Hofmann geodyna 2600 User manual

28002600
geodyna 2600
Operation manual Car wheel balancer
Form ZEEWB703D

2 Operation manual geodyna 2600 EEWB703D
Contents •Safety rules and function
Contents Page
1. Safety rules and function 2
2. Installation of the machine 5
3. Electrical connection 6
4. Controls and displays 7
5. Turning on the machine 13
6. Clamping the wheel 15
7. Entry of balancing mode and wheel size 17
8. Balancing the wheel 27
9. Hidden spoke placement 31
10. Changing modes of operation 33
11. Error codes 40
12. Pro-Match / weight minimisation 46
13. User calibration 57
14. Maintenance 58
15. Technical data 58
16. Electrical diagram 59
1. Safety rules and function
1.1 Special hints for the reader
A few special features were used in this manual to facilitate
reading and understanding of pictures and written instructions:
•signals the operator where to act.
Safety rules are highlighted in grey.
Arrow showing where to look
1.2 Scope of application
The off-the-vehicle wheel balancer is designed for static and/
or dynamic balancing of car and light-truck wheels weighing
up to 150 lbs and having an overall diameter of 44”.
In addition to conventional balancing operations, irregular run-
ning conditions of the wheel caused by geometric deforma-
tions of the rims and/or tires, hence unsmooth ride, can be
identied, improved or, if possible, even eliminated. By exact
adjustment of the two wheel components relative to each
other optimum wheel running conditions or at least balance
weight minimisation can be achieved.

1.3 General safety rules
Only properly trained and authorised personnel shall be al-
lowed to operate the wheel balancer.
The machine must not be used except for the scope of ap-
plication and in the way specied in this manual.
Unauthorized changes and modications to the machine
relieve the manufacturer from any liability for damages and
injuries that might result therefrom.
On no account should safety features be removed or made
inoperative.
In general any work on the electrical system such as tting of
a plug or changing of connections, if necessary, must be car-
ried out by a qualied electrician in line with relevant national
standards and the regulations of the local power station.
It should be noted that working with technical equipment may
involve an unforeseeable acceptable risk.
Therefore the operator should eliminate such dangers in
advance by proper and wise behavior.
The following special points should be observed:
Use technical equipment for its specied scope of application
only.
Always use suitable and proper equipment and tools.
Follow the instructions, notes and technical data of the
machine manufacturer or manufacturer of the wheels to be
balanced.
Wear suitable protective clothing and accessories (e. g.
goggles, safety shoes, helmet).
For further safety rules to be observed, please refer to the
individual chapters.
1
2
1
3
28002600
6
4
5
Safety rules and function
Fig. 1 View wheel balancer
Front view
1 Weight tray
2 Display and key pad
3 Wheel guard
4 Gauge arm for distance rim/machine and rim diameter
5 Pedal for main shaft lock
6 Rear view
Operation manual geodyna 2600 EEWB703D 3

4 Operation manual geodyna 2600 EEWB703D
Safety rules and function
1.4 Description of function
Display and key pad
The display and key pad are arranged on the ergonomic front
panel.
Gauge arm for distance and rim diameter
Entry of rim diameter and distance between left correction
plane and machine is by means of an integrated gauge arm
or also via the key pad. In the latter case the relative function
key is held pressed while the wheel is rotated to choose the
desired inputs and enter them by releasing the function key.
When tting adhesive weights with the weight holder, the
machine will support the operator in relocating the correction
position.
Rim width is entered via the menu keys and rotation of the
wheel.
Balancing mode
Readings in different balancing modes (weight position on
the rim) can be given on the display, depending on the type of
wheel to be balanced (car, light-truck, motorcycle, PAX, steel
or alloy rim).
Measuring run and measured values
All measurements are taken and stored in one run during
the automatic program. On completion of measurement the
machine stops automatically and the wheel is slowed down
to standstill. Amounts and locations of unbalance are read out
separately for each correction plane. Main shaft lock
The machines have a pedal-operated main shaft lock which
is used to retain the wheel in the correction position so that
the balance weights can be tted. This lock is designed only
to facilitate orientation of the wheel and must not be used for
braking the main shaft. Store wheel proles
Wheel proles permit the storage of values for wheels that
are balanced frequently in order to save having to enter the
wheel data etc. each time. It is possible to store up to 4 wheel
proles.
Error codes
Errors in operation or failures in the electronic or mechanical
system are signalled via respective error codes (see § 11.
Error codes).
User calibration
If several measuring runs are necessary to balance a wheel
because balance weight size and position have to be adjusted
repeatedly, this is often due to insufcient measurement ac-
curacy.
In such case the operator has the possibility of readjusting the
machine (see § 13. User calibration). Wheel guard
A wheel guard with electric interlocking is mandatory for the
European Union and is part of the standard equipment. The
measuring run may only be started with closed guard. The
electronic unit can be programmed via code C13 so that mea-
surement is started by closing of the guard.

