Goldmedal 5020 User manual

Part No. 76098
Countertop Baker Unit
Instruction Manual
Domestic and Export
Mechanical and Digital 5020 and 5023 Models
Cincinnati, OH 45241-4807 USA

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 2
SAFETY PRECAUTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any alterations to this equipment
will void the warranty and may cause a dangerous condition. This appliance
is not intended to be operated by means of an external timer or separate
remote-control system. NEVER make alterations to this equipment. Read the
Installation, Operating, and Maintenance Instructions thoroughly before
installing, servicing, or operating this equipment.
014_020416
WARNING
To avoid burns, DO NOT touch heated surfaces.
DO NOT place or leave objects in contact with heated surfaces.
009_092414
WARNING
ALWAYS wear safety glasses when servicing this equipment.
010_010914
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514
WARNING
Read and understand operator’s manual and all other safety instructions
before using this equipment. To order copies of the operator’s manual go to
gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive,
Cincinnati, OH 45241 USA 1-(800)-543-0862
022_060215

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page
SAFETY PRECAUTIONS (continued)
WARNING
DO NOT allow direct contact of this equipment by the public when used in
food service locations. Only personnel trained and experienced in the
equipment operation may operate this equipment.
Carefully read all instructions before operation.
012_010914
WARNING
This machine is NOT to be operated by minors.
007_010914
This applianc is not int nd d for us by p rsons (including childr n) with r duc d physical,
s nsory or m ntal capabiliti s, or lack of xp ri nc and knowl dg , unl ss th y hav b n giv n
sup rvision or instruction conc rning us of th applianc by a p rson r sponsibl for th ir saf ty.
Note: Improv m nts ar always b ing mad to Gold M dal’s quipm nt. This information may
not b th lat st availabl for your purpos s. It is critical that
you call Gold M dal’s T chnical S rvic D partm nt at 1-800-543-0862 for any qu stions
about your machin op rations, r plac m nt parts, or any s rvic qu stions. (Gold M dal
Products Co. do s not assum any liability for injury du
to car l ss handling and/or r ckl ss op ration of this quipm nt.)

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 4
INSTALLATION INSTRUCTIONS
Insp ction of Shipm nt
Aft r unpacking, ch ck thoroughly for any damag which may hav occurr d in transit. Claims should b
fil d imm diat ly with th transportation company. Th warranty do s not cov r damag that occurs in
transit, or damag caus d by abus , or cons qu ntial damag du to th op ration of this machin , sinc
it is b yond our control (r f r nc warranty in back of manual).
Manual
R ad and und rstand th op rator’s manual and all oth r saf ty instructions b for using this quipm nt.
To ord r copi s of th op rator’s manual go to gmpopcorn.com or writ to Gold M dal Products Co.,
10700 M dallion Driv , Cincinnati, OH 45241 USA 1-(800)-543-0862.
S tup
This unit has b n t st d at th factory.
1. R mov all packaging and tap prior to op ration.
2. Plac unit on a sturdy, l v l bas for us .
3. Aft r s tup, th unit should b cl an d prior to us (s Car and Cl aning s ction of this
manual).

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 5
ELECTRICAL RE UIREMENTS
El ctrical R quir m nts
Th following pow r supply must b provid d:
Model No. 5020, 5020E, 5020ET, 5023: 120 Volts, 1000 Watts, 60 H rtz
Model No. 5020EX, 5020ETX, 5023EX: 230 Volts, 1000 Watts, 50 H rtz
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
A c rtifi d l ctrician must furnish suffici nt pow r for prop r machin op ration and install any
suppli d r c ptacl . W r comm nd this quipm nt b on a d dicat d and prot ct d circuit. Failur to
wir prop rly will void th warranty and may r sult in damag to th machin . It is Gold M dal Products
Co.’s r comm ndation that this machin b plugg d dir ctly into a wall outl t. Th us of xt nsion cords
is not r comm nd d du to saf ty conc rns, and may caus sacrific d and/or r duc d p rformanc . Mak
sur cord is locat d to pr v nt a trip hazard or unit ups t.
B for You Plug In Machin
1. Mak sur all machin switch s ar OFF b for plugging quipm nt into r c ptacl .
2. Mak sur wall outl t can acc pt th ground d plugs (wh r applicabl ) on th pow r supply
cord.
3. Th wall outl t must hav th prop r polarity. If in doubt, hav a comp t nt l ctrician insp ct
th outl t and corr ct if n c ssary.
4. DO NOT us a ground d to un-ground d r c ptacl adapt r (wh r applicabl ).
5. Install unit in a l v l position.
CAUTION
If the supply cord is damaged, it must be replaced by Gold Medal Products Co.,
its service agent or similarly qualified persons in order to avoid a hazard.
039_080614

