IHP WINSLOW PS40 User manual

NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE. 1
WINSLOW™ DOOR TRIM KITS
MODELS PS40 AND PI40
INSTALLATION INSTRUCTIONS FOR INSTALLING DOOR TRIM KITS
FOR USE WITH WINSLOW™ MODELS PS40 AND PI40 PELLET APPLIANCES
775274M
Rev. B, 10/2013
HEARTH PRODUCTS
KITS AND ACCESSORIES
KIT CONTENTS (See Figure 1):
2 ea. Trim Pieces
6 ea. #10 nuts
6 ea. #10 washers
1 ea. Instruction Sheet
TOOLS NEEDED:
3/8” Nut Driver or Socket Wrench
Winslow Door Trim Kits
Cat. No. Model Description
79038 P40DT-B Black Door Trim Kit
79034 P40DT-G Gold Door Trim Kit
79037 P40DT-N Nickel Door Trim Kit
79035 P40DT-BRN Brushed Nickel Door Trim Kit
79036 P40DT-BLN Black Nickel Door Trim Kit
Figure 1 - Kit Contents
#10 Nuts
#10 washers
Trim Pieces
(A)
Pellet Stove Door
Trim Pieces
GENERAL INFORMATION
If you encounter any problems, need clarification of these instructions
or are not qualified to properly install this kit, contact you local distribu-
tor or dealer.
Read this instruction sheet in its entirety before beginning the installa-
tion.
ALL WARNINGS AND PRECAUTIONS IN THE INSTALLATION AND
OPERATION MANUAL PROVIDED WITH THE APPLIANCE APPLY TO
THESE INSTRUCTIONS.
TURN OFF THE APPLIANCE AND ALLOW IT TO COMPLETELY COOL
BEFORE PROCEEDING.
INSTALLATION INSTRUCTIONS
Step 1. Remove the trim pieces and hardware from its packaging and
ensure that all pieces are present before beginning installation.
Take care not to scratch finished surfaces (see Figure 1).
Figure 2
Pellet Stove Door
IMPORTANT
If you have a gold or nickel trim, be sure to clean
them with a soft cloth and household glass cleaner
prior to burning the insert. Fingerprints left on the
plated surfaces while burning will usually remain
on the finish permanently.
Upper Door Trim
Lower Door Trim
Upper Door Trim
Lower Door Trim

2
Trim stud
Door Handle
Holes for trim studs
Top edge of lower door trim
Figure 3
Figure 5
Printed in U.S.A. © 2009 IHP LLC
P/N 775274M Rev. B 10/2013
IHP reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor
for fireplace code information.
Innovative Hearth Products™, LLC
1508 Elm Hill Pike, Suite 108 • Nashville, TN 37210
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Figure 4
Figure 6
Figure 7
Step 2. Open right and left side door. The side doors swivel open towards
the back of the stove. See Figure 3.
Step 3. Open front door. Put door trim in place by inserting trim studs into
the corresponding holes in the front door (Figures 3 and 4). The
upper door trim will only fit in one direction, but the lower door
trim can be installed incorrectly. When placing the lower door trim,
make sure that the distance between the top edge of the lower
door trim to the glass in the door is 9/16” (see Figure 5).
Step 4. Place one washer on each stud. Using a 3/8” nut driver, snug up
the nuts on each piece of trim. Do not finish tightening the nuts
yet. See Figure 6.
Step 5. There should be approximately a 7/8” (22 mm) gap between the
top edge of the upper door trim and the top edge of the front
door and a 1-1/2” (38 mm) gap between the lower door trim to
the bottom of the front door. Visually inspect the alignment of
the trim and adjust if necessary. See Figure 7.
Step 6. Finishtighteningnuts.CAUTION - DO NOT OVER-TIGHTEN NUTS,
DIMPLING OF THE TRIM WILL OCCUR!!!
Bottom edge of lower door trim
to bottom edge of front door
1-1/2”
9/16”
