Guldmann Stepless LP11 Operating instructions

© Guldmann GB-2253/06/18 • # 944137
GB .......LP11 - Side Exit lifting platform
Vers. 3.00

2
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
1.00 .........Purpose and use ..............................................3
1.01 .........Manufacturer ..................................................3
1.02 .........Purpose and use ...............................................3
1.03 .........Important/warnings .............................................3
1.04 .........Unpacking and preparation .......................................4
1.05 .........The contents of the box ..........................................4
2.00 .........Description of features .........................................4
2.01 .........Labels .......................................................4
2.02 .........Operation .....................................................5
2.03 .........Brakes .......................................................7
2.04 .........Safety features.................................................8
2.05 .........Charging/connection of charger...................................10
3.00 .........Transport ...................................................10
4.00 .........Maintenance and storage ......................................11
4.01 .........Cleaning.....................................................11
4.02 .........Storage .....................................................11
4.03 .........How is corrosion prevented/avoided? ..............................11
4.04 .........What maintenance should the owner carry out? ......................11
5.00 .........Service and life ..............................................11
5.01 .........Life and servicing..............................................11
5.02 .........Battery and fuses..............................................12
5.03 .........General inspection.............................................12
5.04 .........Troubleshooting ...............................................13
6.00 .........Technical specications .......................................14
7.00 .........CE declaration of conformity ...................................14
. . . . . . . . . . . . . USA and countries outside the EU ..............................15
A. ...........Users guide ..................................................15
B. ..........WARRANTY..................................................15
LP11 - Side Exit
Item no.:
13011-S

3
1.00 Purpose and use
1.01 Manufacturer
V. Guldmann A/S
Graham Bells Vej 21-23A
DK-8200 Aarhus N
Tel. [phone]
Fax [phone]
1.02 Purpose and use
Purpose
LP11 - Side Exit is a mobile lifting platform with a side exit specically concei-
ved for the narrow environments that can be used to negotiate height differen-
ces between a platform and a train. It is designed to lift wheelchair users and
other persons with impaired mobility where the support is plane and stable.
LP11 is also suitable for those places with height differences where a mobile
lifting platform is the preferred option for meeting the need for lifting of wheel-
chairs, e.g. podiums, stages etc.
Prerequisite
The LP11 - Side Exit lifting platform must not be used before reading this
manual.
Use
The lifting platform is intended to lift persons with impaired mobility – and is
not for transport.
The platform is intended to be used parraell with the train.
1.03 Important/warnings
• The lifting platform’s recommended load of 300 kg must not be exceeded.
• The lifting platform may only be used to lift persons with impaired mobility.
• The lifting platform may only be used on an even surface.
• Always brake the lifting platform on lifting and lowering.
• During use persons must not stand immediately adjacent to the lifting platform.
• Do not run into people or objects with the lifting platform.
• The platform must be lowered to its lowest position when being moved.
• The train must be stationary when the lifting platform is in use.
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137

4
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
1.04 Unpacking and preparation
Visual control
If the packaging is damaged, the lifting platform must be examined carefully
for visible lopsidedness, defects and deciencies. If the platform is thought
to be damaged, it must not be used until quality service technicians or the
Guldmann Service Team have approved it.
Preparation
The lifting platform must be charged. See Point 2.05 concerning charging.
The lifting platform is ready for use when charging is complete.
1.05 The contents of the box
1. LP11 - Side Exit – lifting platform
2. Charger
2.00 Description of features
2.01 Labels
24V DC
24V. DC
Disabled sign
Stepless label with CE logo, serial number and max. lifting capacity (300 kg)
max 300 kg/660 lbs
Part no. 13011
Serial no. xxxxxxxxxx
230V, 0.5A
Internally powered
equipment 24V DC
V. Guldmann A/S
Graham Bells Vej 21-23A
DK-8200 Aarhus N
Made in Denmark
yyyy-mm-dd
Lifting Platform LP11