180
2
3
SW 13
4
5
6
523
1
736
190
2
49
Installation of the machine
2. Installation of the machine
When choosing the site, Health and Safety at Work regula-
tions and the regulations on working environment should be
taken into account.
The wheel balancer can be installed on any rm and level
ground. For the weight and space requirement of the machines
refer to § 15., Technical data. For installation on an upper oor,
observe permissible load capacity of the oor.
It is recommended, though not absolutely necessary, that the
machine be secured to the oor. For this purpose three holes
(Fig. 2) are provided in the base of the machine by which the
latter is xed on the oor with 3/8 ” anchor bolts. Fig. 2 shows
the center-to-center distance of the holes. Make sure that the
machine has a stable position, i.e. that it is supported on three
seatings. If not, ensure three-point contact on ground by
inserting appropriate spacers between the oor and machine
base.
For ease of transport the wheel balancer is disassembled
into the following units and provided with special packing (on
pallets):
- Machine
- Wheel guard
2.1 Unpacking the machine
The machine should be unpacked by two persons.
Note
When unpacking the machine make sure that the pedal tted
on the machine base and the whole pedal assembly is not
damaged.
•Cut the strips of the packing (Fig. 3, item 1), lift off the
packing, and set aside the wheel guard and the small
parts packed in the separate small box (Fig. 3, item 2).
• Unscrew the three hexagon screws (use a 1/2 ” wrench
to) which hold the machine on the pallet (Fig. 4, ar-
row).
•Lift the machine by tube of the vibratory system and
wheel guard arbor and turn around by 180 degrees on
the pallet (Fig. 4).
•Then lower one side of the machine laterally on the
oor (Fig. 5).
•Remove the pallet from underneath the machine and
gently lower the entire machine onto the oor (Fig. 6).
2.2 Resiting the machine
If the machine is transported on site, gently tilt it, taking it by
weight box and wheel guard arbor, and push it gently on suit-
able lifting or mobile industrial handling equipment (e. g. forklift
truck, platform truck).
Note
When lifting the machine bear in mind the centre of gravity of
the machine and avoid oscillating movements.
Operation manual geodyna 2600 EEWB703D 5

1
7
1
4
2
5
3
6 Operation manual geodyna 2600 EEWB703D
In general any work on the electrical system such as tting of
a plug or changing of connections, if necessary, must be
carried out by a qualied electrician in line with relevant
national standards and the regulations of the local power
station.
Installation of the machine
2.2 Mounting the wheel guard (Fig. 7)
•
Slide the wheel guard (Fig. 7, item 1) on the arbor
(Fig. 7, item 2) and raise it until the fastening holes of
wheel guard and wheel guard arbor coincide.
•Insert the M10 setscrew (Fig. 7, item 3) with washer
(Fig. 7, item 4) from below, and tighten the hexagon
nut (Fig. 7, item 5) and washer.
The wheel guard inuences the following modes of op-
eration:
- The measuring run is started by closing the wheel guard
(code C13).
- The wheel is braked on lifting the wheel guard during a
measuring run (code C5).
These modes of operation can be changed either permanent-
ly, or only as long as the machine is switched on, by means of
codes (see § 10. Changing modes of operation).
3. Electrical connection
Electrical standard equipment and drive motor of the wheel
balancer are provided for operation on 50/60 Hz, 115-120 V.
The connecting cable of the machine is designed as a
separate power cord. For connection to the power mains the
cable is provided with a NEMA 5-15P (U.S.) or C22.2 No. 42
(Canada) plug.
Fusing is by the customer before the plug connector, using a
15 amp circuit breaker.
The electrical diagram is illustrated in § 16.
The machine operates internally on a line voltage of 230 V
because the voltage is regulated by an integrated transformer.

