HBM SomatXR CX23-R User manual

CX23-R Quick Start Guide
WARNING
Keep protective caps in place when connectors are not in use.
Opening the unit invalidates the warranty and IP rating. There are no user serviceable components inside the unit.
Do not apply more than 10 psi water pressure to the unit.
© HBM, Inc. All rights reserved. All details describe our products in general form only.
They are not to beunderstood as express warranty anddo not constitute any liability whatsoever.
Americas: HBM, Inc. · 19 Bartlett Street · Marlboro · MA 01752 ·USA · Tel.: [phone] · Email: [e-mail]
Asia: Hottinger Baldwin Measurement (Suzhou) Co., Ltd. · 106Heng Shan Road · Suzhou215009 · Jiangsu · China
Free hotline: [phone] (onlyin China) · Tel.: [phone] · Email: hbmchi[email protected]om.cn
Europe: Hottinger Baldwin MesstechnikGmbH · Im Tiefen See 45· 64293 Darmstadt · Germany
Tel.: [phone] · Email: i[email protected]om
measure and predict with confidence
A4049-2.0en SO-269-1000512HBM:Public.
CX23-R Quick Start Guide

CX23-R Data Controller
Setting up the CX23-R
1. Connect the 1-KAB2115 power cable from the INPUT connector to a
10-30VDC power source. Alternatively, use the 1-NTX003 power supply.
NOTE
The green wire of the 1-KAB2115 cable must be insulated or tied to +VDC.
2. Connect the 1-KAB2106 Ethernet cable from the HOST connector to the
host PC. The host PC network settings must be compatible with the
CX23-R default IPaddress 192.168.100.101.
3. Connect desired transducers to DIO, GPS, AUX and CAN ports using the
appropriate sensor cables. Refer to the SomatXR Accessories Data Sheet
for a complete list of sensor cables.
4. Wait at least five seconds after
supplying power to the unit.
5. Press and release the power
button. The green and blue LEDs
turn on. Wait about 15 seconds for
the unit to boot up.
6. Open a web browser and navigate
to the default IP address
192.168.100.101. If presented with
a certificate warning, choose to
proceed. The CX23-R web
interface is displayed.
In the Box
oCX23-R unit with dust caps
o1-KAB2115-2 power cable
o1-KAB2106-2 Ethernet cable
oUSB flash drive
oSomatXR Safety Manual
oCX23-R Quick Start Guide
SYNC (blue)
On Sample clock is synchronized
to PTP source.
4 Hz Sample clock is synchronized
to GPS source.
1 Hz Sample clock is not externally
regulated.
POWER (green)
Off Unit is off.
On Unit is on.
4 Hz Unit is shutting down.
2 Hz Unit is in locate mode.
RUN (yellow)
Off No test run is in progress.
4 Hz Test run is in progress.
ERROR (red)
Off No error.
On Unit error.
1 Hz User alert.
CX23-R Status LEDs
CX23-R Quick Start Guide CX23-R Quick Start Guide

1. Open the web-based interface at the default IP address
192.168.100.101 and navigate to the Test configuration section.
2. In theTest setups page, click the New button from the task pane to
define a new test setup. Edit the setup name and description as
desired. The default name is "test_name."
3. In the Channel setup page, click the Add button from the task pane.
Select the desired inputs and click OK.
View the new channels in the All channels tab of the grid.
Restoring Default Settings
Administrator profile & password
To regain administrator access:
1. Power down the CX23-R.
2. Press and hold the power switch.
3. When the LEDs begin to flash,
quickly release the power switch.
NOTE
No other profiles or users are affected.
Network Settings
To reset the module IP address to
192.168.100.101:
1. Power down the CX23-R.
2. Press and hold the power switch.
3. When the LEDs flash, stay on and
start flashing again, release the
power switch.
NOTE
This procedure activates the Default Auto
Set network and does not delete any user-
defined networks.
Connecting MX Modules
A CX23-R module can be used to control and process data from multiple MX modules to include other transducers such as
voltage, current, bridge and thermocouple. MX modules can be connected directly to the CX23-R module or through one or
more EX23-R Ethernet switches.
Refer to theMX Modules User Manual for more information on using MX modules.
NOTE
The CX23-R automatically configures the MX module network address and checks for firmware updates. If necessary, install new MX
firmware before continuing.
Centralized network using direct Ethernet connections
NOTE
The CX23-R AUX PWR connector can power a maximum of two MX modules.
1. To power the first MX module, connect the CX23-R AUX PWR connector to the X104 connector on the first MX module
using a 1-KAB2110 cable.
CAUTION
Do not exceed 5 A current draw from the CX23-R AUXPWR connector.
2. To power the second MX module, use a 1-KAB272 cable from the X101 or X102 connector on first MX module to the
X101 or X102 connector on the second MX module.
3. Connect the CX23-R ETHERNET1 and ETHERNET2 connectors to the MX module X100 connectors using KAB2100
cables. This establishes communication and synchronization between the CX23-R and MX modules.
Distributed network using EX23-R Ethernet switches
1. Connect the CX23-R, EX23-R and MX modules to a power supply.
NOTE
When designing the power system, note that increased cable lengths can produce significant voltage drops at the module
connectors, especially when using PoE or powering multiple modules from one source.
NOTE
MX modules may also be powered in serial using FireWire connections. Refer to the MX Modules User Manual for details.
2. Use a 1-KAB2107 cable to connect the CX23-R ETHERNET1 connector to the EX23-R switch.
NOTE
For optimal data throughput performance, do not use both CX23-R Ethernet ports when using EX23-R modules.
To use multiple EX23-R modules, connect any Ethernet port on the new EX23-R module to any open EX23-R Ethernet port.
3. Use 1-KAB2100 cables to connect the MX module X100 connectors to the EX23-R switch.
Running a Basic Test Live data displays
To change the display, click on
the display window and select a
new chart type.
Strip chart display.
Digital meter display.
4. Click the Save button in the header or task pane to save changes.
5. Navigate to the Testand data control section.
6. Click Start to run the test. The yellow LED flashes in the status bar of
the web interface and on the unit. To view real time data, select the
check boxes next to the desired channel names.
7. Click Stop to end the test run. To download the SIE data file, click the
file name in the Test run statistics panel.