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 6
OPERATING INSTRUCTIONS
(For Mechanical Bak rs)
For l ctronic bak r op rating instructions, s Digital Bak r s ction.
G n ral Op rating Instructions
1. Always use fresh batter and do not allow it to warm up too much.
2. During op ration, fr qu nt cl aning with a soft-bristl d brush and r -s asoning th grids as
n d d, will nsur a gr at tasting product.
3. L av th grids in th clos d position wh n v r possibl (op n grids caus xc ssiv
carbon build-up).
4. If th bak r is not b ing going to b us d within 20-30 minut s, turn th unit off.
5. DO NOT apply b swax, paraffin, or any oth r wax s to grid surfac s.
Pr -h ating th Unit
1. Flip th Pow r Switch to th ON Position. (Th R d Light will turn ON and stay on whil th
machin is in op ration.)
2. Th Gr n Light will turn ON indicating th machin is h ating. Wh n th Gr n Light go s
OFF, th unit has r ach d th corr ct t mp ratur and you can b gin baking.
Note: Th Gr n Indicator Light will continu to cycl OFF/ON during th baking op ration.
Grid S asoning
COATED (Non-Stick) Grids: Aft r th initial s asoning of a n w unit, coat d grids do not n d to b
s ason d r gularly. D p nding on usag , or if coat d grids hav b n scour d in th cl aning
proc ss, a v ry light spray of S as'n-Kl n may b n d d prior to th n xt us . Follow th st ps
b low to initially s ason n w grids. DO NOT us m tallic ut nsils on coat d grids.
NON-COATED Grids: Prior to first us of a n w bak r, non-coat d grids must b s ason d for at l ast 1½
to 2 hours for prop r op ration. Spray grids with S as'n-Kl n; clos th bak r and wait 20 to 30
minut s. Op n th bak r; notic th grids ar starting to turn dark. R p at this proc ss 3 to 4
tim s until fully s ason d. No silv r will b visibl on fully s ason d grids.
To Season Baker Grids: Follow th st ps b low to s ason bak r grids prior to start-up for th day (and for
th initial s asoning of coat d grids):
1. Flip th Pow r Switch to th ON position and allow th bak r to pr -h at.
2. Op n grids and lightly spray S as'n-Kl n (Gold M dal It m No. 5524CN) on th grid surfac s.
3. Clos th bak r, s t tim r to 3 minut s, and allow th grids to s ason through on cook cycl
without product. (Always turn th Tim r Knob past 3, th n s t th d sir d cooking tim .)
4. If sticking occurs during bak r op ration, lightly r -spray S as'n-Kl n on th grid surfac s.

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 7
Batt r Pr paration
Whil th bak r is pr h ating, pr par th Waf-A-Con Mix (Gold M dal It m No. 8212, six 5 lb. bags p r
cas ) or Old Fashion Waf-A-Con Mix (Gold M dal It m No. 8209) according to th instructions b low.
1. Plac 40 oz. of wat r into a bowl and add (1) 5 lb. bag of mix.
2. Stir with wir whisk until smooth.
3. R st batt r 10 minut s.
4. A 2 oz. ladl mak s on 8 inch con (on cup mak s 5 con s).
Baking Instructions for M chanical Units
Onc th bak r is pr -h at d and th grids ar s ason d accordingly, th unit is r ady to bak .
Note: Th unit tak s approximat ly 1 minut to bak . Cook tim vari s bas d on th mix that
is us d.
1. Op n th grid ass mbly and lightly s ason both grids with S as'n-Kl n (for non-stick coat d
grid mod ls, only spray as n d d).
2. Us a 2 oz. ladl to disp ns batt r into th c nt r of th low r grid.
3. Clos th top grid.
4. Turn Tim r Knob to 1 minut . (Always turn th Tim r Knob past 3, th n s t th d sir d
cooking tim .)
5. Wh n th unit b ps, r mov con from grill and form imm diat ly using th Easy Waffl Con
Roll r (Gold M dal It m #5028).
6. B sur con is push d down into th bottom of th con roll r to mak a clos d nd (this
k ps th con from l aking).
7. Grids should b r -s ason d as n d d during baking and aft r ach cl aning.
Note: K p th grids clos d b tw n baking p riods for b st baking p rformanc . Us a soft
bristl d brush to r mov any con r sidu from grids whil baking.

