Great Little Trading L5156 User manual

1
Growing Garden Wooden Toy
22/03/2021
V2
easy - medium - hard
Assembly Difculty
one-person job
L5156
A few important pointers before you start:
• Please read the instructions right through before you start, and check
that all the components have been included in the pack; we nd
separating all the hardware into piles makes it easier to be sure that
everything is present and correct.
• Make sure you have the right tools.Allen keys are provided if required,
but screw drivers and other tools are not. You’ll nd details of the tools
you need at the beginning of the instructions.
• Do not throw away any packing materials until assembly is complete,
just in case you accidentally discard smaller parts or hardware.
Thank you for shopping with GLTC, we hope you enjoy
having this product in your home.
We know assembling furniture, toys or accessories is not everyone’s
favourite way to spend their time, so we’ve tried to make assembling
this item as quick and painless as possible.
Hopefully our efforts will have been worthwhile and you’ll sail
through the whole process. But if it all feels a bit too much
like hard work, then we do have an assembly company we
can recommend: the Flatpack Construction Company offers a
nationwide service and can be contacted on 0843 289 4951 or
www.atpackconstruction.co.uk.

2
Safety Warnings:
• PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
• WARNING! Not suitable for children under 3 years due to small parts
which may become detached and present a choking hazard.
• CAUTION Adult assembly required.Assembly to be carried out by a
competent adult only.
• Remove all packaging before giving to your child.
• In an unassembled state product contains small parts which may pose
a choking hazard, not suitable for children under 3 years.
• Assemble and use on a at and level surface.
• During assembly children should be kept away from the product due
to possible risk of injury.
• Do not use this item if any components are missing or damaged.
• DO NOT use power tools in the assembly of this product as there is a
risk of over-tightening and consequently splitting of the wood.
• Check all xtures and ttings regularly and tighten as necessary.
Customer Service:
• If you nd that any components are missing or damaged, please do
not begin assembly and do not use the item. Please contact GLTC
Customer Services on 0344 848 6000 immediately.
• We do stock spare hardware packs at our warehouse, so we should be
able to send you a replacement pack immediately if required.
Product Care:
• Wipe clean using a soft damp cloth followed by a dry cloth.
• Do NOT use cleaning products which contain ammonia, solvents or
abrasive material.
• Do NOT expose the item to extremes of heat and humidity.
Could we do better?
If there is anything you think could be improved in these instructions or in
the assembly of this product we’d be grateful if you could let us know; we’ll
pass any helpful hints and tips on to other customers via our website and
update the instructions.
All you need to do is drop us a line at [e-mail]
Thank you
Registered Address:
GLTC Ltd, 12 Buckhold Road,
Wandsworth, London, SW18 4GP, United Kingdom
Authorised Representative:Authorised
Representative Service, 77 Camden Street Lower,
Dublin, D02 XE80, Ireland

3
Component Check List Hardware Check List
You will need
(not supplied)
Phillips Head
Screwdriver
A B C D H1 H2
E F G H
I J K L
M N
1x 1x 1x 1x 12x Bolts 12x Barrel Nuts
1x 1x 1x 1x
1x 1x 1x 2 x
3x 3x 1x 1x
2x 2x 1x 6x
1x 1x 2x 1x
S T
U V
O P
Q R
W X

4
STEP 1:
Attach parts B & C to panel A using 2x barrel nuts (#2) and bolts (#1).
STEP 2:
Slot in assembled panels A,B & C to panel D.
STEP 3:
Line up panel E onto the front edge, using the dowels on panels C & D.
STEP 4:
Insert 1x barrel nut (#2), ready for step 6 into panel E.
Note: ensure the nut is aligned correctly so the bolt can be easily screwed in in
step 6. The hole on the barrel nut should be pointing towards the hole where the
barrel nut bolt will be inserted. You will need this to complete step 6.
A
B
#1
#1
#2
#2
#2
Hardware for Step 1:
2x #1 Barrel Nut Bolts
2x #2 Barrel Nuts
Hardware for Step 4:
C
D






E

#2
D
C
1x #2 Barrel Nut

5
Hardware for Step 7:
1x #2 Barrel Nut
STEP 6:
Attached panel G to the side using 3x barrel nuts (#2) & 3x bolts (#1).
Please note rst Barrel Nut & Bolt to screw in is highlighted on the image.
This is the bolt that will be screwed into the barrel nut in step 4.
STEP 8:
Slide in panel H using the slots on panel B.
STEP 5:
Slide in panel F using the slots on panel C.
STEP 7:
(Repeat step 4 again for the other end).
Insert 1x barrel nut (#2), ready for step 9 into panel E.
Note: ensure the nut is aligned correctly so the bolt can be easily screwed in in
step 9. The hole on the barrel nut should be pointing towards the hole where the
barrel nut bolt will be inserted.You will need this to complete step 9.
#2
#2
#1
#1
Hardware for Step 6:
3x #1 Barrel Nut Bolts
3x #2 Barrel Nuts
#2 #2

F







H
B

6
STEP 9:
Attached panel I to the side using 3x barrel nuts (#2) & 3x bolts (#1).
Please note rst Barrel Nut & Bolt to screw in is highlighted on the image.
This is the bolt that will be screwed into the barrel nut in step 7.
STEP 10:
Attach Panel J to panel K using 2x barrel nuts (#2) & 2x bolts (#1).
STEP 11:
Attach assembled panels J & K to base using 2x barrel nuts
(#2) & 2x bolts (#1).
Your play unit is now complete.
Hardware for Step 9:
Hardware for Step 11:
Hardware for Step 10:
2x #1 Barrel Nut Bolts
2x #2 Barrel Nuts
2x #2 Barrel Nuts
2x #1 Barrel Nut Bolts
J
K





I
#1
#1
#1
#1
#2
#2
#2
#2
#2
#2
#1
#1
#1







Copyright© 2021 G.L.T.C. Ltd. All rights reserved.
Great Little Trading Company and GLTC are registered trade marks of G.L.T.C. Limited.
3x #1 Barrel Nut Bolts
3x #2 Barrel Nuts
