GLITZHOME Console Table User manual

Assembly Instruction
Console Table

1
PARTS LIST
TOP PANEL (A) LEG (B) BASE PANEL (C)
Qty: 1 Qty: 2 Qty: 1
Qty: 6 Qty: 4
HARDWARE LIST
Qty: 1
SPANNER (G)
Qty: 4
ALLEN BOLT (H)
Qty: 1
CONNECTING BAR (D)
PHILLIPS SCREW (E)
M4 x 16MM M6 x 12MM
BOLT LOCK (F)
Qty: 4
FLAT WASHER (J)
Qty: 1
ALLEN KEY (I)
Qty: 4
SPRING WASHER (K)
PRE-ASSEMBLY PREPARATION
•CAUTION: Assembly will require at least 2 adults. DO NOT use power tools.
Please inspect all items BEFORE assembly. If for any reason you need to return this item, please kindly
return it in it's original packaging.
•WARNING!
1. DO NOT let any sharp objects touch or rub the surface of the product.
2. When assembling, do not let children play around the working area.
3. DO NOT tighten all bolts and screws completely until the entire unit has been assembled and set up.
4. DO NOT USE if this product become damaged, and/or components are broken or missing.
•
MAINTENANCE: Please periodically check all fittings and re-tighten as necessary.
CARE AND CLEANING: DO NOT scratch or chip the finish. DO NOT use abrasive chemicals for cleaning.
Clean with mild soap on a soft rag. Rinse and dry thoroughly.
•
Qty: 1
PHILLIPS SCREW (L)
Ø4*12mm

2
C
C
K
B
B
B
FG
J
STEP 1
Attach the Base Panel (C) to the Legs (B) by using Bolt Lock (F), Spring Washer (K),
Flat Washer (J) and Spanner (G).
F x 4 J x 4 G x 1 K x 4
Qty: 1 Qty: 1 Qty: 1
PHILLIPS SCREW (O)
Qty: 2
STEEL PLATE (P)ANTI-TIPPING STRIP (M)
5*200mm Ø8.5*30mm 4*25mm 22*19*20mm
WALL ANCHOR (N)
K
FG
J

3
STEP 3
Attach the Top Panel (A) to both legs (B) by using Phillips Screws (E).
C
B
E
E
E x 6
A
STEP 2
Fix the Connecting Bar (D) to the Legs (B) by using Allen Bolt (H) and Allen Key (I).
C
B
D
D
H
H
H
H
I
I x 1H x 4

4
STEP 4
Attach steel plate (P) to top panel (A) with screw (L) using screwdriver. Place assembled
unit in desired position. Mark position of steel plate (P) on wall and remove unit. Drill one
hole on the wall and then put wall anchor (N) into the predrilled hole. Attach steel plate (P)
to wall anchor (N) with screw (O) using screwdriver. Place unit back into position. Attach
anti tipping strip (M) to steel plates (P) as shown.
After initial assembly, the product may
acclimate to its new environment.
Please ensure all screws are still
securely tightened.
O
WALL
PNOT INCLUDED
M
NOT INCLUDED
WALL
N
NOT INCLUDED
L
M
L x 1 M x 1 N x 1 O x 1 P x 2