8
9
10
1 4
2 3
1 2 3
4 5 6 7
Controls and displays
4. Controls and displays
Fig. 8 Overview
1 START key Start a
measuring run
2 STOP key
- Interrupt the measuring run
- Delete an error code
- If input of a mode of operation is completed with
the STOP key, the new state is deselected automatically
and the former state is re-established. 3 Function keys
(see Fig. 9 to 11)
4 Display (see Fig. 12 to 15)
Fig. 9 Function keys on the left
1 Function key for distance rim / machine
2 Function key for rim width
3 Function key for rim diameter
Fig. 10 Function keys in the center
4 PRO MATCH
- Starts an optimisation program (LED PRO MATCH
lights).
- In the Pro-Match program (OP program): enter valve
position.
5 CLEAR/RESTORE
CLEAR (key pressed briey): Setting the factory adjusted
modes of operation. All settings are deleted and the
display returns to standard.
RESTORE (key pressed for 3 seconds): Restores all
modes the way they were before clear was pressed.
6 CALIBRATE/CODE
CALIBRATE (key pressed briey): Sets the machine in
the user calibration mode (see § 13. User calibration). CODE
(key pressed for 3 seconds): Switches to changing
modes of operation.
7 G/OZ
Switches over the weight unit for unbalance readings
(grammes or ounces).
GReadings in grammes Oz
Readings in ounces
When the machine is switched on the weight unit set with
code C3 is active.
Operation manual geodyna 2600 EEWB703D 7

11a
8 9 10
8 Operation manual geodyna 2600 EEWB703D
Controls and displays
Fig. 11a Function keys on the right
8 ALU/ALU+ toggle key (ALU key) for balancing modes.
ALU (key pressed on top):
Toggles through theALU and standard balancing modes.
While in any ALU mode the ALU status LED lights.
ALU+ (key pressed on bottom):
Sets the machine in the ALU+ mode. This enables the
automatic gauge arm for distance and rim diameter
to measure rst the left-hand distance and then the
righthand hidden weight. Pressing this key disables
one-plane and patch balancing and enables only hidden
weight balancing.
First push: Enables lefthand hammer-on weight and
lights lefthand hammer-on LED for balanc- ing mode
ALU 3P in wheel position display. Second push: Enables
lefthand adhesive weight and lights
lefthand adhesive weight LED for balancing
mode ALU 2P.
Third push: Returns to standard balancing.
9 SPOKE/OPERATOR
SPOKE: Enters the number of spokes for the hidden
spoke placement mode.
Keep the key pressed on top and rotate the wheel to set,
or change, the number of spokes.
When the key is pressed without rotating the wheel, the
current setting is entered.
OPERATOR: Recalls and stores wheel proles. RCL:
Keep the key pressed on bottom. RCL (recall) comes
up in the left-hand section of the display and 1 comes
up in the right-hand section for the rst wheel prole to
be stored.
Keep the key pressed on bottom and rotate the wheel.
Proles 2 through 4 are read out in the right-hand dis-
play. The stored wheel prole is entered once the key
is released.
STO: If a wheel prole is to be stored, keep on press-
ing the key after the rcl readings have come up and
continue rotating the wheel. Now STO (store) comes up
in the left-hand display, and # 1 through 4 can be set in
the right-hand display by rotating the wheel. The cur-
rent prole is stored once the key is
released.
10 RV-S/D
RV (key pressed on top):
Changes the ne resolution to increments for RV/Light
truck.
- Switches resolution to 2 instead of 1/4 ounce.
- Switches suppression minor unbalance readings to a
selectable value (using service code).
Readouts stay in RV mode until deselected by pressing
the key again.
S/D (key pressed on bottom):
- Function key to select display of dynamic or static
unbalance (S/D key).