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 8
OPERATING INSTRUCTIONS
(For Digital Bak rs)
For standard (non-digital) bak r op rating instructions, s M chanical Bak r s ction.
G n ral Op rating Instructions
1. Always use fresh batter and do not allow it to warm up too much.
2. During op ration, fr qu nt cl aning with a soft-bristl d brush and r -s asoning th grids as
n d d, will nsur a gr at tasting product.
3. L av th grids in th clos d position wh n v r possibl (op n grids caus xc ssiv
carbon build-up).
4. DO NOT apply b swax, paraffin, or any oth r wax s to grid surfac s.
Pr -h ating th Unit
1. Flip th Pow r Switch to th ON position.
Th display will r ad “Lo” until th unit r ach s 75°F (24°C), and th H at Indicator Light will
turn ON and r main on until th unit r ach s th s t cooking t mp ratur .
Note: Th digital bak r has a pr s t cooking t mp ratur of 385°F (196°C), and cook tim of
1 minut (1:00). To chang th s s ttings, s Changing Cook Tim and T mp ratur
S t Point s ction of this manual.
2. Wh n th H at Indicator Light go s OFF, th unit has r ach d th corr ct t mp ratur and is
r ady for us .
Note: Th H at Indicator Light will continu to cycl OFF/ON during th baking op ration.
Grid S asoning
COATED (Non-Stick) Grids: Aft r th initial s asoning of a n w unit, coat d grids do not n d to b
s ason d r gularly. D p nding on usag , or if coat d grids hav b n scour d in th cl aning
proc ss, a v ry light spray of S as'n-Kl n may b n d d prior to th n xt us . Follow th st ps
b low to initially s ason n w grids. DO NOT us m tallic ut nsils on coat d grids.
Heat Indicator Light
(Light ON indicat s unit is h ating.)
Digital Control View
(Unit Pr h ating)
°
F or
°
C
Temperature Display
(°F shown as r f r nc )

