Guldmann Evocare 553000 User manual

Free-standing rail systems, adjustable

Item no:

553000

1.00.........Purposeanduse..............................................3

1.01.........Manufacturer..................................................3

1.02 . . . . . . . . . Intended use and description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.03.........Importantprecautions ...........................................3

1.04 . . . . . . . . . Hoists made by other manufacturers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.05 .........Unpacking ....................................................4

1.06.........Settingupthesystem ...........................................5

2.00.........Descriptionoffunctions........................................9

2.01 .........Operation.....................................................9

2.02 .........Lengthandheightadjustment ....................................9

3.00 . . . . . . . . . Demounting and transportation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.01.........Demountingthesystem..........................................9

3.02 .........Transportingthesystem ........................................10

4.00.........Maintenanceandstorage......................................10

4.01.........Cleaning.....................................................10

4.02 .........Storage .....................................................10

4.03.........Maintenance .................................................10

5.00.........Serviceandlifespan..........................................10

5.01 .........Lifespan ....................................................10

5.02 .........Troubleshooting...............................................11

6.00 . . . . . . . . . Technical specications .......................................11

7.00 . . . . . . . . . EC-Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

1.00 Purpose and use

1.01 Manufacturer

V. Guldmann A/S

Graham Bells Vej 21-23A

DK-8200 Århus N

Tel. + 45 8741 3100

Fax + 45 8741 3131

1.02 Intended use and description

The free-standing rail system together with the GH1 hoist shall be used for

transferring an elderly or a disabled person; e.g. in private homes.

The free-standing rail system is a portable rail system which can be set up

practically anywhere and requires no mounting on walls, ceiling or oors.

The free-standing rail system is length and height adjustable.

1.03 Important precautions

Read the entire user manual prior to setting up and starting to use the free-

standing rail system.

The free-standing system can be set up and taken down by one person only.

The maximum load of 250 kg must not be exceeded.

In case of damage to the free-standing rail system, the operation of it should

be discontinued immediately.

The free-standing rail system should be set up on a plane surface.

The end stops have to be properly installed and locked with spring pins, and

the 2 yellow thumb screws on the top brackets have to be properly tightened

before the system must be used.

The free-standing rail system must not be used for any other purpose than

that stated in this user manual; that is, neither as a playground or a swing

device.

1.04 Hoists made by other manufacturers

Guldmann is not liable for defects or accidents caused by the application of

hoists/lifting modules made by other manufacturers.







1.05 Unpacking

Inspection before unpacking

If the packaging is damaged upon receipt, the components of the free-

standing rail system should be carefully checked for noticeable imperfections,

defects or aws.

If damage is suspected, the free-standing system should not be assembled or

taken into use until the system has been approved by qualied service staff

or the Guldmann Service Team.

Unpacking

Unpack the 3 boxes, consisting of:

a. Top bracket and rail module (1 pcs.)

b. Vertical pole module (2 pcs.)

c. User manual

d. 5mm Allen key

Fig. 1

Fig. 3

Fig. 2

Fig. 4

Rise one vertical pole module. Lift the top bracket and rail module

and mount it on top of the vertical

pole module.

Lock the top bracket to the vertical

pole with the locking arm.

Raise the second vertical pole module.

1.06 Setting up the system

Fig. 5

Fig. 7

Fig. 6

Fig. 8

Lift the top bracket and rail module

and mount it on top of the vertical

pole. Lock with the locking arm.

Lock the rail to the top bracket

module with the 2 yellow thumb

screws.

Before inserting the GH1 hoist

loosen the 2 yellow thumb screws

and remove the end stop.

Insert the GH1 hoist in the free-stan-

ding rail system.

Fig. 9

Fig. 11

Fig. 10

Fig. 12

Mount the end stop again and make

sure that the spring pin is positioned

in the pre-drilled hole.

Tighten the end stop.

In order to adjust the free-standing

rail system to the specic room size:

loosen the 2 yellow thumb screws, and

push/pull the top brackets at the rail.

Tighten afterwards the 2 yellow

thumb screws at each top bracket.

Fig. 13

Fig. 15

Fig. 14

Adjust the height by inserting the

accompanying 5 mm Allen key in the

height adjustment socket at the side

of the vertical poles. Make sure that

top bracket and rail module is level.