5
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
2.02 Operation
Prior to use
1. Unlock the brake pedal,
which is located on the
undercarriage under the
ramp, with a key.
2. The battery box is
located on the under-
carriage on the right
(seen from the up ramp
end).
• Unlock the lid on the
battery box.
• The emergency stop is
deactivated by turning
the knob until it pops out.
3. The lift is now ready for use.
Lifting from platform to train
1. The lifting platform should be placed with the
side as close as possible to the point where the
wheelchair leaves the ground.
2. Brake the lifting platform by pressing the brake
using your foot.
3. Unlock and tip the up ramp down onto the
platform after which the wheelchair user can
move up onto the platform. This should take
place at low speed – no run-ups.
4. Tip up the up ramp and lock it. Use the help
strap, if needed.

6
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
5. Use the operation panel to raise and lower the
platform.
6. Raise the lifting platform to the height of the
door to the train. Adjust the width of the ramp
and tip the ramp down. The whole of the width
of the ramp should be supported.
Driving from the lifting platform into the train
can now take place easily and safely.
If LP11 - Side Exit stops and starts beeping,
this indicates that LP11 - Side Exit is overloa-
ded. After the overload has been removed, the
platform can operate again.
7. After use both ramps must be tipped upwards and locked and the lifting
platform must be in its lowest position before it is moved. No persons/objects
must be under the platform when it is lowered.

7
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
Locking after use
1. Lock the brake pedal
into place with the key.
The brake pedal is
located on the under-
carriage under the up
ramp.
2. Press the emergency
stop in the battery box.
3. The lifting platform is
now locked.
Lifting from the train to the platform
Lifting from the train to
the platform takes place
in reverse order to from
the platform to the train.
Before the platform is
lowered, make sure that
no persons/objects are
under the platform.
2.03 Brakes
• Brake the wheels by
applying the brake pedal.
• Always brake the lifting
platform on lifting and
lowering.
• Always leave the plat-
form with brakes applied
and locked to avoid unin-
tended use.

8
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
2.04 Safety features
Important!
The emergency stop has two features:
• As cutout when the lift is not in use.
• As emergency stop where it must only be used for functional errors/in
emergencies. For functional errors/breakdowns the supplier must be
contacted before the lifting platform is reused.
The emergency stop
in the battery box is
located on the under-
carriage on the right
side (seen from the up
ramp end).
Description of emergency stop
If the lifting platform does not react to the operational functions when the
lifting platform is moving – press the emergency stop.
When the emergency stop is activated, all the lifting platform’s electrical
functions are deactivated.
Description of safety jam strip
Between the platform and undercarriage there is a safety jam strip which
prevents risk of jamming. Check that there are no objects/hindrances under
the platform. If the safety jam strip is activated during descent, the platform
will automatically stop the descent. The platform can only descend when the
operations button has been activated – this means that the platform rst
needs to be raised slightly before it can be lowered again. If the safety jam
strip is activated when the platform is stationary, the platform will stay in its
stationary position. The platform works again when the operations button
is activated.
Description of emergency lowering
It is possible to operate the lifting platform if the
operations panel fails.
In the battery box which is located on the under-
carriage on the right (seen from the up ramp end)
there is a box containing the emergency lowering
device as well as up/down buttons. To operate the
emergency lowering device the button must
be activated.

9
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
Description of emergency lowering in case
of electrical wiring brake down
WARNING: Risk of injury. Never stay underneath the platform when
preforming emergency lowering.
This procedure will bypass all safety installations.
The platform will run until the battery is dismounted again.
Please pay attention to operator safety by performing this procedure.
For this procedure you will need a emergency
lowering cable and a TORX 25 key.
Uninstall the cover at the top of the actuator by
using a TORX 25 key and move the cover up
along the actuator.
It is important to follow this procedure in the
right sequence: Install the emergency lowering
cable at the top of the actuator.
After installing the emergency lowering cable in
the actuator then install other end of emergen-
cy lowering cable in battery. The platform will
drive down instantly when connected to battery.
Item number emergency lowering cabel:
558961

