Honeywell ExiLED User manual

GB
ExiLED
Surface Mounted
Installation:
Dimensional Drawings:
266mm
132mm
223mm
53mm
ExiLED 25m 366mm
199mm
289mm
53mm
ExiLED 40m
Step 1: For double sided pictogram, install the appropriate pictograms to both sides, push up until you
hear click sound. For single sided pictogram, there is one blind pictogram in the package.
Step 4. Drill a hole on a black grommet and pass the mains cables through it. Connect the mains cables to
terminal blocks: L for live wire, N for neutral and PE for ground. Power supply cables cross section
2
should be 0.8 - 3 mm . The C1 and C2 terminals are used for elBus communication optional), DALI
communication (optional), or voltage free contact (optional). Tighten the cable tie around the
cables. ATTENTION!!: Pass the tie through one (NOT two), of the available fixing holes.
The product contains bracket for wall mounting and spacers for ceiling mounting.
Step 3: Dismantle the luminaire by sliding the mounting part as shown in picture. Fasten the mounting
part (with screws from within) to either wall bracket(supplied), ceiling (with or without supplied
spacers), pendulum, wire or flag bracket.
Step 6: In case you use a module connect it on the PCB.
Step 5: Connect the battery cable to its respective connector on the PCB.
Step 2: Install the retaining clip to hold the pictograms.
56
4
click click click click
2
13
Honeywell Life Safety AS, Postboks 236, 1372 Asker http://www.hls-nordic.com

10
ON
1 2 3 4
Switch 4 = ON
Maintained operation
(default position)
ON
1 2 3 4
Switch 4 = OFF
Non-maintained
operation
7
ON
1 2 3 4
ON
1 2 3 4
ON
1 2 3 4
1h
(default position)
3h 8h
Step 7: The control of maintained or non maintained operation of the luminary is achieved through Switch
4 of DS1. For maintained operation, switch number 4 must be in ON position. For non-maintained
operation, switch number 4 must be in OFF position.
Step 8: Slide the two aluminium parts carefully together.
Step 9: Fasten the two screws (included) as shown in the picture.
Step 10: Fasten the two screws (included) as shown in the picture.
The user can select one of the 3 available minimum autonomy durations: 1 hour, 3 hours and 8 hours. The
selection must be done while the luminaire is disconnected from AC and battery supplies. The selection is
achieved through Switches 2 & 3 of DS1. Switch 1 is not used.
Two additional labels are included in the package, one for 3 hour duration (180) and one for 8 hour duration
(480). Depending on the selected duration, the installer must cover the default 1 hour (60) printing with
one that has the required duration.
Note: In case of mains power disconnection for a period of more than two months, the battery must be
disconnected.
Note: If the supply cable of the luminaire is damaged, it shall exclusively be replaced by a competent person
in order to avoid hazard.
Note: In case of battery replacement, this must be replaced with parts of the same type and characteristics.
The replacement must be performed by the manufacturer or a competent person.
To avoid that luminaires perform their battery test at
the same day, connect the battery packs with more
than 1,5 minutes inbetween.
Important notice when installing luminaires within the
same area!!!
7 8 9
Indicator LEDs
LED Status explanation
Description
GREEN
YELLOW
RED
Normal
Charging (battery test not possible while charging
Mains off, battery not connected or charger fault
Battery fault
Battery test
Light source test
Light source fault
Battery fault and light source fault
Off On Flashing
At the end of their useful life the packaging, product
and batteries should be disposed of via a suitable
recycling centre. Do not dispose of with your normal
household waste. Do not burn.
Honeywell Life Safety AS, Postboks 236, 1372 Asker http://www.hls-nordic.com
GB

Technical description
Part no.:
Battery (LiFePO ):
4
Battery Protection:
Min. - Max. Charge Current: 25 - 125mA
Overcharge protection / Deep discharge protection
o
5 to 40 C
Up to 95%
8hours
Produced in accordance with:
Ambient Temperature Range:
Maximum Power Consumption:
Operation Voltage:
Relative Humidity:
Charging Time:
Technical lifetime (light source):
Lumen output, normal:
> 100000 hours
155lm 180lm
ExiLED M ST LED 25m 10Y 138h ExiLED M ST LED 40m 10Y 138h
220-240V AC, 50-60 Hz
138126.10138087.10
6.4V / 0.6Ah
3.8W / 4.1VA 4.1W / 4.4VA
IP40
1h / 3h / 8h manually selected (default 1h)
Degress of cover protection:
Emergency Mode Duration:
EN 60598-1, EN 60598-2-22, EN 55015
EN 61547, EN 61000-3-2, EN 61000-3-3
Charge Voltage Range: 5.6 - 7.3V
Lumen output, emergency (1h/3h/8h): 200/90/40lm 210/90/40lm
Weight:
Expected Battery Lifetime:
Controlgear classification in accordance with IEC 62034: with automatic test function
900 gr 1400 gr
10 years
The dimming setting remains stored in the luminaire even when both mains and battery voltages are disconnected.
Manual tests can only be performed if both mains and battery are connected.
By pressing the test button briefly (less than 5 seconds) an emergency operation test is performed. The exit sign will be lit for
approximately 3 seconds, the red indicator LED will flash during this test sequence.
To restore the original settings, repeat the above procedure.
By pressing the test button for a time space between 5 and 10 seconds, a battery condition test is performed. This test will
last for the stated duration and can only be performed when the battery is fully charged (steady green indicator LED). The
exit sign will be lit and the yellow indicator LED will flash during this test sequence.
Dimming
Push the test button for a time space between 10 and 15 seconds to delete all indicated errors. Then the luminaire enters
regular operation mode.
Resetting errors
By pressing the test button continuously for 15 seconds, when luminaire is connected to mains, the luminosity will be
reduced to 10% of its total luminance. In emergency mode the light output will remain unchanged.
Note: When using DALI or Wireless communication, the frequencies and schedules for tests will instead be determined by
the connected PC software.
Every 15 days the luminaire will perform an emergency operation test. This will light the exit sign for approximately 3
seconds. The red indicator LED will flash during this test sequence.
Selftest functions
Manual test functions
The ExiLED is a self-contained LED exit sign with selftest function.
It can be configured as maintained or non-maintained.
Every 6 months the luminaire will perform a battery condition test. The test will last for the stated duration. The exit sign will
be lit and the yellow indicator LED will flash during this test sequence.
