• Carry out all secon movements, maress plaorm, and trendelenburg to check for interference between cables and moving parts.
• Make sure all cables are free and without risk of entangling in moving parts of the bed
Insert the monkey pole (loops from parts box)

10 ENGLISH
In order to avoid the damage of the cables when the engine is starng, strictly follow the
following instrucon:
- Connect the headboard/footboard cables straight to the central motor unit
- Connect the remote cable to the central motor unit
- Connect the mains cable to a 230V general electric supply
- Put the headboard/footboard motors in a high posion
- Perform movements of the secons, maress plaorm and trendelenburg in order to verify possible interference between the
cables and the moving parts
- Make sure all the cables are free from the risk of entanglement with the moving parts of the bed
Take care when handling the footboard the risk of crushing and damage to the product is real as
the adjustable foot-lier is not securely locked into the head or foot board.
Remove the plug from the socket before moving the bed
SIDE PANELS assembly
- Li the bed base approximately 1/4 to make the insert of the panels easier
- Insert the panels from below unl the stops click in posion
Conservare il disposivo eleromedicale in un luogo in cui la spina possa essere facilmente staccata
dalla pre-sa di corrente
5. USE
5.1 Use of the medical device
Keep the electro-medical device in a place where the plug can be easily disconnected from socket
The remote is provided with safety lock thanks to a magnet which turns on automacally when the
device has not been used for more than 30/40 seconds.
The device is not provided with a main switch, just plug into the mains socket to access all the
features. Pulling the plug o the mains socket works as emergency response on the power supply.
The bed must be seton its lowest height and the siderails raised while not supervised in order to
reduce the risk of falling.
