1.00 Manufacturer
V. Guldmann A/S.
Graham Bells Vej 21-23A
DK - 8200 Aarhus N
Tel. [phone]
2.00 Intended Purpose
GL5.2 is intended for lifting and transferring a person with disabilities.
3.00 Area of use
GL5.2 is suitable for professional use in hospitals, nursing homes, rehabilita-
tion centers, institutions and in private homes and buildings, where operators
with medical/clinical training are continually on site or on call.
4.00 Conditions for use
The Guldmann mobile lifter GL5.2 is an all-round lifter, it can be used indoor
whenever elderly and handicapped people have to be lifted or moved. The
lifter is equipped with Guldmann lifting hanger or with another suitable hanger.
Accessories consist of Guldmann lifting slings in various sizes and models.
When the mobile lifter is used the assumption is that:
• The lifter will be operated by a qualied person.
• The mobile lifter is moved at a maximum speed corresponding to normal
walking speed.
• The Guldmann mobile lifter is used with Guldmann lifting slings.
Guldmann cannot be held responsible for any faults or accidents that may
occur due to incorrect positioning of the lifting sling, nor for inadequate atten-
tion paid by the helper. We strongly recommend assessment of the user
before every lift.

5
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
4.01 Where to use GL5.2
GL5.2 is designed to be used indoors whenever the user needs to be lifted or
moved on a level surface.
• The lifter is designed so its legs can t under beds, around chairs / wheel-
chairs
• The lifter can be used in wet areas. However, it must not be exposed to
splash water.
• The lifter is designed to be used with multiple users. When moving the lifter to
another user / ward / room, perform normal hygienic disinfection.
4.02 Warning
Read the user manual fully before using the lifter to familiarize yourself with
the controls and safety features on the lifter.
• Do not exceed the maximum load.
• Use the lifter to lift a person only.
• Use the lifter on an even and level surface only. The lifter has limited
mechanical stability when the lift is placed sideways on a slope.
• Only use a lifting hanger approved for use with the lifter.
• Don’t lift/turn the lifting hanger in vertical direction during the mounting of the
straps of the sling.
• When adjusting the legs of the lifter make sure that no persons stand close to
the legs due to the risk of being jammed.
• Do not run the lifter into persons or objects.
• Exchange of lifting motor/actuator according to the manufacturer’s instructions.
See service chapter
• In case of damage, do not use the lifter until authorized by qualied service
sta󰀨 or the Guldmann service team.
• Do not use the lifter in areas where it can be splashed with water.
• Do not use the lifter in the presence of a ammable anesthetic mixture with
air or with oxygen or nitrous oxide
• Do not modify this equipment without the authorization from the manufacturer,
including opening battery which can damage cell and generate excessive
heat.
• The lifter is not intended to drive over steps and thresholds.
• The lifter needs special precautions regarding EMC and needs to be installed
and put into service according to the EMC information provided in Chapter 15
EMC Information.
• Portable and mobile RF communications equipment can a󰀨ect the lifter.
• The use of ACCESSORIES, transducers and cables other than those speci-
ed, with the exception of transducers and cables sold by Guldmann A/S of
the lifter as replacement parts for internal components, may result in incre-
ased EMISSIONS or decreased IMMUNITY of the lifter.

6
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
• The lifter should not be used adjacent to or stacked with other equipment and
that if adjacent or stacked use is necessary, the lifter should be observed to
verify normal operation in the conguration in which it will be used.
• In case the battery is too hot, disconnect it, evacuate the room, and wait for 2
hours before taking further steps
• Risk of entrapment between manual emergency lowering ring and sealing
ring of actuator
• Risk of entrapment between the legs and the chassis when adjusting the
legs.
Fig. 1 Fig. 2
4.03 Important
• Always plan your lift before commencing.
• Only use slings that are designed to be used with the mobile lifter.
• Never use slings that are damaged, frayed or have unreadable labels.
• Check to make sure the user does not exceed the safe working load of
the lifter.
• For safety reasons we DO NOT recommend transporting users through
Standard door frames.
• Caution must be exercised.
• Any serious incident that occurred in relation to this device should be reported
to the manufacturer and the local competent authority.

