iArmor EDGE User manual

Rev. 20220901
1
iArmor®
Customer Support: [email protected]
PART#: IA-N178H
IARMOR EDGE™
BEFORE INSTALLATION
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE
PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE
STARTING INSTALLATION. ASSISTANCE IS RECOMMEND-
ED. THANK YOU FOR CHOOSING OUR PRODUCT!
*ROCKER PANEL MOUNT
*DRILLING MAYBE REQUIRED
PART LIST
Passenger Front
Support Bracket
(PFS/DRS)
Passenger Rear Mount-
ing Bracket (PRM)
Driver Rear Mounting
Bracket (DRM)
Passenger
Front
Mounting
Bracket
(PFM)
Driver Front
Mounting
Bracket
(DFM)
Driver Front Support
Bracket (DFS/PRS)
Passenger Side Step Bar
Step Pad Step Pad
Driver Side Step Bar
Front
Torque Value
Fastener Size Tightening Torque (ft-lbs) Required
6mm 6-7 √
8mm 16-18 √
10mm 31-32 X
12mm 56-58 X
14mm 92-94 X
Driver Rear Support
Bracket (PFS/DRS)
Passenger Rear Support
Bracket (DFS/PRS)

Rev. 20220901
2
iArmor®
Customer Support: [email protected]
7 # 8 #
1 # 4 #
3 #
2 # 6 #
5 #
Hardware Package A (For Brackets & Bars Installation)
Item QTY Description Item QTY Description
1# 4M8 Bolt/Nut Plates 7# 12 M8 Nylon Lock Nuts
2# 4M8 Plastic Washers 8# 8M6X1-25 Hex Bolts
3# 12 M8X1.25-30 Hex Bolts 9# 16 M6 Large Flat Washers
4# 24 M8 Flat Washers 10# 8M6X1 Nylon Lock Nuts
5# 8M8 Lock Washers 11# 8M8X1.25-20 T-Bolts
6# 4M8 Hex Nuts 12# 8M8 Plastic Washers
Hardware Package B (For Step Pedals Installation)
Item QTY Description Item QTY Description
1# 12 M8X1.25-25 Hex Bolts 3# 12 M8 Lock Washers
2# 12 M8 Large Flat Washers
1# 2# 3#
9 # 10 # 11 # 12 #

Rev. 20220901
3
iArmor®
Customer Support: [email protected]
STEP 2
Starting at the Driver Side Front of the vehicle, remove the
sealing tape covering the factory holes in the side of the inner
panel, if equipped, (Fig 1).
STEP 1
Install (4) Pedals onto the step bars with (24) M8X1.25-25mm
Hex Bolts, (24) M8 Large Flat Washers and (24) M8 Lock
Washers.
IMPORTANT: Don’t hit the pedal with any metal hummer with-
in pedal installation, or the pedal will be damaged.
The instruction here is for your reference only. We strongly
recommend the professional installer for best result. We are
not responsible for any damage caused by the installation.
(6) M8X1.25-25 Hex Bolts
(6) M8 Large Flat Washers
(6) M8 Lock Washers
STEP 3
Determine the correct procedure to attach the Driver Front
Mounting Bracket (DFM) for your model/year:
Models without factory threaded inserts in body panel:
Partially thread (1) M8X1.25-30mm Hex Bolt into the threaded
end of (1) M8 Bolt/Nut Plate, (Fig 2). Thread the hex bolt in
until it is flush with the welded nut, (Fig 3). Use the hex bolt as
a handle and insert the Bolt/Nut Plate into the oval hole, (Fig
4). Feed the threaded bolt on the plate through one of the hex
shaped factory holes. Thread (1) M8 Plastic Washer onto the
threaded end and down tight against the body panel, (Fig 5).
NOTE: The Plastic washer is designed to keep the Bolt/Nut
Plate from falling into the body panel.
Front
(Fig 1) 09-mid 15 Driver Side Front Mounting Location
(No factory holes in pinch weld on some models)
STEP 3
(Fig 2) M8 Bolt/Nut Plate (NOTE: M8 Bolt/Nut Plate is not re-
quired on models with threaded inserts on body panel)