10
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
2.05 Charging/connection of charger
When the lifting platform is not in use, it should be charged as the batteries
are best maintained in this way.
The batteries should immediately be charged in the event of an audio signal
as this means that the battery level is critically low.
Connecting the charger
The platform is charged
using the socket on the
battery box.
Connect the charger
to the mains. Put the
charger’s other plug in
the battery box’s socket.
The charger must only
be used in dry conditions.
The battery box can be disassembled. The connector can be taken out by
pressing the red lock ratchet.
Charging
An audio signal will sound when the battery level is critically low. Take out
the battery and move it to a dry location near a mains socket where it can be
charged. Charge the lifting platform every night or when it is not in use. In this
way the batteries are best maintained and will last the longest. The charger
switches off automatically when the lifting platform is fully charged. The maxi-
mum charging time is approx. 8 hours.
If the green indicator light is lit, the batteries are fully charged. If the red
indicator is lit, the battery is charging.
3.00 Transport
The lifting platform is equipped with wheels and can be pushed. The brake
pedal must be disconnected – see Section 2.02, if required. The lifting plat-
form must be in its lowest position before it is removed.
The battery box can be removed and transported separately.

11
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
4.00 Maintenance and storage
4.01 Cleaning
Clean the lifting platform with a damp cloth or sponge with a standard
cleaning agent.
If the battery box has been removed, the lifting platform can be washed with
a soft brush and soapy water.
The lifting platform should not be rinsed under running water from a hose, etc.
Before the battery box is retted, the lifting platform should be dried
thoroughly.
No chemicals or autoclave must be used to clean the lifting platform.
The charger should be dried with a dry cloth.
4.02 Storage
If the lifting platform is to be stored for a longer period without being used, the
battery box should be disassembled and the batteries charged regularly.
The lifting platform contains electronics that must be disposed of according to
current rules.
4.03 How is corrosion prevented/avoided?
The lifting platform has been made of corrosion-resistant materials and does
not require further corrosion prevention.
4.04 What maintenance should the owner carry out?
• Charge the batteries after the platform has been used
• Keep the lifting platform clean and free of dirt
• Check the platform for assembly and correct function
5.00 Service and life
5.01 Life and servicing
The life of the platform is based on correct use, cleaning and annual check
in accordance with national legislation and maintenance by a professional
service technician or the Guldmann Service Team.
The lifting platform has an expected life of 15 years. The lifting platform must
after this period be evaluated by qualied staff for its future use.
Spare parts lists and drawings can be obtained from the manufacturer or
supplier.

12
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
5.02 Battery and fuses
Replacing batteries and fuses must be carried out by a service technician or
the Guldmann Service Team.
5.03 General inspection
During the statutory service inspection a report must be prepared of what was
checked and replaced. Parts that are worn or defective must be replaced with
new parts from V. Guldmann A/S.
1. Visual check of the product
• Check that the product is not worn
• Check that the product is not lopsided in any way
• Check that no other damage has occurred to the product
2. Testing the product as for normal use
• Check all functions on the product with and without load
(function examples: up, down)
• Check that the emergency stop works
• Check that the emergency lowering device works
3. Checking the product’s electrical condition
• Check the batteries and measure:
• Input/voltage
• Output/voltage
• Check electrical functions and signals
• Check the wiring for faults and defects
• Check the cable lead-ins
• Check the connections, plugs, etc.
4. Checking the product’s mechanical condition
• Clean the product of dirt and other impurities
• Inspect and evaluate vital parts on the product
• Replace defective and worn parts
• Movable parts must be lubricated with Molycote grease
5. Point 2 should be carried out again to check that everything works
6. Have new problems arisen/been found in Point 5?
• If new problems have arisen, go back to Point 2
• If no new problems have been found, nish the inspection

