Hasler WJ 65 User manual

1
ORIG0122-1
4128811U/B
12/08/2006
This guide includes Instructions for Adding Postage and
ConnectingtotheOnlineServicesServer
UNBOX AND SET-UP EQUIPMENT
This machine requires connection to a grounded power
outlet and an analog telephone outlet.
Choose your set-up location with this in mind.
If you are unsure what type of phone line you have, most
fax machines use an anlog line.
STEP 1
OpentheWJ65,WJ95orWJ110cartonandremovethecontents.
Removethecardboardpackinginsertfromthemailingmachine
bypullinginthedirectionofthearrow.
Set aside the Handfeed Platform, Catch Tray, Ink Cartridge,
Labels, Power Cord, Phone Cable, User Guide and optional
WP5WeighPlatform.
Handfeet
Platform
WJ65/95/110
MailMachine
CatchTray
PowerCord
&
Telephone
Cable
OptionalIWP5
WeighPlatform
InkCartridge
Labels

2
ORIG0122-2
4128811U/B
12/08/2006
STEP 2
OpentheoptionalWJ65/95/110AFFeeder,WJMoistenerorWP
weighplatformcartonsandremovethecontents.
Feeder
Moistener
WJWP10,
IWP30,
orWJWP70
Platform

3
ORIG0122-3
4128811U/B
12/08/2006
-IfyouorderedanWJMoistenertousewiththeHandFeed
Platform, go to step 3
-IfyouorderedanWJ65/95/110AFAutofeedandMoistener,
go to step 4
- If you did not order an Autofeed or Moistener, go to step 5
STEP 3
Attach Moistener Unit to the Hand
Feed Platform
IfyouorederedanWJMoistenertousewiththeHandfeedPlatform,
youmustfirstremovethePlatformInfillfromtheHandfeedPlatform.
1)Pressontabwiththumbthenpushup.

4
ORIG0122-4
4128811U/B
12/08/2006
2)Pulldownslightlythenseparateinfillfromhandfeedplatform.
-AttachtheWJMoistenerUnittotheHandfeedPlatform.

5
ORIG0122-5
4128811U/B
12/08/2006
-EnsurethattheTabsandSlotsinterlockasillustrated.
-Presssealerandplatformtogetherthenpushsealeruptolock.

6
ORIG0122-6
4128811U/B
12/08/2006
STEP 4
Attach Optional Moistener Unit to the
AutofeedUnit
IfyoureceivedanoptionalWJ65/95/110AFAutofeed,youmust
firstattachtheWJMoistener.
PlacetheMoistenerUnitonthetable,thenlowertheAutofeedUnit
ontotheSealer ensuringthatthe slotsonthe Autofeed fittightly
overthetabsontheMoistenerUnitasillustrated.
Feeder
Moistener

7
ORIG0122-7
4128811U/B
12/08/2006
STEP 5
Attach WJ 65, WJ 95 or WJ 110 Base
Mailing Unit to theAutofeed or Hand Feed
Platform
WiththeAutofeedorHandfeedPlatforminthedesiredpositionon
the table, lower the WJ 65/95/110 into place so that the slots fit
overthetabsasillustrated.
ThepositionoftheslotsintheWJ65/95/110 areeasilyidentifia-
blebythemetaltabseasilyseen fromthetopwhenloweringthe
unit.

8
ORIG0122-8
4128811U/B
12/08/2006
STEP 6
Attach the optional WP5 Weigh Platform
and Support
Sufficientcablehasbeenprovidetoenabletheunittobeplaced
onthetableadjacentto themailingmachine ifthisispreferred.
1)Positiontheweighplatformonitssupport.Excesscablecanbe
looselyintheclipsunderthesupport.
2)Positionthesupportplatform ontopof theWJ65/95/110unit
sothatthepinsontheundersideofthesupportfitintothelocating
pointson therear coverof theWJ65/95/110.
ThepositionoftheslotsintheWJ65/95/110areeasilyidentifia-
blebythemetaltabseasilyseen fromthetopwhenloweringthe
unit.

9
ORIG0122-9
4128811U/B
12/08/2006
STEP 7
Fill the Label Dispenser
ApackageofpostagelabelsisincludedwithyourWJ65/95/110
mailmachine.Thelabel dispenserwillholdup to50labels.
1)Openthetopcover toaccessthe labelreleaselever.
2)Insertlabelsintothedispenserwiththetabuppermostandthe
labelside to be printedfacing the directionoftravel.
3)Usingonefinger,applypressuretothelabelreleaseleverthus
allowingthelabelstodropintocontactwiththefeedmechanism,
then,releasethelever.
4)Close thetop cover.
Tab
Printing
surface

10
ORIG0122-10
4128811U/B
12/08/2006
STEP 8
Fill the optionnal Moistener Reservoir
For safety always, disconnect mailing machine from the power
outletandkeeptopcoverclosedwhenfillingthemoistener.
-Pullopenthemoistenerbottlecompartmentdoor.
-Grasptheplasticwater bottleandlifttoremove.
-Unscrewthecapandfillthebottleto1/2inchfromtopwithwater.
- Screwthe capback onthe bottle.
-Invertthewaterbottleandinstallsothecapfitsinreservoircup.
-Squeezethebottleslightlytostartthewaterflowtothemoistening
spongethenclosethecompartmentdoor.