Rev. 20220901
4
iArmor®
Customer Support: [email protected]
(Fig 6) Driver Front Mounting Bracket
b. Attach the Driver Front Mounting Bracket (DFM), (Fig 6) to
the threaded end of the M8 Bolt/Nut Plate with (1) M8 Flat
Washer, (1) M8 Lock Washer and (1) M8X1.25 Hex Nut, (Fig
7A). Remove the M8X1.25-30mm Hex Bolt from the nut on the
Bolt/Nut Plate from Step 3. Rotate the Bolt on the Bolt/Nut
Plate until the threaded nut lines up with the remaining hole in
the Mounting Bracket and body panel, Do not fully tighten hard-
ware at this time.
(Fig 3) Thread (1) M8X1.25-30mm Hex Bolt into the nut on the
plate. Stop when bolt reaches end of nut as pictured)
(Fig 4) Use the loose Hex Bolt as a handle. Insert the Bolt/Nut
Plate into the oval hole and feed the threaded end out either
factory hex shaped hole. IMPORTANT: Do not let go of the hex
bolt until after Plastic Washer has been threaded onto bolt (Fig
5).
(Fig 5) Thread Plastic Washer onto the bolt to hold the Bolt/Nut
Plate in position
M8 Plastic Washer
Flush DFM
(Fig 7A) Attach Driver Front Mounting Bracket to M8 Bolt/Nut
Plate. Remove Hex Bolt, rotate Bolt/Nut Plate to line up threaded
nut with body panel and Mounting Bracket
(1) M8 Flat Washer
(1) M8 Lock Washer
(1) M8X1.25 Hex Nut
DFM
M8 Bolt/Nut Plate
(1) M8X1.25-30mm Hex Bolt
(1) M8 Lock Washer
(1) M8mm Flat Washer
DFM
(Fig 7B) Attach Driver Mounting Bracket to threaded end of the
M8 Bolt/Nut Plate
c. Attach the Driver Front Mounting Bracket (DFM) to the
threaded nut on the M8 Bolt/Nut Plate with (1) M8x1.25- 30mm
Hex Bolt, (1) M8 Lock Washer and (1) M8 Flat Washer, (Fig
7B). Do not fully tighten hardware at this time.

Rev. 20220901
5
iArmor®
Customer Support: [email protected]
Front
Models with factory threaded inserts:
Attach Driver Front Mounting Bracket to the threaded inserts
with (2) M8X1.25-30mm Hex Bolts, (2) M8 Lock Washers and
(2) M8 Flat Washers, (Figs 8 & 9). Do not fully tighten hard-
ware at this time.
(Fig 8) Driver Side Front Mounting Location mid 2015-on, an
example of models with factory installed threaded inserts
(2) M8X1.25-30mm Hex Bolts
(2) M8 Lock Washers
(2) M8 Flat Washers
(Fig 9) Driver Front Mounting Bracket Installed (Models w/ facto-
ry installed threaded inserts/M8 Bolt/Nut Plate not required)
STEP 4
Attach the Driver Front Support Bracket (DFS/PRS) to the Driv-
er Front Mounting Bracket (DFM) with (1) M8X1.25-30mm Hex
Bolt, (2) M8 Flat Washers and (1) M8X1.25 Nylon Lock Nut,
(Fig 10). Rotate the support bracket to the back of the pinch
weld.
(Fig 10) Attach Driver Front Support Bracket to Drive Front
Mounting Bracket
DFM
DFS/PRS
(1) M8X1.25-30mm Hex Bolt
(2) M8 Flat Washers
(1) M8X1.25 Nylon Lock Nut
(Fig 11) Attach Driver Front Support Bracket to back of pinch
weld (models with factory holes in pinch weld only)
(2) M6X1-25mm Hex Bolts
(4) M6 Large Flat Washers
(2) M6X1 Nylon Lock Nuts
DFS/PRS
Line up the slots in the top of the Support Bracket with the (2)
factory holes in the pinch weld. Attach the Bracket to the back
of the pinch weld with (2) M6X1-25mm Hex Bolts, (4) M6 Large
Flat Washers and (2) M6X1 Nylon Lock Nuts, (Figs 11 & 12).
Do not fully tighten hardware at this time.
IMPORTANT: Some models are not equipped with factory
holes and will require drilling through the pinch weld to
attach the Support Bracket. Do not drill through pinch weld
at this time, (Refer to Step 8).