13
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
5.04 Troubleshooting
If the LP11 - Side Exit does not react to use of the operation panel
• Check that the emergency stop has not been activated. The emergency stop
is released by turning the knob until it pops out
• Check that the battery box is charged and connected
• Contact the Guldmann Service Team or the distributor
If the LP11 - Side Exit can go up, but not down
• Remove impurities from the safety jam strip
• Check the safety jam strip for other blockages
If the LP11 - Side Exit starts to beep
• An audio signal is a sign of critically low battery levels. The batteries must
therefore be charged before the platform is used again
If the LP11 - Side Exit stops and starts beeping
• If the platform is overloaded, it stops and starts beeping.
• Remove some of the load from the platform
• Observe the maximum load indication of the platform

14
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
6.00 Technical specications
Exterior dimensions (W x H x L) ................ 1140 x 1200 x 1590 mm
Interior dimensions (W x L) ...........................822 x 1365 mm
Lifting interval ...................................... 180 - 955 mm
Maximum lifting capacity ....................................300 kg
Lifting speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 - 32 mm/second
Upper ramp width adjustable .......................... 630 - 800 mm
Number of lifts with max. load per charge....................approx. 45
Turning diameter ........................................1600 mm
Total weight ..............................................149 kg
Electrical connection for charger .......................... 100 - 240 V
Charger, fully automatic ....................................0.5 Amp
Charging time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . max. 8 hours
Batteries, gas-proof and maintenance-free ...............2 x 12 V, 7.2 Ah
Permissible connection time/intermittence factor ..................10/90
(Work/break ratio in percent)
Noise level ..............................................63 dB(A)
7.00 CE declaration of conformity
The product is manufactured in compliance with the Council Directive
2006/42/EC of May 17th 2006 on machinery and amending Direvtive 95/16/EC.

15
USA and countries outside the EU
A. Users guide
Before using the product, read the entire operation manual
including warranty.
B. WARRANTY
Guldmann warrants its equipment is free from material defects under normal
use, and will perform substantially in accordance with the specications set
forth in documentation provided with the equipment.
This express warranty shall be in effect for one year from the date of original
purchase and installation (the “Warranty Period”). If a valid claim is made
during the Warranty Period for malfunction or equipment defect, Guldmann will
repair or replace the equipment at no additional cost to you. Guldmann retains
sole discretion as to whether the equipment will be repaired or replaced.
This warranty shall be null and void if the equipment is operated and main-
tained in any manner inconsistent with its intended use or the instructions
provided with the product. Further, in order for the warranty to remain in effect
for the full Warranty Period, all service to the equipment must be provided
by a Guldmann designated technician. Any parts or components repaired or
replaced by a Guldmann designated technician will be guaranteed for the
remainder of the Warranty Period.
The warranty does not cover any part of the equipment which has been sub-
ject to damage or abuse by the user or others. The warranty does not cover
any part of the equipment which has been altered or changed in any way by
the user or others. Guldmann does not warrant that the lifting device functions
will meet your requirements, be uninterrupted or error free.
The warranty set forth is in lieu of all other express and implied warranties,
whether oral, written or implied, and the remedies set forth above are your
sole and exclusive remedies. Only an authorized ofcer of Guldmann may
make modications to this warranty, or additional warranties binding on Guld-
mann. Accordingly, additional statements such as advertising or presentati-
ons, whether oral or written, do not constitute warranties by Guldmann.
Service or Repair
Contact Guldmann Repair for an authorization to return any defective item
during the Warranty Period. You will be provided with a return authorization
number and address for returning the item for warranty service or replace-
ment. Do not return items to Guldmann under warranty without receiving a
Return Authorization Number.
If mailing the item, pack it carefully in a sturdy carton to prevent damage. Include
your Return Authorization Number, a brief description of the problem and your
return address and phone number. Guldmann does not assume the risk of loss
or damage while in transit, so it is recommended you insure the package.
© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137

© Guldmann GB-2253/06/18 • # 944137 © Guldmann GB-2253/06/18 • # 944137
V. Guldmann A/S
Tel. [phone]
Fax [phone]
E-mail [email protected]
www.stepless.com
