Herdegen Clipper I 500400 User manual

Ref. 500 400 -410 -411 -420 -421 -430 -431
CLIPPER ME_5RWC02
119/07/2017 Rev 1 (26/09/2017)
HERDEGEN SNC 2, Rue Freyssinet 77500 CHELLES-FRANCE
Clipper I Clipper II
Clipper III
Clipper IV Clipper V Clipper VI
500400 500410
500420 500421 500430 500431
500411
Clipper VII
A
C
1
2
3
B
Ref
500400
11 cm
41 cm
42 cm 25*21 cm
1.1 kg
185 kg
500410 1.2 kg
500411 1.6 kg
500420 66 cm 2.7 kg 100 kg
500421 3.1 kg
500430 52/64.5 cm
6x2.5 cm 60 cm 5.4 kg 150 kg
500431 5.9 kg


Ref. 500 400 -410 -411 -420 -421 -430 -431
CLIPPER ME_5RWC02
319/07/2017 Rev 1 (26/09/2017)
HERDEGEN SNC 2, Rue Freyssinet 77500 CHELLES-FRANCE
Please
read these safety instructions carefully before use, and keep
them for future question.
1.Safety indications
♥ALWAYS consult with your physician or supplier to determine proper
adjustment and use of the device.
♥Do not lean out of the raised seat to avoid falling out of the device.
♥Do not seat or step on the lid.
♥Don’t store outside and don’t let under the sun (Beware: don’t let the product
in a car in case of high outside temperature !!).
♥Don’t use outside but only inside and on standard toilet bowls.
♥Check carefully all parts of this item (screws, tubes, clips..) and if all screws
are tightened.
♥Use only as a raised toilet seat and in proper way : don’t knee or step on the
product, don’t seat on the lid.
♥ALWAYS observe the weight limit on the labelling of your device.
♥No modication must be made on this device. Use only original parts to
replace the broken or defect one and let this be done by the technical staff.
♥After assembling the product, make sure that it is securely locked and xed
before using.
♥In case you didn’t use your raised seat for a long time, let it checked by the
technical staff, before using.
♥Always check stability before using.
2. Indications & Contraindications
Indication
Contraindication
Don‘t use the commode chair in case of:
- Cognitive disorder - Loss of balance - Siting impairment
2. Installation
Only specialists can adjust the product and teach you how to use it. A wrong use
or adjustment could lead to overstress of the device or of the patient. The device
must be adjusted individually by the technical staff to suit your needs.
Ask the technical staff how to use this product and make sure that you understood
clearly their explanation.
In case of doubt, don’t hesitate to ask again.
Those items (except ref 500400) are equipped with clips enabling a tight xation
on the toilet bowl.
The references 500420 and 500421, Clipper 4 and 5, are equipped with armrests
which offer extra support to the user. However, if you suffer from a severe disability
and need a strong support, you should use the ref 500430 and 500431. Do not
use the product if you see any risk.
Ref. 500400
1-Lift the toilet seat and lid.
2-Position the raised seat correctly on rim of toilet.
3-This product isn’t xed on the toilet, so it can be instable. In case of doubt ask

Ref. 500 400 -410 -411 -420 -421 -430 -431
CLIPPER ME_5RWC02
419/07/2017 Rev 1 (26/09/2017)
HERDEGEN SNC 2, Rue Freyssinet 77500 CHELLES-FRANCE
the technical staff.
Ref. 500410 et 500411 see [A]
1-Lift the toilet seat and lid.
2-Adjust the clips at the required position (1), place the seat onto the toilet bowl
(2). Position raised toilet seat correctly on rim of the toilet and push the blue
brackets (rst the ones located at the front) tight to the bowl (3).
3-Check the stability before using.
4-Simply remove the raised seat by lifting up. Restart from point 1 to install again.
Ref. 500420 et 500421 see [B]
1-Proceed as for ref 500410/411.
2-The arms can be rotated backwards : rst press the pushbutton located under
the armrest (1), then push the armrest on side (2) and fold up the armrest (3).
Ref. 500430 et 500431 see [B]+[C]
1-Proceed as for ref 500410/411.
2-Adjust the legs with the push buttons. All legs must be leveled to the ground.
Rental:
This product can be rented to different patients. A thorough maintenance,
cleaning and disinfection must be performed before the product is given to a
new patient in accordance with the following steps:
1- Visual inspection: ensure that the product has not been damaged and
check for any defect.
2- Functional inspection: ensure that the product functions properly and
repair it if needed.
3- Cleaning and disinfection: this product can be cleaned and disinfected
with mild, chlorine-free detergents such as Survanios (Anios laboratories).
Do NOT use any abrasive cleaners or high-pressure cleaners that could damage
the product.
Use only appropriate tools to perform the maintenance, cleaning and disinfection.
The user’s manual is an integral part of the product and must be handed over to
every new user.
4. Cleaning
The raised seat has to be cleaned regularly with a mild cleaning agent and a soft
cloth. It may be washed with soap and water or disinfected with non-chlorinated
products.
5. Materials
Ref 500400: Seat from polypropylene equipped with 4 antslipp stickers.
Ref 500410 et 411: Seat from polypropylene equipped with 4 xing brackets.
Ref 500420 et 421: Seat from polypropylene equipped with 4 xing brackets and
2 removable armrests.
Ref 500430 et 431: Seat from polypropylene equipped with 4 xing brackets and
an adjustable safety frame. Some items are also equipped with a lid.
Armrests and frame are made up of steel covered with epoxy painting.
6. Disposal
Dispose of this product in accordance with your regional waste disposal
regulations.
7. Technical specications
This product has a 2 years warranty, from the date of purchase, against any
manufacturing defect. This product is biocompatible. Duration of use : 2 years.
Test: DIN EN ISO 999 (08/98) 091215, EN 12182.