11b
11
Controls and displays
Fig. 11b Function keys on the right
11 FINE/INT
FINE (pressed on top):
- Show amount reading with higher resolution:
1 gramme instead of 5 grammes or 0.05 oz instead of
0.25 oz (only for as long as the key is pressed)
- Display residual wheel unbalance below the threshold for
suppression of minor unbalance readings: As long as
the key is pressed the suppression of minor unbalance
readings is switched off and the actual unbalance in the
wheel is read out.
- Display unbalance for standard balancing mode: if bal-
ancing mode Alu 1 to Alu 5 is selected, press and hold
the FINE key and then press the function key for balanc-
ing mode (ALU, ALU+). The unbalance readings switch
over to those for standard balancing mode and the rela-
tive rim symbol appears.
- In the OP and Un programs the FINE key serves as
change-over key.
INT (pressed on bottom):
Switches to the patch balance mode. All wheel data
must have been entered. In addition the height-to-width
ratio specied on the tire has to be entered by pressing
the diameter key and rotating the wheel.
Readout display changes to single-plane. Both loca-
tion displays are active and work in parallel. Distance
and diameter dimensions have no effect and are preset
to nominal values. All special functions are inactive and
cannot be selected.
Operation manual geodyna 2600 EEWB703D 9

12
1
2
3
4
5
6
13
1 2 3 4
inch mm
ALU
FINE
INT
PROMATCH
= 0
RV-LIGHT TRUCK
ALU
FINE
INT
PROMATCH
= 0
RV-LIGHT TRUCK
CALIBRATE
SPOKE
7 8
5
CALIBRATE
SPOKE
9
10 Operation manual geodyna 2600 EEWB703D
Controls and displays
Fig.12 Display panel - left section
1 Direction indicator of left correction plane
2 Indicates when correction position in the left
correction plane has been reached.
3 Inch/mm
The unit of measurement (inch or mm) is chosen by using
the rim width key .
4 Rim width Symbol
Lights whenever width key is pressed.
5 Digital Display for left correction plane to show:
- rim width
- amount of unbalance of left correction plane
- amount of static unbalance
- error codes
- C codes
- balancing mode in plain language (upon operation of
ALU key)
- STO, RCL of wheel proles
Note: Error codes are read out in both digital displays.
Fig. 13 Status LEDs
1 ALU: Any ALU balance mode is selected
2 FINE: FINE key is pressed (cancels supression of small
imbalances). Display changes to normal resolution as
soon as key is released.
3 INT: Patch Balance is selected. All special functions
(including FINE) are inactive and cannot be selected.
4 PRO MATCH is selected.
5 = 0 Compensation run has been carried out
6 RV/LIGHT TRUCK resolution is selected.
7 CALIBRATE: Operator calibration mode is entered or
programmable interval is reached.
The LED is automatically activated after 5000 measuring
runs and alerts the operator that operator calibration is
recommended. The LED remains on until the operator
completes the operator calibration.
8 SPOKE: Hidden spoke placement (HSP) mode is
selected.
9 Number of spokes
Number of spokes for hidden spoke placement. Holding
the SPOKE key pressed rotate the wheel to set the
number of spokes between 3 and 12.

