GSi 40 Series Instructions for use

18 Ft., 21 Ft., 24 Ft., and 27 Ft.
Diameter Bins (All Rings)
Models:
40-SERIES 4.00'' CORRUGATION BINS
6000 LB. PEAK LOAD ROOF WITH FC
STIFFENERS
Construction Manual
PNEG-4224
Version 3.0
Date: 10-24-18
PNEG-4224

All information, illustrations, photos, and specifications in this manual are based on the latest
information available at the time of publication. The right is reserved to make changes at any
time without notice.
2PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins

Contents
Chapter 1 Safety Precautions ....................................................................................................................5
Safety Guidelines for Bins............................................................................................................6
Cautionary Symbol Definitions......................................................................................................7
Safety Cautions...........................................................................................................................8
Safety Decals ...........................................................................................................................13
Safety Sign-off Sheet.................................................................................................................15
Chapter 2 General Overview....................................................................................................................17
General Information...................................................................................................................17
Tools Required for Construction..................................................................................................17
Guidelines for Proper Storage of Grain Bin Materials Prior to Construction.....................................18
Overview for a Typical Bin Installation .........................................................................................18
Guidelines for Construction Procedures and Lifting Jack Usage....................................................19
Instructions for Stirring Devices ..................................................................................................20
Guidelines for Placement of the Decal Sidewall Sheet..................................................................21
Chapter 3 Foundations ............................................................................................................................23
Foundation Recommendations...................................................................................................23
Selecting the Proper Site Location..............................................................................................23
Scribe the Diameter...................................................................................................................24
Foundation Forms .....................................................................................................................25
Preparing the Foundation Forms ................................................................................................25
Placing the Reinforcement .........................................................................................................26
Anchor Bolt Detail .....................................................................................................................26
Anchor Bolt Charts ....................................................................................................................27
Placement of the Vane Axial Fan Foundation...............................................................................31
Placement of the Centrifugal Fan Foundation ..............................................................................32
Floating Monolithic Foundations for Bins (with up to 5 Rings)........................................................34
Frost Free Foundation Recommendations...................................................................................35
Inverted “T” Foundation (3000 PSF Soil Bearing Capacity) ...........................................................37
Chapter 4 Hardware requirements...........................................................................................................39
Bolt and Nut Pairings.................................................................................................................39
Hardware for 2–Post Sidewall Sheets on 4 in. Corrugation Bins 12 to 60 ft. in Diameter ..................40
Bolt Torque Specifications..........................................................................................................40
Identifying Bolt Grades ..............................................................................................................41
Bolt Identification.......................................................................................................................42
Bolt S-10260.............................................................................................................................42
Bolt S-7483...............................................................................................................................42
Bolt S-7485...............................................................................................................................43
Bolt S-7487...............................................................................................................................43
Bolt S-7488...............................................................................................................................43
Bolt S-10261.............................................................................................................................44
Color Chart for Bin Hardware Bucket Lids ...................................................................................44
Chapter 5 Gauge Sheet............................................................................................................................45
Stiffener and Sidewall Gauge Sheet (18 ft Diameter Bins) ............................................................46
Stiffener and Sidewall Gauge Sheet (21 ft Diameter Bins) ............................................................47
Stiffener and Sidewall Gauge Sheet (24 ft Diameter Bins) ............................................................48
Stiffener and Sidewall Gauge Sheet (27 ft Diameter Bins) ............................................................50
Chapter 6 Assembling Sidewall Sheets ...................................................................................................51
Guidelines for Constructing Sidewall Sheets ...............................................................................51
Color Codes for Sidewall Gauge Identification .............................................................................51
Orientation Detail for Top Sidewall Sheets ...................................................................................52
Caulking and Bolting Detail for Standard Sidewall Sheets.............................................................53
Chapter 7 Farm Stiffeners........................................................................................................................55
Stiffener Starting Location..........................................................................................................56
PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins 3