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 9
NON-COATED Grids: Prior to first us of a n w bak r, non-coat d grids must b s ason d for at l ast 1½
to 2 hours for prop r op ration. Spray grids with S as'n-Kl n; clos th bak r and wait 20 to 30
minut s. Op n th bak r; notic th grids ar starting to turn dark. R p at this proc ss 3 to 4
tim s until fully s ason d. No silv r will b visibl on fully s ason d grids.
To Season Baker Grids: Follow th st ps b low to s ason bak r grids prior to start-up for th day (and for
th initial s asoning of coat d grids):
1. Flip th Pow r Switch ON and allow th bak r to pr -h at.
2. Op n grids and lightly spray S as'n-Kl n (Gold M dal It m No. 5524CN) on th grid surfac s.
3. Clos th grids, th n pr ss th Start Button and allow th grids to s ason through on cook
cycl without product.
4. If sticking occurs during bak r op ration, lightly r -spray S as'n-Kl n on th grid surfac s.
Batt r Pr paration
Whil th bak r is pr -h ating, pr par th Waf-A-Con Mix (Gold M dal It m No. 8212, six 5 lb. bags p r
cas ) or Old Fashion Waf-A-Con Mix (Gold M dal It m No. 8209) according to th instructions b low.
1. Plac 40 oz. of wat r into a bowl and add (1) 5 lb. bag of mix.
2. Stir with wir whisk until smooth.
3. R st batt r 10 minut s.
4. A 2 oz. ladl mak s on 8 inch con (on cup mak s 5 con s).
Baking Instructions for Digital Units
Onc th bak r is pr -h at d and th grids ar s ason d accordingly, th unit is r ady to bak .
Note: Th unit tak s approximat ly 1 minut (1:00) to bak . Cook tim vari s bas d on th
mix that is us d. To adjust th product cook tim , s Changing Cook Tim and
T mp ratur S t Point s ction of this manual.
1. Op n th grid ass mbly and lightly s ason both grids with S as'n-(for non-stick coat d grid
mod ls, only spray as n d d).
2. Us a 2 oz. ladl to disp ns batt r into th c nt r of th low r grid.
3. Clos th top grid and pr ss th Start Button. Th digital display will show th cook tim
countdown. Wh n th countdown is compl t , th unit will b p and th display will r turn to
th t mp ratur vi w (unl ss th tim display was s l ct d).
4. Wh n th unit b ps, r mov con from grill and form imm diat ly using th Easy Waffl Con
Roll r (Gold M dal It m #5028).
5. B sur con is push d down into th bottom of th con roll r to mak a clos d nd (this
k ps th con from l aking).
6. Grids should b r -s ason d as n d d during baking and aft r ach cl aning.
Note: K p th grids clos d b tw n baking p riods for b st baking p rformanc . Us a soft
bristl d brush to r mov any con r sidu from grids whil baking.

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 10
Changing Cook Time and
Temperature Set Point
(for DIGITAL Bak rs Only)
Th cook tim (1 minut ) and t mp ratur s t point 385°F (196°C) for this l ctronic bak r ar pr s t at
th factory. To chang th pr s t cook tim or t mp ratur , follow th instructions b low.
To Chang Cook Tim
1. Pr ss SET and DN for 3 s conds to display th tim s tting (X:XX, th min:s cs colon will b
flashing to show it is in tim r program mod ).
2. Pr ss UP to incr as th tim s tting. Pr ss DN to d cr as th tim s tting.
3. Pr ss SET again to sav th tim s tting.
To Chang T mp ratur S t Point
1. Pr ss SET and UP for 3 s conds to display th t mp ratur s t point (XXX°F, th d gr symbol
will b flashing to show it is in t mp ratur program mod ).
2. Pr ss UP to incr as th tim s tting. Pr ss DN to d cr as th tim s tting.
3. Pr ss SET again to sav th t mp ratur s t point.
UP Button
DN Button
Degree Symbol
(flash s to show
unit
is in t mp ratur program mod )
Min:Secs Colon
(flash s to show
unit is in tim r program mod )
SET Button

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 11
Care and Cleaning
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
DO NOT immerse in water. DO NOT clean appliance with a water jet.
Always unplug the equipment before cleaning or servicing.
025_111616
WARNING
To avoid burns, DO NOT touch heated surfaces.
DO NOT place or leave objects in contact with heated surfaces.
009_092414
Good sanitation practic d mands that all food pr paration quipm nt b cl an d r gularly (only us
non-toxic, food grad cl an rs). A cl an looking, w ll-k pt machin is on of th b st ways of adv rtising
your product.
Daily Cl aning/R moving Exc ss Carbon (for Non-coat d Mod ls)
S n xt s ction for cl aning bak rs with non-stick coated grids.
Follow th dir ctions b low ach day aft r us to cl an and sanitiz bak rs with non-coated grids.
1. With th machin OFF, unplug th unit and allow it to cool b for att mpting to cl an.
2. Plac a shallow drip pan und r th grids. Op n top grid, th n wip down both grid surfac s to
cl an, using a cl an cloth damp n d with hot wat r. A soft PLASTIC bristl brush may b us d
if n d d.
3. Us a cloth spray d with conc ssion quipm nt cl an r (Gold M dal It m #2580 Watchdog
Conc ssion Equipm nt Cl an r) to wip down th r st of th bak r.
DO NOT us ov n cl an rs or abrasiv mat rials as th y will damag parts of th machin .
4. Th drip pan may b tak n to th sink to cl an.
5. R -s ason grids as d scrib d in Grid S asoning s ction.
For EXTREME purposes only, to cl an xtra dirty grids, us a LIGHT coating of Kl n-Sw p (Gold M dal
It m No. 2173CN) on grids ONLY (DO NOT USE ON NON-STICK COATED GRIDS), th n compl t ly
r mov any Kl n-Sw p using a cl an cloth damp n d with hot wat r. Always discard th first waffl /con
mad aft r using Kl n-Sw p.
CAUTION
DO NOT get Kleen
-
Sweep on skin, paint, floors, walls, or plastic tiles.
DO NOT USE ON ANY COATED GRID OR COATED SURFACE! Use
rubber gloves and protective eyewear when using Kleen-Sweep. If contact is
made, wash immediately with water. Review all warnings on Kleen Sweep
product prior to use.
029_061214

