INSTRUCTION MANUAL
DC SIGNAL SOURCE
7011

Contents
Introduction i
Shipping Check i
Safety ii
Points for Attention During Use v
Layout of This Manual ix
Chapter 1 Product Overview 1
1.1 Product Overview 1
1.2 Product Features 2
1.3 Names and Functions of Parts 3
Chapter 2 Before Starting Output or
Measurement 13
2.1 Preparing for the Power and Replacing
the Batteries 13
2.1.1 Installation of LR6 Alkaline Batteries
or Optional 9420 BATTERY PACK 16
2.1.2 Connecting the Optional 9418-10 AC
ADAPTER 17
2.1.3 Charging the Optional 9420 BATTERY
PACK 17
2.2 Connecting the Input and Output
Terminals 20
2.2.1 Connecting Method 21
2.3 Turning the Power On and Off 24

Chapter 3 Basic Operation 27
3.1 Constant Voltage (CV:2.5V/25V) Generation
and Constant Current (CC:25mA) Generation 28
3.2 Thermoelectric Power (TC: 0℃/RJ) Generation 31
3.3 Voltage (V: 2.5 V/25 V) Measurement,
Current (A: 25 mA) Measurement 37
3.4 Temperature Measurement (TEMP) 40
3.5 0℃Check of the 100 ΩResistance
Thermometer 42
Chapter 4 Detailed Description of Functions 43
4.1 Output Monitor 43
4.2 Memory Generation 46
4.2.1 Data Store to Memory 46
4.2.2 Memory Data Recall Generation 49
4.2.3 Memory Data Autoscan Generation 50
4.2.4 Memory Clear 52
Chapter 5 Applications 55
5.1 Source and Sink Area 55
5.2 Secondary Battery Charge/Discharge 55
5.3 Signal Loop Testing of Industrial Machinery 57
Chapter 6 Maintenance, Adjustment, and
Disposal 59
6.1 Maintenance and Servicing 59
6.2 Changing the Battery 60
6.3 How to Change the Circuit Protection Fuse 62

6.4 Replacing the Battery Protecton Fuse 66
6.5 Shipping the Unit 67
6.6 Troubleshooting Checklist 67
6.7 Disposing of the Unit. 69
Chapter 7 Specifications 71
7.1 General Specifications 71
7.2 Generation and Measurement Ranges,
Accuracy 75

i
―――――――――――――――――――――――――――
Introduction
――――――――――――――――――――――――
Please note that we no longer sell th
e
optional 9420 BATTERY PACK as it i
s
no longer in production.
I
ntroduction
Thank you for purchasing this HIOKI "7011
DC SIGNAL SOURCE." To get the maximum
performance from the unit, please read this
manual first, and keep this at hand.
For this unit, the batteries and AC adapter
are not supplied. Use LR6 alkaline batteries,
optional 9420 BATTERY PACK, or 9418-10
AC ADAPTER (PSA-30U-120, PHIHONG).
A Request
We have tried to bring this manual as close to
perfection as we could achieve. If perchance
you find any unclear portions, mistakes,
omissions, or the like, we would be most
obliged if you could please notify us of them
via any HIOKI agent, or directly.

ii
―――――――――――――――――――――――――――
Shipping Check
――――――――――――――――――――――――
S
hipping Check
When the unit is delivered, check and make
sure that it has not been damaged in transit.
In particular, check the accessories, panel
switches, keys, and terminals.
If the unit is damaged, or fails to operate
according to the specifications, contact your
dealer or HIOKI representative.
Check the 7011 Unit and the Supplied
Accessories
Main unit
7011 DC SIGNAL SOURCE
Supplied accessories
Instruction manual 1
9168 INPUT CORD 1 set
9170-10 TEST LEAD 1 set
Spare fuses 250VF50mAH 3

iii
―――――――――――――――――――――――――――
Safety
――――――――――――――――――――――――
WARNIN
G
Incorrect measurement procedures could result in
injury or death, as well as damage to the unit.
(Please read this manual carefully and be sure
that you understand its contents before using the
unit. The manufacturer disclaims all
responsibility for any accident or injury except
that resulting due to defect in its product.)
S
afety
This Instruction Manual provides information
and warnings essential for operating this unit
in a safe manner and for maintaining it in
safe operating condition. Before using this
unit, be sure to carefully read the following
safety notes.