Stiffener Part Number Description ..............................................................................................57
Color Codes for Stiffener Gauge Identification .............................................................................57
Top Stiffeners............................................................................................................................57
Standard Stiffeners....................................................................................................................58
Stiffeners Splice ........................................................................................................................59
Base Boot.................................................................................................................................59
Base Stiffeners .........................................................................................................................60
One-Ring Top Stiffener (16 Ga) to a One-Ring Stiffener (12-16 Ga)...............................................61
One-Ring Top Stiffener (16 Ga) to a Two-Ring Stiffener (12-16 Ga) ...............................................61
Two-Ring Stiffener (10 Ga) to a Two-Ring Stiffener (8 Ga) ............................................................62
Two-Ring Stiffener (12 - 16 Ga) to a Two-Ring Stiffener (12 - 16 Ga) .............................................62
Two-Ring Stiffener (5 - 8 Ga) to a Base Stiffener (5 - 8 Ga) ...........................................................63
Two-Ring Stiffener (10 - 16 Ga) to a Base Stiffener (10 Ga) ..........................................................63
Two-Ring Stiffener (12 - 16 Ga) to a Base Stiffener (12 -14 Ga).....................................................64
Two-Ring Stiffener (5 - 8 Ga) to a Base Stiffener (5 Ga)................................................................64
Transitional Stiffener (10 Ga) to a Base Stiffener (8 Ga) ...............................................................65
Base Stiffener (8 Ga) to a Base Boot (10 Ga)...............................................................................65
Base Stiffener (10-14 Ga) to a Base Boot (10 Ga)........................................................................66
Base Stiffener (5 Ga) to a Base Boot (10 Ga)...............................................................................66
Chapter 8 Door Assembly........................................................................................................................67
Door Placement (3 to 6 Ring Heights) .........................................................................................67
Two Ring Door Installation Instructions .......................................................................................68
Options for Two Ring Door - Bin Step..........................................................................................72
Options for Two Ring Door – Inner Door Auger Hood ...................................................................73
Unloading from a Bin Door .........................................................................................................74
Chapter 9 Roof Assembly........................................................................................................................75
Roof Assembly Instructions........................................................................................................75
Assembling Center Collar ..........................................................................................................77
Roof Flashing ...........................................................................................................................78
Roof Panel Instructions..............................................................................................................79
Installing the Manway Cover ......................................................................................................84
Roof Ring Locations ..................................................................................................................86
Installing a Roof Ring.................................................................................................................87
Chapter 10 Accessories ............................................................................................................................89
Ladder Section Assembly ..........................................................................................................90
Inside Ladder Placement ...........................................................................................................91
Installing the Inside Ladder Bottom Bracket .................................................................................94
Guidelines for Installing a Sidedraw System ................................................................................95
Locating the Chutes...................................................................................................................97
Locating Discharge Opening ......................................................................................................98
Sidewall Overlap .......................................................................................................................99
Caulking ................................................................................................................................. 100
Installing the Wind Rings..........................................................................................................101
Temperature Cable Support Package Instructions for Eave Heights of 40 ft. - 5 in. (12.32 m) or
Less (Optional) ...........................................................................................................102
Temperature Cable Support Package Instructions for Eave Heights Greater than 40 ft. - 5 in.
(12.32 m) (Optional) .................................................................................................... 104
Assembling Weather Cover for Roller Valve .............................................................................. 107
Transition Assembly ................................................................................................................108
Seal Kit (Optional) ................................................................................................................... 110
GSI Group, LLC Limited Warranty ......................................................................................... 111
4PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins

1Safety Precautions
Topics Covered in this Chapter
▪ Safety Guidelines for Bins
▪ Cautionary Symbol Definitions
▪ Safety Cautions
▪ Safety Decals
▪ Safety Sign-off Sheet
PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins 5

