HOMCOM A91-120 Installation guide

ASSEMBLY & INSTRUCTION MANUAL
INadd039V01_UK
A91-120
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY

-1-
BOX-1/2 BOX-2/2
NO. PARTS QTY NO. PARTS QTY
PACKING DETALS:TOTAL 2 BOXES
Hardware
F1A2
1
B
C1
1
D
E1
1
H

-2-
PART
LIST
Fill the base(F) with water or sand replacethe cap.
01
H1
G12
F1
E1
D1
C1
B1
A2
N1
L1
K2
J1
I15

-3-
02
A
B
C
D
E
F
G
H
I
J
L
N
K
A
K
1.Install the suction cup (G) on the bottom of the base (F)
2.Fix the connector (E )on base(F) with the wrench (J)and the Screw(I)
3.Insert the upper secttion (C) into the Percussion body (D) and set to the desired height.use the butterffly screw to
fix the upper section into place.
4.Install the rotating rod (B) on the upper end ofthe adjusting rod (C) ,Install the pipe fitting(N) onto the main
rod(C)and fix it
5.Put the washer on top of adjusting rod (C) and install the spring (K)
6.Pump up the punch ball by using the pump(H) proided ,then screw into position at the top of the Spring(K)
7.Only use a safe place, well aways from all obstacles, breakaable items or other hazards.
Boxing is a contact sport.Any contact can be dangerous and result in serious injury. When boxing, be sure you are
in good physicai condition and under expert supervision.This eqquipment will provide limited protection but will not
protect you against serious injury. Anyone using this equipment must assume the risk of any injury.