iv
―――――――――――――――――――――――――――
Safety
――――――――――――――――――――――――
WARNIN
G
Indicates that incorrect operation
presents significant danger of accident
resulting in death or serious injury to
the user.
CAUTIO
N
Indicates that incorrect operation
presents possibility of injury to the user
or damage to the unit.
NOTE
Denotes items of advice related to
performance of the unit or to its correct
operation.
This symbols is affixed to locations on
the unit where the operator should
consult corresponding topics in this
manual (which are also marked with the
symbol) before using relevant
functions of the unit.
In the manual, this mark indicates
explanations which it is particularly
important that the user read before using
the unit.
Indicates DC (Direct Current)
The following symbols are used in this
Instruction Manual to indicate the relative
importance of cautions and warnings.
Safety Symbols

v
―――――――――――――――――――――――――――
Points for Attention During Use
――――――――――――――――――――――――
WARNIN
G
When a power supply from AC adapter terminal
on the unit, before turning on the power, make
sure that the voltage of the power supply being
used matches the supply voltage indicated on
the part of the AC adapter terminal on the unit.
If an attempt is made to use an improper supply
voltage particularly in excess of 13.2 VDC, there
is danger of damage to this unit and of life-
threatening risk to the operator.
The optional 9418-10 AC ADAPTER is
constructed so as to be connected to a ground
line via a grounded two cable power cord such
as the power cord that is supplied with the unit.
In order to avoid electric shock, connect the unit
to a properly grounded power supply socket
using the power cord provided. In addition, if
using a ground adapter, be absolutely sure to
connect the green ground wire which protrudes
from the adapter to a ground line.
P
oints for Attention During Use
In order to ensure safe operation and to
obtain maximum performance from the unit,
observe the cautions listed below.

vi
―――――――――――――――――――――――――――
Points for Attention During Use
――――――――――――――――――――――――
WARNIN
G
This unit is designed for safe operation only at
low voltage. Ensure that no more than 60 V is
present between any terminal and ground, and
that the potential difference between any two
terminals does not exceed 60 V. The unit
cannot be guaranteed in an overrange situation,
such as due to an inadvertent electric shock or
faulty insulation, and we cannot accept
responsibility for any consequences that might
occur from misuse.
The output terminals and the voltage and
current input terminals (terminals for the
standard resistor) are all isolated. Before
connecting the terminals, ensure that the device
being measured will not provide excessive
output to, or require excessive input from, the
terminals. The unit cannot be guaranteed in an
overrange situation, such as due to an
inadvertent electric shock or faulty insulation,
and we cannot accept responsibility for any
consequences that might occur from misuse.

vii
―――――――――――――――――――――――――――
Points for Attention During Use
――――――――――――――――――――――――
WARNIN
G
If the battery voltage drops while the unit is
running off of battery power, the 7011 will
automatically switch off the power supply. Note
that if the unit is left in this state for an
extended period of time, the optional 9420
BATTERY PACK may be discharged too much.
If the battery is left in the battery compartment
for a long time, it may leak. Such leakage may
damage the unit, or cause an electrical hazard,
so please remove the battery if the unit is not to
be used for a long period.
CAUTIO
N
･Do not store or use the unit where it will be
exposed to direct sunlight, high temperature, high
humidity, or condensation. If exposed to such
conditions, the unit may be damaged, the insulation
may deteriorate, and the unit may no longer satisfy
its specifications.
･To avoid damage to the unit, do not subject the unit
to vibrations or shocks during transport or handling.
Be especially careful to avoid dropping the unit.