11
ORIG0122-11
4128811U/B
12/08/2006
MACHINE CONNECTIONS TO WEIGH PLATFORM
Do not plug the power cord into the machine until all the
other connections have been made
STEP 9
Connect optionnal IWP5 Five Pound Weigh
Platform to WJ 65/95/110 Base mailing ma-
chine
Cable
The weigh platform must be plugged into the lower
connector

12
ORIG0122-12
4128811U/B
12/08/2006
Do not plug the power cord into the machine until all the
other connections have been made
STEP 10
Connect optional WJWP10, IWP30 or
WJWP70 Weigh Platform to WJ 65/95/110
BaseMailingMachine
The weigh platform must be plugged into the lower
connector

13
ORIG0122-13
4128811U/B
12/08/2006
Do not plug the power cord into the machine until all the
other connections have been made
STEP 11
Connect optional Autofeed to WJ 65/95/110
BaseMailingMachine
Cable

14
ORIG0122-14
4128811U/B
12/08/2006
Do not plug the power cord into the machine until all the
other connections have been made
STEP 12
ConnectoptionalHaslerMailAccountingPC to
WJ 65/95/110 Base Mailing Machine
Thisisonlyapplicablefor connectiontoaHaslersupplied
PC Mail Accounting system

15
ORIG0122-15
4128811U/B
12/08/2006
Do not plug the power cord into the machine until all the
other connections have been made
If you have a Hasler PC Mail Accounting system :
1) Power on PC
2) Open the Mail Manager 2 PC software
3) Power on the machine
STEP 13
Telephone connection to WJ 65/95/110
BaseMailingMachine
Telephone
Cable
Caution,to reduce the risk of fire, useonly No. 26 AWG or
larger telecommunication line cord.
The telephone connection is only required when adding
postage to the mailing machine or connecting to the
Online Services server.

16
ORIG0122-16
4128811U/B
12/08/2006
Do not plug the power cord into the machine until all the
other connections have been made
STEP 14
Power Cord Connection to WJ 65/95/110
BaseMailingMachine
Power
cord
After you plug the power cord into the WJ 65/95/110, it will
beep and display «PLEASE WAIT» while it goes through a
power-up sequence.
Whenitdisplays:
SUPERVIS USER
Go to Step 15 to install the Ink Cartridge

17
ORIG0122-17
4128811U/B
12/08/2006
STEP 15
Install Ink Cartridge in WJ 65/95/110
MailingMachine
1. RemovetheInkCartridgefromitspackagingandcarefully
removethetapeseals.
2. TheWJ65/95/110mailingmachinemustbepluggedinand
displaying
SUPERVIS USER
toinstalltheInkCartridge.
3. PressthebluebuttonunderUSER
4. Thedisplayis:
OK
CARTRIDGE
INSERT CARTRIDGE & PRESS OK
5. Openthemachinetopcover
6. Placethe newcartridge initsholder.

18
ORIG0122-18
4128811U/B
12/08/2006
7)Lockthecartridgeinpositionbycarefullypushingdownonthe
depressedsemi-circleonthetopofthecartridgewithyourindex
finger,thenuseyourthumbtopushthecartridgetotherearuntilyou
hear it ‘click’ into place.
8)Closethemachinecoverandpressthebluebuttonunder OK .
9) After a short delay the prompt to make a Test Print will be
displayed:
10)TomakeaTestprint,insertablankenvelopeintothemachine
andpressthegreenSTART/STOPbutton.
11) Inspect the Test Print and enter the straightest line (for the
exampleaboveitisline5)bypressingtheappropriatenumeric
keyonthekeypad thenpressthebluebuttonunder OK .

19
ORIG0122-19
4128811U/B
12/08/2006
STEP 16
Adding postage to the meter
PostageispurchasedfromthePostOfficeusingtheHaslerTele
MeterSetting®(TMS)system.YoumusthavefundsinyourTMS
accounttoaddpostagetoyourmeter.
Ensure that the telephone cable from the modem socket
located in the rear of the machine is connected to an
analog telephone outlet (as detailed STEP 13 of this
guide). If your analog telephone system requires dialing
a prefix, please refer to page 94 of the User Guide for set-
up instructions.
1)FromReadymode,press onthekeyboard(thisistheFunds
key).
2)TheENTERAMOUNTscreenisdisplayed:
3)Usethe numeric keypadto enter the amountof postage you
wishtopurchase(wholedollarsonly)e.g$100.
Press .
4) Press OK .

20
ORIG0122-20
4128811U/B
12/08/2006
5)Youwillnowbeaskedtoverifytheamountbeforeproceeding.
-Iftheamountdisplayediscorrect,press OK toconfirm
-Iftheamountisincorrect,pressESCAPEandstartagain
fromtheEnterAmountscreen.
6) The postage meter will connect to the Hasler Tele Meter
Setting®system and system and upon completion of the Add
Postagetransaction,thefollowingscreenwillbedisplayed.
7) Press OK or ESCAPE to return to Ready Mode.