7
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
5.00 Denitions
1. Sling attachment hooks
2. Lifting boom
3. Battery
4. Control box
5. Hand control
6. Emergency lowering
manual (option)
7. Push handle
8. Lifting actuator
9. Chassis leg
10. Brake/release
Accessories can be
found in the Guldmann
product catalogue.
9
1
2
6
7
3
4
10
5
8
5.01 Accessories for the lifter
Lifting slings
Ask for special brochure from supplier or manufacturer.

8
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
6.00 Unpacking and preparation of the lifter
Visual check of lifter
If the packaging is damaged on receipt, each part of the lifter must be careful-
ly examined for visible defects or deciencies. In case of suspected damage,
do not use the lifter until authorized by qualied service sta󰀨 or the Guldmann
Service Team.
6.01 Assembly instruction
Guldmann recommends that the person making the assembly of the mobile
lifter have a basis mechanical understanding.
Unpack the lifter on a level surface and gently remove cable ties and protec-
tive-foam.
Assembling mast/chassis – electrical
Loosen screw (pos. 3) tted to mast. Position
the mast (pos. 1) in the Chassis (pos. 2). Make
sure that the mast hits the chassis in the bot-
tom of the chassis tube, tighten screw using an
M5 Allen key. To dismantle, remove screw to
pull mast out of base. Retighten screw in mast.
Fitting actuator
Fasten the actuator base (pos. 4) using the
attached screw (pos. 6) with nut (pos. 7).
Fasten the actuator top (pos. 4) using the
attached washers (pos. 5) and screw (pos. 6)
with nut (pos. 7).
Tighten screw and nut with 17 mm spanners.
Complete by adding protective caps (pos. 8) on
nut and bolt.
1
2
3
7
4
6
6578

9
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
Mounting of connectors for motors
Start by opening cable cover by sliding down
and straight out.
Insert connector from the lifting actuator to port
1 (pos. 9) on the control box.
Insert the cable from the lifting actuator into the
cable clips (pos. 10).
Insert connector for width adjustment motor to
port 2 (pos. 11) on the control box. Insert the
cable from the width adjustment motor into the
2 cable clips (pos. 10).
Mounting of the hand control
Connect the hand control to the DIN port
on the control box (pos. 12).
Push cable cover back on directly over
designated snaps.
Fasten push handle (pos. 13) to the mast by
tightening the two screws (pos. 14).
10
9
10
11
13
14
12

10
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
Batteries
The batteries supplied with the lifter are not fully charged on delivery.
The battery pack must be charged before use. A full charge is recommended,
duration approximately 4 hours.
6.02 Checklist before use
• The lifter must be o󰀨 charge.
• Before rst use the service indicator must be reset, done by pressing up and
down button at the same time for 5 seconds.
• Check the lifter is lifting and lowering and the legs are opening and closing,
if you hear the audio warning (a beeping sound) DO NOT USE THE LIFTER
– it needs to be charged.
• Check that the green light located on the hand control is illuminated when the
lifter is activated.
• Check that the emergency stop and lowering is working (See section 5.02
safety features).
• Make sure the lifter is running freely.
• Check the slings for damage or fraying.
Once you have tted the sling (see section 8.01 - How to use the sling) you
are ready to lift.
With the user in a seated position
• If the user is in a wheelchair or commode chair the brakes must be applied.
• Open the lifter’s chassis leg width adjustment to allow access around the
chair.
Working with the Mobile lifter
Always maintain a good working posture when applying the sling or working
with the lifter. When moving a person use the push handle and walk forward
and backwards with the lifter keeping the load as close as possible to your
body. NEVER pull or twist at arm’s length, this can cause injury to the helper.
6.03 Charging and installing battery
Before use, the battery needs to be fully
charged. For details, see 6.04 Charging
procedure.
Remove battery packaging and mount the
battery on top of the control box. The battery
is mounted and secured correctly after hearing
a click.