Fix the recharging dock on the ver-

tical pole just below the Guldmann

logo with the enclosed Velcro.

The free-standing rail system is now ready for use

2.00 Description of functions

2.01 Operation

The free-standing rail system, adjustable, is a portable system that, once

installed, does not require any further operation.

2.02 Length and height adjustment

Length adjustment

(when the system is in the lowest position):

• Set up the system (see 1.06).

• Loosen the 2 yellow thumb screws on the

top of the brackets manually.

• Pull the rail out of the top brackets until

the required length has been reached

• Tighten the 2 yellow thumb screws on

the top of the brackets manually after the

adjustment is nished.

Height adjustment:

• Set up the system (see 1.06).

• Insert the accompanying 5mm Allen key

or a power drill with 5mm bit in the height

adjustment socket at the side of the ver-

tical pole.

Adjust each pole to the required height

and afterwards adjust the system until the

top bracket and rail module is level

3.00 Demounting and transportation

3.01 Demounting the system

Lower the system to the lowest position.

Demount the free-standing rail system in the reverse order of the mounting

(see 1.06).

It may be necessary push the top bracket upwards in order to separate it from

the Vertical pole module.

Important:

Before taking down the free-standing rail system, the hoist must be taken out

or secured by means of the end stops.

3.02 Transporting the system

As a minimum, the free-standing rail system should be taken apart so that the

vertical pole modules are separated from the top brackets and rail (see 3.01).

During transportation, Guldmann recommends that system, after it has been

demounted, is always transported in the Guldmann Bag carrier portable, item

No. 553225.

4.00 Maintenance and storage

4.01 Cleaning

Clean the free-standing system with a damp cloth using ordinary household

detergents. Chemicals or an autoclave must not be used when cleaning the

free-standing rail system.

4.02 Storage

The free-standing rail system should be stored in a room where the humidity

does not exceed 70%. The system free-standing rail system must not be

stored in bathrooms or the like.

4.03 Maintenance

Check regularly that the system is stable.

5.00 Service and life span

5.01 Life span

The Free-standing rail system, adjustable, has an expected life span of 15

years, on the condition of correct use and correct service inspections

(see 4.04).

Spare parts drawings can be obtained from the manufacturer or supplier.

5.02 Troubleshooting

1. The system is not stable

• Check that the feet is mounted correctly

• Check the Vertical poles have been pushed securely in the Top bracket

• Check that the top brackets are tightened

• Check that the top brackets have been positioned correctly

• Check the top brackets for defects or deformities?

• Check that the Yellow thumb screws are tightened

2. The vertical height adjustment is not working

Check carefully with a 5mm Allen key that the system is not stuck in the far

end position.

If the top part of the Vertical pole is not moving when turning the 5mm Allen

key, stop using the system and contact the distributor or the manufacturer.

6.00 Technical specications

Free-standing rail system

Dimensionsmin.(HxW).............................2020 x 2720 mm

Dimensions in extended pos. max. (HxW) . . . . . . . . . . . . . . 2820 x 3890 mm

Maximumliftingcapacity.................................... 250 kg

Total weight without hoist

Free-standingrailsystem ...................................52,0 kg

Verticalpole,each.........................................13,5 kg

Topbracketsandrail.......................................25,0 kg

Materials

Railsandposts: ............................... Anodized aluminium

Feet:......................................Powdervarnishedsteel

Brackets: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Powder varnished steel

7.00 EC-Declaration of conformity

The products are manufactured in compliance with the Council Directive

93/42/EEC of 14 June 1993 – with amendments, as medical device class 1.

USA and countries outside the EU

A. Users guide – Free-standing rail system, adjustable

Read the entire warranties and the entire chapter before use of the product.

B. Warranties

The Guldmann lifting equipment is designed to be used for the lifting, trans-

ferring, and transporting of persons with a physical handicap who are not

able to physically self transfer or who are temporarily incapacitated by illness,

anaesthesia or other causes.

This lifting equipment is designed to relieve the users, their relatives, and

nursing personnel in the task of lifting elderly or handicapped people, thereby

minimizing the risk of back injury during such lifting and transfer operations.

If the product is used in any fashion or in an irresponsible manner or for any

use other than that described above or in the enclosed written instructions,

the manufacturer’s warranty will be nullied and rendered void.