Chapter 1: Safety Precautions
Safety Guidelines for Bins
Safety guidelines must be followed at all times. This manual is written to help you understand safe operat-
ing procedures and problems that can be encountered by the operator and other personnel when using
this equipment. Save these safety guidelines for future reference.
As owner or operator, you are responsible for understanding the requirements, hazards, and precautions
that exist and to inform others as required. Unqualified persons must stay out of the work area at all
times.
Alterations must not be made to the equipment. Alterations can produce dangerous situations resulting in
SERIOUS INJURY or DEATH.
This equipment must be installed in accordance with the current installation codes and applicable regula-
tions, which should be carefully followed in all cases. Authorities having jurisdiction must be consulted
before installations are made.
When necessary, you must consider the installation location relative to electrical, fuel and water utilities.
Personnel operating or working around equipment must read this manual. This manual must be delivered
with equipment to its owner. Failure to read this manual and its safety instructions is a misuse of the
equipment.
This product is intended for the use of grain storage only. Any other use is a misuse of the product.
Sidewall bundles or sheets must be stored in a safe manner. The safest method of storing sidewall bun-
dles is by laying them horizontally with the arch of the sheet upward, like a dome. Sidewall sheets stored
on edge must be secured so that they cannot fall over and cause injury. Use care when handling and
moving sidewall bundles.
CAUTION
This product has sharp edges, which may cause serious injury. To avoid injury,
handle sharp edges with caution and always use proper protective clothing and
equipment.
ST-0035
6PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins

Chapter 1: Safety Precautions
Cautionary Symbol Definitions
Cautionary symbols appear in this manual and on product decals. The symbols alert the user of potential
safety hazards, prohibited activities and mandatory actions. To help you recognize this information, we
use the symbols that are defined below.
Table 1-1 Description of the different cautionary symbols
Symbol Description
This symbol indicates an imminently hazardous situation which, if
not avoided, will result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, can result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, can result in minor or moderate injury.
This symbol is used to address practices not related to personal
injury.
This symbol indicates a general hazard.
This symbol indicates a prohibited activity.
This symbol indicates a mandatory action.
ST-0005–2
PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins 7

Chapter 1: Safety Precautions
Safety Cautions
Use Personal Protective Equipment
• Use appropriate personal protective equipment:
Eye
Protection
Respiratory
Protection
Foot
Protection
Hearing
Protection
Head
Protection
Fall
Protection
Hand
Protection
• Wear clothing appropriate to the job.
• Remove all jewelry.
• Tie long hair up and back.
ST-0004–1
Follow Safety Instructions
• Carefully read all safety messages in this manual and safety
signs on your machine. Keep signs in good condition.
Replace missing or damaged safety signs. Be sure new
equipment components and repair parts include the current
safety signs. Replacement safety signs are available from
the manufacturer.
• Learn how to operate the machine and how to use controls
properly. Do not let anyone operate without instruction.
• If you do not understand any part of this manual or need
assistance, contact your dealer.
ST-0002–1
8PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins

Chapter 1: Safety Precautions
Maintain Equipment and Work Area
• Understand service procedures before doing work. Keep
area clean and dry.
• Never service equipment while it is operating. Keep hands,
feet, and clothing away from moving parts.
• Keep your equipment in proper working condition. Replace
worn or broken parts immediately.
ST-0003–1
Do Not Enter Bin
• Rotating flighting will kill or dismember.
• Flowing material will trap and suffocate.
• Crusted material will collapse and suffocate.
— If you must enter the bin:
1. Shut off and lock out all power sources.
2. Use a safety harness and safety line.
3. Station another person outside the bin.
4. Avoid the center of the bin.
5. Wear proper breathing equipment or respirator.
ST-0061–1
PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins 9

