Great Little Trading Abbeville Storage- Four CubeUnit User manual

1
Abbeville Storage- Four Cube
Unit
A few important pointers before you start:
• Please read the instructions right through before you start, and check
separating all the hardware into piles makes it easier to be sure that
everything is present and correct.
• Make sure you have the right tools. Allen keys are provided if
of the tools you need at the beginning of the instructions.
• It’s a good idea to build the unit in the room where you are going to
be using it, to avoid the need to move it after it’s been assembled.
• Do not throw away any packing materials until assembly is complete,
just in case you accidentally discard smaller parts and hardware.
Thank you for shopping with GLTC, we hope you enjoy having this
product in your home.
We know assembling furniture, toys or accessories is not everyone’s
favourite way to spend their time, so we’ve tried to make assembling
this item as quick and painless as possible.
Hopefully our efforts will have been worthwhile and you’ll sail through
the whole process. But if it all feels a bit too much like hard work,
then we do have an assembly company we can recommend: the
Flatpack Construction Company offers a nationwide service and can
be contacted on
one-person job 08/12/2017
V3
easy - medium - hard
www.gltc.co.ukwww.gltc.co.uk

2
Safety Warnings:
• Adult assembly required, assemble and use on a flat surface.
• CHOKING HAZARD – This product contains small parts and must
be assembled by an adult. Special care should be taken in the
unpacking and assembly of this item as unassembled parts may be a
choking hazard to children under 3 years old.
• During assembly, children should be kept away from the product due
to possible risk of injury.
• Do not use power tools in the construction of this product.
• This product is heavy, so we recommend that you build it where you
are planning to use it.
• All assembly fastenings should be tightened properly and periodically
checked; care should be taken that no fittings are loose.
• Serious or fatal crushing injuries can occur from furniture tipping over.
Ensure you secure this furniture product to the wall before you use it using
the kit provided. If you have not received an anti-tip kit with your
product please contact Customer Services.
• Keep all relevant information for future reference.
Customer Service:
•
not begin assembly and do not use the item. Please contact
GLTC Customer Services on 0344 848 6000 immediately.
•We do stock spare hardware packs at our warehouse, so we should
be able to send you a replacement pack immediately if required.
Product Care:
•Wipe clean using a soft damp cloth followed by a dry cloth.
•Do NOT use cleaning products which may contain ammonia,
solvents or abrasive material.
•Do NOT expose the furniture to extremes of heat and humidity.
Could we do better?
If there is anything you think could be improved in these instructions or in
the assembly of this product we’d be grateful if you could let us know;
we’ll pass any helpful hints and tips on to other customers via our website
and update the instructions.
All you need to do is drop us a line at [email protected]
Thank you

3
AAAA
G
C
B
D
EF
#7
Component Check List: All Hardware Component Check List:
H
#5 6 x Bolts
42mmL
#6 6 x Barrel Nuts
9mmDia
1 x Allen Key
#2 10 x Cam Dowels
35mL
#1 16x Wooden Dowels
20mmL
#3 10 x Cam Locks
14mmDia
#4 12 x Screws
12mmL
1 x Base Panel
1 x Right Side Panel
1 x Left Side Panel
1 x Horizontal Shelf
1 x Vertical Divider Panel
1 x Top Panel
1 x Bottom Back Panel
1 x Top Back Panel
You will need:
(not supplied)
Philips Head Screwdriver

4
Assembly:
STEP 3: Attach the right side panel
STEP 2: Prepare the right side panel
Hardware for Step 2: Hardware for Step 3:
2x #1 Wooden Dowels
2x #2 Cam Dowels
STEP 1: Slot the shelf panels together as shown
#2
#1
B
2x #3 Cam Locks
Note: 1. Wooden dowels should fit snuggly and push in with your fingers.
Do not use force or a hammer as the wood may split.
2. Do not over-tighten the cam dowels.
Note:
Do not use power tools.
Turn each of the cam locks
(#3) clockwise to lock them.
C
D
C
D
B
#3
#3

STEP 4: Prepare the left side panel
Hardware for Step 4:
2x #1 Wooden Dowels
2x #2 Cam Dowels
#2
#1
#2 #1
A
Note: 1. Wooden dowels should fit snuggly and push in with your fingers. Do not use force
or a hammer as the wood may split.
2. Do not over-tighten the cam dowels.
5
B
A
C
D
Hardware for Step 5:
2x #3 Cam Locks
STEP 5: Attach the left side panel
B
A
C
D
F#5
#5
#1
#1
#6
#6
#1
STEP 6: Attach the base panel
Do not use force or a hammer as the wood may split.
Hardware for Step 6:
6x
6x #6 Barrel Nuts
6x #1 Wooden Dowels
#5 Bolts
#5
#5
#1
Do not use power tools.
Turn each of the cam locks
(#3) clockwise to lock them.
#3

6
STEP 8: Attach the top panel
STEP 7: Prepare the top panel
Hardware for Step 8:
6x#3 Cam Locks
STEP 9: Attach the back panels. Please note that the
x2 pilot holes indicated are to attach the anti-tip
straps included separately with this item.
The anti-tip straps should now be attached to the unit
and the wall. For details on securing this please see
the anti-tip kit instructions included with the product.
Alternative safety straps available at www.gltc.co.uk
Your unit is ready to use.
Hardware for Step 9:
12x#4 Screws
Hardware for Step 7:
6x #1 Wooden Dowels
6x #2 Cam Dowels
E
#1
#2
#2
#2 #1
#1
2. Wooden dowels should fit snuggly and push in with your fingers. Do not
use force or a hammer as the wood may split.
Note: 1. Do not over-tighten the cam dowels
Note:
Do not use power tools.
Turn each of the cam locks
(#3) clockwise to lock them.
E
#3
#3
#4
#4
#4
#4
#4
#4
#4
#4
#4
H
G