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 12
Daily Cl aning/R moving Exc ss Carbon (for Non-stick Coat d Grid Mod ls)
Follow th dir ctions b low ach day aft r us to cl an and sanitiz bak r units with non-stick coated
grids.
Note: NEVER us Kl n-Sw p on non-stick coat d grids. It can caus damag to th non-stick
coating.
1. With th machin OFF, unplug th unit and allow it to cool b for att mpting to cl an.
2. Plac a shallow drip pan und r th grids.
3. Op n top grid, th n wip down both grid surfac s to cl an, using a cl an cloth damp n d with
hot wat r. A soft PLASTIC bristl brush may b us d if n d d.
4. Us a cloth spray d with conc ssion quipm nt cl an r (Gold M dal It m #2580 Watchdog
Conc ssion Equipm nt Cl an r) to wip down th r st of th bak r.
DO NOT us ov n cl an rs or abrasiv mat rials as th y will damag parts of th machin .
5. Th drip pan may b tak n to th sink to cl an.

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 1
MAINTENANCE INSTRUCTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any alterations to this equipment
will void the warranty and may cause a dangerous condition. This appliance
is not intended to be operated by means of an external timer or separate
remote-control system. NEVER make alterations to this equipment. Read the
Installation, Operating, and Maintenance Instructions thoroughly before
installing, servicing, or operating this equipment.
014_020416
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514
CAUTION
THE FOLLOWING SECTIONS OF THIS MANUAL ARE INTENDED ONLY
FOR QUALIFIED SERVICE PERSONNEL WHO ARE FAMILIAR WITH
ELECTRICAL EQUIPMENT. THESE ARE NOT INTENDED FOR THE
OPERATOR.
027_010914

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 14
ORDERING SPARE PARTS
1. Identify the needed part by checking it against the photos, illustrations, and/or
parts list.
2. Use only approved replacement parts when servicing this unit.
3. When ordering, please include part number, part name, and quantity needed.
4. Please include your model number, serial number, and date of manufacture (located on the
machine nameplate/data plate) with your order.
5. Address all parts orders to:
Parts Department
Gold Medal Products Co.
10700 Medallion Drive
Cincinnati, Ohio 45241-4807
Or, place orders by phone or online:
Phone: [phone]
[phone]
Fax: [phone]
[phone]
E-mail: [e-mail]
Web Page: gmpopcorn.com

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 15
PARTS BREAKDOWN (Pg. 10-14)
Exterior View - Mechanical Timer Models
R d Pilot Light (1)
P.N. 41033
Export Mod ls (1) P.N. 41032
Gr n Pilot Light
(1)
P.N.
41469
Export Mod ls (1) P.N. 41466
Waffl Iron Cov r (2
)
P.N. 76049
S N xt Pag for
Handl Compon nts
Toggl Switch (1)
P.N. 47201
Toggl Switch Boot (1)
P.N. 76382
Tim r (1)
P.N. 76300
Tim r Knob (1)
P.N. 76301
S n xt pag for
Hing Compon nt
br akdown
Drip Pan (1)
P.N. 76104
Acorn Nut (4)
P.N. 46528
Switch Pan l D cal (1)
P.N. 76309