Chapter 1: Safety Precautions
Unload the Bin Correctly
• Use CENTER FLOOR OUTLET ONLY until NO grain
remains above this outlet.
• Side floor outlets to be used ONLY when above condition
is satisfied.
• Lock all side floor outlets to avoid accidental premature
use.
• See manufacturers instructions for proper use of factory
supplied sidedraw (wall) discharge systems.
ST-0060–1
Prevent Roof Damage Due to Vacuum Pressure
• Roof damage can result from excessive vacuum or internal
pressure from fans or other air moving systems. The manu-
facturer does not warrant this type of roof damage.
• Adequate ventilation or “makeup air” devices must be pro-
vided for all powered air handling systems.
• The manufacturer does not recommend the use of down-
ward flow systems (suction).
• Severe roof damage can result from any blockage of air
passages.
• Operating fans during high humidity or cold weather condi-
tions can cause air exhaust or intake ports to freeze.
ST-0028–2
Sharp Edge Hazard
• This product has sharp edges, which can cause serious
injury.
• To avoid injury, handle sharp edges with caution and always
use proper protective clothing and equipment.
ST-0036–2
10 PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins

Chapter 1: Safety Precautions
Rotating Auger Hazard
• Keep clear of rotating augers and
moving parts.
• Do not remove or modify guards or
covers.
• Lock-out power source before making
adjustments, cleaning, or maintaining
equipment.
• Failure to follow these precautions will
result in serious injury or death.
ST-0037–1
Stay Clear of Hoisted Equipment
• Always use proper lifting or hoisting equipment when assem-
bling or disassembling equipment
• Do not walk or stand under hoisted equipment.
• Always use sturdy and stable supports when needed for
installation. Not following these safety precautions creates
the risk of falling equipment, which can crush personnel and
cause serious injury or death.
ST-0047–1
Do Not Overfill the Bin
• Do not overfill bin. Stored grain must be no higher than the
roof eaves at the outer edge.
• Filling the bin above this point creates excessive internal
pressure and can cause swelling and eventual roof failure.
The over filling of a bin can also cause the blockage of roof
vents and eaves, which will lead to a build-up of air pres-
sure causing roof damage.
ST-0050–1
Install and Operate Equipment Properly
• This product is intended for the use of grain storage only.
Any other use is a misuse of the product.
ST-0057–1
PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins 11

Chapter 1: Safety Precautions
Store Bin Sheets Properly
• Sidewall bundles or sheets must be stored in a safe manner.
The safest method of storing sidewall bundles is by laying
them horizontally with the arch of the sheet upward, like a
dome.
• Sidewall sheets stored on edge must be secured so that they
cannot fall over and cause injury.
• Use care when handling and moving sidewall bundles.
ST-0058–1
12 PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins

Chapter 1: Safety Precautions
Safety Decals
The safety decals on your equipment are safety indicators which must be carefully read and understood
by all personnel involved in the installation, operation, service and maintenance of the equipment.
To replace a damaged of missing decal, contact us to receive a free replacement.
GSI Decals
1004 E. Illinois Street
Assumption, IL 62510
Phone: [phone]
Location Decal No. Decal Description
Located next to
aeration system. DC-995 Caution Vacuum Pressure
PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins 13

Chapter 1: Safety Precautions
Location Decal No. Decal Description
On bin door
covers DC-GBC-1A Danger Keep Clear of
Augers
On bin door
covers DC-GBC-2A Warning Unload Instructions
14 PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins

Chapter 1: Safety Precautions
Safety Sign-off Sheet
Below is a sign-off sheet that can be used to verify that all personnel have read and understood the safety
instructions. This sign-off sheet is provided for your convenience and personal record keeping.
Date Employee Name Supervisor Name
ST-0007
PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins 15

