FT6380-50
CLAMP ON EARTH TESTER
Instruction Manual
Feb. 2021 Revised edition 1
FT6380B981-01 21-02H
FT6380-50
CLAMP ON EARTH TESTER
Instruction Manual
Feb. 2021 Revised edition 1
FT6380B981-01 21-02H
HIOKI FT6380B981-01
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

HIOKI FT6380B981-01
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

i
Contents
Introduction .......................................................................... 1
Verifying Package Contents ................................................ 2
Option (sold separately) ....................................................... 3
Safety Information ................................................................ 4
Operating Precautions ......................................................... 8
Chapter 1 Overview 13
1.1 Product Overview .............................................. 13
1.2 Features ............................................................ 14
1.3 Names and Functions of Parts .......................... 16

Operation key ............................................................ 18
 Display Indicators ...................................................... 19
Chapter 2 Measurement 21
2.1 Measurement process ....................................... 21
2.2 Preparing for Measurement .............................. 22

Attaching the Strap .................................................... 22
 Installing (or Replacing) the Battery and
Wireless Adapter ....................................................... 23
2.3 Pre-Operation Inspection .................................. 26

Using the included resistance check loop to
inspect the instrument................................................ 27
2.4 Measurement Procedure ................................... 28

Resistance Measurement .......................................... 29
 Current Measurement ................................................ 33
2.5 Convenient function .......................................... 37

Data hold function (Holding the measured value) ..... 37
 Backlight function
(Making measurements in a dark location)................ 37
 Filter function (Rejecting noise) ................................. 38
 Alarm function
(Judging measured values and sounding an alarm) .. 39
FT6380B981-01
HIOKI FT6380B981-01
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

ii
 Memory function (Saving measurement data) ........... 42
 Wireless Communication Function
(GENNECT Cross)..................................................... 46
 Useful functionality of the Z3210 ................................49
 Function mode ...........................................................50
2.6 Advanced Settings and Functions .....................51

Enabling/disabling the measurement range
display function .......................................................... 52
 Enabling/disabling the auto-power-saving (APS)
function....................................................................... 53
 Reverting the instrument to factory settings
(system reset) ............................................................ 54
Chapter 3 Specifications 55
3.1 General Specifications .......................................55
3.2 Input, Output, and Measurement Specifications 56
3.3 Function specifications ......................................62
Chapter 4 Maintenance and Service 63
4.1 Cleaning ............................................................63
4.2 Troubleshooting .................................................64

Inspection and Repair ................................................64
 Before returning for repair .......................................... 64
4.3 Errors and Operating Status ..............................65
HIOKI FT6380B981-01
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Introduction
1
Thank you for purchasing the Hioki FT6380-50 Clamp on Earth
Tester. To obtain maximum performance from the instrument,
please read this manual first, and keep it handy for future refer-
ence.
Introduction
HIOKI FT6380B981-01
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Verifying Package Contents
2
Confirm that these contents are provided.
Use the original packing materials when transporting the instrument, if
possible.
For other transportation notes, refer to the “Transporting” (p.64).
Verifying Package Contents
When you receive the instrument, inspect it carefully to ensure
that no damage occurred during shipping. In particular, check
the accessories, panel switches, and connectors. If damage is
evident, or if it fails to operate according to the specifications,
contact your authorized Hioki distributor or reseller.
□ FT6380-50 Clamp on Earth Tester
□ Instruction Manual (this manual)
□ Carrying case
□ Resistance check loop
(1 Ω ±2%, 25 Ω ±1%)
□ LR6 Alkaline battery ×2
□ Strap
□ Operating Precautions
(0990A907)
Accessories
HIOKI FT6380B981-01
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Option (sold separately)
3
The option listed below is available for the instrument. To order
an option, please contact your authorized Hioki distributor or
reseller. Options are subject to change. Check Hioki’s website
for the latest information.
Option (sold separately)
□ Z3210 Wireless Adapter
HIOKI FT6380B981-01
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Safety Information
4
This instrument is designed to conform to IEC 61010 Safety
Standards and has been thoroughly tested for safety prior to
shipment. However, using the instrument in a way not described
in this manual may negate the provided safety features. Care-
fully read the following safety notes before using the instrument.
Safety Information
Mishandling instrument could result in bodily injury or
even death, as well as damage to the instrument.
Familiarize yourself with the instructions and precautions
in this manual before use.
Symbols on equipment
Indicates the need for caution or the presence of a
hazard. For more information about locations
where this symbol appears on instrument compo-
nents, see “Operating Precautions” (p.8), warning
messages listed at the beginning of operating
instructions, and the document entitled “Operating
Precautions” that comes with the instrument.
Indicates a double-insulated device.
Indicates AC (Alternating Current).
Indicates that using the instrument in an external
magnetic field of exceeding 30 A/m is prohibited.
Indicates that the instrument may be connected to
or disconnected from a live circuit.
Indicates whether the power is on or off.
HIOKI FT6380B981-01
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Safety Information
5
The following symbols in this manual indicate the relative impor-
tance of cautions and warnings.
Indicates an imminently hazardous situation
that, if not avoided, will result in death of or
serious injury to the operator.
Indicates a potentially hazardous situation that,
if not avoided, could result in death of or seri-
ous injury to the operator.
Indicates a potentially hazardous situation that,
if not avoided, could result in minor or moder-
ate injury to the operator.
Indicates the possibility of equipment damage.
Symbols for Various Standards
Indicates the Waste Electrical and Electronic
Equipment Directive (WEEE Directive) in EU
member states.
Indicates that the instrument complies with stan-
dards imposed by EU directives.
Other Symbols
Indicates a prohibited action.
(p. #)
Indicates the location of reference information.
[ ] Information displayed on the screen is enclosed
in brackets.
Fn
(bold
characters)
Bold text indicates alphanumeric characters
shown on operation keys.
HIOKI FT6380B981-01
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Safety Information
6
Screen displays that differ from the above notation:
Hioki expresses accuracy as error limit values specified in terms
of percentages of reading.
The screen of this instrument displays characters in the fol-
lowing manner.
Symbols for Various Standards
Over-range display
Open display
Resistance measurement: When the read-
ing exceeds 1,600 Ω
Current measurement: When the reading
exceeds 60.0 A.
This screen is displayed when the clamp
sensor is not completely closed during use
of the resistance measurement function.
Reading
(displayed
value)
Refers to the displayed value of the measur-
ing instrument. The limit values of reading
errors are expressed in percent of reading
(% of reading, % rdg).