There are no warranties which extend beyond the description in the enclosed

written instructions.

Guldmann warrants that its lifting equipment is free from defects in materials

and workmanship under normal use. Guldmann warrants that the lifting equip-

ment itself will perform substantially in accordance with the specications set

forth in the documentation provided with the equipment.

The above express warranties are made for a period of 365 days from the

date the lifting equipment is delivered to you as the rst user.

Your distributor will replace any lifting equipment which proves defective in

materials or workmanship, without additional charge, on an exchange basis.

Your distributor will either replace or repair without additional charge any

Guldmann lifting equipment that does not perform in substantial accordance

with the specications of the documentation.

Guldmann does not warrant that the functions contained in the lifting devices

will meet your requirements or that the operation of the services will be unin-

terrupted or error-free. The warranty does not cover any of the part of the

lifting equipment which has been subject to damage or abuse by you.

The warranty does not cover any part of the lifting equipment which has been

altered or changed in any way by you or others. Guldmann is not responsible

for problems caused by changes in the operating characteristics of the ope-

rating system which are made after the delivery of the lifting equipment. Any

implied warranties including any warranties of merchant ability or tness for a

particular purpose are limited to the term of the express warranties.

Guldmann shall not in any case be liable for special, incidental,

consequential, indirect or other similar damages arising from any breach of

these warranties even if Guldmann or its agent has been advised of the pos-

sibility of such damages.

You must call Guldmann or your distributor for an authorization to return

any defective item during the warranty period. If your distributor is unable to

correct your problem by telephone, you will be provided with a return aut-

horization number and address for returning the defective item for warranty

service or replacement. You must insure any defective item being returned

because Guldmann does not assume the risk of loss or damage while in tran-

sit. Do not return items or warranty service to Guldmann.

The warranties set forth above are in lieu of all other express and implied

warranties, whether oral, written or implied, and the remedies set forth above

are your sole and exclusive remedies. Only an authorized ofcer of Guld-

mann may make modications to this warranty, or additional warranties bin-

ding on Guldmann. Accordingly, additional statements such as advertising or

presentations, whether oral or written, do not constitute warranties by Guld-

mann and should not be relied upon as such. The warranty gives you specic

legal rights, and you may also have the other rights which vary from state/

country to state/country.

Other manuals for Evocare 553000

Table of contents

Other Guldmann Mobility Aid manuals

Guldmann

Guldmann GH User manual

Guldmann

Guldmann GTP1 User manual

Guldmann

Guldmann Twin Turner II User manual

Guldmann

Guldmann 28355 User manual

Guldmann

Guldmann GH3 Twin User manual

Guldmann

Guldmann GL5 .2 User manual

Guldmann

Guldmann Stepless Plain Series User manual

Guldmann

Guldmann GL5.1 User manual

Guldmann

Guldmann BASIC HAMMOCK User manual

Guldmann

Guldmann GLS5.2 User manual

Guldmann

Guldmann Active Micro Plus User manual

Guldmann

Guldmann Stepless LP11 Operating instructions

Guldmann

Guldmann GH1 User manual

Popular Mobility Aid manuals by other brands

Essential Medical Supply

Essential Medical Supply W1630 manual

COMPASS HEALTH

COMPASS HEALTH PROBASICS Three-in-One Commode manual

Golden Technologies

Golden Technologies GP162 Service guide

Orliman

Orliman actius ACAN01 UNI Instructions for use and care

Cobi Rehab

Cobi Rehab 0173-050-000 user manual

Days

Days 091275965 User instructions

Invacare

Invacare CareGuard 90-2 Assembly, installation and operating instructions

ARmedical

ARmedical AR-010 User manual and warranty card

NRS Healthcare

NRS Healthcare M99266 User instructions

Timago

Timago JMC-C 3016W5 Instructions for use

Vitea Care

Vitea Care BILLY VCBK52211 user manual

Enable Lifecare

Enable Lifecare Oxford Up User instruction manual

Beasy

Beasy 4200 Instruction guide

Guardian

Guardian Aspire M10 User instruction manual & warranty

Carex

Carex Mobilator A334-00 Assembly instructions

Kid-Man

Kid-Man FIJI 316 user manual

Innova

Innova AirRise200 Quick user guide

Drive

Drive GiGo operating instructions