6
5
4
14
ALU
1
1
2
3
Controls and displays
Fig.14 Display panel - central section
1 Measuring run indicators ash alter-
nately in top and bottom panel
- during measurement after pressing the START key
- during PRO MATCH
2 Possible weight tting positions LEDs change with
successive pushs of the ALU key.
3 Valve stems
- Top valve stem ashes during PRO MATCH when
valve must be positioned perpendicular to the main
shaft.
- After the valve has been placed perpendicular to the
main shaft and the PRO MATCH key is pressed, the
LED is turned off.
4 SAPE symbol
- As the distance lever is moved the rst bar and grad-
ually the remaining bar segments light up. reaching
the correction position, the segment furthest to the
right lights up and the speaker beeps.
- The symbol lights up when the weight tting position is
rst entered and later relocated.
Note
When the wheel is rotated manually, the SAPE symbol will not
light up.
5 ALU+ lights whenever ALU+ is
chosen.
6 OK
lights whenever in two-plane mode both imbalance
readouts are 0.00.
Operation manual geodyna 2600 EEWB703D 11

1
15
16
START
8
2 3 4 5
inch mm
7
6
12 Operation manual geodyna 2600 EEWB703D
Controls and displays
Fig. 15 Display panel - section on the right
1Loudspeaker symbol
2 inch/mm
The unit of measurement (inch or mm) is chosen by using
the rim diameter key.
3 Rim diameter
lights whenever rim diameter key is pressed.
4 Digital display of right correction plane to show:
- rim diameter
- distance rim/machine (always in mm)
- amount of unbalance of right correction plane
- state of modes of operation or preset limit values
5 Direction indicator of right correction plane
6Indicates when correction position in the right
correction plane has been reached.
7 Distance machine/left correction plane
lights whenever distance key is pressed or gauge arm for
distance and rim diameter is moved.
8 START
ashes when the START key is to be pressed during pro
match and operator calibration.
Fig. 16 Pedal of main shaft lock
The main shaft is locked when the pedal is depressed. This
will facilitate tightening or untightening of the clamping nut, as
well as retaining the wheel in correction position for correct
tting of the balance weights.
This lock is designed only to facilitate orientation of the wheel
and must not be used for braking the main shaft.

17
18
19
20
1
Turning on the machine
5. Turning on the machine
When switched on by the switch (Fig. 17, item 1) the
electronic unit performs a number of self-tests. On successful
completion of these tests a melodious three-tone signal is
given. OK is read out on the displays, and the code number of
the program version is briey viewed on the display; then both
displays show wheel dimensions which were entered before
and are still stored in the electronic memory.
As long as the machine is carrying out the self-tests, no inputs
and no other operations whatsoever must be made. During
this starting phase the machine must not be subjected to even
the slightest vibration.
The electronic unit is factory-adjusted to the following modes
of operation, which are available after turning on:
- car wheel with nominal dimensions in inches width 6.5“
and diameter 15.0“
- entry of rim data in inches
- display of amount of unbalance in 1/4 ounce increments
- suppression of minor unbalance readings (limit set to
1/4 ounce)
- automatic braking of wheel when guard is opened during
the measuring run
- compensation of adapter unbalance switched off
- start of measuring run by START key only
Error codes at power on
If an error code occurs it must be acknowledged by pressing
the STOP key. No audible signal is given.
The following malfunction codes may occur at power-on:
E900 - Fig. 18
Unknown machine model.
E901 - Fig. 19
The machine is not calibrated.
E89 - Fig. 20
A key is jammed at power-on.
•Find and release the jammed key, call service if neces-
sary.
Operation manual geodyna 2600 EEWB703D 13

21
22
23
24
25
26
27
14 Operation manual geodyna 2600 EEWB703D
Turning on the machine
H82 - Fig. 21
The self-test was disturbed (e.g. by rotating the wheel). The
message is displayed for 3 seconds, after which the mea-
surement is repeated (max. 10 times), or aborted by pressing
the STOP key.
E3 - Fig. 22
Gauge arm for distance and rim diameter is not in home
position.
•Move gauge arm to its home position. Press the STOP
key.
E92 - Fig. 23
During the second attempt the gauge arm for distance and rim
diameter was still not in the home position. The gauge arm is
rendered inoperative.
•Wait 3 seconds, or press the STOP key to continue.
E145 - Fig. 24
The contents of both permanent memories are different (but
both contain valid data).
Fatal error codes
The self-test program has detected an error and displays an
alphanumeric code consisting of six digits and/or letters.
Note
The displayed error codes refer only to the internal line voltage
of the machine.
C10 800 - Fig. 25
Line voltage too low. Balancing is feasible if the motor can
drive the main shaft to the measuring speed. Wheel data may
be lost.
•Connect the machine to 115-120 VAC.
C10 801 - Fig. 26
Line voltage too high. Damage to the electronic unit of the
machine is likely!
•Turn off machine immediately.
Damage is not covered under warranty.
C10 804 - Fig. 27
Line voltage too high. Damage to the electronic unit of the
machine is likely!
•Turn off machine immediately.
Damage is not covered under warranty.