Rev. 20220901
6
iArmor®
Customer Support: [email protected]
STEP 5
(Fig 12) Driver Front Brackets installed
Rear
IMPORTANT: Models w/o
holes in pinch weld will re-
quire drilling 1/4” holes
through pinch weld to at-
tach Support Brackets. Do
complete installation of Step
Bar first and level Step Bar
before drilling holes for
Support Brackets (refer to
Step 7).
(Fig 13) Drier Side Rear Mounting location
Front
Move to the Driver Side Rear Mounting location, (Fig 13). Re-
peat Step 3 to install the Driver Rear Mounting Bracket (DRM).
Repeat Step 4 to attach the Driver Rear Support Bracket (PFS/
DRS) to the Driver Rear Mounting Bracket and factory holes (if
equipped) in the pinch weld, (Fig 14).
DRM
PFS/DRS
(Fig 14) Driver Rear Brackets installed
Rear
STEP 6
Once all (2) brackets have been installed, select (4) M8X1.25-
20mm T-Bolts, thread (1) M8 Plastic Washer on each T-Bolt,
(Fig 15). Install the (4) M8X1.25-20mm T-Bolts with plastic
washers in the slots on the assembled step bar. Rotate the T-
Bolts to 90 degree, thread down the M8 Plastic Washers
against the step bar (Fig 16).
NOTE: The Plastic Washer is designed to keep the T-Bolt
in place to avoid falling into the tube during installation.
(Fig 15) Thread (1) M8 Plastic Washer on each T-Bolt Before
Inserting into the slot !!!
(Fig 16) T-Bolt with plastic washer in the slot
M8X1.25-20 T-Bolt
M8 Plastic Washer
Thread down the M8
Plastic Washer
against the step bar
Insert the T-bolt
with M8 Plastic
Washer in the
slot on the step
bar and rotate
the T-bolt to
90° !!

Rev. 20220901
7
iArmor®
Customer Support: [email protected]
STEP 7
Attach the Assembled Driver Side Step Bar onto the Mounting
Brackets with (4) M8 Plastic Washers, (4) M8X1.25-20mm T-
Bolts, (4) M8 Flat Washers, (4) M8 Nylon Lock Nuts, (Fig 17).
Do not fully tighten hardware at this time.
STEP 9
Level and adjust the assembled Step Bar properly and tighten
all hardware.
Move to the other side of the vehicle. Repeat Steps 2-8 for the
other Side Step Bar installation.
Attention
Do periodic inspections to the installation to make sure
that all hardware is secure and tight.
In order to protect your bars/boards, please use mild
soap/non-abrasive products for cleaning only.
STEP 8
Properly level and adjust the Step Bar and fully tighten all hard-
ware.
Models requiring drilling for driver side Support Brackets:
a. Make sure the Step Bar is level to the vehicle. Adjust and
tighten all mounting hardware.
b. Line up the slots on the Support Brackets with the back of
the pinch weld. Mark the location of the slots onto the pinch
weld.
c. Drill (2) 1/4” holes through the pinch weld for each Support
Bracket. IMPORTANT: Do not drill too close to the bottom
edge of the pinch weld. Adjust the Brackets as necessary to
move the slots up the body panel away from the edge. Drill the
holes toward the outside of the marked slots.
d. Attach each Support Brackets to the pinch weld with (2)
M6X1-25mm Hex Bolts, (4) M6 Large Flat Washers and (2)
M6X1 Nylon Lock Nuts, (Fig 11). Check for level then fully
tighten all hardware.

Rev. 20220901
8
iArmor®
Customer Support: [email protected]
(Fig 17) Driver Side Step Bar Installation
Front
(4) M8 Plastic Washers
(4) M8X1.25-20mm T-Bolts
(4) M8 Flat Washers
(4) M8 Nylon Lock Nuts
Bottom View