11
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
6.04 Charging procedure
Recharge lifter every night or when it is not in use. This maintains the batte-
ries and ensures a long life span. Avoid fully discharging the battery.
Recharging
• Recharge by plugging the power cord
(pos. 15) into a wall socket. While charging,
the green LEDs on the control box are lit.
• The green LED on the control box is lit during
charging when the power cord is plugged in.
• The power supply is automatically disconnect-
ed when the lifter is fully charged. The green
“Charge” LED turns o󰀨 on the control box.
• Recharge when only 1 green LED positioned
above a battery symbol on the hand control is
lit.
• When the green LED of the empty battery
indicator is lit on the hand control and the
alarm sounds, there is limited use of the
mobile lifter.
• The lifter cannot be used while charging.
• Do not recharge in wet areas/bathrooms.
• Maximum recharging time is approx. 4 hours.
• After recharging, please allow up to 15
seconds battery capacity calibration before
using the lifter.
• When fully charged 3 green LED illuminates
on both the control box and hand control.
15
Note!
Ensure the wall socket is turned o󰀨 when connecting the power cord to the
control box to charge the battery.

12
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
7.00 Operation
To lift/lower and adjustment of chassis leg in/out
• To lift the patient press UP arrow and to lower
the patient press DOWN arrow on the hand
control or the control box.
• On GL5.2 mobile lifter the leg spread width
adjustment of the chassis is operated via the
sideways arrows on the hand control. To switch
between modes on hand control, one button
needs to be released before activating the next.
• Use maximum width setting when lifting to/from
wide chairs, or as necessary when lifting to/
from bed, toilet and oor.
• When not in use, the hand control is designed
to be placed on the push handle.
• When maneuvering the lifter the chassis legs
must be in the closed narrow position.
• The lifter will go into standby after 2 min.
without use.

13
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
7.01 Indicator lamps and audio signals
Status Indicator lamps Audio signals Possible GL5.2 signals
Up Down Leg spread Emergency
down
Hand control
Battery charged 75-100% 3 Green lights x x x x
Battery charged 50-75% 2 Green lights x x x x
Battery charged <50% 1 Green light x x x x
Critical low battery,
two cycles left
1 Yellow light Beeps at button
activation
x x x x
Lifter service Yellow
Is lit during use
and 2 minutes
after
x x x x
Overload Yellow
Flashes 3 times
+ lights up for 10
seconds
x x
Control box
Charger Green - ashes
Charged Green
Yellow light
(overload)
One green light
(battery < 50%)
Yellow ashing
light (battery,
two cycles left,
buzzer active) Yellow lifter service light
Two green lights
(battery 50-75%)
Three green lights
(battery 75-100%)
Control boxHand control

14
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
LED 1 - LED 2 - LED 3 LED state (Not listed = o󰀨) States while charging
LED 1 - 3 constantly on 90 - 100%
LED 1 + 2 constantly on
LED 3 ashes slowly
65 - 90%
LED 1 constantly on
LED 2 ashes slowly
40 - 65%
LED 1 ashes slowly 0 - 40%
LED 1 + 2 + 3 ash slowly Charging stopped due to low battery
temperature, high battery temperature or
other error conditions
No light in LEDs Charging stopped due to lost
communication to battery

15
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
PRIORITY LED 4 + LED 5 LED state (Not
listed = o󰀨)
States in
normal
usecharging
Comments Reset
0
LED 4 ashing
according to
Bluetooth
pairing state*
Pairing
Bluetooth
Not ready to
drive
Wait until
ready
1LED 4+5 con-
stantly on
Emergency
stop activated
Not ready to
drive
Reactivate
emergency
stop
2LED 4+5
ashing fast
(synchronous)
FATAL
ERROR
Cannot drive,
has to be
reset
No movement
possible
Contact
supplier prior
to using lifter
again
3LED 5 ashing
slowly
OVERLOAD Momentary
not ready to
LIFT
Reduce load
4LED 4 ashing
slowly
Duty cycle
guard
Momentary
not ready to
LIFT
Wait until
ready
5LED 5 con-
stantly on
Position not to
be trusted
Drive is
possible
Drive into End
of Service
6LED 4 con-
stantly on
Service
needed
Drive is
possible
Contact
supplier prior
to using lifter
again