28.1
28.2
28
1
1
2 3
2 3
Clamping the wheel
6. Clamping the wheel
6.1 Fitting the wheel adapter on the main shaft
Fig. 28 Fitting the wheel adapter
28.1 MZV-4 cone adapter for rims with center bore loca-
tion, or at least sufciently accurate center bore. Vari-
ous accessories are available for this wheel adapter.
28.2 Adapters for closed rims, or stud hole located rims.
Various accessories are available for this wheel
adapter.
1 Cone of the main shaft
2 Basic body of the wheel adapter
3 Fastening screw (width across ats 14 mm)
• Before tting the wheel adapter clean the cone of the
main shaft (Fig. 28, item 1) and the inner cone of the
wheel adapter.
•Slide the wheel adapter onto the cone of the main shaft
so that the head of the hexagon socket head cap screw
attached to the end of the cone engages with one of
the recesses in the basic body of the adapter (Fig. 28,
item 2).
•Tighten the wheel adapter using the fastening screw
(Fig. 28, item 3).
6.2 Performing a compensation run
All clamping and centring means are balanced in our works to
within a certain tolerance.
To compensate for any residual unbalance that might be left
in the clamping means, it is recommended that an electrical
compensation run be performed (also see § 10. Changing
modes of operation). This mode cannot be transferred into the
permanent memory.
This mode of operation is retained until deleted via code C4,
by starting an Pro-Match run or readjustment, or by switching
off the machine.
•Press and hold the CODE key (Fig. 10, item 6) and
rotate the main shaft to set C4 in the display.
•
Press the START key.
The compensation run takes longer than a regular measur-
ing run. Once the compensation run is completed, C4 is read
out in the left display, 1 is read out in the right display, and the
compensation LED (Fig. 13, item 12) appears in the middle.
When another clamping means is used:
•
Repeat the compensation run.
or
•cancel compensation by pressing and holding the FINE
key (Fig. 11b, item 11) and rotating the wheel, or by
switching the machine off for a few seconds.
In the right display, 0 is read out.
Operation manual geodyna 2600 EEWB703D 15

29
30
1 2 3
1
2
16 Operation manual geodyna 2600 EEWB703D
Clamping the wheel
6.3 Clamping car and light-truck wheels
Fig. 29 Cone adapter to clamp center bore located wheels
1 Cone
2 Rim
3 Clamping head with clamping nut
Fig. 30 Universal clamping adapter for clamping stud hole
located wheels or wheels with closed rim.
1 Rim with center bore (center bore location)
2 Closed rim

1 2 3
31
- +
Entry of balancing mode and wheel size
7. Entry of balancing mode and wheel
size
For determination of unbalance the following inputs have to be
made:
-balancing mode (weight tting position on rim)
-wheel size (wheel width and diameter)
-distance between machine and left correction plane
The wheel dimensions to be entered are usually given on the
rim. Rim diameter is also given on the tire.
Rim width is entered by pressing and holding the relative
function key (Fig. 31, item 2) and rotating the wheel until the
desired value is read out. On releasing the function key the
input is retained until another input is made.
The distance between left correction plane/machine and the
rim diameter are usually entered using the integrated gauge
arm, but may also be entered by pressing and holding the
relative function keys (Fig. 31, items 1 and 3) and rotating the
wheel until the desired values are read out. On releasing the
function key the input is retained until another input is made.
Operation manual geodyna 2600 EEWB703D 17