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 16
PARTS BREAKDOWN (Continued)
Hinge Components
Should r Scr w (2)
P.N. 68726
Hing Block (1)
P.N. 68760
Wir Harn ss M chanical
Mod ls (1) P.N. 76557
(includ s sl ving)
Wir Harn ss Digital Mod ls
(1) P.N. 76557E (includ s
sl ving; do s NOT includ
th rmocoupl s)
11” Conduit (11”)
Part No: 76651-11
Conduit Clamp S t (2)
Part No: 87319
Top Support (1)
Part No: 68729
Bottom Support (1)
Part No: 76226
Wir Clip (2)
Part No: 76216
Cag Nut (4)
Part No: 76081

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 17
PARTS BREAKDOWN (Continued)
Interior and Handle arts for
Mechanical Timer Models and Digital Baker Models
500W Tubular El m nt (1)
P.N. 76552
Export Mod ls
(500W Tubular El m nt)
P.N. 76552EX
10
-
24
”
x
¾
” Scr w (4)
P.N.
75107
Mechanical Timer Models Only:
Th rmostat (1) P.N. 76337
Us Th rmostat fast n rs:
8-32 x 1” Scr w - P.N. 49076
#8 Int. Tooth LW - P.N. 12132
El m nt Clamp (2)
P.N. 76072
Latch (1)
P.N. 76094
3/8” x
16
”
H x Nut
(1)
P.N. 46000
Handl
(1)
P.N. 76075
Gr n Bak Handl
Mod l 5023, 5023E, 5023EX
P.N. 67856
Thr ad d Pin
P.N. 76107
10
-
24 Acorn Nut
P.N. 46528
Bak r Handl Shaft
P.N. 56045
Con Iron Grid (2)
Mod l No. 5020, 5020E,
5020EX, 5020XE P.N. 75090
Mod l No. 5020T, 5020ET,
5020ETX P.N. 75090T
Danish Grid (2)
Mod l No. 5023, 5023E,
5023EX P.N. 76195
Electronic Models
with
Th rmocoupl P.N. 76346
Us fast n r: 8-32 X 1/4 HX HD
Scr w P.N. 42045

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 18
PARTS BREAKDOWN (Continued)
Mechanical Timer Models – Control Interior, Bottom View
Bottom Glid (4)
P.N 47328
Crutch Tip (4)
P.N 49123
Pow r Supply Cord (1)
P.N 22038
Export Mod ls
P.N. 42369
Strain R li f (1)
P.N. 76026
Control Box Cov r (1)
P.N. 76053

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 19
PARTS BREAKDOWN (Continued)
Digital Baker Models - Exterior View and Control Interior View
*Digital Baker Interior Control Breakdown
Rock r Switch (1)
P.N. 42798
Rock r Switch Cov r (1)
P.N. 48786
Mount Scr w (2)
P.N 76190
Timm rman Nut (2)
P.N. 76081
Ov rlay (1)
P.N. 76549
Digital Bak r
Control (1) P.N. 76540A
Export Mod ls (1) P.N. 76540AX
Push Button (1)
P.N. 41031
Toggl Switch Boot (1)
P.N. 76382
H at Sink (1)
P.N. 48673
R lay (1)
P.N. 76542
Th rmal Compound
P.N 87481
Th rmocoupl Wir s
P.N 76346
Us fast n r:
8-32 X 1/4 Scr w
P.N. 42045
1UF 250VAC Capacitor (Not shown in
int rior vi w)
Export Mod l 5020XE,
5020ETX P.N. 55515
Pow r Supply Cord (1)
P.N 22038
Export Mod ls
P.N. 42369
S Hing Compon nt
Br akdown s ction
Bottom Glid (4)
P.N 47328
Crutch Tip (4)
P.N 49123
Strain R li f (1)
P.N. 76026
Control
Box Cov r (1)
P.N. 76053
Wir Harn ss Digital
Mod ls (1) P.N. 76557E
(includ s sl ving;
do s NOT includ
th rmocoupl s)

Countertop Baker Unit Model No. 5020, 5020T, 5020E, 5020ET, 5020EX, 5020XE 5020ETX, 502 , 502 E, 502 EX
http://www.gmpopcorn.com Page 20
Wiring Diagram
Domestic Mechanical Timer Models