viii
―――――――――――――――――――――――――――
Points for Attention During Use
――――――――――――――――――――――――
CAUTIO
N
･If this unit is subject to shock or vibration, do not
make any connections to the terminals until each of
the display selections and measurement function
selections have been checked to ensure that no
damage has been sustained.
･Before generation or measurement, make sure of
the function position.
If current or voltage in excess of generation or
measurement range is input, the unit may be
damaged.
･If output is impossible when "ON" is displayed
which indicates outputting, set to "OFF" with
OUTPUT ON/OFF and set output to "ON" again.
･The case is not hermetically sealed for protection
against explosion, so do not use in a flammable
atmosphere.

ix
―――――――――――――――――――――――――――
Layout of This Manual
――――――――――――――――――――――――
L
ayout of This Manual
Chapter 1
Product Overview
Describes the product generally, and lists the
parts and functions.
Chapter 2
Before Starting Generation and Measurement
Preparing for the power cord or how to
connect the input and output cord etc., and
important precautions before operation.
Chapter 3
Outline of Basic Operation
Explanations of each function.
Chapter 4
Detailed Description of Functions
Detailed explanation of the functions.
Chapter 5
Detailed Description of Applications
The application of the sink function
Chapter 6
Maintenance, Adjustment, and Disposal
Chapter 7
Specification and Options

x
―――――――――――――――――――――――――――
Layout of This Manual
――――――――――――――――――――――――

1
―――――――――――――――――――――――――――
Chapter 1 Product Overview
――――――――――――――――――――――――
Chapter
1
Product Overview
1
.1 Product Overview
The compact 7011 DC SIGNAL SOURCE uses
LR6 alkaline batteries (optional 9420
BATTERY PACK or *9418-10 AC ADAPTER),
and can output DC voltage and current, and
thermocouple power equivalent to preset
temperature (K, E, J, T, R, S, B). In addition,
it can measure DC voltage, current and
temperature which are electric potentially
insulated from generation circuit.
This unit is intended primarily for the
maintenance of measurement
instrumentation systems and industrial
meters, and for testing electronic circuits and
machinery. It includes standard voltage and
current source functions suitable for use in
the research laboratory. The miniaturized
design makes it easily portable, and the
internal rechargeable battery power source
ensures long term operation by simply
recharging the battery in the field.
*:9418-10 AC ADAPTER (PSA-30U-120, PHIHONG)

2
―――――――――――――――――――――――――――
Chapter 1 Product Overview
――――――――――――――――――――――――
1
.2 Product Features
Generation and measurement of DC voltage
from -25.000 V to 25.000 V (minimum resolution
100 μV), and of DC current from -25.000 mA to
25.000 mA (minimum resolution 1 μA).
Generate seven types of thermocouples K, E,
J, T, R, S and B (JIS C 1602-1981) to a preset
temperature.
Temperature measurement from -25℃to 80℃with
optional accessory 9184 TEMPERATURE PROBE.
Bipolar output can be used for load current sink.
So loop testing in the instrumentation system
is possible.
The 7011 is provided with following monitor
functions: current when constant voltage
generates, voltage when constant current
generates, reference junction temperature
when thermoelectric power generates.
Up to 20 memories are available to each
function to store displayed settings for
different conditions. Memory contents can be
recalled and can be generated in autoscan.
Common alkaline batteries support use in
situations where AC power is not available.
The 9420 BATTERY PACK is available as an
option for rapid recharging with the *9418-10
(less than 2 hours for full recharge).
The optional *9418-10 allows continuous long-
term operation.

3
―――――――――――――――――――――――――――
Chapter 1 Product Overview
――――――――――――――――――――――――
5
7
6
10
9
8
17
11
13
12
Front pane
l
4
15
16
14
1
.3 Names and Functions of Parts

4
―――――――――――――――――――――――――――
Chapter 1 Product Overview
――――――――――――――――――――――――
Rear pane
l
18
Right sid
e
19
20
1
2
3