2 1 1 2
2
12 1 2 2 2
32
1
33
ALU
- +
18 Operation manual geodyna 2600 EEWB703D
Entry of balancing mode and wheel size
7.1 Balancing modes
The use of different types on a standard (alloy) wheel and the
resulting different tting positions of the weights on the rim
produce differences between the rim data which have been
entered and the actual correction dimensions.
Fig. 32 Possible positions of the balance weights
- nominal rim data / actual correction data
1 Nominal rim dimensions to be entered
2 Actual correction data (center of gravity of weights) which
are used for determination of unbalance
The mode chosen is read out on the display, showing the
relative rim symbol (Fig. 33), or on the digital displays when
the Alu key is pressed (reading e.g. Alu 1).
•Press and hold the Alu key (Fig. 33, item 1) and rotate
the wheel to set the desired balancing mode (weight
tting positions - Fig. 33).
•Release the Alu key as soon as the desired mode is
read out.
Fig. 33 Rim symbols showing weight position
nor. Standard balancing mode where hammer-on weights
are attached to the rim anges
Alu 1 Fitting of adhesive weights to the bead seats
Alu 2 Adhesive weights - hidden adhesive weight attached
(Alu 2P) in the rim so as not to impair the decorative appear-
ance of alloy wheels or to balance PAX wheels
Alu 3 Hammer-on weight on left rim ange, adhesive
weight
(Alu 3P) attached in hidden position in the rim disc
Alu 4 Hammer-on weight on left rim ange, adhesive
weight attached to right bead seat
Alu 5 Hammer-on weight on right rim ange, adhesive
weight attached to left bead seat

1
.* ALU
34
35
+
Entry of balancing mode and wheel size
7.2 Input of wheel dimensions for the standard
balancing mode
If several wheels with identical wheel size are balanced in suc-
cession, it is only necessary to enter the data for the rst wheel.
It will remain stored until new entries are made.
7.2.1 Determination and input of rim width
Use the optional rim width callipers (Fig. 35).
Fig. 34 Input of rim width
•To enter the rim width, press and hold the function key
(Fig. 34, item 1).
•Rotate the wheel while the key is pressed in order to
set the value for the rim width on the display, and then
release the key.
Operation manual geodyna 2600 EEWB703D 19

36
15.5
15.5
15.5
normal
Alu 1
Alu 2
7.5
MZV
Alu 2 P
Alu 3
7.5
MZV
Alu 3 P
Alu 4
Alu 5
15.5
15.5
20 Operation manual geodyna 2600 EEWB703D
Entry of balancing mode and wheel size
7.2.2 Gauge head applications
In order to be able to determine unbalance in a single measur-
ing run, the rim dimensions have to be entered correctly.
Fig. 36 shows correct application (with and without adhesive
weight) of the gauge on various rims and for various weight
positions. There are either one, or two positions where the
gauge has to be applied.
normal Standard balancing mode where hammer-on weights
are attached to the rim anges
Alu 1 Attachment of adhesive weights to the bead seats
Alu 2 Adhesive weights - adhesive weight on bead seat, hid-
den adhesive weight attached in the rim: the correc-
tion planes for the adhesive weights are determined
automatically by the machine
Alu 2P Adhesive weights - adhesive weight on bead seat,
hidden adhesive weight attached in the rim; the
correction planes for the adhesive weights can be
determined exactly
Alu 3 Hammer-on weight on left rim ange, adhesive weight
attached in hidden position in the rim; the correction
plane for the adhesive weight is determined auto-
matically by the machine
Alu 3P Hammer-on weight on left rim ange, adhesive
weight attached in hidden position in the rim; the
correction plane for the adhesive weight can be de-
termined exactly
Alu 4 Hammer-on weight on left rim ange, adhesive
weight attached to right bead seat
Alu 5 Hammer-on weight on right rim ange, adhesive
weight attached to left bead seat
Point of application of gauge arm
Given weight position
Point of appliction of gauge arm = weight position