16
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
7.02 Safety functions
Only use the emergency stop button and emergency lowering functions in
emergencies. If it has been necessary to apply the emergency/safety func-
tions due to an error on the lifter, the supplier must be contacted prior to
using the lifter again.
Activating the emergency stop function
Should the lifter not respond to the func-
tions selected on the hand control when it is
in motion, push red button on top of battery.
When the emergency stop function is applied,
the lifter ceases to function.
To release the emergency stop, take o󰀨 battery
by using thumb and index/middle nger to push
buttons on battery sides, and pull battery out.
To replace the battery again, grab battery on
sides and steer battery base on steering pin,
and push in place.
In order to disconnect the lifter from mains sup-
ply, pull the mains plug out of the power out-let.
Activating the emergency lowering function
If the lifter fails to lower, activate the following:
1. Press the arrow key on the control box.
This functions as an emergency lowering
in case the hand control does not work.
If the lifting boom does not lower
2. Turn the red knob on the lifting boom in the
direction of the arrow (Optional)
Use of brakes
The rear castors are tted with brakes. Apply
the brake by stepping on the lower kick pedal.
To release the brake, kick the top part of the
kick pedal.
In daily operating the lifters castors are not
locked for the lifter to center itself according
to the patient’s line of gravity. If the brakes
are activated in these situations, shearing of
the patient’s skin or the patient being pulled
out the lifter is a potential hazard. Individual
circumstances might lead to clinical assements
where the lifter castors must be locked.
The brakes must be activated when the lifter is parked.

17
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
8.00 Use of Mobile lifter
Lifting hanger
The lifting hanger can be mounted on the mobile lifter without the use of any
tools.
1. Hold the lifting hanger in the right hand
and press the yellow button using the
index nger as shown. The slot on the
lifting hanger’s top cover must face up
(g. 1).
2. Insert the lifting hanger in the slot on the
side of the lifting hanger’s top cover (g. 2).
3. Check that the yellow button has returned
to its locked position by checking that it is
ush with the cover of the lifting hanger
and that the strap attachment can rotate
freely (g. 3).
Fig. 1
Fig. 3
Fig. 2
8.01 How to use the Sling
Use slings with 4-6 lifting straps designed for tting on Guldmann lifting han-
ger as shown in the sling manual.
The Lifter can be positioned under a bed. It can be moved through normal doors.
The lifter can be used in wet areas, but must not be exposed to splash water.
The lifter is protected against corrosion (See 11.00 Environmental conditions).
The lifter can be used for multiple users. When moving the lifter to another
user, perform normal hygienic disinfection.

18
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
Lifting to and from a sitting position
When lifting from, e.g., a wheelchair, move the lifter towards the person to be
lifted. Lifting boom and lifting hanger should be level with the chest and posi-
tioned above the middle of the thigh.
Position the lifting hanger parallel to the user’s shoulders. Now t the lifting
sling to the lifting hanger. For instructions on how to t the sling, see separate
Guldmann Slings manual for details.
Lifting to and from a lying position in bed
Position lifting boom and lifting hanger right over the bed. Now pull the lifter
back until the lifting boom and lifting hanger are positioned above the center
of the person to be lifted. The lifting hanger and lifting boom should be paral-
lel with the person’s shoulders. Now t the lifting sling to the lifting hanger.
For instructions on how to t the sling, see separate Guldmann Slings manual
for details.
Working with the mobile lifter
To obtain a correct working posture when moving the lifter, the caregiver
should always, by placing one leg in front of the other, push the lifter in a for-
ward motion thus utilizing his/her body weight.
Turning the lifter should be carried out by two persons, otherwise, stand
alongside the lifter and push on the side of the mast thereby minimizing the
center of rotation. It is a good idea to make the heaviest point of the lifter the
center of rotation. If there is limited space, you can use your foot to push on
the chassis of the lifter in the direction you wish to turn.
Hook the top set of straps (from the back) to the hooks facing the user. Hook
the lower set of straps (from the legs) to the hooks facing away from the user.
Lifting hanger, 4 attachment points
Caution!
Be careful when attaching the lifting sling’s straps on the hooks. Check
that the straps have been correctly placed in the lifting hanger’s hooks.
When pressing the up button on the hand control to lift the user, check
again that all straps remain correctly placed in the lifting hanger’s
hooks (Fig. 1).
Fig. 1