NOTES
16 PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins

2General Overview
Topics Covered in this Chapter
▪ General Information
▪ Tools Required for Construction
▪ Guidelines for Proper Storage of Grain Bin Materials Prior to Construction
▪ Overview for a Typical Bin Installation
▪ Guidelines for Construction Procedures and Lifting Jack Usage
▪ Instructions for Stirring Devices
▪ Guidelines for Placement of the Decal Sidewall Sheet
General Information
General information, overview and instructions needed before performing work.
Read this manual carefully. This manual will provide instructions on building the sidewall and stiffeners.
You will also need to consult other instructions in building the bin.
These include, but may not be limited to:
• A stiffener and sidewall gauge layout chart. If such a chart is not included with this manual, contact
GSI.
• Roof instructions must be followed. Roof instructions are included in this manual.
• Ladders, roof stairs, roof handrails and other products are covered by separate instruction manuals.
Consult the appropriate accessory manual. Inside ladder instructions are included in this manual.
• Aeration systems and transitions are to be installed according to the instructions provided with the
system or transition.
• It is critical that the anchor bolts are installed and spaced correctly.
Tools Required for Construction
General tools needed to perform this construction:
• Combination wrench set 7/16 in. to 1 in.
• Alignment punches 12 in. long
• 1/2 in. Drive socket set and ratchet
• Nail aprons or tool pouches to hold supplies
• Gloves for hand protection
• Tape measure
• 1/2 in. Drive electric or pneumatic torque gun with variable impact capabilities
• 1/2 in. Drive impact socket set
PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins 17

Chapter 2: General Overview
• Lifting jacks
• Center pole roof support
• Step ladders
• Large C-clamp or welding V-grip for clamping
NOTE: Quantities required will depend on the number of workers and size of the bin.
Guidelines for Proper Storage of Grain Bin Materials Prior to
Construction
Storage of the build materials prior to construction is important. Do not to allow moisture to remain
between sheets or panels.
Wet storage stain (rust) will develop when closely packed bundles of galvanized material, such as
sidewall and roof sheets, have moisture present. Inspect roof and sidewall bundles on arrival for any
moisture. If moisture is present, it must not be allowed to remain between the sheets. Separate the
sheets or panels immediately and wipe them down. Spray with a light oil or diesel fuel.
If possible, sidewall bundles, roof sheets and other closely packed galvanized materials should be stored
in a dry, climate controlled building. If outdoor storage is unavoidable, the materials should be stored so
that they are raised above the ground and vegetation. Any stacking and spacing materials should not be
corrosive or wet. Be sure to protect materials from the weather, but permit air movement around the
bundles if possible.
Storing roof bundles and sidewall sheets at a slight incline can also help minimize the presence of
moisture. Storing the bundles with the center of the dome up (like an arch) is one option for minimizing
moisture during storage. Sidewall bundles can also be stored on edge but must be secured so that they
do not fall over and cause injury.
If “white rust” or “wet storage stain” occurs, contact the manufacturer immediately about ways to minimize
the adverse effect upon the galvanized coating.
Overview for a Typical Bin Installation
These are the typical steps one would perform when constructing a grain bin. Procedures may vary
depending on site requirements.
Pre-Assembly Activities
• Sorting and grouping parts.
Assembly
• For 18 ft – 27 ft bins, build 2 rings of sidewall sheets for even ringed bins or one ring for odd ringed
bins, making sure to caulk all seams.
• Install wind ring to help support the rings.
• Install the center collar tower support in the center of the bin.
• Install eave clips and intermediate eave angles to the sidewall sheets. (Note how these are aligned.)
• Install roof panels.
• Install roof flashing.
• Install peak cap.
18 PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins

