iArmor EDGE IA-W058 User manual

1Rev. 20220501
iArmor®
Customer Support: [e-mail]
PART#: IA-W058
BEFORE INSTALLATION
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE
PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE
STARTING INSTALLATION. ASSISTANCE IS RECOMMEND-
ED. THANK YOU FOR CHOOSING OUR PRODUCT!
*ROCKER PANEL MOUNT
*DRILLING/TRIMMING NOT REQUIRED
Torque Value
IARMOR EDGE™
Driver Center/Rear
Mounting Bracket
(DCM/DRM)
Passenger Center/
Rear Mounting
Bracket (PCM/PRM)
Passenger Front Mounting
Bracket (PFM)
Driver Front Mounting
Bracket (DFM)
PART LIST
Driver Side Step Bar Passenger Side Step Bar
Front
Fastener Size Tightening Torque (ft-lbs) Required
6mm 6-7 X
8mm 16-18 √
10mm 31-32 √
12mm 56-58 X
14mm 92-94 X

2Rev. 20220501
iArmor®
Customer Support: [e-mail]
2#
1# 3# 5#
4# 6#
Hardware Package (For Brackets & Step Bars Installation)
Item QTY Description Item QTY Description
1# 12 M8X1.25-30 Hex Bolts 4# 12 M10X1.5-25 Hex Bolts
2# 12 M8 Large Flat Washers 5# 24 M10 Flat Washers
3# 12 M8 Lock Washers 6# 12 M10X1.5 Nylon Lock Nuts

3Rev. 20220501
iArmor®
Customer Support: [e-mail]
The instruction here is for your reference only. We strongly
recommend the professional installer for best result. We are
not responsible for any damage caused by the installation.
STEP 1
Start from the driver side front of the vehicle, remove all plastic
plugs or hex bolts from the factory mounting threaded holes on
the body panel if equipped, (Fig 1).
(Fig 1) Driver Side Front Mounting Location
Front
Remove Plastic Plugs Or
Factory Hex Bolts (if equipped)
STEP 2
Front
(2) M8X1.25-30 Hex Bolts
(2) M8 Lock Washers
(2) M8 Large Flat Washers
(Fig 2) Driver Front Mounting Bracket Installation
Select the Driver Front Mounting Bracket (DFM). Attach the
Bracket to the mounting threaded holes with the included (2)
M8X1.25-30 Hex Bolts, (2) M8 Lock Washers and (2) M8 Large
Flat Washers, (Figs 2 & 3). Do not fully tighten hardware at this
time.
Front
(2) M8X1.25-30 Hex Bolts
(2) M8 Lock Washers
(2) M8 Large Flat Washers
(Fig 3) Driver Front Mounting Bracket Installed
STEP 3
Move to the Driver Side Center and Rear Mounting Locations,
(Fig 4). Repeat Steps 1-2 to install the Driver Center & Rear
Mounting Brackets (DCM/DRM), (Figs 5 & 6). Do not fully
tighten hardware at this time.
DFM

4Rev. 20220501
iArmor®
Customer Support: [e-mail]
Front
(2) M8X1.25-30 Hex Bolts
(2) M8 Lock Washers
(2) M8 Large Flat Washers
(Fig 5) Driver Center Mounting Bracket Installed
(Fig 4) Driver Side Rear Mounting Location
Rear
STEP 4
Once all (3) Mounting Brackets have been installed, attach the
Driver Side Step Bar to the Mounting Brackets with (6)
M10X1.5-25 Hex Bolts, (12) M10 Flat Washers and (6)
M10X1.5 Nylon Lock Nuts, (Fig 7). Do not fully tighten hard-
ware at this time.
Front
(2) M8X1.25-30 Hex Bolts
(2) M8 Lock Washers
(2) M8 Large Flat Washers
(Fig 6) Driver Rear Mounting Bracket Installed
DCM/DRM
DCM/DRM
STEP 6
Move to the other side of the vehicle. Repeat Steps 1-5 for the
other Side Step Bar installation.
STEP 5
Properly level and adjust the Step Bar and fully tighten all hard-
ware.
Attention
Do periodic inspections to the installation to make
sure that all hardware is secure and tight.
In order to protect your bars/boards, please use mild
soap/non-abrasive products for cleaning only.

5Rev. 20220501
iArmor®
Customer Support: [e-mail]
(Fig 7) Driver Side Step Bar Installed
(6) M10X1.5-25 Hex Bolts
(12) M10 Flat Washers
(6) M10X1.5 Nylon Lock Nuts
Front
DFM
DCM/DRM
DCM/DRM
Bottom View