19
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
Lifting hanger
Caution!
Be careful when attaching the lifting sling on the hooks. Check that the
straps have been pulled completely through the rubber safety catch
(A) and into place in the lifting hanger’s hooks. When pressing the up
button to lift the user, check again that all the straps remain correctly
placed in the lifting hanger’s hooks (g. 1a and g. 1b).
Fig. 1a Fig. 1b
AA
From a chair, wheelchair or other sitting positions
Place lifting sling behind user’s back, e.g., between the back of the chair and
the user’s back.
The center band of the lifting sling should follow the user’s spine. As for the
slings type Active, the strap showing the size of the sling should be opposite
the spine. Bring the leg straps along the outer thigh and then under the thigh
between the back of the knee and the hip.
Now cross the leg straps in front of the user.
All four straps are now ready to be mounted onto the lifting hanger.
Lying position in bed, on a mattress or on the oor
Turn the user on his side. Place the high back sling so that its upper edge
is ush with the top of the user’s head. Put the sling on the user so that the
center band follows the spine. Turn the user on his back and pull the sling
out. Bring the leg straps under the thigh and cross them over.
All four straps are now ready to be mounted onto the lifting hanger.
If in doubt about how to use the sling, please contact your supplier.
Guldmann cannot be held responsible for any faults or accidents that may
occur due to incorrect positioning of the lifting hanger, or for reasons of inade-
quate attention paid by helpers or the user.
8.02 Cleaning and disinfection
We recommend that the products and the parts patients and caregivers can
come in contact with, are cleaned with a damp cloth using warm water and a
mild soap solution.
When disinfection is needed, use disinfectant wipes with up to a 85% solution of
isopropyl, or a damp cloth using warm water and a disinfectant cleaner, e.g., an
chlorine dissolving up to 1500 ppm.

20
© Guldmann GB/US-04/2023 • # 561577_102 © Guldmann GB/US-04/2023 • # 561577_102
If other chemicals and/or liquids with higher resolution should be used to clean
or disinfect these products, please contact Guldmann providing the item´s safety
sheet chemical composition for consideration.
Caution: Take great care to ensure that no liquids get inside the lift. The lift is
not waterproof. Failure to protect the lift from liquids may result in damage to
the lift and/or may cause personal injury.
9.00 Troubleshooting
Error:
Lifter does not react to input from the buttons on the hand control.
1. Does the green or yellow LED on the hand control light up when the
control buttons are activated?
Yes see point 6.
No no light visible – see point 2.
No only yellow light visible – see point 3.
No yellow service light visible or audible “Beep”– see “indicator and audio
signals matrix”
2. Is the battery mounted on the lifter?
Yes see point 4.
No install a fully charged battery.
3. Is a battery with su󰀩cient charge installed in the lifter?
No install a fully charged battery or charge the battery.
4. Is the emergency stop activated?
Yes To release the emergency stop, take o󰀨 battery by using thumb and
index/middle nger to push buttons on battery sides, and pull battery
out.
To replace the battery again, grab battery on sides and steer battery
base on steering pin, and push in place.
No see point 5
5. Is the connector for the hand control tted in the lifter, and is the lifter
reacting to the buttons located on the control box?
Yes replace hand control
No t connector