Chapter 2: General Overview
Guidelines for Construction Procedures and Lifting Jack Usage
The following procedure is a guideline when using a lifting jack. Follow this general guideline when lifting
the bin as sidewall sheets are being installed.
NOTE: The roof and the top ring for odd ringed bins or the roof and 2 rings for even ringed bins, will be
installed prior to the beginning of bin lifting procedures. Refer to all other procedures on sidewall
and stiffener installation prior to the start of construction.
IMPORTANT: Begin building with the bin oriented for doors and material handling equipment to be in the
correct position when bin construction is complete.
1. Consider the starting location of the bin, relative to the location of the doors and other accessories.
Proper placement of lifting jacks in relationship to anchor bolts could make a difference in final
locations. Note that the sidewall sheets will be staggered.
2. The bin is lifted by the use of lifting jacks. Lifting jacks are used to slowly and evenly lift the bin
during construction. Lifting jacks must be properly sized and designed to carry all loads and job site
conditions associated with the construction of the bin.
The number of lifting jacks required is best determined by personal experience and expertise.
Factors such as bin size, jack design, construction conditions, support surface, etc., are all to be
considered when deciding how many to use. If in doubt, use one jack on every sheet. The lifting jack
must be adequate to carry all loads. Heavy duty jacks, generally hydraulic or electric powered in the
case of large bins, should be used for commercial installation. All jacks should be secured with
braces or otherwise maintained in a stable condition.
Lifting of the bins should not be done under windy conditions.
Follow the jack manufacturers recommendations on capacity and operations.
3. Lifting brackets should be attached through the stiffener bolt holes. Normally you will need to attach
to at least four bolts per stiffener.
4. Raise the bin just high enough to assemble the next ring. When lifting the bin, all jacks must lift at
an equal rate. Monitor the lift to ensure even lifting is occurring.
5. To the inside of the first ring, bolt the next ring. Be sure to stagger the sheets and select the proper
gauge material.
6. Lower the bin onto the foundation after assembling and tightening bolts on the new ring or rings.
7. Attach stiffeners to the body sheets every two tiers (on the external surface of the bin). You may
want to leave sheets loose to make the attachment of the stiffeners easier.
8. Now re-bolt the lifting brackets to the lowest ring in place thus far. Continue ring additions by
repeating step 5, page 19 and step 6, page 19.
9. Add inside and outside ladders as you continue to raise the bin. (Refer to the manual supplied with
the ladders and platforms.)
10.Add platforms as you raise the bin. (Refer to the manual supplied with the ladders and platforms.)
11.Lower the tank and secure to the foundation before leaving the job site.
12.At the completion of the tank, set stiffeners over the anchor bolts and measure the tank to ensure it
is in a round condition. Consult with GSI for questions on tolerances.
PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins 19

Chapter 2: General Overview
Instructions for Stirring Devices
Bins are offered in more than one structural series for specific uses. To maintain the warranty, the
appropriate “series” grain bin must be used. Consult the sales catalog or contact the Engineering
Department for current recommendations.
NOTE: Use of any stirring device with three or more vertical screws may require a heavier than “standard”
series bin. Any re-circulating device or system should be used in the “re-circulating” series bins.
NOTE: For GSI bins larger than 33 ft. diameter an alternate method of mounting is to attach
suspension chain to the intermediate center collar.
WARNING
Stirring devices may create additional loads on the grain bin sidewalls, roofs and
floors. If high-moisture grain is loaded too deep and too fast, unstiffened bin walls
can become overloaded. Observe the following installation and operation
procedures if the bin is to be equipped with a stirring device.
1. Read owner’s manual for the stirring device and follow all instructions set forth by the manufacturer.
2. Make sure there are no obstructions, such as protruding ladders.
3. After loading approximately 3 ft. of grain, run the unit one complete revolution to determine if it is
working properly.
4. If the unit is functioning properly, operate the stirring device continuously while filling and drying to
avoid compacted grain around the vertical screws.
5. If it becomes necessary to stop a stirring device using laterally moving screws, try to stop it with the
vertical screws nearest to the center of the bin, away from the sidewall. Should a device stop or stall
for any reason and remain inoperable for any length of time, the auger carriage should be supported
to the grain surface before restarting. The vertical auger should be turned by hand, with a pipe
wrench, before power is applied.
6. For best results, fill the bin to one-half of the final intended depth. Dry grain to 16% and continue
filling. Use filling rates specified by stirring device manufacturer. If necessary to fill to the top without
stopping, reduce the filling rate and drying air temperature so that the stirring rate can keep up with
the drying rate.
7. Do not overfill the bin. Filling should be stopped at the bottom of the top ring or 30 in. below the
track.
NOTE: The above steps are only general instructions which apply to the majority of stirring devices.
Since there are different manufacturers of these devices, it is important to read the operator’s
manual thoroughly for specific instructions applicable to the machine.
20 PNEG-4224 18 Ft. – 27 Ft. Diameter 40-Series Bins
